Weidmüller IE-SW-EL18-16TX-2GC Manual

1 2 3
Hardware Installation Guide
Unmanaged Fast/Gigabit Ethernet Switches
IE-SW-EL18-16TX-2GC (Part No. 2682200000)
1. Introduction
Ethernet Switches from Weidmüller are designed with a very compact housing size and
are fitted with a robust housing. To ensure reliable, error-free operation, and to prevent
damage or injury, please read the operating instructions, all safety information provided in
this document and any other safety information that were supplied with the product.
2. Safety notice
Switch off the electrical power before removing the power connection!
The device heats up during operation. Allow the unit to cool down or use
protection gloves when carrying out any work.
The device may only be connected to the supply voltage shown on the
product label. Higher voltage than specified will destroy the device.
The device must be supplied by a SELV source as defined in the Low
Voltage Directive 2014/35/EU and 2014/30/EU.
Installation, commissioning and maintenance may only be performed by
qualified electricians.
Observe the operating instructions.
Indoor use and pollution degree II, it must be wiped with a dry cloth for
clean up the device and label.
oUtilisation en intérieur et degré de pollution II, il faut l'essuyer avec un
chiffon sec pour nettoyer l'appareil et son étiquette.
Do not block air ventilation holes.
oNe bouchez pas les orifices de ventilation.
If the equipment is used in a manner not specified by the manufacturer,
the protection provided by the equipment may be impaired.
oSi l’appareil est utilise d’une maniere non specifiee par le fabricant, la
protection qu’il apporte peut se voir diminuee.
Shall be mounted in the Industrial Control Panel and ambient
temperature is not exceed 75 degrees C.
oDoit être monté dans le panneau de commande industriel et la
température ambiante ne doit pas dépasser 75 degrés C.
Intended use
The device is intended for the realization of communication networks within an industrial
environment, it is intended to be used in a restricted access location. The device may only
be used within the scope of the specified technical data. The device is intended to be
mounted to a well-grounded mounting surface, such as a metal panel. Any other use may
result in unintentional malfunction and damage. Observing the documentation is part of the
intended use.
Environmental conditions
This equipment is intended to be used in a restricted access location.
When planning the installation site make sure that the ambient temperature during
operation will not exceed the temperature given in the technical data.
Also make sure that the air flow will not be compromised by other devices.
Ensure that the mounted and wired device is not exposed to any mechanical stress.
FCC compliance
This device complies with part 15 of FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
3. Package Checklist
Your Ethernet Switch is shipped with the following items:
Ethernet Switch
Hardware Installation Guide (printed)
6-Pin Terminal connector
Protective caps for RJ45 ports and SFP ports
4. Panel Layouts
1.Terminal block for power input
PWR1/PWR2 and Power failure
relay (output)
2. Grounding screw / Frame ground
(Note: The shielding ground of the
LAN port is electrically connected to
the grounding screw)
3. Power input LEDs (PWR1 / PWR2)
4. LAN port Link/Activity LED
5.LAN port duplex mode (LED Amber
= full duplex, Off = half duplex,
Blinking = collisions)
6. 10/100Base-T(X) ports
7.SFP slot 1000Base-X (LED Green =
link up, Blinking = activity)
8.10/100/1000Base-T(X) ports (Upper
LED Green = link up, Blinking =
activity; lower LED Amber =
100Mbps, Off = 1G/10Mbps)
9.Article Number
10. DIN-rail Kit
5. Mounting Dimensions
(units = mm)
6. DIN-Rail Mounting
Slide the switch onto a DIN-rail and make sure that the switch’s Din-rail clip clicks into
the rail firmly.
STEP 1: Insert the top of the DIN-
Rail into the slot just below the stiff
metal spring.
STEP 2: The DIN-Rail attachment
unit will snap into place as shown
below.
To remove the DIN-rail from the
Ethernet Switch, simply reverse Steps 1 and 2.
7. Grounding Ethernet Switch
ATTENTION
- Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI).
- the ground connection from the ground screw to the grounding
surface prior to connecting devices.
- This product is intended to be mounted to a well-grounded
mounting surface, such as a metal panel.
- The shielding ground of the RJ45 ports are electrically connected
to the ground connection (screw).
8. Wiring Redundant Power Inputs and Power Fault
Relay
The switch supports redundant power supply inputs and provides a power fault relay
which can be used for alarming in case of interruption of Power 1 or Power 2 on the 6-pin
terminal block. Refer to illustration below for correct wiring.

4 5 6 V1.0 / 2020-10-29
Warning / Avertissement
Take into consideration the following guidelines before wiring the device
oTenez compte des directrices suivantes avant de câbler l’appareil.
Terminal block is mating with Plug and suitable for 12-24AWG. Torque
value 4.5 lb-in.
oLe bornier est compatible avec les connecteurs et convient pour 12-
24AWG. Valeur de couple 4,5 lb-in.
The temperature rating of the input connection cable should higher than
105°C.
oLa température de service nominale du câble d’entrée doit être
supérieure à 105 °C.
Supplied by SELV source evaluated by UL 61010-1 or 61010-2-201
power supply only.
oFourni par la source SELV évaluée uniquement par l'alimentation UL
61010-1 or 61010-2-201.
Note about behavior of power failure relay:
Relay contact is closed if the device is powered-off.
Relay contact is open if the device is powered by PWR1 and PWR2
Relay contact is closed if device is powered either by PWR1 or PWR2
9. Communication Connections
Switch IE-SW-EL18-16TX-2GC is equipped with following communication interfaces:
16x 10/100Base-T(X) ports
2x Ethernet-Combo-Ports, that can be used either as 10/100/1000Base-T ports or
alternatively as 1000Base-X ports with respective SFP Transceivers (mini-GBIC)
Please only use cables suitable for the respective type of communication and ensure that
signals are protected from possible interference.
9.1 10/100Base T(X) RJ45 Ports
The 10/100BaseT(X) ports located on Ethernet Switch’s front panel are used to connect
to Ethernet-enabled devices. Below we show pinouts for both MDI (NIC-type) ports and
MDI-X (HUB/Switch-type) ports. Auto MDI-X ensures that both wiring-schemes are
supported (Automatic crossover function).
10/100Base T(X) RJ45 Pinouts
MDI Port Pinouts MDI-X Port Pinouts 8-pin RJ45
Pin Signal Pin Signal
1 Tx+ 1 Rx+
2 Tx- 2 Rx-
3 Rx+ 3 Tx+
6 Rx- 6 Tx-
9.2 1000Base Combo-Ports
The switch is equipped with 1000Base combo ports that can be used either as 10/100/
1000Base-T ports with RJ45 connector or with optional SFP transceivers (mini GBIC) for
1000 Base-X (e.g. for connections with fiber optic technology over long distances). For
correct function, please note that only one function of a combo port may be used and
connected at a time. The RJ45 port can only be used if no SFP module is plugged. in.
9.2.1 1000BaseT Ethernet Port Connection
1000BaseT data is transmitted on differential TRD+/- signal pairs over copper wires.
Pin Signal
1 TRD(0)+
2 TRD(0)-
3 TRD(1)+
4 TRD(2)+
5 TRD(2)-
6 TRD(1)-
7 TRD(3)+
8 TRD(3)-
9.2.2 1000Base-X SFP (mini-GBIC) Fiber Port
The 1000Base-X type slots, require 1000Base-X SFP (mini-GBIC) fiber transceivers to
work properly. Weidmüller provides transceiver models for various distance requirements.
Please only use SFP modules and cables that are compatible with each other to establish
an optical connection.
LC-Port with separate Transmit and Receive Port:
Remember to connect the Tx (transmit) port of Device-1 to the Rx (receive) port of Device-
2I, and the Rx (receive) port of Device-1 to the Tx (transmit) port of Device-2.
LC-Port Pinouts LC-Port to LC-Port Cable Wiring
10. LED Indicators
The front panel of the Ethernet Switch contains several LED indicators. The function of
each LED is described in the table below.
LED Color Status Description
PWR1 Green On Power is supplied to power input PWR1.
Off Power is not supplied to power input PWR1.
PWR2 Green On Power is supplied to power input PWR2.
Off Power is not supplied to power input PWR2.
LNK/ACT
(Ports 1- 16) Green
On Port’s link is active.
Off Port’s link is inactive.
Blinking Transmitting data.
Full/Half
Duplex
(Ports 1- 16)
Amber
On Port is set to Full Duplex Mode.
Off Port is set to Half Duplex Mode.
Blinking Packet collisions detected.
LNK/ACT
(Combo Ports
G1/G2)
Green
On RJ45-Link of Combo-Port is active.
Off RJ45-Link of Combo-Port is inactive.
LNK/ACT
1000Base-X
(Combo Ports
G1/G2)
Green
On Fiber-Link of Combo-Port is active.
Off Fiber-Link of Combo-Port is inactive.
10/100/1000M
(Combo Ports
G1/G2)
Amber
On Port speed of RJ45-Port is 100 Mbps.
Off Port speed of RJ45-Port is either 10 or 1000
Mbps (1000 Mbps supports only Full Duplex).
11. Specifications
Technology
Standards
IEEE 802.3 for 10Base-T
IEEE 802.3u for 100Base-TX
IEEE 802.3z for 1000Base-X
IEEE 802.3ab for 1000Base-T
IEEE 802.3x for Flow Control
Processing Type Store and Forward
MAC Table size 8K
Packet buffer size 1 Mbit
Backplane bandwidth 7.2 Gbps
Interfaces
RJ45 Ports 10/100BaseT(X) auto negotiation speed, F/H duplex mode
and auto MDI/MDI-X connection
SFP / RJ45 1000Base
Combo-Port
10/100/1000Base-T auto negotiation speed, F/H duplex
mode and auto MDI/MDI-X connection or 1000Base-X
LED Indicators
PWR1, PWR2 (Power)
SFP/RJ45 Combo-Port Link/Activity
RJ45: Port Link/Activity, Port Speed
Relay Contact Max. 1A @ 24 VDC
Power
Input Voltage 24 V DC (12 - 48 V DC), 2 redundant inputs
Input Current @24 VDC 0.35 A
Connection One removable 6-pin terminal block, Wiring cable 12-24AWG
Overload Current
Protection Present
Reverse Polarity
Protection Present
Physical Characteristics
Housing IP30 protection, metal
Dimension (W x H x D) 96.4 x 154 x 108.5 mm (3.8 x 6.06 x 4.27 in)
Weight 1235 g
Installation DIN-rail
Environmental conditions
Operating Temperature -40 to 75°C (-40 to 167°F)
Storage Temperature -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity 5 to 95% (non-condensing)
Altitude up to 2000 m
Regulatory Approvals
Safety UL 61010-1; UL 61010-2-201
EMC
EN 55032, EN 55024, FCC Part 15 Subpart B Class A
IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV,
IEC 61000-4-3 RS: 80 MHz to 1 Ghz: 3 V/m,
IEC 61000-4-4 EFT: Power: 0.5 kV; Signal: 0.5 kV,
IEC 61000-4-5 Surge: Power: 0.5 kV; Signal: 1 kV,
IEC 61000-4-6 CS: 3 Vrms
Shock IEC 60068-2-27
Free Fall IEC 60068-2-31
Vibration IEC 60068-2-6
MTBF
Time 748.087 hrs
Database Telcordia SR332
Warranty
Time Period 5 years
Contact Information
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 26, 32758 Detmold / Germany
Phone [phone], Fax [phone]
E-Mail [e-mail], Internet www.weidmueller.com
