Weidmüller IE-SW-BL05-4GT-1GS Manual

Gigabit Ethernet Switch –Basic Line
IE-SW-BL05-4GT-1GS
IE-SW-BL05T-4GT-1GS
Hardware Installation Guide
First Edition, May 2016
2467470000/00/05.16
Important note:
This document and additional product information can
be downloaded using following link:
http://www.weidmueller.com
► Select Product Catalogue
Select „Industrial Ethernet active“
Select „BasicLine unmanaged Switches “
Select the relevant product model
Click and expand section „Downloads“
Download needed documentation
Copyright Notice
Copyright 2016 Weidmüller Interface GmbH & Co. KG
All rights reserved.
Reproduction without permission is prohibited.

- 2 -
Overview
The BasicLine Gigabit Ethernet Switches are equipped with 5 Gigabit
Ethernet ports (4x 10/100/1000BaseT(X) ports and 1x combo
10/100/1000BaseT(X) or 100/1000BaseSFP port), making them ideal,
economical solutions for demanding, high bandwidth Gigabit Ethernet
applications. In addition, the built-in relay warning function alerts system
administrators when power failures or port breaks occur, and the add-on
4-pin DIP switches can be used to configure broadcast storm protection,
jumbo frame rate, IEEE 802.3az energy saving, and 100/1000 SFP
speed switching. The two available models differ in terms of operating
temperature range. One model is for use at an operating temperature
range of -10 to 60°C and the other one for an extended operating
temperature range of -40 to 75°C. Both models have passed a 100%
burn-in test to ensure that they fulfill the special needs of industrial
automation control. The switches can be easily installed on a DIN rail or
in distribution boxes.
Package Checklist
Your Ethernet Switch is shipped with the following items. If any of these
items is missing or damaged, please contact your Weidmüller customer
service for assistance.
1 Ethernet Switch IE-SW-BL05(T)-4GT-1GS
Hardware Installation Guide
Features
High Performance Network Switching Technology
10/100/1000BaseT(X) (RJ45), auto negotiation speed, F/H duplex
mode
100BaseSFP/1000BaseSFP; easily configure speed by DIP switch
IEEE 802.3/802.3u/802.3ab/802.3z
Store and Forward switching process type, 8K MAC address entries.
Industrial Grade Reliablity and Efficiency
•Power failure and port break alarm by relay output
•Redundant dual 12/24/48 VDC power inputs
•IEEE 802.3az energy-efficient Ethernet settings by DIP switch
•Jumbo frame setting by DIP switch
Rugged Design
Standard operating temperature range from -10 to 60°C or extended
operating temperature of -40 to 75°C for (-T) models
IP30, rugged high-strength case
DIN-Rail or panel mounting ability

- 3 -
Panel Layout of IE-SW-BL05-4GT-1GS
1. Terminal block for power input
(PWR1, PWR2) and relay output
2. PWR1: LED for power input 1
3. PWR2: LED for power input 2
4. FAULT: LED indicator
5. 10/100/1000BaseT(X) LED
indicator (Amber: 10/100M;
Green: 1000M)
6. Port number
7. Ports 2 to 5: 10/100/1000
BaseT(X) ports
8. Port 1: 10/100/1000 BaseT(X) or
100/1000Base SFP slot combo
port
9. Article number
10. Grounding screw
11. DIP switches
12. Screw hole for wall mounting kit
13. DIN rail kit

- 4 -
Mounting Dimensions (unit = mm)

- 5 -
DIN-Rail Mounting
The aluminum DIN-rail attachment plate should already be fixed to the
back panel of the Ethernet Switch when you take it out of the box. If you
need to reattach the DIN-rail attachment plate, make sure the stiff metal
spring is situated towards the top, as shown in the figures below.
STEP 1:
Insert the top of the DIN-rail into the
slot just below the stiff metal spring.
STEP 2:
The DIN-rail attachment unit will
snap into place as shown below.
To remove the Ethernet Switch from the DIN-rail, simply reverse Steps 1
and 2.
Wall Mounting (optional)
For some applications, you will find it convenient to mount the switch on
the wall, as illustrated below.
STEP 1:
Remove the aluminum DIN
rail attachment plate from
the switch’s rear panel, and
then attach the wall mount
plates, as shown in the
figure.
STEP 2:
Mounting the switch on the wall requires 4 screws.
Use the switch, with wall mount plates attached, as a
guide to mark the correct locations of the 4 screws.
The heads of the screws should be less than 6.0 mm
in diameter, and the shafts should be less than 3.5
mm in diameter, as shown in the figure at the right.
NOTE
Before tightening the screws into the wall, make sure the screw
head and shank size are suitable by inserting the screw into one
of the keyhole-shaped apertures of the wall mounting plates.
Do not screw the screws in all the way—leave about 2 mm to allow room
for sliding the wall mount panel between the wall and the screws.

- 6 -
STEP 3:
Once the screws are fixed in
the wall, insert the four screw
heads through the large parts
of the keyhole-shaped
apertures, and then slide the
switch downwards, as
indicated. Tighten the four
screws for added stability.
ATEX Information
1. Certificate number: ATEX: DEMKO 16 ATEX 1727X
2. Ambient range:
-40°C ≤ Tamb ≤ +75°C for models with suffix of “-T”;
-10°C ≤ Tamb ≤ +60°C for models without suffix of “-T”
3. Certification string: ATEX: Ex II 3G Ex nA nC IIC T4 Gc
4. Standards covered: EN 60079-0:2012+A11:2013, EN 60079-15:2010
5. The conditions of safe usage:
The equipment shall only be used in an area of not more than
pollution degree 2, as defined in IEC 60664-1.
The equipment shall be installed in an enclosure that provides a
degree of protection not less than IP 54 in accordance with EN
60079-15 and accessible only by the use of a tool.
When end users are providing optical SFP communications
modules, these must be limited to Laser Class 1 only.
Wiring Requirements
WARNING
Safety First!
Turn the power off before disconnecting modules or wires.
The proper power supply voltage is listed on the product
label. Check the voltage of your power source to make sure
you are using the correct voltage. Do NOT use a voltage
greater than what is specified on the product label.
These devices must be supplied by an SELV source as
defined in the Low Voltage Directive 2014/35/EU and
2014/30/EU.

- 7 -
WARNING
Safety First!
Calculate the maximum possible current in each power wire
and common wire. Observe all electrical codes dictating the
maximum current allowable for each wire size.
If the current goes above the maximum ratings, the wiring
could overheat, causing serious damage to your equipment.
You should also pay attention to the following items:
Use separate paths to route wiring for power and devices. If power
wiring and device wiring paths must cross, make sure the wires are
perpendicular at the intersection point.
NOTE: Do not run signal or communications wiring and power wiring
in the same wire conduit. To avoid interference, wires with different
signal characteristics should be routed separately.
You can use the type of signal transmitted through a wire to
determine which wires should be kept separate. The rule of thumb is
that wiring with similar electrical characteristics can be bundled
together.
Keep input wiring and output wiring separated.
It is strongly advised that you label wiring for all devices in the system
when necessary.
Grounding Ethernet Switch
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI). Run the ground connection from the
ground screw to the grounding surface prior to connecting devices.
ATTENTION
This product is intended to be mounted to a well-grounded
mounting surface, such as a metal panel.
Wiring the Alarm Contact
The Alarm Contact consists of the two middle contacts of the terminal
block on the Ethernet Switch top panel. You may refer to the next
section for detailed instructions on how to connect the wires to the
terminal block connector, and how to attach the terminal block connector
to the terminal block receptor. In this section, we explain the meaning of
the two contacts used to connect the Alarm Contact.

- 8 -
FAULT: The two middle contacts of the
6-contact terminal block connector are
used to detect both power faults and port
faults. The two wires attached to the Fault
contacts form an open circuit when:
1. Ethernet Switch has lost power from
one of the DC power inputs.
OR
2. The PORT ALARM DIP switch for one
of the ports is set to ON, but the port is
not connected properly.
If neither of these two conditions is
satisfied, the Fault circuit will be closed.
Wiring the Redundant Power Inputs
The top two contacts and the bottom two contacts of the 6-contact
terminal block connector on the Ethernet Switch top panel are used for
the Ethernet Switch DC inputs. Top and front views of one of the
terminal block connectors are shown here.
STEP 1: Insert the negative/positive
DC wires into the V-/V+ terminals.
STEP 2: To keep the DC wires from
pulling loose, use a small flat-blade
screwdriver to tighten the wire-clamp
screws on the front of the terminal
block connector.
STEP 3: Insert the plastic terminal
block connector prongs into the
terminal block receptor, which is
located on switch´s top panel.
ATTENTION
Before connecting the Ethernet Switch to the DC power
inputs, make sure the DC power source voltage is stable.

- 9 -
Communication Connections
IE-SW-BL05(T)-4GT-1GS switches have 2 types of communication port:
•4 x 10/100/1000BaseT(X) Ethernet ports
•1 x Combo-port, usable as 10/100/1000T(X) or 100/1000BaseSFP
port
10/100/1000BaseT(X) Ethernet Port Connection
The 10/100/1000BaseT(X) ports located on switch’s front panel are used
to connect to Ethernet-enabled devices. Most users will choose to
configure these ports for Auto MDI/MDI-X mode, in which case the port’s
pinouts are adjusted automatically depending on the type of Ethernet
cable used (straight-through or cross-over), and the type of device
(NIC-type or HUB/Switch-type) connected to the port.
In what follows, we give pinouts for both MDI (NIC-type) ports and
MDI-X (HUB/Switch-type) ports. We also give cable wiring diagrams for
straight-through and cross-over Ethernet cables.
10/100BaseT(x) RJ45 Pinouts
MDI Port Pinouts
MDI-X Port Pinouts
8-pin RJ45
Pin
Signal
1
Tx+
2
Tx-
3
Rx+
6
Rx-
Pin
Signal
1
Rx+
2
Rx-
3
Tx+
6
Tx-
1000BaseT RJ45 Pinouts
8-pin RJ45
Pin
MDI
MDI-X
1
BI_DA+
BI_DB+
2
BI_DA-
BI_DB-
3
BI_DB+
BI_DA+
4
BI_DC+
BI_DD+
5
BI_DC-
BI_DD-
6
BI_DB-
BI_DA-
7
BI_DD+
BI_DC+
8
BI_DD-
BI_DC-

- 10 -
RJ45 (8-pin) to RJ45 (8-pin) Straight-Through Cable Wiring
RJ45 (8-pin) to RJ45 (8-pin) Cross-Over Cable Wiring
100/1000BaseSFP (mini-GBIC) Fiber Port
One of the Gigabit Ethernet ports on the IE-SW-BL05(T)-4GT-1GS is a
SFP slot, which requires 100M or 1G mini-GBIC fiber transceivers to
work properly. Weidmüller offers several SFP-transceiver models for
various distance requirements.
The concept behind the LC port and cable is straightforward. Suppose
you are connecting devices I and II. Unlike electrical signals, optical
signals do not require a circuit in order to transmit data. Consequently,
one of the optical lines is used to transmit data from device I to device II,
and the other optical line is used to transmit data from device II to device
I, for full-duplex transmission.
Remember to connect the Tx (transmit) port of device I to the Rx
(receive) port of device II, and the Rx (receive) port of device I to the Tx
(transmit) port of device II. If you make your own cable, we suggest
labeling the two sides of the same line with the same letter (A-to-A and
B-to-B, as shown below, or A1-to-A2 and B1-to-B2).
LC-Port Pinouts
LC-Port to LC-Port Cable Wiring

- 11 -
ATTENTION
This is a Class 1 Laser/LED product. To avoid causing serious
damage to your eyes, do not stare directly into the laser beam.
Redundant Power Inputs
Both power inputs can be connected simultaneously to live DC power
sources. If one power source fails, the other live source acts as a backup,
and automatically supplies all of the switch´s power needs.
Alarm Contact
The Ethernet switch has one Alarm Contact located on the top panel.
For detailed instructions on how to connect the Alarm Contact power
wires to the two middle contacts of the 6-contact terminal block
connector, see the Wiring the Alarm Contact section on page 7. A
typical scenario would be to connect the Fault circuit to a warning light
located in the control room. The light can be set up to switch on when a
fault is detected.
The Alarm Contact has two terminals that form a Fault circuit for
connecting to an alarm system. The two wires attached to the Fault
contacts form an open circuit when (1) the switch has lost power from
one of the DC power inputs, or (2) one of the ports, for which the
corresponding PORT ALARM DIP switch is set to ON, is not properly
connected.
If neither of these two conditions occurs, the Fault circuit will be closed.
DIP Switch Settings
The default setting for each DIP switch is OFF.
The following table explains the effect of setting
the DIP switches to the ON positions.

- 12 -
DIP Switch
Setting
Description
BSP
ON
Enables broadcast storm protection
OFF
Disables broadcast storm protection
Jumbo Frame
ON
Enables jumbo frame function
OFF
Disables jumbo frame function
802.3az
ON
Enables the energy-efficient Ethernet
function
OFF
Disables the energy-efficient Ethernet
function
100/1000BaseSFP
ON
Supports 100M SFP module
OFF
Supports 1000M SFP module
Port Alarm
ON
Enables the corresponding PORT
Alarm. If the port’s link fails, the relay
will form an open circuit and the fault
LED will light up
OFF
Disables the corresponding PORT
Alarm. If the port’s link fails, the relay
will form a closed circuit and the fault
LED will never light up
ATTENTION
To actively update DIP switch settings, power off and then
power on the switch.
LED Indicators
The front panel of the switch contains several LED indicators. The
function of each LED is described in the table below.
LED
Color
State
Description
PWR1
AMBER
On
Power is being supplied to power input
PWR1
Off
Power is not being supplied to power input
PWR1
PWR2
AMBER
On
Power is being supplied to power input
PWR2
Off
Power is not being supplied to power input
PWR2
FAULT
RED
On
When the corresponding PORT alarm is
enabled, and the port’s link is inactive.
Off
When the corresponding PORT alarm is
enabled and the port’s link is active, or when
the corresponding PORT alarm is disabled.
10/100/
1000M
AMBER
On
TP port’s 10/100 Mbps or SFP port’s 100
Mbps link is active.
Blinking
Data is being transmitted at 10/100 Mbps
Off
TP port’s 10/100 Mbps or SFP port 100 Mbps
link is inactive.
GREEN
On
TP/SFP port’s 1000 Mbps link is active.
Blinking
Data is being transmitted at 1000 Mbps
Off
TP/SFP port’s 1000 Mbps link is inactive

- 13 -
Auto MDI/MDI-X Connection
The Auto MDI/MDI-X function allows users to connect the Ethernet
Switch 10/100/1000BaseT(X) ports to any kind of Ethernet device,
without paying attention to the type of Ethernet cable being used for the
connection. This means that you can use either a straight-through cable
or cross-over cable to connect the Ethernet Switch to Ethernet devices.
Triple Speed Functionality and
Switching
The switch´s 10/100/1000 Mbps RJ45 ports auto negotiates with the
connected device for the fastest data transmission rate supported by
both devices. The Ethernet Switch is a plug-and-play device, so
software configuration is not required at installation or during
maintenance.
The half/full duplex mode for the RJ45 ports is user dependent and
changes (by auto-negotiation) to full or half duplex, depending on which
transmission speed is supported by the attached device.
Auto-Negotiation and Speed Sensing
The switch´s RJ45 ports independently support auto-negotiation for
transmission speeds of 10 Mbps, 100 Mbps, and 1000 Mbps, with
operation according to the IEEE802.3 standard.
This means that some nodes could be operating at 10 Mbps, while at the
same time, other nodes are operating at 100 Mbps or 1000Mbps.
Auto-negotiation takes place when an RJ45 cable connection is made,
and then each time a LINK is enabled. The switch advertises its
capability for using 10 Mbps, 100 Mbps, or 1000 Mbps transmission
speeds, with the device at the other end of the cable expected to
advertise similarly. Depending on what type of device is connected, this
will result in agreement to operate at a speed of 10 Mbps, 100 Mbps, or
1000 Mbps.
Note about possible lost of data packages in case of “Duplex
mismatching”
If the switch´s RJ45 port is connected to a non-negotiating device, then
the switch will set its port transmission speed same as the connected
device but is unable to correctly detect the duplex mode. As result the
port is set to the correct speed but is using always the half duplex mode
as required by the IEEE 802.3u standard in such cases. For correct
transmission the non-negotiating port has to be set to half-duplex mode
(speed either 10 or 100 or 1000 Mbit/s).

- 14 -
Specifications
Technology
Standards
IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X) and 100BaseFX
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.3z for 1000BaseX
IEEE 802.3x for Flow Control
IEEE 802.3az for Energy-Efficient Ethernet
Interface
RJ45 Ports
10/100/1000BaseT(X) auto negotiation speed,
half/full duplex mode, and auto MDI/MDI-X
connection
Fiber Ports
Optional 1000BaseSX/LX/LHX/ZX (LC
connector) or 100BaseSFP
LED Indicators
PWR1, PWR2, FAULT, 10/100M/1000M
DIP Switch
Port break alarm, broadcast storm protection,
jumbo frame, IEEE 802.3az,
100/1000BaseSFP
Alarm Contact
One relay output with current carrying capacity
of 1A @ 24 VDC
Power Requirements
Input Voltage
12/24/48 VDC (9.6 to 60 VDC), redundant input
Input Current @ 24VDC
0.16 A
Connection
One removable 6-pin terminal block
Overload Current
Protection
Present
Reverse Polarity
Protection
Present
Physical Characteristics
Housing
IP30 protection, metal case
Dimensions (WxHxD)
29 x 135 x 105 mm (1.14 x 5.31 x 4.13 in)
Weight
290 g
Installation
DIN rail, wall mounting (optional kit)
Environmental Limits
Operating Temperature
-10 to 60°C (14 to 140°F)
-40 to 75°C (-40 to 167°F) for -T models
Storage Temperature
-40 to 85°C (-40 to 185°F)
Ambient Relative
Humidity
5 to 95% (non-condensing)
Regulatory Approvals
Safety
UL 508
Hazardous Location
UL/cUL Class I, Division 2, Groups A, B, C, and
D; ATEX Zone 2, Ex nA nC IIC T4 Gc
EMI
FCC Part 15, CISPR (EN 55022) ClassA
EMS
EN 61000-4-2 (ESD), Level 3
EN 61000-4-3 (RS), Level 3
EN 61000-4-4 (EFT), Level 3
EN 61000-4-5 (Surge), Level 3
EN 61000-4-6 (CS), Level 3
EN 61000-4-8
Shock
IEC 60068-2-27
Freefall
IEC 60068-2-32
Vibration
IEC 60068-2-6

- 15 -
MTBF (meantime between failures)
Time
2,823,446 hrs
Database
Telcordia (Bellcore), GB 25°C
Warranty
Time Period
5 years
Weidmüller gives a 5 year warranty on this product in accordance with
the warranty terms as described in the general conditions of sale of the
Weidmüller company which has sold the products to you. Weidmüller
warrants to you that such products the defects of which have already
existed at the time when the risk passed will be repaired by Weidmüller
free of charge or that Weidmüller will provide a new, functionally
equivalent product to replace the defective one. Safe where expressly
described otherwise in writing in this catalogue/product description,
Weidmüller gives no warranty or guarantee as to the interoperability in
specific systems or as to the fitness for any particular purpose. To the
extent permitted by law, any claims for damages and reimbursement of
expenses, based on whatever legal reason, including contract or tort,
shall be excluded. Where not expressly stated otherwise in this warranty,
the general conditions of purchase and the expressive liability
commitments therein of the respective Weidmüller company which has
sold the products to you shall be applicable.
Contact Information
Weidmüller Interface GmbH & Co. KG
Postfach 3030
32760 Detmold
Klingenbergstraße 16
32758 Detmold
Germany
Phone [phone]
Fax [phone]
E-Mail [e-mail]
Internet www.weidmueller.com
