1
OWNER'S MANUAL
Read Rules for
Safe Operation
and Instructions
Carefully
Fine Finish
STATI-KIT
CAUTION
T.M.
VM200
HV
I
O
T0.2A
VM200
HV
I
O
T0.2A
Model No. 0292003
R
2000
T.M.
R
ELECTROSTATIC
SPRAYING SYSTEM
APPROVED
FOR ELECTROSTATIC FINISHING APPLICATION
POWER PACK,VM 200
SPRAY GUN ,
P/N 0179637
GM 2000 EAC P/N 0179673
AIR HOSE P/N 0128510
FLUID HOSE P/N 9984482
SPRAY GUN , GM 2000 EA P/N 0179221
FLUID HOSE
AIR HOSE
P/N 0179248
POWER PACK, EPP 2000
POWER PACK P/N 0179633
,EPP 200
P/N 0179966
Form No.0292522-4/91A

1
CONTENTS
SAFETY PRECAUTIONS .................................................................... 3-6
SPECIFICATIONS................................................................................ 7
INTRODUCTIONS ............................................................................... 7
GENERAL DESCRIPTION .................................................................. 8
MOUNTING ARRANGEMENT ............................................................. 9
SET UP ................................................................................................ 9
OPERATION ........................................................................................ 10
CLEAN UP ........................................................................................... 11
TIP CHANGE ....................................................................................... 12
FILTER REPLACEMENT ..................................................................... 13
FRONT & REAR PACKING REPLACEMENT ..................................... 13
TROUBLE SHOOTING ........................................................................ 14-15
PARTS LIST ......................................................................................... 16-17
SPARE TIPS ........................................................................................ 18
WARRANTY ......................................................................................... 20
2

1
SAFETY PRECAUTIONS
This manual contains information which must be read and understood before using the equipment. When you come to an
area which has one of the following symbols, pay particular attention and make certain to heed the safeguard.
Important safety information indicates a hazard which may cause serious injury or loss of life.
WARNING
CAUTION
Important information that tells how to prevent damage to equipment or how to avoid causes of minor injuries.
Notes: Gives important information which should be given special attention.
3

1
HAZARD
WARNING
Electrostatic arcing may cause an explosion or fire.
Solvent and paint fumes can explode or ignite causing
property damage and/or severe injury.
PREVENTION
•Operator must be grounded. Grounding straps must be
used when wearing rubber soled shoes.
•Operator must be in contact with the spray gun handle;
cut out palm section of any work gloves to be used.
•Operator must remove all metal objects from his or her
person which are not grounded.
•The object being sprayed must be grounded.
•All metal objects within the spray area must be grounded
(including spray booth, part hangers, fire extinguishers,
etc.)
•Grounded conductive floor must be provided in spray
area.
•Turn off the Power Pack and unplug from outlet before
flushing out the gun, cleaning or replacing parts on the
gun such as changing tips.
4
Explosion or fire. Solvent and paint fumes can ex-
plode or ignite causing property damage and/or se-
vere injury.
•Exhaust and fresh air introduction must be provided to
keep the air within the spray area free of accumulation of
flammable vapors.
•Smoking must not be allowed in spray area.
•Fire extinguishing equipment must be present and in
working order.
•Electrostatic arcing must be prevented. (See Electro-
static arcing)
•When flushing the system use only solvents recom-
mended by the coatings manufacturer. Be sure Power
Pack is turned off and unplugged.
•Use only grounded high pressure fluid hose.
•Avoid all ignition sources such as static electrcity
sparks,open flames such as pilot lights, hot objects such
as cigarettes and sparks from connecting and discon-
necting power cords and working light switches.

1
HAZARD
WARNING
•Follow the requirements of the Material Safety Data
Sheet supplied by the coatings manufacturer.
•Exhaust and fresh air introduction must be provided
within the spray area to keep the air free of accumula-
tions of toxic materials.
•Wear a mask or respirator. Read all instructions for the
mask to insure that it will provide the necessary protec-
tion against the inhalation of harmful vapors.
PREVENTION
•Maximum operating range of the gun - 3625 PSI fluid
pressure.
•NEVER aim the gun at any part of the body under any
circumstances.
•NEVER let any part of the body come in contact with the
fluid stream. DO NOT come in contact with a fluid stream
created by a leak in the fluid hose.
•Paint hose can develop leaks from wear, kinking, abuse
etc. A leak is capable of injecting material into the skin.
Paint hose should be inspected before each use. Re-
place a damaged hose.
•NEVER put hand in front of the gun. Gloves will not
provide protection against an injection injury.
•ALWAYS lock the gun trigger when cleaning, changing
tips or leaving unattended.
•Some spray pumps prohibit the use of halogenated
hydrocarbon solvents.
•Halogenated hydrocarbon solvents such as methylene
chloride and 1,1,1 - Trichlorethane are not compatible
with aluminum and may cause an explosion. If you are
not sure of a material’s compatibility with aluminum,
contact your coatings supplier. Halogenated hydrocar-
bon solvents are compatible with the GM2000 spray gun
and may be used if the solvents are compatible with the
pump and other accessories.
•ALWAYS shut fluid pump off and release all pressure
before servicing, cleaning, or changing tips.
Toxic Substances: Some materials may be harm-
ful if inhaled or come in contact with the skin.
Explosion hazard incompatible materials. May cause
property damage or severe injury.
Injection. A high pressure stream of paint can pierce the
skin and underling tissues, leading to serious injury and
possible amputation.
5

1
WARNING
PREVENTION
HAZARD
General
•All accessories must be rated at or above the maximum
pressure rating of spray pump (includes spray tips, guns,
extensions and fluid hose.
•If you are injected, see a physician immediately.
Injection (Con't)
DO NOT TREAT AS A SIMPLE CUT! It can lead
to amputation. See a physician immediately.
NOTE TO PHYSICIAN: Injection into the skin
is a traumatic injury. It is important to treat
the injury surgically as soon as possible. DO
NOT delay treatment to research toxicity.
Toxicity is a concern with some coatings
injected directly into the blood stream. Con-
sultation with a plastic surgeon or recon-
structive hand surgeon may be advisable.
•Read all instructions and safety precautions before oper-
ating.
•Comply with all appropriate local, state and national
codes governing ventilation, fire prevention, and opera-
tion of Electrostatic equipment usage.
•The United States Government Safety Standards have
been adopted under the Occupational Safety and Health
Act. These standards, particularly the General Stan-
dards, Part 1910 and the Construction Standard, Part
1926, should be consulted.
•NFPA Standard No. 33 is to be followed when setting up
your spray area. Contact the National Fire Protection
Association, Batterymarch Park, Quincy, Massachusetts,
02269 for more information.
•Check with insurance company for additional require-
ments.
•DO NOT substitute any other spray gun or power pack
with this system. Use only identical replacement parts.
6

1
SPECIFICATIONS
GM2000 EAC SPRAYGUN (P/N 0179673)
Air Pressure, max. 145 psi
Material Pressure, max. 3625 psi
Air Volume 10 CFM@ 45 PSI
Material Volume Varies due to Tip size
Air Connector 1/4 inch
Material Connector NPS 1/4
Length 11.8 inches
Height 10 inches
Weight 21 oz.
Input voltage 22 VAC
Input Current, max. 0.8 A
Frequency 26 kHz
High Voltage 80 kV DC
Output Current, max. 100 A AC
Polarity Negative
Cable, Connecting 36 ft.
INTRODUCTION
INTRODUCTION TO ELECTRO-STATIC
SPRAYING
VM200 ELECTROSTATIC POWER PACK
(P/N 0179637)
Length 7.5 inches
Width 4.75 inches
Height 3.5 inches
Weight 3.9 lbs.
Input - VAC 110 - 60 Hz
Power consumption max. 15 W
Output Voltage 80 KV
Output Current max 0.7 A
Output Frequency 17 kHz
Power Cord 9 ft.
The spraying medium is atomized using a pneumatic or
diaphragm pump and a booster air feed supply. A high DC
voltage (up to 80 kV), applied across the grounded compo-
nent and the electrode fitted to the gun body generates an
electric field and applies a negative charge to the paint
particles. These repel each other as they move from gun to
workpiece and so distribute evenly through the fine spray
cloud and then uniformly deposit on the positively grounded
surface. Particles shooting past the component remain
trapped in the electric field and deposit on the backside of
the work object. Effective material yield up to 90%, time
savings up to 80%, markedly improved quality of finish, less
cleaning and a healthier environment are the principal
properties of the process.
FEATURES:
Minimum overspray
Coating by electrostatic wrap-around action
Good atomization of charged particles
ADVANTAGES:
Effective material utilization up to 90%
Enormous time and labor savings
NOTE
Use only coating materials with a specific re-
sistance of 50 - 3.500 K Ohms . If you are not
sure of the specific resistance check with the
coatings supplier before using.
7

1
Figure 1
Figure 2
HV
GM 2000
O
I
T0.2A
VM200
GROUND CONNECTION FUSE
ON - OFF SWITCH
RED HIGH VOLTAGE
LAMP
HIGH VOLTAGE CABLE
SOCKET
GENERAL DESCRIPTION
GM2000 EAC SPRAY GUN
The GM2000 EAC Electrostatic Air Coat Spraygun is
very light and easy to service. It can be used up to a
maximum operating pressure of 3625 PSI.
Trigger Lock: Turn knob clockwise to lock the trigger.
Electrostatic On/Off Switch: This switch can be used to turn
off the electrostatics. Sometimes the Faraday Cage effect
prevents proper coverage on inside corners. If you run into
this problem turn this switch off (up), spray the inside
corner(s), then turn the switch back on (down), and resume
electrostatic spraying.
Fluid Inlet: Securely fasten airless hose to this threaded
port. Be sure to use only hose with adequate pressure
rating.
Air Inlet: Securely fasten air hose to this threaded port.
Air Adjustment: This knob can be used to regulate the
amount of air that is used in spraying. Turn knob clockwise
until it closes, slowly turn knob counterclockwise until ade-
quate air flow results.
AIR CONTROL KNOB
TRIGGER LOCK
SPRAY GUN BODY
HANDLE WITH HIGH VOLT-
AGE GENERATOR
PAINT FILTER
TRIGGER
TIP ELECTROSTATIC
ON/OFF SWITCH
HIGH VOLTAGE
VM 200 ELECTROSTATIC POWER PACK
The heavy metal case is water tight. All external compo-
nents and operating controls, as well as the case finish are
largely solvent-resistant.
With the power switch on, the green pilot lamp lights up.
Internal components now convert the supplied voltage into
a pulsating DC voltage of 12 V and 17 kHz frequency. This
low output voltage supplies the GM 2000 EAC gun via the
connecting cable.
When the gun trigger is pulled, a solenoid-operated Reed
contact initiates the switching on of the high voltage, signal-
led by lighting up of the red high voltage lamp. Via the
connecting cable to the gun, the 12 V/17 kHz, medium-
frequency, low voltage is now fed to the high-voltage
generating section inside the guard of the gun. Here, a
transformer within the cascade converts the low voltage into
a high voltage of 80 kV and applies this with negative
polarity to the electrodes.
GREEN ON - OFF LAMP
8

1
TYPICAL MOUNTING AR-
RANGEMENT
WAGNER AIRLESS SPRAYER
MOUNTING INSTRUCTIONS
1. Use the allen wrench provided, attach the mounting
bracket (1) to the power pack (2) with the 2.4mm
lockwashers (3) and socket head screws (4).
2. Place the power pack/mounting bracket assembly on
any 1" diameter tube, preferably as illustrated below.
3. Align support clamps (5) with mounting bracket (1),
using the other allen wrench provided, attach the 2
pieces with the 4-1/4" lockwashers (6) and socket
head screws (7), tightening down equally on both
sides.
Figure 3
1
2
3
4
5
6
7
9

1
Power cord ground must remain intact. Do
not clip off ground pole on plug to fit a non-
grounded socket. Static build up will result
which may cause an explosion.
WARNING
Figure 4
SET-UP
SET-UP VM 200 POWER PACK:
1. GM 2000 EAC Socket Outlet
2. Ground Connection Knob
3. Fuse
4. On/Off Switch
5. On/Off Indicator Lamp (Green)
6. High Voltage Indicator Lamp (Red)
7. Grounding Cable
8. Ground Washer
9. GM 2000 EAC Connecting Cable
Step 1: Attach the grounding cable (7). Remove the ground
connection knob (2) and the ground washer (8). Put the ring
terminal end of the grounding cable on the grounding stud
and replace the ground washer (8) and the ground connec-
tion knob (2) securely. The end of the grounding cable with
the spring clip is to be attached to the object being sprayed.
Step 2: Attach the GM2000 EAC Connecting Cable (9) to
the Socket Outlet (1) on the Power Pack. Secure the cable
in place by screwing the nut onto the threads of the power
pack cable receptor.
Step 3: Plug power cord into a grounded 110 volt outlet.
POWER PACK
OPERATION
1. Set the VM 200 Power Pack Switch to the “I” position
(the green light turns on)
2. Adjust the fluid pressure to achieve maximum atomi-
zation.
3. If air assist is used, adjust air pressure regulator
between 10 & 30 psi.
4. Be sure all items within the spray area are well grounded
— Refer back to Warnings — Electrostatic arcing may
cause fire/explosion.
5. Test spray pattern and finish on a sample surface.
Keep the spray 8 - 12 inches away from the work
surface. Readjust fluid and/or air pressure to achieve
the optimum atomization and spray pattern.
6. Use the Air Adjustment Knob (located at rear of the
spray gun) to control the volume of air. For additional
fine tuning rotate tip nut. (Round tip only).
7. For best results, move the entire arm while spraying,
not just the wrist.
8. When Power Pack is turned on and the trigger on the
spray gun is pulled, both the green light and the red
light will be lit. The red light indicates the high voltage
is on.
9. The electrostatic On/Off Switch is to be turned off
when spraying into corners. With this switch in the “Off”
position, the red light on the Power Pack will not be lit.
(If the red light is lit with the electrostatic switch in the
“Off” position, DO NOT USE - TAKE TO AN AUTHOR-
IZED SERVICE CENTER FOR REPAIR.)
10. Lock the trigger on the spray gun after each use by
turning the trigger lock knob (located at the rear of the
spray gun) all the way to the right until it stops.
NOTE: The GM2000 EAC spray gun has a two-
stage trigger:
1. Pulling the trigger part way - Only the air is on.
2. Pulling the trigger all the way - Both air and fluid
are on.
10
2
1
3
45
6
9

1
CLEAN UP
WHEN CLEANING THE ELECTROSTATIC
SYSTEM, THESE SAFETY PROCEDURES
MUST BE FOLLOWED. FAILURE TO FOL-
LOW THESE PROCEDURES MAY RESULT
IN AN EXPLOSION/FIRE.
•Turn power pack to the “OFF” position and unplug from
power source before starting to clean.
•Be certain that gun, cable, and power pack are free of all
paint spots and cleaning agent residue.
•Exhaust and fresh air introduction must be maintained
during the clean up operation.
•Keep cleaning solvents in approved safety containers
and only in minimum quantities.
•All personnel and cleaning equipment, including con-
tainer used in cleaning operation, must be grounded.
•DO NOT turn on the VM200 power pack until the
cleaning operation has been completed, all cleaning
materials have been removed from spray area, and
spray area is free of any vapors produced by the cleaning
operation.
•If defects in the equipment are found , DO NOT use until
repairs are completed.
WARNING
11
•Clean equipment immediately after use.
•NEVER IMMERSE SPRAY GUN IN ANY FLUID
AT ANY TIME.
•Flush out fluid passages with a cleaning sol-
vent compatible with the coating material be-
ing sprayed after each use.
1. Be sure the VM200 Power Pack is turned off and
unplugged from the power source.
2. Check the coating manufacturer’s recommen-
dation for a compatible cleaning solvent.
NOTE
•The fluid passages of the spray gun should be
cleaned while cleaning the fluid hose and fluid
pump, following instructions, provided with
the fluid pump.
•Clean the spray tip and air cap by removing
from spray gun, rinsing in solvent, drying and
replacing on spray gun.
CAUTION

1
TIP CHANGE
CHANGING THE ROUND SPRAY TIP
1. Screw out spray tip (B) with tip wrench (A). (See Fig.5)
2. Attach desired spray tip and tighten with tip wrench.
CLEANING OF THE FLAT SPRAY TIP
• Remove air cap (H). (See Fig. 8)
•Remove flat spray tip (G) and clean it.
•Carefully handle the carbide flat spray tip (G); avoid
cleaning with sharp-edged metal objects.
Figure 7
Figure 8
.
•Assemble in reverse order.
•Mount tip body ( D ) and tighten by hand. ( Do not use
tip removal tool ).
•When adjusting tip nut leave a gap for atomizing air
between the air cap and tip body.
12
(OPTIONAL):
ALL PARTS NEEDED FOR THE FLAT TIP MUST BE
PURCHASED SEPARATELY. SEE PAGE 18 FOR PART
NUMBERS AND ORDERING INFORMATION.
•Mount tip (G) on paint channel of spray gun body (F).
See Fig.8.
•Place air cap ( H ) on tip ( G ) fitting lugs of air cap into
grooves of tip insert.
•Mount air cap ( H) onto spray gun body until past the tip
security lever.
•Adjust desired air jet level by means of air cap horns
( J) and tighten air cap.
ASSEMBLY OF FLAT SPRAY TIP
If the round nozzle body is attached: Fig. 7.
•Remove tip body (D) from the spray gun body (F). Using
the procedure described in changing the round nozzle
body.
A
B
Figure 5
CHANGING THE ROUND NOZZLE BODY
•To remove the tip body (D) place the tip body removal
tool on the tip security lever (E) fig. 6A. Squeeze and
hold as shown in fig. 6B while unscrewing the tip body.
•Screw out spray tip (B) using the tip spanner and
remove diffuser ( C ) fig 6C.
•Carefully handle the carbide spray tip; avoid cleaning
with sharp-edged metal objects.
Figure 6A
Figure 6C
E
D
C
G
F
H
J
B
Tip nut
Figure 6B
Tip removal tool
D
F

1
VALVE SEAL REPLACEMENT
To replace valve seals you must remove the entire valve
rod.
1. Actuate trigger (3) and unscrew trigger lock knob (2),
remove the compression spring. Fig. 11
2. Remove screws holding trigger asembly in place and
remove trigger (3). Fig. 11
3. Unscrew seal screw (11/C) from gun body. Fig. 12
4. Carefully remove complete valve rod by pulling end of
rod (12). Fig. 12
5. Hold the rod valve using the universal spanner at
surface (F) and using a pliers turn the valve seal
(8/B) and remove. Fig. 12
6. Remove compression ring (9) and front seal
(10). Fig.12
7. To remove push rod cap (14) hold universal spanner
at surface (E) and unscrew at surface (D). Fig.12
8. Replace compression ring with O-Ring (9), front seal
(12), rear seal (11) and if necessary push rod seal
(15) and O-Ring (16) of the air valve . Fig. 12
9. Assemble in reverse order.
MAINTENANCE
WARNING
FILTER REPLACEMENT AND CLEANING.
10
8
12
10 11 13 914 15 16
C
BDEF
G
A
7
6
11
Figure 10
Figure 9
Figure 12
13
5
3
Figure 11
1
4
2
FRONT PACKING ADJUSTMENT
1. If there is evidence of material leakage past the front
seal (10) lightly tighten the packing nut (11)with the
universal wrench. Fig. 10
1. Disconnect material hose at fitting (1) Fig 11. Hold
material connecting tube with the universal spanner
wrench at surface (A ).
2. Disconnect union nut (4). Do not allow locking nut
(5) to rotate while disconnecting union nut.
3. Unscrew red filter screw. Fig. 9
4. Slip filter cylinder(6) from filter screw.
5. Rinse or replace filter cylinder, (7).
6. Assemble in reverse order.
Turn off Power Pack and unplug from power source.
Relieve pressure to the Spray Gun, Lockout trigger and
turn off supply pump and air supply before cleaning or
replacing filters, tips, or any other parts failure to follw these
procedures may result in fire, explosion or injection injury.

1
14
Problem
• No green light on Power Pack
• Gun on-off switch performing
opposite.
• No red light on Power Pack.
• Spray pattern not even;
unsymmetrical or poor atomization.
• Spray pattern is correct, but there is
no wraparound.
• Dead outlet.
• Fuse blown.
• Not plugged in.
• Faulty circuit board.
• Defective switch.
• Cable from gun to Power Pack
loose or not connected.
• Cable from gun to Power Pack
defective.
• Blown fuse.
• If the trigger on the gun is pressed
and the above causes have been
checked and remedied and there is
still no high voltage, then the high
voltage generator or Power Pack
need service.
• Plugged spray tip.
• Worn or faulty tip.
• Paint too thick.
• Uneven air distribution at tip nut.
• Object not grounded.
• Cable not fitted properly.
• Cable faulty.
• High voltage generator
• Power Pack is turned off.
• Gun on/off switch is off.
• Fluid pressure too high.
• Air pressure too high.
• Electrode dirty or damaged.
• Live outlet.
• Replace fuse.
• Plug in.
• Take to Authorized Service Center.
• Take to Authorized Service Center.
• Tighten power cable.
• Replace power cable.
• Check fuse; replace if necessary.
• Take to Authorized Service Center
• Clean tip.
• Replace tip.
• Thin paint.
• Clean all air passages.
• Check ground.
• Check connection.
• Replace cable.
• Replace.
• Turn on.
• Turn on.
• Reduce fluid pressure.
• Reduce air pressure.
• Clean or replace.
Cause Solution
TROUBLESHOOTING

1
TROUBLESHOOTING
Problem
• Air leaking at tip without pulling
trigger.
• Air leaks between gun body and
gun barrel.
• No air at tip when trigger is pulled.
• Air valve is faulty.
• Gun Barrel Nut.
• Air hose not connected.
• No air supply
• Wrong tip body fitted
• Round tip nut screwed down too
hard.
• Air channels in tip body or cascade
blocked
• Replace air valve.
• Tighten nut.
• Connect air hose
• Check air supply
• Fit correct EAC tip body
• Unscrew nut slightly
• Unblock air channels as necessary
or take to authorized service center
Cause Solution
• No material at tip when trigger is
pulled.
• Material leaks at joint between gun
body and gun barrel when trigger is
pulled.
• No material supply
• Gun filter blocked or fitted upside-
down.
• Tip plugged.
• Gun barrel nut loose
• Material channel faulty
• Check supply pressure
• Replace filter, or mount it correctly.
• Packings not tight enough.
• Packing faulty.
• Valve stem and valve seat dirty or
faulty.
.• Lightly tighten packing nuts.
• Replace packings as necessary.
• Clean or replace as necessary
• Material leaks at front or rear pack-
ings.
• Material leaks at tip without pulling
trigger.
• Tighten nut. DO NOT overtighten.
• Take to Authorized Service Center.
• Unplug tip.
15

1
Figure 9
16

1
GM 2000 EAC
Item Description Part Number
1Spray gun barrel 0179500
2Bushing 0128336
3Screw countersunk 0179354
4Type plate 9900962
5Screw flathead 9900810
6O-ring 9971003
7Knob, Air Adjustment 0179416
8Trigger sleeve 0179396
9Valve rod complete 0179254
10 Valve sealing element 0179236
11 O-ring 9971182
12 Compression ring 0179343
13 Seal 0179341
14 Sealing screw 0179342
15 Push-rod cap 0179340
16 Seal 0179395
17 Push-rod seal 0179339
18 O-ring 9971372
19 Valve push-rod 0179337
20 Valve rod 0179335
21 Valve rod spring guide 0179394
22 Compression spring 9994247
23 Adjusting element 0179253
24 Compression spring 9994248
25 Compressing element EAC 0179488
26 Locking nut 0179356
27 Double socket 9994627
28 Air hose 0128510
30 Connection adapter BSP 1/4 9983226
31 Connecting cable Call Factory
32 Connecting adapter M16x1.5 0097201
33 Hose cover 0179248
34 Flat-head screw* 9900808
35 Trigger* 0179219
36 Cylindrical filter* 9995611
37 Filter screw 0179383
38 Material connector 0179241
39 High pressure hose 9984482
40 Protecting cap EAC 0179482
41 Nozzle EAC, flat 0179678
44 Compression spring 9994269
45 Tip insert EAC, flat See Nozzle List
46 Nozzle EACR 2000 0179679
47 Tip insert EACR 15, standard 0132724
48 Air cap EACR 0179536
49 Tip body, EACR 0179664
50 Locking screw 0132351
51 Diffuser with sealing nipple 0132516
52 Wrench Universal 0179901
53 Glove 9994682
54 Tip Wrench 0179902
55 Tip body removal tool 0179963
17

1
Flat Tip
Part Tip Orifice Size Fan
Number Marking (Inch) Width
0128550 9/15 .009 15°
0128216 9/20 .009 20°
0128552 11/15 .011 15°
0128217 11/20 .011 20°
0128201 11/50 .011 50°
0128554 13/15 .013 15°
0128218 13/20 .013 20°
0128212 13/50 .013 50°
0128556 15/15 .015 15°
0128219 15/20 .015 20°
0128213 15/50 .015 50°
0128215 18/50 .018 50°
0128565 21/20 .021 20°
0128559 21/50 .021 50°
0128561 26/50 .026 50°
0128562 31/50 .031 50°
0128563 36/50 .036 50°
Accessories
0088154 Fluid Pressure Gauge
Round Tip
Orifice
Size
Part Tip .001 Volume @ 250 PSI
Number Marking (Inch) oz./Min G.P.M.
0132720 R11/2 .0066 2.28 .0178
0132721 R12/2 .0080 3.07 .0240
0132722 R13/2 .0092 3.74 .0292
0132723 R14/2 .0104 4.77 .0373
0132724 R15/2 .0110 5.29 .0413
0132725 R16/2 .0115 6.02 .0470
0132726 R17/2 .0121 6.72 .0525
0132727 R18/2 .0126 7.30 .0570
0132728 R19/2 .0132 8.32 .0650
0132729 R20/2 .0139 9.22 .0720
0132730 R21/2 .0145 9.92 .0775
0132731 R22/2 .0151 10.75 .0840
18

19

LIMITED WARRANTY
ELECTROSTATIC PAINT SPRAY EQUIPMENT
To validate this warranty, the completed registration card must be mailed within one week of the date of purchase to Wagner Spray
Tech Corporation.
Wagner Spray Tech Corporation extends to the original purchaser of its electrostatic paint spray equipment a one year warranty
against defects in material or workmanship provided that the equipment is installed and operated in accordance with the
recommendations and instructions of Wagner Spray Tech Corporation. Wagner Spray Tech will repair or replace, at its option,
defective parts without charge if such parts are returned with transportation charges prepaid to the nearest authorized service
agency or to Wagner Spray Tech Corporation, 1770 Fernbrook Lane, Minneapolis, Minnesota.
This warranty does not cover:
1. Equipment and accessories supplied to Wagner Spray Tech Corporation by other manufacturers including hose are covered
by the express warranties of the original manufacturers. Wagner Spray Tech Corporation will provide the purchaser with
reasonable information and assistance in making claims to the original manufacturers under their warranty.
2. Normal wear and/or defects caused by or related to abrasion, corrosion, abuse, negligence, accident faulty installation or
tampering in a manner which impairs normal operation.
3. Transportation costs and other incidental, direct, special or consequential damages or loss.
Any implied warranty of merchantability or fitness for a particular purpose on Wagner Spray Tech Corporation’s spray equipment
is limited in duration to the duration of this warranty.
Some states do not allow the exclusion of incidental or consequential damages, or allow limitations on how long an implied warranty
lasts, so the above limitations or exclusion may not apply to you. This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
Copyright 1989 by Wagner Spray Tech Corporation
ALL RIGHTS RESERVED
R
Wagner Spray Tech Corporation
1770 Fernbrook Lane
Minneapolis, Minnesota 55447
Telephone [phone] PRINTED IN U.S.A.
U.S. PATENT 3,843,052
20
