LOBO TABLE WITH
HARDWOOD TOP
PARTS



PARTS x QTY
# DESCRIPTION x QTY
1 Hardwood Top Half x 1
2 Hardwood Top Half x 1
3 LOBO Frame x 1
4 LOBO Leg x 4
5 Gusset x 4
6 Heavy-Duty Caster x 4
HARDWARE x QTY
Tite Joint Fastener x Varies
0406902
#10 x ⁄” Square Pan
Screw x 26
0408231
⁄” Lock Washer x 4
040379
NOTE: These instructions are based on
model #LOB9108-ADJ-G-HDCA. These
instructions work for all LOBO Table with
Hardwood Top models. Product images are
for illustrative purposes only and may differ
from actual product.
V051022 Version subject to change
TOOLS NEEDED
Drill ⁄” Wrench
⁄” Wrench
#S2 Square
Bit
Assistance

LOB -ADJ LOB -ABPLOB -ALR LOB -FX
Model #
Smooth Silver
Sku #
Black
Sku# Description
LOB -ADJ 0409195-G4 0409195 LOBO 1.5" (40mm) Square Adj. Leg
LOB -ALR 0409193-G4 0409193 LOBO 2" (50mm) Round Adj. Leg
LOB -ABP N/A 0409196 LOBO 2" (50mm) Big Paw Sq. Adj. Leg
LOB -FX 0409194-G4 0409194 LOBO 1.5" (40mm) Square Fixed Leg
LOBO Adjustable & Fixed Legs
⁄” Hex Nut x 4
040379
Hardware Pack for -ALR &
-ABP Legs - 04066968
⁄” Star Washer x 4
04067460
M6 1x18 Screw x 4
04068064
Hardware Pack for -ADJ
Legs - 04002020
⁄” Star Washer x 4
04067460
M6 1x14 Screw x 4
0401259
#10-16 x ⁄” Hex Head
Self-Drilling Screw x 32
04009742
NOTE: Before you begin, please make sure
all parts and proper quantities are included.
Any parts damaged during shipment must be
reported within 24 hours of receipt. To report
information regarding damages or if you have
any questions, please call 800-242-2303.

2wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
CAUTION! Some parts may have sharp
edges. Care must be taken when handling
various pieces to avoid injury. For your safety,
wear a pair of work gloves when assembling.
NOTE: Hardware packs are included in
packaging. You may receive more hardware
than needed. Discard any extra hardware after
assembly.
The assembly of this table requires the
assistance of another person.
ASSEMBLY
1a. If assembling a hardwood top that has a depth of
36” or less, it will be in one piece. Place the top face
down on a protected flat surface. Proceed to Step 3.
1b. If assembling a hardwood top that has a depth
greater than 36”, top will be in 2 pieces (.5”
undersized on length). Place both top halves face
down on a protected flat surface. Align together the
dog bone holes on both tops.
2. Adjust tite joint fastener to the size of the field
joint opening and then place the fastener into each
opening. Using a ⁄” wrench, tighten each fastener
so that both tops are securely clamped together.
3. Place LOBO frame tabs down on top of the top and
align tabs with pre-drilled pilot holes.
4. Using a #S2 square bit, secure the frame to top with
#10 x ⁄” square pan screws, one screw per tab.
5. Starting at one corner, place the ⁄” bolt that is
welded to leg through corner support brace of frame.
Place the ⁄” lock washer and ⁄” hex nut onto the
leg bolt and tighten with a ⁄” wrench.
Repeat for remaining legs.

3
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
ASSEMBLY
6. Place gusset in corner where leg and frame meet.
Use a rubber mallet to tap the #10 self-drilling screws
into place.
7. Use a screw gun along with a ⁄” hex bit to finish
fastening the gussets to the leg and frame with the
#10 self-drilling screws.
Repeat for remaining gussets.
8. Adjust legs to desired height.
9. Remove nylon glide from leg by rotating counter
clockwise until glide is free.
10. Place stem of optional footing into the hole on the
leg. Rotate clockwise until fully inserted into leg.
11. Tighten with a wrench.
Repeat for each caster or glide.
NOTE: Casters are not to be used as a leveling
device. Loctite on casters will cause some
resistance while tightening, please make sure
that casters are tightened all the way to prevent
possible damage to the stem of the caster.
