WB Manufacturing UNE-T User manual

wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product. 1
UNE-T Desk/Table/Workstations
Assembly Instructions
Before you begin, please make sure all parts and proper quantities are included. (See Part Identifier Key) Any parts damaged during shipment must be reported
within 24 hours of receipt. To report information regarding damages or if you have any questions, please call 800.242.2303.
V101221 Version subject to change
Step 1:
• Place workfurface face down on protected flat surface so that the
threaded inserts are facing up.
Step 2:
• Align mouting plates (attached to legs) with threaded inserts in
the worksurface.
• Using a 4mm Allen wrench or 4mm hex bit, secure worksurface
with ⁄”-20x15mm joint connector bolts. DO NOT FULLY
TIGHTEN until Step 6.
Tools Required
• Screw gun
• 4mm Allen wrench OR
• 4mm hex bit
• Phillips head screwdriver
Step 2
Fig. A
Fig. B
Step 3
Step 4
Step 4:
• If assembling a desk with a foot rest bar, repeat Step 3, but in
the location shown in the image to the right.
• DO NOT FULLY TIGHTEN until Step 6.
Step 3:
• Remove the #12 star lock washers and
M6-1x10mm screws located in the legs.
(Location shown in Fig. A.)
• Align holes in connector bar with pilot
holes in legs. Attach using #12 star lock
washers and M6-1x10mm screws. The bar
should rest inside the legs. DO NOT FULLY
TIGHTEN until Step 6. (Fig A)
• If you have an adjustable connector bar,
use #12 star lock washers and M6-1x14mm
screws to fasten the two connector bars
together. DO NOT FULLY TIGHTEN until
Step 6. (Fig B) Star washers
and screws
located HERE
Star washers
and screws
located HERE

wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product. 2
UNE-T Desk/Table/Workstations
Assembly Instructions
with Dual Wheel Locking Casters
or 2.5” Grand Hank Glides
Tools Required
• 14mm open-ended wrench
Step 1:
• Remove nylon glide from leg by rotating it
counterclockwise until glide is free.
Step 2:
• Place stem of optional footing into the hole on the leg.
Rotate clockwise until fully inserted into leg.
Step 3:
• Tighten with a 14mm open-ended wrench (for dual
wheel caster only).
Step 4:
• Repeat for each caster/glide.
Step 5:
• If assembling a table/workstation with metal wire
management, align metal wire management with pilot
holes in the worksurface.
• Attach wire management to worksurface using
#8x⁄” screws. Fasten down tightly.
Step 6:
• Fully tighten leg, connector bar & foot rest (if foot rest
was ordered) with fasteners. Adjust leg height and
glides as needed.
• With someone’s help, turn table upright.
Step 7:
• If assembling a table/workstation with grommet(s),
insert grommet(s) into the pre-determined location in
the worksurface.
Step 5
Wire
management

wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product. 3
Step 1:
• Place worksurface face down on protected flat
surface.
Step 2:
• Align tab of the backpack hook on top of the metal leg
plate.
Step 3:
• Using a 4mm Allen wrench or 4mm hex bit, secure
backpack hook to the top leg plate with ⁄”-20x15mm
joint connector bolt.
Tools Required
• Screw gun
• 4mm Allen wrench OR
• 4mm hex bit
with Backpack Hook
UNE-T Desk/Table/Workstations
Assembly Instructions
Part Identifier Key
Part # Description Qty.
NSL-33056 1.38” nylon glide 4
NSL-33056S
(-SG) 1.25” steel glide 4
04067920
(-FG) 1.5” soft touch glide 4
040164
(-HG) 2.5” Grad Hank glide 4
04067540
(-CA) 2” Dual wheel soft tread locking caster 4
04066852 (black)
04066852-G4 (smooth silver)
04088861
Backpack hook
⁄”-20x20mm joint connector bolt
(Used to attach backpack hook to top)
1
1 per backpack hook
04009023 ⁄”-20x15mm joint connector bolt
(Used to attach leg to top) 6 per leg
Adjustable Legs
Code
Smooth Silver
SKU
Black
SKU Description Weight Height"
UNET -ADJ 04067351-G4 04067351 UNET 1.5" Square Adj. Leg 10 26 - 38
UNET -EJA 04067355-G4 04067355 UNET 1.5" Square Jr. Adj. Leg 8 19 - 31
-F 04066605-G4-AE Black Lotz AE™ Footrest w/Grand Hank Glides 5 N/A
UNET -ADJ UNET -EJA

wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product. 4
UNE-T Desk/Table/Workstations
Assembly Instructions
Part # Description Qty.
04009770 (27”L top size) fixed bar
04009771 (36”L top size) fixed bar
04009772-G4 (48”L top size) fixed bar
04009773 (54”L top size) fixed bar
04077747-G4 (27”, 30” & 36”L top sizes)
adj. bar
04066970 (27”-44”L top size) adj. bar
04066939 (38”-66”L top size) adj. bar
UNE-T connector bar (adj. or non-adjustable) 1
04067356 M6-1x10mm button head socket screw
(Used to attach non-adj. connector bars to legs)
4
0401259 M6-1x14mm screw
(Used to connect adjustable connector bar)
2
0404281 #12 star lock washer
(Used to attach non-adj. connector bars to legs)
(Used to connect adjustable connector bar)
4
2
04066605 UNE-T foot rest 1
04067356 M6-1x10mm button head socket screw 4
0404281 #12 star lock washer
(Used to attach foot rest to legs) 4
04009316 (36”L)
04009242 (48”L)
04009241 (60”L)
0400350 (72”L)
Metal wire management
(Used only on UNE-T workstations and tables) 1
0404248 #8x⁄” screws
(Used to attach metal wire management to top) 10
0406659 2⁄”D black grommet w/ cover
(Used only on UNE-T workstations)
1 - 48”L
2 - 60” & 72”L
Part Identifier Key
