Weidmüller Value Line IE-SW-VL05M Series Manual

Managed Fast Ethernet Switches
Value Line
IE-SW-VL05M Series (from product Rev. 2.0.0)
IE-SW-VL08MT-8TX/6TX (from product Rev. 2.0.0)
IE-SW-VL08MT-5TX (from product Rev. 1.5.0)
Hardware Installation Guide
Seventh Edition, February 2019
1243340000/06/02.19
Important note:
This document, the detailed user manual, additional product
information, configuration tool and latest firmware can be
downloaded using following link:
http://www.weidmueller.com
► Select Product Catalogue
 Select „Active Industrial Ethernet“
 Select „ValueLine managed switches“
 Select Product model
 Click and expand section „Downloads“
 Download needed software and documentation
Copyright Notice
Copyright  2019 Weidmüller Interface GmbH & Co. KG
All rights reserved.
Reproduction without permission is prohibited.

2
Overview
The IE-SW-VL05/08M series are managed Fast Ethernet switches with
5-port or 8-ports in various copper and fiber variants. In addition, the
built-in smart alarm function helps system maintainers monitor the
health of your Ethernet network.
Package Checklist
Your Ethernet switch is shipped with the following items. If any of these
items is missing or damaged, please contact your Weidmüller customer
service for assistance.
 1 Ethernet Switch of IE-SW-VL05/08M series
 Hardware Installation Guide (printed)
 RJ45 to DB9 console port cable
 Protective caps for unused ports
Regarding further documentation like the manual please download it
from the Weidmüller Internet server as described on page 1.
Brief Information for quick access to the
Web interface
The Web interface of the managed Switch can be accessed
via IP address 192.168.1.110 and subnet mask
255.255.255.0 (Factory default value).
Connect the PC to any port of the managed Switch and set
the PC’s IP address to a free one of range 192.168.1.0 /
255.255.255.0
Start a web browser and enter the IP address of the
connected Switch into the browser’s address line.
http://192.168.1.110
After the appearance of the login prompt, please enter
following login data (factory settings):
User name:
admin
Password:
Detmold
Note: The Web interface uses Java Runtime applets for
displaying some Switch parameters. For this reason, your
PC must have installed the Java Runtime Engine to be able
to configure the Switch without any limitations.
For general settings of the Switch parameters please
refer to the manual.

3
Panel Layouts of
IE-SW-VL08MT-8TX and IE-SW-VL05M(T)-5TX
Device description:
1. Grounding screw
2. Terminal block for power input
PWR1/PWR2 and relay output
3. Heat dissipation orifices
4. Console port
5. DIP switches
6. Power input PWR1 LED
7. Power input PWR2 LED
8. Fault LED
9. MSTR/HEAD: LED indicator
10. CPLR/TAIL: LED indicator
11. TP port's 100 Mbps LED
12. TP port's 10 Mbps LED
13. Article Number
14. 10/100BaseT(X) ports
15. Screw hole for wall mounting kit
16. DIN-Rail kit

4
Panel Layouts of
IE-SW-VL08MT-6TX-2SCS and IE-SW-VL05M(T)-3TX-2SC
Note:
The appearance of the IE-SW-VL08MT-6TX-
2SC is identical to that of the IE-SW-
VL08MT-6TX-2SCS.
Device description:
Grounding screw
2. Terminal block for power input
PWR1/PWR2 and relay output
3. Heat dissipation orifices
4. Console port
5. DIP switches
6. Power input PWR1 LED
7. Power input PWR2 LED
8. Fault LED
9. MSTR/HEAD: LED indicator
10. CPLR/TAIL: LED indicator
11. TP port's 100 Mbps LED
12. TP port's 10 Mbps LED
13. Article number
14. 10/100BaseT(X) ports
15. 100BaseFX ports
16. FX port's 100 Mbps LEDs
17. Screw hole for wall mounting kit
18. DIN-Rail kit

5
Panel Layouts of
IE-SW-VL08MT-6TX-2ST and IE-SW-VL05M(T)-3TX-2ST
Device description:
Grounding screw
2. Terminal block for power input
PWR1/PWR2 and relay output
3. Heat dissipation orifices
4. Console port
5. DIP switches
6. Power input PWR1 LED
7. Power input PWR2 LED
8. Fault LED
9. MSTR/HEAD: LED indicator
10. CPLR/TAIL: LED indicator
11. TP port's 100 Mbps LED
12. TP port's 10 Mbps LED
13. Article number
14. 10/100BaseT(X) ports
15. 100BaseFX ports
16. FX port's 100 Mbps LEDs
17. Screw hole for wall mounting kit
18. DIN-Rail kit

6
Panel Layout of
IE-SW-VL08MT-5TX-3SC
IE-SW-VL08MT-5TX-3SC
Front Panel View
Note:
The appearance of the
IE-SW-VL08MT-5TX-1SC-2SCS
is identical to that of the
IE-SW-VL08MT-5TX-3SC
Device description:
1. Grounding screw
2. Terminal block for power input
PWR1/PWR2 and relay output
3. Console port
4. DIP switches
5. Heat dissipation orifices
6. Power input PWR1 LED
7. Power input PWR2 LED
8. Fault LED
9. MSTR/HEAD: LED indicator
10. CPLR/TAIL: LED indicator
11. 10/100BaseT(X) ports
12. TP port’s 100 Mbps LED
13. TP port’s 10 Mbps LED
14. 100BaseFX ports
15. 1 FX port’s 100Mbps LEDs
16. Article Number
17. Screw hole for wall mounting kit
18. DIN-Rail kit
Top Panel View
Rear Panel View

7
Mounting Dimensions
Units: mm (in)
DIN-Rail Mounting
The aluminum DIN-Rail attachment plate should already be fixed to the
back panel of the IE-SW-VL05/08M switch when you take it out of the
box. If you need to reattach the DIN-Rail attachment plate, make sure
the stiff metal spring is situated towards the top, as shown in the
following figures.
STEP 1:
Insert the top of the DIN-Rail into
the slot just below the stiff metal
spring.
STEP 2:
The DIN-Rail attachment unit will
snap into place as shown below.
To remove the device from DIN-Rail, simply reverse Steps 1 and 2.

8
Wall Mounting (optional)
For some applications, you will find it convenient to mount the Ethernet
switch on the wall, as shown in the following figures.
STEP 1: Remove the
aluminum DIN-Rail
attachment plate from the
switch rear panel, and then
attach the wall mount
plates as shown in the
diagram at the right.
STEP 2:
Mounting the switch on the wall requires 4 screws.
Use the switch, with wall mount plates attached, as a
guide to mark the correct locations of the 4 screws.
The heads of the screws should be less than 6.0 mm
in diameter, and the shafts should be less than 3.5
mm in diameter, as shown in the figure at the right.
NOTE Before tightening the screws into the wall, make sure the screw
head and shank size are suitable by inserting the screw into
one of the keyhole-shaped apertures of the wall mounting
plates. Do not screw the screws in completely—leave about 2
mm to allow room for sliding the wall mount panel between the
wall and the screws
STEP 3:
Once the screws are fixed on the wall, insert the four screw heads
through the large parts of the keyhole-shaped apertures, and then slide
the switch
downwards, as
indicated. Tighten
the four screws
for added stability

9
ATEX Information
1. Certificate number DEMKO 18 ATEX 2137X
2. Ambient range: -40°C ≤ Tamb ≤ 75°C
3. Certification string:
IE-SW-VL08MT-8TX: Ex nA nC IIC T4 Gc
IE-SW-VL08MT-6TX-2SC/2ST/2SCS: Ex nA nC op is IIC T4 Gc
4. Standards covered:
EN 60079-0:2012+A11:2013,
EN 60079-15:2010,
EN 60079-28:2015
5. The conditions of safe usage:
 Provisions shall be made to provide the transient protection to be
set at a level not exceeding 140% of the peak rated voltage.
 These devices shall be mounted in a suitable tool-accessible
ATEX-Certified enclosure rated to at least IP54 as defined in
EN 60529 and Pollution Degree 2 as defined in EN60664-1, and
used within their rated electrical and environmental ratings.
Wiring Requirements
WARNING
Safety First!
Be sure to disconnect the power cord before installing
and/or wiring your Ethernet Switch.
Calculate the maximum possible current in each power wire
and common wire. Observe all electrical codes dictating the
maximum current allowable for each wire size.
If the current goes above the maximum ratings, the wiring
could overheat, causing serious damage to your equipment.
Be sure to read and follow these important guidelines:
 Use separate paths to route wiring for power and devices. If power
wiring and device wiring paths must cross, make sure the wires are
perpendicular at the intersection point.
NOTE: Do not run signal or communications wiring and power wiring
through the same wire conduit. To avoid interference, wires with
different signal characteristics should be routed separately.
 Use the type of signal transmitted through a wire to determine which
wires should be kept separate. The rule of thumb is that wiring that
shares similar electrical characteristics can be bundled together.
 Keep input wiring and output wiring separate.
 It is strongly advised that you label wiring to all devices in the
system.

10
Grounding the Ethernet Switch
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI). Run the ground connection from
the ground screw to the grounding surface prior to connecting devices.
A 4 mm2 conductor must be used when connection to the external
grounding screw is utilized.
ATTENTION
This product is intended to be mounted to a well-grounded
mounting surface, such as a metal panel.
Wiring the Relay Contact
The Relay Contact consists of the two middle contacts of the terminal
block on the IE-SW-VL05/08M series top panel. Refer to the next
section for detailed instructions on how to connect the wires to the
terminal block connector, and how to attach the terminal block
connector to the terminal block receptor.
In this section, we explain the meaning of the two contacts used to
connect the Alarm Contact.
FAULT: The two middle contacts of the 6-
contact terminal block connector are used to
detect both power faults and port faults. The
two wires attached to the fault contacts form
an open circuit when:
A relay warning event is triggered.
OR
The IE-SW-VL05/08M is the Master of a
Turbo Ring, and the Turbo Ring is broken.
OR
There is a start-up failure.
If none of these three conditions is satisfied,
the fault circuit will remain closed.
Wiring the Redundant Power Inputs
The top two contacts and the bottom two contacts of the 6-contact
terminal block connector on the IE-SW-VL05/08M series top panel are
used for the two DC inputs. Top and front views of one of the terminal
block connectors are shown in the following figures:

11
STEP 1: Insert the negat
ive/positive DC wires
into the V-/V+ terminals, respectively.
STEP 2: To keep the DC wires from pulling
loose, use a small flat-blade screwdriver to
tighten the wire-clamp screws on the front of
the terminal block connector.
STEP 3: Insert the plastic terminal block
connector prongs into the terminal block
receptor, which is located on the Switch´s top
panel.
ATTENTION
Before connecting the Ethernet Switch to the DC power
inputs, make sure the DC pow
er source voltage is stable.
Communication Connections
IE-SW-VL05/08M models have 8, 6, 5 or 3 10/100BaseT(X) Ethernet
ports, and 0 (zero), 2, or 3 100BaseFX (SC/ST-type connector) fiber
ports.
10/100BaseT(X) Ethernet Port Connection
The 10/100BaseT(X) ports located on the Ethernet Switches front panel
are used to connect to Ethernet-enabled devices.
Next, we show pinouts for both MDI (NIC-type) ports and MDI-X
(HUB/Switch-type) ports, and also show cable wiring diagrams for
straight-through and cross-over Ethernet cables.
MDI Port Pinouts MDI-X Port Pinouts 8-pin RJ45
Pin
Signal
Pin
Signal
1
Tx+
1
Rx+
2
Tx
-
2
Rx
-
3
Rx+
3
Tx+
6
Rx
-
6
Tx
-
RJ45 (8-pin) to RJ45 (8-pin) Straight-Through Cable Wiring

12
RJ45 (8-pin) to RJ45 (8-pin) Cross-Over Cable Wiring
100BaseFX Ethernet Port Connection (Fiber)
Remember to connect the Tx (transmit) port of device 1 to the Rx
(receive) port of device 2, and the Rx (receive) port of device 1 to the Tx
(transmit) port of device 2. Fiber optic connections generally are using
the full-duplex transmission mode.
SC
-
Port Pinouts
SC
-
Port to SC
-
Port Cable Wiring
ST
-
Port Pinouts
ST
-
Port to ST
-
Port Cable Wiring
ATTENTION
This is a Class 1 Laser/LED product. To avoid causing
serious damage to your eyes, do not stare directly into the
Laser Beam.
Redundant Power Inputs
Both power inputs can be connected simultaneously to live DC power
sources. If one power source fails, the other live source acts as a
backup, and automatically supplies the Ethernet Switch with power.

13
Relay Contact
The Ethernet switch has one Relay Contact located on the top panel.
For detailed instructions on how to connect the Relay Contact power
wires to the two middle contacts of the 6-contact terminal block
connector, see the Wiring the Relay Contact section. A typical
scenario would be to connect the fault circuit to a warning light located
in the control room. The light can be set up to switch on when a fault is
detected.
The Relay Contact has two terminals that form a fault circuit for
connecting to an alarm system. The two wires attached to the fault
contacts form an open circuit when (1) a relay warning event is
triggered, (2) the switch is the Master of this Turbo Ring, and the Turbo
Ring is broken, or (3) start-up failure. If none of these three conditions
occur, the fault circuit will be closed.
Turbo Ring DIP Switch Settings
IE-SW-VL05/08M models are managed Ethernet switches that offer
redundancy. The proprietary Turbo Ring protocol provides better
network reliability and faster recovery time. Turbo Ring’s recovery time
is less than 300 ms (Turbo Ring) or 20 ms (Turbo Ring V2) -
compared to a 3- to 5-minute recovery time for commercial switches -
decreasing the possible loss caused by network failures in an industrial
setting.
There are 4 Hardware DIP Switches for Turbo Ring on the top panel of
IE-SW-VL05/08M series that can help setup the Turbo Ring easily
within seconds. If you do not want to use a hardware DIP switch to
setup the Turbo Ring, you can use a web browser, telnet, or console to
disable this function.
NOTE Please refer to the Turbo Ring DIP Switch section and
Using Communication Redundancy section in User’s
Manual for more detailed information about the settings and
usage of Turbo Ring and Turbo Ring V2.
IE
-
SW
-
VL05/08M Series DIP Switches
The default setting for each DIP Switch is OFF.
The following table explains the effect of setting
the DIP Switch to the ON position.

14
“
Turbo Ring
”
DIP Switch Settings
DIP 1
DIP 2
DIP 3
DIP 4
Reserved for
future use.
ON: Enables
this Ethernet
Switch as the
Ring Master.
ON: Enables the
default “Ring
Coupling” ports.
ON: Activates
DIP switches 1,
2, 3 to configure
“Turbo Ring”
settings.
OFF: This
Ethernet Switch
will not be the
Ring Master.
OFF: Do not use
this Ethernet
Switch as the ring
coupler.
OFF: DIP
switches 1, 2, 3
will be disabled.
“
Turbo Ring V2
”
DIP Switch Settings
DIP 1
DIP 2
DIP 3
DIP 4
ON: Enables
the default
“Ring
Coupling
(backup)”
port.
ON: Enables
this Ethernet
Switch as the
Ring Master.
ON: Enables
the default
“Ring Coupling”
port.
ON: Activates
DIP switches 1,
2, 3 to configure
“Turbo Ring V2”
settings.
OFF: Enables
the default
“Ring
Coupling
(primary)”
port.
OFF: This
Ethernet Switch
will not be the
Ring Master.
OFF: Do not
use this
Ethernet Switch
as a ring
coupler.
OFF: DIP
switches 1, 2, 3
will be disabled.
NOTE If you do not enable any of the IE-SW-VL05/08M switches to
be the Ring Master, the Turb
o Ring protocol will automatically
choose the switch with the smallest MAC address range to
be the Ring Master. If you accidentally enable more than one
IE-SW-VL05/08M switch to be the Ring Master, these
switches will auto-negotiate to determine which one will be
the Ring Master.
NOTE To switch on the Master or Coupler functions of the DIP
switch, you have to enable the Turbo Ring Pole first.
LED Indicators
There are several LEDs on the Ethernet Switches front panel. The
function of each LED is described in the following table.
LED
Color
State
Description
PWR1 AMBER
On Power is being supplied to power input
PWR1.
Off Power is not being supplied to power
input PWR1.
PWR2 AMBER On Power is being supplied to power input
PWR2.

15
Off Power is not being supplied to power
input PWR2.
FAULT RED
On
When (1) a relay warning event is
triggered, (2) the switch is the Master of
this Turbo Ring, and the Turbo Ring is
broken, or (3) start
-
up failure.
Off
When a relay warning event is not
triggered.
MSTR/
HEAD GREEN
On
When the switch is set as the Master of
the Turbo Ring, or as the Head of the
Turbo Chain.
Blinking
The switch has become the Ring Master
of the Turbo Ring, or the Head of the
Turbo Chain, after the Turbo Ring or the
Turbo Chain is
down.
Off
When the switch is not the Master of this
Turbo Ring or is set as the Member of
the Turbo Chain.
CPLR/
TAIL GREEN
On
When the switch coupling function is
enabled to form a back-up path, or when
it's set as the Tail of the Turbo Chain.
Blinking
When the Turbo Chain is down.
Off
When the switch disables the coupling
function, or is set as the Member of the
Turbo Chain.
10M
(TP) GREEN
On
TP port’s 10 Mbps link is active.
Blinking
Data is being transmitted at 10 Mbps.
Off
TP
Port’s 10 Mbps link is inactive.
100M
(TP) GREEN
On
TP port’s 100 Mbps link is active.
Blinking
Data is being transmitted at 100 Mbps.
Off
TP Port’s 100 Mbps link is inactive.
100M
(FX) GREEN
On
FX port’s 100 Mbps is active.
Blinking
Data is
being transmitted at 100 Mbps.
Off
FX port’s 100 Mbps is inactive.
Auto MDI/MDI-X Connection
The Auto MDI/MDI-X function allows users to connect the
10/100BaseTX ports to any kind of Ethernet device, without needing to
pay attention to the type of Ethernet cable being used for the
connection. This means that you can use either a straight-through
cable or cross-over cable to connect the IE-SW-VL05/08M switches
to Ethernet devices.

16
Specifications
Technology
Standards IEEE802.3, 802.3u, 802.3x, 802.1D-2004, 802.1Q,
802.1w, 802.1p
Protocols
IGMP V1/V2 device, GMRP, GVRP,
SNMPv1/v2c/v3, DHCP Server/Client, TFTP,
SNTP, SMTP, RARP, RMON, HTTP, Telnet,
Syslog, DHCP Option 66/67/82, BootP, LLDP,
Modbus TCP, Ethernet/IP, PROFINET RT (PN-I/O
device according to CC
-
B)
, IPv6
MIB MIB-II, Ethernet-Like MIB, P-BRIDGE MIB, RMON
MIB Group 1, 2, 3, 9, Bridge MIB, RSTP MIB
Forwarding and
Filtering Rate
148.810 pps
Processing Type
Store and Forward
Flow Control
I
EEE802.3x flow control, back
pressure flow control
Interface
RJ45 Ports 10/100BaseT(X) auto negotiation speed, F/H
duplex mode, and auto MDI/MDI
-
X connection
Fiber Ports 100BaseFX ports (SC/ST-Duplex connector,
multi/single
-
mode)
Console
RS
-
232 (RJ45)
LED Indicators PWR1, PWR2, FAULT, 10/100M (TP port),
100M (Fiber Port), CPLR/TAIL and MSTR/HEAD
Relay Contact One relay output with current carrying capacity of
1A @ 24 VDC
DIP Switches
Master, Coupler, Turbo Ring, Reserve
Optical Fiber
100Base FX
Multi
-
mode
Single
-
mode
Fiber Cable Type OM1
50/125 μ
m
G.652
800 MHz*Km
Typical Distance
4 km
5 km
40 km
Wavelength
Typical (nm)
1300
1310
TX Range (nm)
1260 to 1360
1280 to 1340
RX Range (nm)
1100 to 1600
1100 to 1600
Optical Power
TX Range (dBm)
-
10 to
-
20
0 to
-
5
RX Range (dBm)
-
3 to
-
32
-
3 to
-
34
Link Budget (dB)
12
29
Dispersion
Penalty (dB)
3 1
Note: When connecting single-mode fiber over a short distance, we
recommend putting an attenuator to prevent the transceiver from being
damaged by excessive optical power.
Typical Distance: To reach the typical distance of a specified fiber
transceiver, please refer to the following formula: Link budget(dB) >
dispersion penalty(dB) + total link loss(dB).

17
Power
Input Voltage
12/24/48 V
DC (9.6 to 60 V
DC), 2 redundant inputs
Input Current
IE-SW-VL05M series:
0.594 A/0.286 A/0.154 A @ 12/24/48 V
IE-SW-VL08MT series:
0.61 A/0.3 A/0.16 A @ 12/24/48 V
IE-SW-VL08MT-5TX-3SC/2SCS-1SC:
0.73
A
/0.35 A/0.18 A @ 12/24/48 V
Connection
One removable 6
-
pin terminal block
Overload Current
Protection
Present
Reverse Polarity
Protection
Present
Mechanical
Housing
Metal, IP30 protected
Dimensions
53.6

135

105 mm (W

H

D)
Weight 0.65 kg (IE-SW-VL05M series)
0.89 kg (
IE
-
SW
-
VL08
M
T
series
)
Installation
DIN
-
Rail, Wall Mounting
(optional kit)
Environment
Operating
Temperature
Standard models: -10 to 60°C (14 to 140°F)
Wide temp. models:
-
40 to 75°C (
-
40 to 167°F)
Storage
Temperature
-40 to 85°C (-40 to 185°F)
Ambient Relative
Humidity
5% to 95% (non-condensing)
Regulatory Approvals
Safety
U
L60950
-
1, UL 508,
EN60950
-
1
Hazardous
Location
UL/cUL Class I, Division 2, Groups A, B, C, and D
ATEX
Zone 2: only IE-SW-VL08MT series (copper
and 2 fiber models):
EN 60079-0:2012+A11:2013
EN 60079-15:2010
EN 60079
-
28:2015
(for IE-SW-VL08MT-2SC/2ST/2SCS only)
EMC
EN 55032/24; CISPR 32, FCC Part 15B
Class A
IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 20 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 1 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 2 kV
IEC 61000-4-6 CS: 10 V
IEC 61000
-
4
-
8
Shock
IEC60068
-
2
-
27
Freefall
IEC60068
-
2
-
31
Vibration
IEC60068
-
2
-
6
MTBF
(meantime between failures)
Time
1,547,941 hrs (IE-SW-VL05M(T)-5TX models)
1,429,327 hrs (IE-SW-VL05M(T)-3TX models)
1,339,439 hrs (IE-SW-VL08MT-8TX/6TX models)
1,253,072 hrs (IE
-
SW
-
VL08MT
-
5TX models)

18
Database
Telcordia (Bellcore), GB
WARRANTY
Time Period
5 years
WARNING This equipment is intended to be used in a
restricted access location.
HOT SURFACE!! Before touching it, special
attention or protection is required.
Weidmüller gives a 5 year warranty on this product in accordance with
the warranty terms as described in the general conditions of sale of the
Weidmüller company which has sold the products to you. Weidmüller
warrants to you that such products the defects of which have already
existed at the time when the risk passed will be repaired by Weidmüller
free of charge or that Weidmüller will provide a new, functionally
equivalent product to replace the defective one. Safe where expressly
described otherwise in writing in this catalogue/product description,
Weidmüller gives no warranty or guarantee as to the interoperability in
specific systems or as to the fitness for any particular purpose. To the
extent permitted by law, any claims for damages and reimbursement of
expenses, based on whatever legal reason, including contract or tort,
shall be excluded. Where not expressly stated otherwise in this
warranty, the general conditions of purchase and the expressive liability
commitments therein of the respective Weidmüller company which has
sold the products to you shall be applicable.
Contact Information
Weidmüller Interface GmbH & Co. KG
Postfach 3030
32760 Detmold
Klingenbergstraße 16
32758 Detmold
Germany
Phone [phone]
Fax [phone]
E-Mail [e-mail]
Internet www.weidmueller.com
