WAGO 750-486/040-000 User manual

Manual
WAGO-I/O-SYSTEM 750 XTR
750-486/040-000
4AI 0/4
-20mA NE43 Ex i XTR
4
-channel analog input; 0/4 … 20 mA; NE43;
intrinsically safe; extreme
Version 1.0.0

2 WAGO-I/O-SYSTEM 750 XTR
750-486/040-000 4AI 0/4-20mA NE43 Ex i XTR
Manual
Version 1.0.0
© 2018 WAGO Kontakttechnik GmbH & Co. KG
All rights reserved.
WAGO Kontakttechnik GmbH & Co. KG
Hansastraße 27
D-32423 Minden
Phone: [phone] – 0
Fax: [phone] – 1 69
E-Mail: [email protected]
Web: http://www.wago.com
Technical Support
Phone: [phone] – 5 55
Fax: [phone] – 85 55
E-Mail: [email protected]
Every conceivable measure has been taken to ensure the accuracy and
completeness of this documentation. However, as errors can never be fully
excluded, we always appreciate any information or suggestions for improving the
documentation.
E-Mail: [email protected]
We wish to point out that the software and hardware terms as well as the
trademarks of companies used and/or mentioned in the present manual are
generally protected by trademark or patent.
WAGO is a registered trademark of WAGO Verwaltungsgesellschaft mbH.

WAGO-I/O-SYSTEM 750 XTR Table of Contents 3
750-486/040-000 4AI 0/4-20mA NE43 Ex i XTR
Manual
Version 1.0.0
Table of Contents
1Notes about this Documentation.............................................................6
1.1 Validity of this Documentation.................................................................6
1.2 Copyright................................................................................................6
1.3 Symbols .................................................................................................7
1.4 Number Notation ....................................................................................9
1.5 Font Conventions ...................................................................................9
2Important Notes ......................................................................................10
2.1 Legal Bases..........................................................................................10
2.1.1 Subject to Changes..........................................................................10
2.1.2 Personnel Qualifications ..................................................................10
2.1.3 Use of the WAGO-I/O-SYSTEM 750 in Compliance with
Underlying Provisions ......................................................................10
2.1.4 Technical Condition of Specified Devices.........................................11
2.1.4.1 Disposal ......................................................................................11
2.2 Safety Advice (Precautions) .................................................................12
3Device Description..................................................................................14
3.1 View .....................................................................................................17
3.2 Connectors...........................................................................................18
3.2.1 Data Contacts/Local Bus..................................................................18
3.2.2 Power Jumper Contacts/Field Supply ..............................................19
3.2.3 CAGE CLAMP®Connectors.............................................................20
3.3 Display Elements..................................................................................21
3.4 Operating Elements..............................................................................22
3.5 Schematic Diagram..............................................................................23
3.6 Technical Data .....................................................................................24
3.6.1 Device..............................................................................................24
3.6.2 Power Supply...................................................................................24
3.6.3 Inputs...............................................................................................25
3.6.4 Explosion Protection ........................................................................26
3.6.5 Communication................................................................................26
3.6.6 Connection Type..............................................................................27
3.6.7 Mechanical Conditions.....................................................................27
3.6.8 Climatic Environmental Conditions...................................................27
3.7 Approvals .............................................................................................28
3.8 Standards and Guidelines ....................................................................30
4Process Image.........................................................................................36
4.1 Overview ..............................................................................................37
4.2 Status Bytes.........................................................................................38
4.3 Process Data........................................................................................39
4.3.1 Overview of Sensor Types...............................................................39
4.3.2 Standard Format (Two's Complement Representation)....................39
4.3.2.1 Sensor Type “0-20 mA” ...............................................................39
4.3.2.2 Sensor Type “4-20 mA” ...............................................................40
4.3.2.3 Sensor Typ “3,6-21 mA” (NAMUR NE43)....................................41
4.3.3 Special Format (Amount/Sign Format).............................................42

4 Table of Contents WAGO-I/O-SYSTEM 750 XTR
750-486/040-000 4AI 0/4-20mA NE43 Ex i XTR
Manual
Version 1.0.0
4.3.3.1 Sensor Type “0-20 mA” ...............................................................42
4.3.3.2 Sensor Type “4-20 mA” ...............................................................43
4.3.3.3 Sensor Typ “3,6-21 mA” (NAMUR NE43)....................................44
5Mounting..................................................................................................45
5.1 Mounting Sequence..............................................................................45
5.2 Inserting and Removing Devices..........................................................46
5.2.1 Inserting the I/O Module...................................................................46
5.2.2 Removing the I/O Module ................................................................47
6Connect Devices.....................................................................................48
6.1 Connecting a Conductor to the CAGE CLAMP®...................................48
6.2 Power Supply Concept.........................................................................49
6.2.1 Supplementary Power Supply Regulations ......................................52
6.3 Connection Examples...........................................................................55
7Commissioning.......................................................................................57
7.1 Parameterization with WAGO-I/O-CHECK............................................57
7.1.1 Parameterization Dialog...................................................................59
7.1.1.1 Title Bar.......................................................................................60
7.1.1.2 Main Menu ..................................................................................60
7.1.1.3 Horizontal Tab Menu...................................................................61
7.1.1.3.1 ”File” Tab................................................................................61
7.1.1.3.1.1 “Open” Menu Item..............................................................62
7.1.1.3.1.2 “Save” Menu Item...............................................................63
7.1.1.3.2 “Start” Tab...............................................................................63
7.1.1.3.3 “Connection” Tab....................................................................64
7.1.1.4 Vertical Tab Menu .......................................................................64
7.1.1.4.1 “Module settings” Menu Item...................................................65
7.1.1.4.2 “Channel settings” Menu Item.................................................66
7.1.1.4.3 “Scaling” Menu Item................................................................69
7.1.1.4.4 “Calibration” Menu Item...........................................................71
7.1.1.4.5 “Monitoring” Menu Item...........................................................74
7.1.1.4.6 “Information” Menu Item..........................................................75
7.1.1.5 Application Area..........................................................................76
7.1.1.6 Status Messages.........................................................................76
7.1.1.7 Status Bar ...................................................................................77
7.2 Calibrating Measured Values................................................................78
7.2.1 Example of Determining Gain and Offset.........................................79
7.3 Scaling Measured Values.....................................................................80
8Diagnostics..............................................................................................81
8.1 I/O Module Behavior in the Event of an Error........................................81
9Use in Hazardous Environments ...........................................................84
9.1 Marking Configuration Examples..........................................................85
9.1.1 Marking for Europe According to ATEX and IECEx..........................85
9.1.2 Marking for America (NEC) and Canada (CEC)...............................89
9.2 Installation Regulations.........................................................................92
9.2.1 Special Notes Regarding Explosion Protection ................................92
9.2.2 Special Notes Regarding ANSI/ISA Ex ............................................94

WAGO-I/O-SYSTEM 750 XTR Table of Contents 5
750-486/040-000 4AI 0/4-20mA NE43 Ex i XTR
Manual
Version 1.0.0
10 Appendix .................................................................................................95
10.1 Configuration and Parameterization via GSD for PROFIBUS DP and
PROFINET IO ......................................................................................95
10.1.1 Configuration 4AI 0/4-20 mA Ex i (NAMUR).....................................95
10.1.1.1 PROFIBUS DP Fieldbus Coupler 750-333/040-000.....................95
10.1.2 Parameterization 4AI 0/4-20 mA Ex i (NAMUR)...............................95
10.1.2.1 PROFIBUS DP Fieldbus Coupler 750-333/040-000.....................96
List of Figures ..................................................................................................97
List of Tables....................................................................................................99

6 Notes about this Documentation WAGO-I/O-SYSTEM 750 XTR
750-486/040-000 4AI 0/4-20mA NE43 Ex i XTR
Manual
Version 1.0.0
1 Notes about this Documentation
Always retain this documentation!
This documentation is part of the product. Therefore, retain the documentation
during the entire service life of the product. Pass on the documentation to any
subsequent user. In addition, ensure that any supplement to this documentation
is included, if necessary.
1.1 Validity of this Documentation
This documentation is only applicable to the I/O module 750-486/040-000
(4AI 0/4-20mA NE43 Ex i XTR).
The I/O module 750-486/040-000 shall only be installed and operated according
to the instructions in this manual, in the system description for the WAGO-I/O-
SYSTEM 750 XTR and in the manual for the used fieldbus coupler/controller.
Consider power layout of the WAGO-I/O-SYSTEM 750 XTR!
In addition to these operating instructions, you will also need the system
description “Design Notes XTR – Guidelines and Recommendations for
Increasing Operational Safety” and the manual for the used fieldbus
coupler/controller, which can be downloaded at www.wago.com. There, you can
obtain important information including information on electrical isolation, system
power and supply specifications.
1.2 Copyright
This Manual, including all figures and illustrations, is copyright-protected. Any
further use of this Manual by third parties that violate pertinent copyright
provisions is prohibited. Reproduction, translation, electronic and phototechnical
filing/archiving (e.g., photocopying) as well as any amendments require the
written consent of WAGO Kontakttechnik GmbH & Co. KG, Minden, Germany.
Non-observance will involve the right to assert damage claims.

WAGO-I/O-SYSTEM 750 XTR Notes about this Documentation 7
750-486/040-000 4AI 0/4-20mA NE43 Ex i XTR
Manual
Version 1.0.0
1.3 Symbols
Personal Injury!
Indicates a high-risk, imminently hazardous situation which, if not avoided, will
result in death or serious injury.
Personal Injury Caused by Electric Current!
Indicates a high-risk, imminently hazardous situation which, if not avoided, will
result in death or serious injury.
Personal Injury!
Indicates a moderate-risk, potentially hazardous situation which, if not avoided,
could result in death or serious injury.
Personal Injury!
Indicates a low-risk, potentially hazardous situation which, if not avoided, may
result in minor or moderate injury.
Damage to Property!
Indicates a potentially hazardous situation which, if not avoided, may result in
damage to property.
Damage to Property Caused by Electrostatic Discharge (ESD)!
Indicates a potentially hazardous situation which, if not avoided, may result in
damage to property.
Important Note!
Indicates a potential malfunction which, if not avoided, however, will not result in
damage to property.

8 Notes about this Documentation WAGO-I/O-SYSTEM 750 XTR
750-486/040-000 4AI 0/4-20mA NE43 Ex i XTR
Manual
Version 1.0.0
Additional Information:
Refers to additional information which is not an integral part of this
documentation (e.g., the Internet).

WAGO-I/O-SYSTEM 750 XTR Notes about this Documentation 9
750-486/040-000 4AI 0/4-20mA NE43 Ex i XTR
Manual
Version 1.0.0
1.4 Number Notation
Table 1: Number Notation
Number Code
Example
Note
Decimal
100
Normal notation
Hexadecimal
0x64
C notation
Binary
'100'
'0110.0100'
In quotation marks, nibble separated
with dots (.)
1.5 Font Conventions
Table 2: Font Conventions
Font Type
Indicates
italic
Names of paths and data files are marked in italic-type.
e.g.: C:\Program Files\WAGO Software
Menu
Menu items are marked in bold letters.
e.g.: Save
>
A greater-than sign between two names means the selection of a
menu item from a menu.
e.g.: File > New
Input
Designation of input or optional fields are marked in bold letters,
e.g.:
Start of measurement range
“Value”
Input or selective values are marked in inverted commas.
e.g.: Enter the value “4 mA” under
Start of measurement range
.
[Button]
Pushbuttons in dialog boxes are marked with bold letters in square
brackets.
e.g.: [Input]
[Key]
Keys are marked with bold letters in square brackets.
e.g.: [F5]

10 Important Notes WAGO-I/O-SYSTEM 750 XTR
750-486/040-000 4AI 0/4-20mA NE43 Ex i XTR
Manual
Version 1.0.0
2 Important Notes
This section includes an overall summary of the most important safety
requirements and notes that are mentioned in each individual section. To protect
your health and prevent damage to devices as well, it is imperative to read and
carefully follow the safety guidelines.
2.1 Legal Bases
2.1.1 Subject to Changes
WAGO Kontakttechnik GmbH & Co. KG reserves the right to provide for any
alterations or modifications. WAGO Kontakttechnik GmbH & Co. KG owns all
rights arising from the granting of patents or from the legal protection of utility
patents. Third-party products are always mentioned without any reference to
patent rights. Thus, the existence of such rights cannot be excluded.
2.1.2 Personnel Qualifications
All sequences implemented on WAGO-I/O-SYSTEM 750 devices may only be
carried out by electrical specialists with sufficient knowledge in automation. The
specialists must be familiar with the current norms and guidelines for the devices
and automated environments.
All changes to the coupler or controller should always be carried out by qualified
personnel with sufficient skills in PLC programming.
2.1.3 Use of the WAGO-I/O-SYSTEM 750 in Compliance with
Underlying Provisions
Fieldbus couplers, fieldbus controllers and I/O modules found in the modular
WAGO-I/O-SYSTEM 750 receive digital and analog signals from sensors and
transmit them to actuators or higher-level control systems. Using programmable
controllers, the signals can also be (pre-) processed.
The devices have been developed for use in an environment that meets the IP20
protection class criteria. Protection against finger injury and solid impurities up to
12.5 mm diameter is assured; protection against water damage is not ensured.
Unless otherwise specified, operation of the devices in wet and dusty
environments is prohibited.
Operating the WAGO-I/O-SYSTEM 750 devices in home applications without
further measures is only permitted if they meet the emission limits (emissions of
interference) according to EN 61000-6-3. You will find the relevant information in
the section “Device Description” > “Standards and Guidelines” in the manual for
the used fieldbus coupler/controller.
Appropriate housing (per 2014/34/EU) is required when operating the
WAGO-I/O-SYSTEM 750 in hazardous environments. Please note that a
