WB Manufacturing Two-Station Drafting Table User manual

wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
1
Two-Station Drafting Table
Assembly Instructions
w/ Drawers in Middle
Step 1:
• Lay the two top assemblies on a protected flat
surface with apron side facing up.
Step 2:
• Insert hanger bolt on one leg through the corner
bracket and insert lock washer and hex nut.
• Screw on nut using a ⁄” wrench or ⁄” socket and
torque wrench.
• Do NOT tighten all the way.
• Repeat for other 3 legs.
• The two legs with a chamfer must go on the front of
the table with chamfered edges facing out.
Step 3:
• Screw leg levelers into t-nut on bottom of legs.
Before you begin, please make sure all parts and proper quantities are included. (See Part Identifier Key) Any parts damaged during shipment must be reported
within 24 hours of receipt. To report information regarding damages or if you have any questions, please call 800.242.2303.
Tools Required
• ⁄” wrench
• ⁄” socket and
torque wrench
(optional)
• 4mm wrench
V031521 Version subject to change
Step: 1
Front leg Back leg
Front apron
Leg with a
chamfer needs to
be facing out (Both
top assemblies)
Hinge
Step: 2
Levelers
Step: 3
Apron side
facing up

wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
2
Two-Station Drafting Table
Assembly Instructions
w/ Drawers in Middle
Step 4:
• Attach braces between each set of legs by inserting
confirmats into the legs. Tighten using a 4mm
wrench.
• Make sure braces are straight and all comfirmats are
secure.
Step 5:
• Attach stretchers to the braces with confirmats,
tighten with 4mm wrench.
• Go back to Step 2 and tighten the hanger bolt for
each leg using a ⁄” wrench or ⁄” socket and torque
wrench, to a minimum of 12ft lbs but not to exceed
17ft lbs.
Step 6:
• Take out drawers to attach stretcher from inside the
cabinet.
• With someones help, flip one apron assembly over
onto legs.
• Align holes up on stretcher to holes on left side of
cabinet.
• Attach the stretcher to the cabinet with confirmats.
Tighten with a 4mm wrench.
• Repeat process for other apron assembly.
Left side
Stretcher
Outside of cabinet Inside of cabinet
Confirmats
Step: 6
Leg braces
Step: 4
Stretchers
Step: 5

wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
3
Two-Station Drafting Table
Assembly Instructions
w/ Drawers in Middle
Step 7:
• Position one apron assembly so inner holes of
brackets on internal apron are lined up with the two
holes on left side of cabinet.
• Front apron will be flush with front of cabinet and
back apron wil be flush with the back of the cabinet.
• Attach apron assembly to left side of cabinet with
hardware provided.
• Adjust leg levelers to level apron assembly with
cabinet.
• Repeat processs for other apron assembly.
Step 8:
• Line up pencil ledge on side of adjustable tops in
desired location.
• Pre-drill holes in top to prevent splitting.
• Screw pencil ledges to tops using hardware provided.
• Set your table in place.
• Put drawers back in.
Attach apron assembly to cabinet
through here on both brackets
Bracket - typical
Internal apron
Front apron
Back apron
Pencil ledge
Pencil ledge

wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
4
Two-Station Drafting Table
Assembly Instructions
w/ Drawers in Middle
Items Included Part # Part Description QTY
Top and apron assembly N/A Top assembly (factory assembled) 2
Cabinet N/A Cabinet - size varies 1
Legs Varies Leg, Mpl - Height varies 4
Leg hardware 520001-4 Leg hardware kit, 4 legs 1
Leg brace N/A Leg brace - size varies 2
Stretcher N/A Stretcher - size varies 2
Confirmats - legs 227578 Screw, 7mmx90mm, conn, Allen head, black 8
Confirmats - Stretcher 228564 Screw, 7mmx90mm, conn, Allen head,black 8
Bolt - internal apron 231922 Bolt, ⁄-16x1.625 hex head 4
Washer - internal apron 100451 Washer, ⁄” flat zinc plated 4
Pencil ledge 14-0027 Pencil ledge 2
Screws - pencil ledge 236263 Screws, #6x⁄” truss head, quad black 12
Part Identifier Key
