WaterLogic WL380 Operating instructions

WL380Manual Page39‐Revision:2‐5‐2018
POWERTROUBLESHOOTINGINDEX
1. Red Power Switch and Green Heater & Compressor Switch won't light
2. Red Power Switch and Green Heater & Compressor Switch is lit but the Status LED lights
on the Front are not lit
3. Compressor Runs but does Not Chill
4. Compressor is Not Running


1. RedPowerSwitchandGreenHeater&Compressor
Switchwon’tlight


PossibleReason Solution
CircuitBreaker ChecktheCircuitBreaker
FuseisBlown ReplaceFuse.Use15‐ampWaterlogicFuse
Defective/LoosePowerCord

CheckthatPowerCordisproperlypluggedin.Ifitisproperly
pluggedin,useadifferentpowercordtoverify.Useonly
Waterlogicsuppliedpowercord.

FailedSocket‐PowerLine
NoiseFilter,Electro‐Magnetic
Interferencefilter(EMI)
ReplaceSocket‐PowerLineNoiseFilter,Electro‐Magnetic
Interferencefilter(EMI)
DefectiveRedPowerSwitch ReplaceRedPowerSwitch
DefectiveGreenHeater&
CompressorSwitch ReplaceGreenHeater&CompressorSwitch



WL380Manual Page40‐Revision:2‐5‐2018

2. RedPowerSwitchandGreenHeater&CompressorSwitchislitbuttheStatus
LEDlightsonthefrontarenotlit


PossibleReason Solution
BadTransformer ReplaceTransformer
BlackPowerConnectortothe
PCBisnotproperlyconnected Properlyconnect.
BadFrontPCB ReplaceFrontPCB
DefectiveGreenHeater&
CompressorSwitch ReplaceGreenHeater&CompressorSwitch

3. CompressorRunsbutDoesNotChill


PossibleReason Solution
Condenserisdirty Cleanthecondensingcoilofanyobstructionsordust.
Reductionofairflowintounit.

Makesureunitisnotunderminimumventilationrequirements
(2to4inchesofclearancearoundtheunitforheatexchange).

Compressorisrunningvery
hot(over150oF)

Loworlostrefrigerant.

Refrigerantrechargeasnecessary.SeeSpecificationsfor
refrigerantchargedata.




WL380Manual Page41‐Revision:2‐5‐2018

4. CompressorisNotRunning


PossibleReason Solution
RedPowerandGreenHeater
&CompressorSwitchinthe
O=OFFposition


TurnGreenHeater&CompressorSwitchon.
I=ON


ColdThermostatisFaulty


IsolatePowerandremoveredleadsfromcoldthermostattocheck
continuity.Thermostatshouldbeclosedifsensorisatroom
temperature.Checkforcontinuity.Replacethermostat


CompressorStartingCircuit
FaultyorOverHeated
(tripped)

TurnGreenHeater&CompressorSwitchoff.O=OFF.

Removethecompressorcaponsideofthecompressor;

Disconnecttheblackandredterminalconnectors;

Inspectthestarterandoverloadrelayforanydefects.

CheckwithMulti‐Metertoensure120VACisbeingsuppliedtothe
compressorstarter.TurnONRedPowerandGreenHeater&
CompressorSwitchwithmeterhookedtoredandblack
compressorleads.

Replacecomponents(s)asneeded.




