VQ Models PIPER PA-18 SUPER CUB User manual

PIPER PA-18
Radio control model
R/C Flugmodell
MONTAGEANLEITUNG
Designed for brushless electric motors (.46-.52 class glow conversion optional)
Entwickelt für Brushless Elektro Motoren (7,5 -8,5cc Glühzündermotor Einbau möglich)
INSTRUCTION MANUAL
SPECIFICATIONS
Wingspan 63.7in.
Length 49.2 in.
Electric Motor (See next page)
Glow Engine .46 2Stroke / .52 4-Stroke
Radio 5 Channel / 4 -5 Servos
WARNING! This radio controlled model is NOT a toy. If modified or flown carelessly it could go out of controll and
cause serious human injury or property damage. Before flying your airplane, ensure the air field is spacious enough.
Always fly it outdoors in safe areas and seek professional advice if you are unexperienced.
ACHTUNG! Dieses ferngesteuerte Modell ist KEIN Spielzeug! Es ist für fortgeschrittene Modellflugpiloten bestimmt,
die ausreichende Erfahrung im Umgang mit derartigen Modellen besitzen Bei unsachgemäßer Verwendung kann
hoher Personen- und/oder Sachschaden entstehen. Fragen Sie in einem Modellbauverein in Ihrer Nähe um
professionelle Unterstützung, wenn Sie Hilfe im Bau und Betrieb benötigen. Der Zusammenbau dieses Modells ist
durch die vielen Abbildungen selbsterklärend und ist für fortgeschrittene, erfahrene Modellbauer bestimmt.
TECHNISCHE DATEN
Spannweite 1620mm
Lange 1250mm
Elektroantrieb (siehe nächste Seite)
Verbrennerantrieb 7.5cc 2-T / 8.5cc 4-T
Fernsteuerung 5 Kanal / 4 -5 Servos
SUPER CUB
Floats available as an option! (No. C4682)
Schwimmer als Sonderzubehör erhältlich! (Best.Nr.C4682)

.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
1.5mm
AB
!
CA
L/R
Assemble left and right
sides the same way.
X
Drill holes using the stated
size of drill
(in this case 1.5 mm Ø)
Use epoxy glue
Take particular care here Hatched-in areas:
remove covering
film carefully
Not included.
These parts must be
purchased separately
Check during assembly that these
parts move freely, without binding
Apply cyano glue
SILICON
EPOXY A
EPOXY B
CA
Epoxy Glue (30 minutes type)
Silicon Glue
Cyanoacrylate Glue
Sekundenkleber
Epoxy-Klebstoff (30min)
5 - channel radio
RECOMMENDED ACCESSORIES (Purchase separately)
5 - Kanal
Fernsteuerung
Egänzungskit Verbrenner
(Tank + Motorträger)
Best.Nr. C4165
Empfohlenes Zubehör (Nicht im Lieferumfang enthalten)
Antrieb Standard:
BOOST 40 Brushless Combo Set, Best.Nr. C2983
LiPo Battery RED POWER 3200-3S, Best.Nr. C3164
Luftschraube 12*6, Best.Nr. C1937
Antrieb Tuning (Kraftvoller Kunstflug):
BOOST 60 Brushless Combo Set, Best.Nr. C3174
LiPO Akku RED POWER 4250-5S, Best.Nr. C4547
Luftschraube 13*8, Best.Nr. C2846
Silikonkleber
Tool Required/ Empfohlenes Werkzeug
The pre-covered film on ARF kit may wrinkle due to variations of temperature.
Store model in a cool and dry place for awile.
Then, staring with low heat, you may carefully use a hair dryer to smooth out wrinkels.
Die Bespannung des Modells kann durch Temeratureinflusse erschlaffen oder Falten
werfen z.b bei zu starker Sonnenenstrahlung oder Hitze.
Stellen Sie das Modell zunachst an einen kuhlen Platz fur eine bestimmte Zeit. Danach
konnen Sie versuchen die restlichen Falten vorstichtig mit einem Haartrockner zu behandeln.
!
CONVERSION TABLE
1.0mm = 3/64”
1.5mm = 1/16”
2.0mm = 5/64”
2.5mm = 3/32”
3.0mm = 1/8”
4.0mm = 5/32”
5.0mm = 13/64”
6.0mm = 15/64”
10mm = 13/32”
12mm = 15/32”
15mm = 19/32”
20mm = 51/64”
25mm = 1”
30mm = 1-3/16”
45mm = 1-51/64”
1 x Servo S4020
(für Seitenruder)
Best.Nr. C1687
3 x Servo S4020
(für Höhen- und Querruder)
Best.Nr. C4995

102mm
!
Align the mark on both
mounts with the center
mark on the fire-wall
Securely attach the engine mount to the
fire-wall using the four 4x25mm screws.
Position the engine on the engine mount beams so the
distance from the prop hubto the fire-wall is 102mm/(4”).
Using a pencil, mark th engine mounting plate where
the four holes are to be drilled. Note: Mark the mounting
plate through the engine mounting flanges.
Trim the cowling for
engine and muffler.
Then, position the
cowling in place.
FRONT VIEW
A
A
Note the side thrust for motor!
Sturz und Zug beachten!
Reposition the engine on the mounting
beams, aligning it with the holes drilled
in Step 3. Insert one 3x25mm screw through
each of the mounting holes. Apply Silicon
to each of the 3x25mm screws and firmly
secure the engine to the motor mount using
four 3mm nut.
Set the engine on the
engine mounting beams.
Adjust the spacing of
the beams so they are
centered in relation to
the mounting plate and so they are
almost touching both sides of the
engine crankcase.
1
3.5mm
A
B
Remove the engine and drill
a 3.5mm hole through the
beam at each of the four marks
made in Step B.
C
D
2.5mm
Drill the hole through the fire-wall
for the plastic pushrod tube
Note: It may be easier to temporarily remove the throttle
arm from the engine to insert the Z bend of throttle push-rod.

Firewall
90mm
(3.54”)
B’
B
B=B’
A
A=A’
A’ ! Engine thrust on balk head
is already adjust at factory
Attach the aluminum motor mounting
plate on to the motor and secure it in
place with four screws ( included with
motor set).
Push the four 5x35mm bolts through the fire-wall as shown (5).
Reposition the plywood motor mounting plate and secure
it in place with twelve 5xmm nuts and washers (6).
Note: B=B’(Side-view) and A=A’(Top-view)
Using a plywood motor mounting plate as a template,
mark the fire wall where the four holes are to be drilled .
Motorspant
TOP-VIEW / Draufsicht
SIDE-VIEW / Seitenansicht
Sturz und Zug beachten!
Sperrholztrager Platten zusammenkleben, wie gezeigt ausrichten
und Locher bohren.
Motor nach untenstehendem Schema einbauen.
Fur optimale Leistung empfehlen wir folgende Komponenten:
-Brushless-Motor PICHLER BOOST 60
-Brushless Regler PICHLER XQ-70
-LiPO Akku LEMONRC 3700-5S
-Luftschraube 12*6 - 13*8
For maximum performance, we recommended
the following:
-Brushless-Motor PICHLER BOOST 60
-Brushless Regler PICHLER XQ-70
-LiPO Battery LEMONRC 3700-5S
-Propeller 12*6 - 13*8
X4 X16
X12
5x35 screw 5mm washer
5mm nut
Remove the plywood motor mounting plate and drill a
13/64”(5mm) hole through the fire-wall at each of the four
marks marked above.
AB
C
5mm
13/64”
D
2

2.mm
2.5x8mm screw
............3
3
2.mm
2.mm
85mm 4mm 85mm
4mm
HORIZONTAL STABILIZER
Cut two slots (3x7mm and 3mm deep)
along the trailing edge of the horizontal
stabilizer.
4
Full the elevator out of the
horizontal stabilizer.
Cut away only
the film both side
5A
5B
5
TOP VIEW / Draufsicht
TOP VIEW / Draufsicht

! Securely glue together If coming off during
fly, you lose control of your air plane.
Cut away only
the covering
both side
Remove the horizontal stabilizer from the fuselage.
Using the sharp hobby knife, carefully cut away the
covering inside the lines which were marked above.
Install the horizontal stabilizer into the fuselage and
adust the alignment as described in steep 5B. Secure
the horizontal stabilizer in place using CA glue.
When you are satisfied with the alignment,
use a pencil to trace around the top and
bottom of the stabilizer where it meets the
fuselage.
6A
6B
6C
* WARNING: When removing any covering from the airframe,
please ensure that you secure the cut edge with CA or similar
cement. This will ensure the covering remain tight.
BB’
B=B’
Aluminum wing joiner
6
Apply a thin layer of machine oil or petroleum jelly
to only the pivot point of the hinges on the elevator,
then push the elevator and its hinges into the hinge
slots in the trailing edge of the horizontal stabilizer.
There should be a minimal hinge gap.
When satisfied with the and alignment, hinge the
elevator to the horizontal stabilizer using CA glue.
Hinge
Petroleum jelly
STABILIZER
6D
6E
Note: the hole on the center of
the stabilizer must be coincidental
with the center line of the fuselage.
Control horn
...........2
Note: The slots for the control horn
installation are pre- cut at factory.
Cut away only
the covering.

7
CA
10mm
Cut a slots (3x7mm and through
both the covering and balsa wood)
along the trailing edge of the
vertical stabilizer.
CA
FRONT-VIEW
8
Cut away the covering
where the vertical stabilizer
meet the fuselage.
Trial fit the vertical stabilizer in place. Check the alignment of the vertical stabilizer.
If the parts will join, but with a gaps, sand or trim the parts a little at a time until the parts meet
exactly with no gaps.
When you are satisfied with the alignment, use a pencil to trace around the left and right of the
stabilizer where it meets the fuselage.
Remove the vertical stabilizer from the fuselage. Using the sharp hobby knife, carefully cut
away the covering inside the lines which were marked above.
Paper hinge
CA
Install the vertical stabilizer into the fuselage and
adust the alignment. Secure the vertical stabilizer
in place using CA glue.
CA
! Securely glue together If coming off during
fly, you lose control of your air plane.
Cut away only
the covering

............4
4X20mm screw
1.5mm
CA
1/8(3mm) screw
Collar
8mm
12~15mm
1.5mm
1/16
0.5~0.6in.
0.3in.
1/16
3x12..........2
........................1
........................1
9
Cut away only the covering
Cut away the
covering and
balsa wood
* WARNING: When removing any covering
from the airframe, please ensure that you
secure the cut edge with CA or similar cement.
This will ensure the covering remain tight.
10
11
3mm
BOTTOM - VIEW / Unteransicht

12
Aluminum landing
gear Hauptfahrwerk
4x30mm
screw
4mm nut
............2
4X40mm screw
4mm nut-washer
13 BOTTOM - VIEW / Unteransicht
......4
Connector
3mm connector
3mm connector
Aluminum landing
gear
Hauptfahrwerk
4x30mm
screw
4mm nut
3mm connector
FUSELAGE
Aluminum landing
gear
Hauptfahrwerk
3mm connector
4mm
4mm washer
4mm nut
4x40mm screw
Aluminum landing gear
BURDA VERSION
VQA082
AUSTRIA VERSION
VQA083

Throttle pushrod
FRONT
TOP VIEW
Servo tray
Servo tray
Elevator pushrod
Elevator servo
Rudder servo
Throttle servo
14
16
15
...1

Akku Kiettband
aus dem PICHLER
Sortiment
Best.Nr. C4739
Battery seat bell
X
Tipp
17
18
Magnetic seating
(front seating only)
Magnetic piece.
CA

L/R
Assemble left and right
side the same way
CA
Aluminum tube
L/R
X
X
BOTTOM - VIEW / Unteransicht
Cut here for standard servo
1.2mm O Alenk-Gestange
Aileron extension
cord Aileron pushrod
Trial fit the control horn into
the slot.
If the parts will join, but with
a gaps, sand or trim the parts
a little at a time until the parts
meet exactly with no gaps.
BB’
B=B’
Aluminum
tube
BOTTOM - VIEW / Unteransicht
Cut away only
the covering
CA
CA
20
19
21
CA
Plastic control horn
Linkage Stopper set
.....................2
..................2
Note: check the length (B=B’) of the
aluminum tube with the fuselage before glue.

Note: The hole on the surface of the top of the
wing are pre-drilledat factory.
2.mm drill bit
Aluminum
tube inside 3x15mm screw
TOP A
B
3x15mm screw
.........2
Secure the wing in place
using 3x15mm screw.
WRONG
A
B
22
RIGHT
23
24

Rear landing gear mount
220mm
Note: The rear landing gear mount is
pre-installed at factory
BOTTOM - VIEW / Unteransicht
X
Rear landing gear
not included
IN CASE OF FLOATING USING
3x15mm screw
.........6
26
25
.........4
Cut away only
the covering
CA
A
B
C
C
C

27
VQA082
VQA083
0.5mm dia. Cable
...1 roll
2mm metal tube
.....................4
28

65 ~ 70mm
20mm
10mm
10mm
10mm
Aileron
Rudder
Elevator
10mm
20mm
Querruderausschlag
Hohenruderausschlag
Seitenruderausschlag
Do not try to fly an out-of balance model!
Uberprufen Sie vor dem Flug den Schwerpunkt.
IMPORTANT: Please do not clean your model with pure alcohol, only use liquid soap with water or use glass cleaner
to clean on surface of your model to keep the colour not fade.
All details are subject to change
without notice !
Technische Anderungen und Irrtumer
vorbehalten !
WARNING !
Do not put in a large-than recommended engine. A bigger engine does not necessarily mean better performance.
29
