VQ Models KING QUEST 100 User manual

SPECIFICATIONS
Wingspan:.....................................2210mm
Length:..........................................1580mm
Electric Motor:.........................2300-2500w
Glow Engine:..............90-120 2-T / 120 4-T
RTF Weight: 5.8-6.1kg (Will vary with
Equipment Used).
Radio:.......Minimum 7 Channels / 9 Servos
Function: Ailerons-Elevator-Rudder-Throttle
Flaps.
WARNING! This radio controlled model is NOT a toy. If modified or flown carelessly it could go out of controll and
cause serious human injury or property damage. Before flying your airplane, ensure the air field is spacious enough.
Always fly it outdoors in safe areas and seek professional advice if you are unexperienced.
Radio control model
ALL BALSA, PLYWOOD CONSTRUCTION AND ALMOST READY TO FLY
Instruction manual
KING QUEST 100

1.5mm
B
!
CA L/R Assemble left and right
sides the same way. X
Drill holes using the stated
size of drill
(in this case 1.5 mm ÿ)
Use epoxy glue
Take particular care here
Hatched-in areas:
remove covering
film carefully
Not included.
These parts must be
purchased separately
Check during assembly that these
parts move freely, without binding
Apply cyano glue
EPOXY A
EPOXY B
CA
GLUE
Epoxy Glue ( 5 minute type)
Thread locker
Cyanoacrylate Glue
Minimum 7 channels radio
for airplane with 9 servos
Silicone tube (in case of Gas or Glow engine using)
Servo extension cord
Epoxy Glue (30 minute type)
TOLLS REQUIRED
Hobby knife
Needle nose Pliers
Phillip screw driver
Awl
Scissors
Wire Cutters
(Purchase separately) Hex Wrench
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
Sander
Masking tape - Straight Edged Ruler - Pen or pencil - Drill and Assorted Drill Bits
Read through the manual before you begin, so you will have an overall idea of what to do.
Symbols used throughout this instruction manual, comprise:
(Purchase separately)
CONVERSION TABLE
1.0mm = 3/64”
1.5mm = 1/16”
2.0mm = 5/64”
2.5mm = 3/32”
3.0mm = 1/8”
4.0mm = 5/32”
5.0mm = 13/64”
6.0mm = 15/64”
10mm = 13/32”
12mm = 15/32”
15mm = 19/32”
20mm = 51/64”
25mm = 1”
30mm = 1-3/16”
45mm = 1-51/64”
If exposed to direct sunlight and/or heat, wrinkels can appear. Storing the
model in a cool place will let the wrinkles disappear. Otherwise, remove
wrinkles in covering film with a hair dryer, starting with
low temperature. You can fix the corners by using a hot iron.
REQUIRED FOR OPERATION (Purchase separately)
Low seting
A
2300-2500 Watt
6 standard servo for Aileron. Flap, Nose gear and Throttle
3 mini servo (3x19gr) for Rudder and Elevator (2pcs).
26cc Gas Engine 120-4T Glow Engine
700mm for Aileron servos (2pcs)
400mm for Flap servos (2pcs)
600mm for Elevator and
Rudder servos (3pcs)

KING QUEST 100 1-Nose gear mount
2-Installing the nose gear & nose gear arm
Step 1
Step 2
Step 3
3x20mm hexagonal bolt
............4
3mm nut / washer
............4
Nose gear mount
........1
1- Slide one end of the 2x500mm white plastic
tube into the pre-drilled hole on the right side
of the nose gear mount, the end of the plastic
tube fits across the front of the fire-wall. The
other end of the plastic tube leads to where the
nose gear servo arm will be.
2- Hold the end of the plastic tube firmly to
fire-wall with thin CA glue.
1- Thread one end with the Z bend of the nose gear push rod into the hole
on the nose gear control horn (Step 1).
2- Thread the other end of the nose gear push rod into the white plastic.
3- Put the nose gear control horn in place with the screw hole facing foward
(Step 2).
4- Put the nose gear in place (Step 3).

QUEST KODIAK 3-Installing the nose gear & nose gear arm
4-Installing the engine mount
Hex wrench
6mm
Drill expands to 6mm
Attach the engine mount to the
fire-wall using four of the 4x25mm
hexagonal bolt, washer and
blind nut.
4x25mm hexagonal bolt
.......4
.......4
Washer and blind nut

QUEST KODIAK 5-Installing the engine
Position the engine to the engine mounts so the distance
from the prop hub to the fire-wall is 139mm.
Mark the engine mounting plate where the four holes are
to be drilled.
Remove the engine and drill a 4mm holes through the beam
at each of the four marks made above.
Marking sure that you drill the holes perpendicular to the beam
of the engine mount.
4mm
139mm

QUEST KODIAK 6-Installing the engine
7-Installing the electric motor mounting
Reposition the engine on the engine mount beams,
aligning it with the holes. Secure the engine to the
engine mount using four 4x25mm hexagonal bolt.
Note: Apply Silicon sealer to each of the 4x25mm
hexagonal bolt and nut.
.......4
4x25mm screw
4mm Washer
.......4
.......4
4mm Nut
6mm
Drill expands to 6mm

QUEST KODIAK 8-Installing the electric motor mounting
6x100mm bolt.....4
6mm nut..........12
6mm washer...16
Attach the four of the 6x100mm bolts
washer and nuts to the fire-wall as shown.
Secure the Motor to the wooden motor mounting plate using the
four of the 3x20mm hexagonal bolts, washer and nut.
.......4
3x20mm screw
3mm Washer
.......4
.......4
3mm Nut
Adjust the wooden motor mount so the
distance from the prop hub to the fire-wall
is 143mm.
143mm

Remove the adhesive tape and remove the cover
from the fuselage.
4x15mm hexagonal bolt
.......6
QUEST KODIAK 9-Installing the main landing gear
3mm
A=42mm
A
5 min.
Step 1
3x20mm bolt
Step 2
Step 3 Step 4

Put the cover back on the fuselage and secure it with
two 3x12mm self-drilling screws.
3x12mm self-drilling screw
...........2
QUEST KODIAK 10-Installing the main landing gear

Step 1
Step 2
QUEST KODIAK 11-Installing the main landing gear
3mm
Mark to drill
When putting the plastic gear cover on the aluminum landing gear,
you have to separate the two pieces of plastic gear cover a litter on
the narrow end (Step 1), once it is in place, you will glue the
separated part with thin CA glue (Step 2).
Thin CA
3x20mm bolt
Plastic landing gear cover, view from the narrow end.
Mark to drill
3mm
Narrow end
Adjust the plastic cover until the holes on the plastic cover
coincide with the holes on the aluminum landing gear, use
3x20mm bolt to fix the plastic cover as shown.

...2
4X45mm screw
4mm nut
............4
............6
4mm washer
75mm wheel
...2
4mm nut
4x45mm screw
Aluminum landing gear
4mm nut
2x8mm self-drilling screw
...........12
1mm
1mm
2x8mm self-drilling screw
...........12
QUEST KODIAK 12-Installing the main landing gear

Carefully,push the horizontal stabilizer into the slot on the
fuselage as show.
Pull the left and right elevator out of the horizontal
stabilizer (not glue yet).
Using a sharp hobby knife, carefully cut away
the covering around of all slots for the horizontal
stabilizer and vertical fin installation.
you may need to widen the slot a little more so
that pushing the horizontal stabilizer into the
fuselage is not too difficult.
NOTE:
Check the alignment of the horizontal stabilizer by measuring
from a fixed point along the center line of the fuselage to the
leading edge on each side of the horizontal stabilizer.
The distance must be equal on both sides .
If not, adjust the stabilizer until the measurements are the same.
QUEST KODIAK 13-Installing the horizontal stabilizer
Step 1
Step 4
Step 5
Cut away only the covering.
Step 2
sander
Step 3
A
A’
A=A’
B=B’
B
B’

Cut away only the
covering both sides.
Aluminum wing joiner Aluminum wing joiner
Horizontal stabilizer Horizontal stabilizer
When viewing visually from the back of the fuselage, the aluminum wing joiner should
be parallel to the horizontal stabilizer.
When you are satisfied with the alignment, use a pencil to trace around the top and bottom
of the stabilizer where it meets the fuselage.
Remove the horizontal stabilizer
from the fuselage. Using a straight edge
and a sharp hobby knife, carefully cut away
the covering inside the lines which were marked
above. Be cautious not to cut into the wood-this
will weaken the structure.
! Securely glue together. If coming off during fly,
you lose control of your air plane.
Apply CA glue
both sides.
(thin CA)
Apply thin CA glue into the slot
where the fuselage meet the
horizontal stabilizer.
Install the horizontal stabilizer onto the fuselage and adjust the alignment as described in step 5 and 6.
Note: it is important to ensure that the horizontal stabilizer is also level in regards to the fuselage.
Apply the thin CA along the area where the covering was removed in the previous step and to the
fuselage where the horizontal stabilizer mounts .
QUEST KODIAK 14-Installing the horizontal stabilizer
Step 6
Step 7
Step 8
Step 9

When you are satisfied with the alignment, use a pencil to trace
around the stabilizer where it meets the fuselage.
QUEST KODIAK 15-Installing the horizontal stabilizer
Cut away only the
covering.
16-Installing the verticaltal stabilizer
Trial fit the vertical stabilizer in position. Ensure that the
vertical stabilizer is perpendicular to the horizon stabilizer.
C C’
C=C’
5 min. Epoxy
5 min. Epoxy
Control horn
2x20mm bolt
......2 set
........4
2mm

QUEST KODIAK 17-Installing the vertical stabilizer
Cut away only the
covering inside the
pencil line.
Glue the torque rod bearing into the slot in
the vertical stabilizer, using a thin layer of
5 minute epoxy.
5 min. Epoxy
15 min. Epoxy

QUEST KODIAK 18-Installing the vertical stabilizer
Drill a hole 2.5mm in diameter on the leading edge
marked with a pencil, making sure that you drill the
hole perpendicular to the leading edge of the rudder. 2.5mm
Use a pencil to mark the leading edge of the rudder
where the rudder torque rod meets.
5 min. Epoxy
5 min. Epoxy
VERY IMPORTANT
If you not make this step, the rudder or
elevator may be comming off when
your airplane flying with high speed.
You will lose control of your airplane.
1.5mm
VERTICAL STABILIZER
Cut the excess toothpick and secure it
in place using little Thin CA glue.
CA
Thin CA glue
Toothpick (not included)
Drill a hole with a diameter of 1.5mm through
the vertical stabilizer and rudder as shown
in the figure.
VERTICAL STABILIZER
VERTICAL STABILIZER
Hinge

Note:
2mm connector for flap servo
3mm connector for aileron servo
2mm connector
......1
3mm connector
......1
QUEST KODIAK 19- Flap & Aileron servo
FLAP & AILERON SERVO HATCH - BOTTOM VIEW
1.5mm
1.5mm
2x8mm
2x8mm
AILERON&FLAP SERVO HATCH - TOP VIEW
To be safe, you must attach the four screws
as shown in this picture.
!
IMPORTANT:
1.5mm
Thin CA
CA
Hard wood servo mount
A
A
! Securely glue together. If coming off during fly,
you lose control of your air plane.
2x8mm screw
servo mount
servo hatch

Control horn
...........1 set
Control horn
..................1
2mm
Thin CA
QUEST KODIAK 20- Flap & Aileron linkages
2x175mm rod with clevis one end
.....1 set
3x175mm rod with clevis one end
.....1 set
AILERON LINKAGE
3x175mmm push-rod
3mm connector
FLAP LINKAGE
2x175mmm push-rod
2mm connector

The hole on the wing surface
is already pre-drilled.
Aluminum wing brace.
Aluminum wing brace.
Do the same way with other wing half.
6x20mm wooden
dowel
6x20mm wooden
dowel
The wooden dowels must be perpendicular
with the root rib.
3x15mm self drilling screw
...............1
you may need to widen the hole a little more so
that pushing the wooden dowel into the fuselage
is not too difficult.
NOTE:
NOTE:
CA
Thin CA
CA Thin CA
6x20mm wooden dowel
.............2
QUEST KODIAK 21- Flap & Aileron linkages
22- Dowel installation
X
1mm
Light
Step 1 Step 2
1.2x8mm self-drilling screw
.....................6

Control horn
...........2 set
2mm connector
......1
3mm connector
......2
2x175mm rod with clevis one end
.....1 set
3x175mm rod with clevis one end
.....2 set
2mm
2mm
Rudder torque rod
3x175mm elevator push rod
3x175mm elevator push rod
2x175mm rudder push rod
3mm connector
2mm connector
QUEST KODIAK 23- Elevator & Rudder servo
24- Elevator & Rudder linkages
