WB Manufacturing Boat Conference Table User manual

1
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Conference Tables
With 5 Dierent Bases
Assembly Instructions
Before you begin, please make sure all parts and proper quantities are included. (See Part Identier Key) Any parts damaged during shipment must be reported
within 24 hours of receipt. To report information regarding damages or if you have any questions, please call 800.242.2303.
Step 1:
• Place top face down on a protected at surface.
Step 2:
• Align base with threaded inserts.
• Using a 4mm Allen wrench or 4mm Hex bit, secure table
top with 10-24 x 1” joint connector bolts.
• Repeat this step for each base. (Number of bases are
determined by length of table.)
Step 4:
• With someone’s help, turn table upright.
Tools Required
• Screw gun
• 4mm Allen wrench OR
• 4mm Hex bit
Conference Table Base Options
Part # 1142, 1143 or 1144
Panel Base
Part # 3320, 3324 or 4430
H-Base
Part # 7034 or 036
Tubular TT-Base
Part # 7236
Arch TT-Base
Part # 5088 or 5092
DuraCast T-Base
Boat Conference table shown
with Arch TT-Bases.
V062419 subject to change.

4
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Panel Bases (Perforated)
DuraCast T-Bases
Table D” Base # Base Part #
Bolt Type
(Used to attach base to top) Bolt Part # Qty.
48 & 57 7036 0409891 ¼-20x15mm joint connector bolts 04009023
16 for 2 bases
24 for 3 bases
Tubular TT-Bases
Table D” Base # Base Part #
Bolt Type
(Used to attach base to top) Bolt Part # Qty.
48 & 57 7236 04066858 ¼-20x15mm joint connector bolts 04009023
16 for 2 bases
24 for 3 bases
Arch TT-Bases
H-Bases
Boat Conference Tables
Part Identifier Key
Table D” Base # Leg Part #
Perforated
Panel Part #
Bolt Type
(Used to attach base to top) Bolt Part # Qty.
36 1142 04067706 04067707 ¼-20x15mm joint connector bolts 04009023
32 for 2 bases
48 for 3 bases
48 1143 04067708 04067709 ¼-20x15mm joint connector bolts 04009023
32 for 2 bases
48 for 3 bases
57 1143 04067710 04067711 ¼-20x15mm joint connector bolts 04009023
32 for 2 bases
48 for 3 bases
Table D” Base # Base Part #
Bolt Type
(Used to attach base to top) Bolt Part # Qty.
36 5088 04009354 ¼-20x15mm joint connector bolts 04009023
16 for 2 bases
24 for 3 bases
48 5092 04067603 ¼-20x15mm joint connector bolts 04009023
24 for 2 bases
36 for 3 bases
Table D” Base # Base Part #
Bolt Type
(Used to attach base to top) Bolt Part # Qty.
36 3320 04009472 ¼-20x15mm joint connector bolts 04009023
20 for 2 bases
30 for 3 bases
48 3324 04067713 ¼-20x15mm joint connector bolts 04009023
32 for 2 bases
48 for 3 bases
57 4430 04067714 ¼-20x15mm joint connector bolts 04009023
32 for 2 bases
48 for 3 bases
