VQ Models SCOOTER User manual

SPECIFICATIONS
Wingspan:........................1630mm (64.1in.)
Length:................................1170mm (46in.)
Electric Motor:.....................See next pager
RTF Weight: 2.6Kg / 5.7lbs (Will vary with
Equipment Used).
Radio:....................6 Channel / 6 Servos
Function: Ailerons-Flaps-Elevator-Rudder-Motor
WARNING! This radio controlled model is NOT a toy. If modified or flown carelessly it could go out of controll and
cause serious human injury or property damage. Before flying your airplane, ensure the air field is spacious enough.
Always fly it outdoors in safe areas and seek professional advice if you are unexperienced.
ACHTUNG! Dieses ferngesteuerte Modell ist KEIN Spielzeug! Es ist für fortgeschrittene Modellflugpiloten bestimmt,
die ausreichende Erfahrung im Umgang mit derartigen Modellen besitzen. Bei unsachgemässer Verwendung kann
hoher Personen- und/oder Sachschaden entstehen. Fragen Sie in einem Modellbauverein in Ihrer Nähe um
professionelle Unterstätzung, wenn Sie Hilfe im Bau und Betrieb benötigen. Der Zusammenbau dieses Modells ist
durch die vielen Abbildungen selbsterklärend und ist für fortgeschrittene, erfahrene Modellbauer bestimmt.
Radio control model / Flugmodel
ALL BALSA, PLYWOOD CONSTRUCTION AND ALMOST READY TO FLY
Instruction manual / Montageanleitung
TECHNISCHE DATEN
Spannweite:...................................1630mm
Lange:............................................1170mm
Elektroantrieb.............(siehe nächste Seite)
Brushless Motor:.............
Fluggewicht:.......................................2.6Kg
Fernsteuerung................6 Kanal / 6 Servos

1.5mm
AB
!
CA L/R Assemble left and right
sides the same way. X
Drill holes using the stated
size of drill
(in this case 1.5 mm )
Use epoxy glue
Take particular care here
Hatched-in areas:
remove covering
film carefully
Not included.
These parts must be
purchased separately
Check during assembly that these
parts move freely, without binding
Apply cyano glue
SILICON
CA
GLUE
X1075 Silex Silicon # X3572 Zoom Sekundenkleber
TOLLS REQUIRED
Hobby knife
Needle nose Pliers
Phillip screw driver
Awl
Scissors
Wire Cutters
(Purchase separately) Hex Wrench
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
Sander
Masking tape - Straight Edged Ruler - Pen or pencil - Drill and Assorted Drill Bits
Read through the manual before you begin, so you will have an overall idea of what to do.
Symbols used throughout this instruction manual, comprise:
(Purchase separately)
CONVERSION TABLE
1.0mm = 3/64”
1.5mm = 1/16”
2.0mm = 5/64”
2.5mm = 3/32”
3.0mm = 1/8”
4.0mm = 5/32”
5.0mm = 13/64”
6.0mm = 15/64”
10mm = 13/32”
12mm = 15/32”
15mm = 19/32”
20mm = 51/64”
25mm = 1”
30mm = 1-3/16”
45mm = 1-51/64”
If exposed to direct sunlight and/or heat, wrinkels can appear. Storing the
model in a cool place will let the wrinkles disappear. Otherwise, remove
wrinkles in covering film with a hair dryer, starting with
low temperature. You can fix the corners by using a hot iron.
Bei Sonneneinstrahlung und/oder Wärme kann die Folie erschlaffen bzw. Falten
entstehen. Verwenden Sie ein Warumluftgebläse (Haartrockner) um evtl. Falten aus der Folie
zu bekommen. Die Kanten können Sie mit einem Bügeleisen behandeln. Nicht zuviel Hitze anwenden !
REQUIRED FOR OPERATION (Purchase separately)
Low seting
# C2983
Brushless Combo BOOST 40
inkl. Motor, Regler, Programmkarte
including motor, ESC and program card
# C6741 LiPo LEMONRC 3700-11,1V
EPOXY A
EPOXY B
# C5753
Propeller P-CON 12x6
# C4995
MASTER Digital Servo DS3012 oder/or
# C5638
MASTER Digital Servo DS3012 MG
# C2036
Servo Verlängerungskabel 400mm
Servo Extension Cord 400mm
CA Glue
X3598-120 Epoxy
5-Min.

1Pull the magnetic top hatch out
of the fuselage.
Using a pencil or felt tipped pen,
mark the fire wall where the four
holes are to be drilled.
! Align the mark on both
mounts with the mark
on the fuselage
Position the engine on to the engine mounts
so the distance from the prop hub to the fire-
wall is 112mm.
...4
.................4
4x25mm screw
Blind-nut
3x20mm screw
1/8”(3mm) nut
.................4
...4
4x20mm screw
1A
1B
1C
Remove the engine mounts
and drill four 5mm holes
as marked.
5mm
1D
1E

A=A’
! Engine thrust on balk head
is already adjust at factory
Attach the aluminum motor
mounting plate on to the motor
and secure it in place with four
screws ( included with motor set).
Reposition the plywood motor mounting plate and secure
it in place with twelve 5xmm nuts and washers (6).
Note: B=B’(top-view) and A=A’(side-view)
Using a plywood motor mounting plate as a template,
mark the fire wall where the four holes are to be drilled .
X4 X16
X12
5x60mm screw 5mm washer
5mm nut
Remove the plywood motor mounting plate and drill a
13/64”(5mm) hole through the fire-wall at each of the four
marks marked above.
Using the aluminum mounting plate as
template, mark the plywood motor mounting
plate where the four holes are to be drilled
(2A).
Remove the aluminum mounting plate and
drill 3mm hole through the plywood at each
of the four marks marked (2B).
Note: The aluminum motor mounting
included with electric motor set.
112mm
A
A’
Fire-wall
Fire-wall
22A
2B
2C
5mm
B’
B
SIDE VIEW
TOP VIEW
2D
2E

Cut away only
the covering
both side
Remove the horizontal stabilizer from the fuselage.
Using the sharp hobby knife, carefully cut away the
covering inside the lines which were marked above.
When you are satisfied with the alignment,
use a pencil to trace around the top and
bottom of the stabilizer where it meets the
fuselage.
* WARNING: When removing any covering from the airframe,
please ensure that you secure the cut edge with CA or similar
cement. This will ensure the covering remain tight.
Full the elevator out of the
horizontal stabilizer.
Note: the rectangular hole on the center of the stabilizer
must be coincidental with the center line of the fuselage.
3
3A
3B
3C
3D
3E

Remove the elevator and drill the hole as marked,
marking sure that you drill the hole perpendicular to
the leading edge of the elevator half (7E).
Do the same way with second elevator.
Use the pencil, mark on each elevator where the one
end of “U” torque rod meets the elevator.
3mm
Apply a thin layer of machine oil or petroleum jelly to only the top and bottom of
the trailing edge of the elevator, then push the elevator and its hinges into the hinge
slots in the trailing edge of the horizontal stabilizer.
When satisfied with the and alignment, hinge the elevator to the horizontal stabilizer using
CA glue.
Test-fit one end of the “U” torque rod into
each elevator half before glue the elevator
hinges to the horizontal stabilizer.
When you are satisfied with the alignment,
Secure the horizontal stabilizer onto the
fuselage using CA glue.
Note: Glue on the top and bottom of the
horizontal stabilizer, where it meets the
fuselage, and inside the slot for the vertical
stabilizer installation.
Insert the left and right elevator onto the
horizontal stabilizer
Note: Do not glue at this time.
Place the “U” torque rod onto the
top of the elevator as shown.
Hinge
Petroleum jelly
STABILIZER
Thin CA glue
! Securely glue together If coming off during
fly, you lose control of your air plane.
4
4A
4B
4C
4D
4E

Control horn
...........2
Note: The slots for the control horn
installation are pre- cut at factory.
Hinge
Petroleum jelly
STABILIZER
Thin CA glue
Cut away only
the covering.
CA
Carefully, cut away only the
covering inside the line, both
side of the vertical fin.
When you are satisfied with the alignment, use a pencil to
trace around the right and left of the stabilizer where it
meets the fuselage.
Again, push the vertical fin onto the fuselage,
when you are satisfied with the alignment,
secure the vertical fin in place using CA glue
Thin CA glue
Carefully, cut a slot on the
bottom of the rudder for the
tail gear horn installation.
! Securely glue together If coming off during
fly, you lose control of your air plane.
* WARNING: When removing any covering from the airframe,
please ensure that you secure the cut edge with CA or similar
cement. This will ensure the covering remain tight.
5
66A 6B
6C
6D
6E
6F

............4
3X15mm screw
Cut away only
the covering
* WARNING: When removing any covering
from the airframe, please ensure that you
secure the cut edge with CA or similar cement.
This will ensure the covering remain tight.
Cut away only
the covering.
Note: The slots for the control horn
installation are pre- cut at factory.
Fuselage - bottom view
Fuselage - bottom view
............2
4X40mm screw
4mm nut-washer
............2
4mm nut
4x40mm screw
Aluminum landing gear
4mm washer
3x15mm screw
7
3x12mm screw
.........2
3x12mm screw
3mm collar
3mm collar.....1
7B
7A
88A
8B

1.5mm
X
To muffler
Filler tube
To engine
Rubber
stopper
Cap
Stopper
Fuselage - top view
Hatch servo tray (FND)
Bottom hatch
Important: Please insert the hatch pushrod into the hole on the hatch control horn before insert and glue the control
horn onto the hatch.
Control horn
Checking for leaks - block the vents and blow
into the feed - if in doubt submersing the tank
in a blow of water will show up any problems.
Blow
Water
2.5x12mm screw
............4
2.5x12mm screw
Insert the fuel tank (in case of gas engine)
or Li-po battery (in case of Electric motor)
9
9A
9B
Cut the opening
10

L/R
X
X
Wing - bottom view
Aileron extension
cord
Aileron pushrod
CA
Plastic control horn
Linkage Stopper set
.....................2
.................2
CA
Elevator and
Rudder servo
3mm set Screw
2 mm
Elevator and rudder
pushrod
D=5/64”(2mm)
Linkage Stopper set
.................21
175mm pushrod
......2
Cut away only
the covering
Cut away only
the covering
Rudder servo
Elevator servo
6x22mm
wooden dowel
CA
Elevator and
Rudder servo
3mm set Screw
2 mm
Aileron and flap
pushrod
6x22mm dowel
........1
11
11A
11B
12

BB’
B=B’
Aluminum
tube
Note: check the length (B=B’) of the
aluminum tube with the fuselage before glue.
2.mm drill bit
Aluminum
tube inside 3x15mm screw
TOP A
B
3x15mm screw
.........2
Secure the wing in place
using 3x15mm screw (B).
WRONG
B
RIGHT
Note: The holes on the surface
of the top of the wing are
pre-drilled at factory.
CA
Aluminum
tube
A
13
13A
13B
13C

68 ~ 73mm
20mm
10mm
Aileron
Rudder
10mm
20mm
Querruderausschlag
10mm
10mm
Elevator
Hohenruderausschlag
Seitenruderausschlag
Do not try to fly an out-of balance model!
Uberprufen Sie vor dem Flug den Schwerpunkt.
IMPORTANT: Please do not clean your model with pure alcohol, only use liquid soap with water or use glass cleaner
to clean on surface of your model to keep the colour not fade.
All details are subject to change
without notice !
Technische Anderungen und Irrtumer
vorbehalten !
WARNING !
Do not put in a large-than recommended engine. A bigger engine does not necessarily mean better performance.
Flap
20mm
14 BALANCE AND CONTROL SURFACE
