Volt VSPL-9001-25-BBZ User manual

VOLT®Solar Landscape Lighting
VOLT®Solar Area Light Kit
VSPL-9001-25-BBZ
INSTALLATION INSTRUCTIONS
Specications and product details subject to change without notice.
© Copyright 2020, VOLT® Lighting, Lutz FL USA 33549 • All rights reserved.
[email protected] • 813.978.3700
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
- 1 -

VOLT®Solar Area Light Kit
VSPL-9001-25-BBZ
Package Contents
Important: Please Read Before Installation
Important Safety Instructions
INSTALLATION INSTRUCTIONS
!
!
www.voltlighting.com
- 2 -
Parts Required (sold separately)
This luminaire is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situations.
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS
Lighted lamp is HOT!
WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.
1. Lamp gets HOT quickly!
2. Do not touch the hot lens, guard or enclosure.
3. Keep lamp away from materials that may burn.
4. Do not touch lamp at any time. Use a soft cloth. Oil from skin may dam-
age lamp.
5. Do not operate the luminaire tting with a missing or damaged shield.
SAVE THESE INSTRUCTIONS
A. (1) Area Light
A. (1) Solar Panel with Bracket

Product Dimensions
[email protected] • 813.978.3700
- 3 -
23.25”
7.5”
Install Stake
1
Determine the desired location
for mounting the stake. Hammer
the stake into the ground until
ange of stake is ush to grade.
To avoid damage to the stake,
place a board on top of the stake
while hammering.
Note: If the ground is hard and
the stake is difcult to install,
make a crosscut in the ground
using a at shovel.
Board
Ground
Soil
Stake

www.voltlighting.com
INSTALLATION INSTRUCTIONS
- 4 -
2
VOLT®Solar Area Light Kit
VSPL-9001-25-BBZ
Install Fixture to Stake
Pass the xture wire through
the center hole of the stake.
Thread the xture onto the
stake. Hand tighten until snug.
Fixture
Fixture Wire
Ground
Soil
Stake
3
Wire Connection: Option A
Solar Panel
Area
Light
Area Light Supply
Wire
Optional A: Connect with Connection Hub
Connection Hub
Solar Panel
Supply Wire

[email protected] • 813.978.3700
- 5 -
1
Wire Connection: Option B
You can choose from Option A or Option B to complete the installation.
Option A is the recommended method to install the solar lights.
Optional A: Strip the supply wire leads from the solar panel and the sup-
ply wire leads from the area lights. Insert both the lead wires into the
connection hub. There is a maximum of 7 xtures that can be connect-
ed to the hub.
Optional B: Strip the supply wire leads from the solar panel and the
supply wire leads from the area light. Using two wire connectors (sold
separately), connect the leads from the solar panel to the area light.
Solar Panel
Solar Panel
Supply Wire
Area Light Supply
Wire
Wire Connector
Connect with Wire Connectors
Area
Light

INSTALLATION INSTRUCTIONS
www.voltlighting.com
- 6 -
VOLT®Solar Area Light Kit
VSPL-9001-25-BBZ

[email protected] • 813.978.3700
- 7 -

is-VSPL-9001-25-ver1-pdf
Specications and product details subject to change without notice.
© Copyright 2020, VOLT® Lighting, Lutz FL USA 33549 • All rights reserved.
[email protected] • 813.978.3700
www.voltlighting.com
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
- 8 -
