WB Manufacturing FLIP TOP RECTANGLE TABLE User manual

1
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.





800-242-2303
wibenchmfg.com
FLIP TOP RECTANGLE TABLE
PARTS
PARTS x QTY
# DESCRIPTION x QTY
1 Leg with Casters x 1
2 Leg with Casters x 1
3 Laminate Top x 1
4 Flip Mechanism Rod x 1
5 Stretcher Bar x 1
HARDWARE x QTY
NOTE: Before you begin, please make sure
all parts and proper quantities are included.
Any parts damaged during shipment must be
reported within 24 hours of receipt. To report
information regarding damages or if you have
any questions, please call 800.242.2303.
Item #0600012 V021423 Version subject to change
TOOLS NEEDED
Drill 4mm Allen
Wrench
4mm Hex
Bit
Assistance
Hardware B | ⁄” - 20x19mm JCB x 8
04069027
NOTE: These instructions work for all Flip Top Rectangle Tables. Product images are for illustrative
purposes only and may differ from actual product.
Hardware A | M8x25 x 4
04069004
Hardware D | Leg Cover x 1
04069006 (Set)
Hardware E | Leg Cover x 1
04069006 (Set)
Hardware F | Stretcher Support x 1
(Only required for tables 60” or longer)
04069008
Hardware G | Leg Screw Cap x 1
04069009
6mm Allen
Wrench
Hardware C | 6mm Allen Wrench x 1
04069005
Hardware H | 4mm Allen Wrench x 1
0447162
The assembly of this table requires the
assistance of another person.
NOTE: Hardware packs are included in packaging. You
may receive more hardware than needed. Discard any
extra hardware after assembly.
Casters (Attached) x 4
04069007

2
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
ASSEMBLY
1. Place the top  face down on a protected flat
surface so threaded inserts are facing up.
2. Place the legs (parts  & ) on top of the threaded
inserts in the top.
3. Align the flip mechanism rod  with the flip
mechanism pin on the legs.
4. Insert hardware F into the stretcher bar  and
twist clockwise until secure.
5. Using hardware A, secure stretcher bar  to the
legs with the included 6mm Allen wrench (C).
5. Place hardware G over hardware A, into the legs.
6. Using a 4mm Allen wrench (H) or 4mm hex
bit, fasten legs to top with ⁄”-20x19mm joint
connector bolts.
7. Snap hardware D & E over legs as shown in image.
7. With assistance, turn table upright. Push flipping
handle to release the flip function.
