Hardware Installation Guide
Managed Gigabit Ethernet Switch
IE-SW-AL012M-8GT-4GESFP (Part No. 2682340000)
1. Introduction
Ethernet Switches from Weidmüller are designed for industrial applications and fitted with
a robust housing. To ensure reliable, error-free operation, and to prevent damage or
injury, please read the operating instructions, all safety information provided in this
document and any other safety information that were supplied with the product.
2. Safety notice
The device heats up during operation. Allow the unit to cool down or use protection
gloves when carrying out any work.
The device may only be connected to the supply voltage shown on the product label.
Higher voltage than specified will destroy the device.
The device must be supplied by a SELV source as defined in the Low Voltage
Directive 2014/35/EU and 2014/30/EU.
Installation, commissioning and maintenance may only be performed by qualified
electricians.
Observe the operating instructions.

Indoor use and pollution degree II, it must be wiped with a dry cloth for clean up
the device and label.
oUtilisation en intérieur et degré de pollution II, il faut l'essuyer avec un chiffon sec
pour nettoyer l'appareil et son étiquette.
Do not block air ventilation holes.
oNe bouchez pas les orifices de ventilation.
If the equipment is used in a manner not specified by the manufacturer, the
protection provided by the equipment may be impaired.
oSi l’appareil est utilise d’une maniere non specifiee par le fabricant, la protection
qu’il apporte peut se voir diminuee.
Shall be mounted in the Industrial Control Panel and ambient temperature is not
exceed 75 degrees C.
oDoit être monté dans le panneau de commande industriel et la température
ambiante ne doit pas dépasser 75 degrés C.
Intended use: The device is intended for the realization of communication networks within an
industrial environment, it is intended to be used in a restricted access location. The device may only
be used within the scope of the specified technical data. The device is intended to be mounted to a
well-grounded mounting surface, such as a metal panel. Any other use may result in unintentional
malfunction and damage. Observing the documentation is part of the intended use.
Environmental conditions: This equipment is intended to be used in a restricted access location.
When planning the installation site make sure that the ambient temperature during operation will not
exceed the temperature given in the technical data. Also make sure that the air flow will not be
compromised by other devices. Ensure that the mounted and wired device is not exposed to any
mechanical stress.
FCC compliance: This device complies with part 15 of FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
3. Package Checklist
Your Ethernet Switch is shipped with the following items:
Ethernet Switch
Hardware Installation Guide (printed)
6-Pin Terminal connector
Serial console cable
Protective caps for RJ45 ports and SFP ports
4. Panel Layouts
1. Terminal block for power input
PWR1/PWR2 and fault relay (output)
2. Power Input LEDs (PWR1 / PWR2)
3. Fault LED (Power fault / Port link loss)
4. Ring Master Status LED
5. Ring Status LED
6. Reset Button
7. 8 x 10/100/1000Base-T(X) Ports
8. Link/Activity LED RJ45 port
9. LED for speed indication (Green = 1000
Mbps, Amber = 100 Mbps, Off = 10 Mbps)
10. Article Number
11. Serial Console Port (Baud Rate 115200
Bit/s, 8 Data Bit, No Parity, 1 Stop Bit)
12. 4 x 100/1000Base-X Ports (SFP Slots)
13. Link/Activity LED SFP port G10
14. Link/Activity LED SFP port G9
15. Grounding screw / Frame ground (Note:
The shielding ground of the LAN port is
electrically connected to the grounding
screw)
16. DIN-Rail kit
5. DIN-Rail Mounting
STEP 1: Place the mounting clip from
above onto the mounting rail.
STEP 2: Press the device against the DIN
rail until the fastening element engages on
the mounting rail.
To remove the Ethernet Switch from the
DIN-rail pull down the latch with a
screwdriver then move the device away from the DIN rail and lift it up.
6. Mounting Dimensions (units = mm)
7. Grounding Ethernet Switch
ATTENTION
- Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI).
-
the ground connection from the ground screw to the grounding surface prior to
connecting devices.
- This product is intended to be mounted to a well-grounded mounting surface,
such as a metal panel.
- The shielding ground of the RJ45 ports are electrically connected to the
ground connection (screw).
8. Wiring Redundant Power Inputs and Fault Alarm
Relay
The switch supports redundant power supply inputs and provides a fault alarm relay for
detecting the user-configurable failure events
Interruption of Power 1 or Power 2 and
Link Loss of Ethernet Ports.
Warning / Avertissement
Take into consideration the following guidelines before wiring the device
oTenez compte des directrices suivantes avant de câbler l’appareil.
Terminal block is mating with Plug and suitable for 12-24AWG. Torque value
4.5 lb-in.
oLe bornier est compatible avec les connecteurs et convient pour 12-24AWG.
Valeur de couple 4,5 lb-in.
The temperature rating of the input connection cable should higher than
105°C.
oLa température de service nominale du câble d’entrée doit être supérieure à
105 °C.
Supplied by SELV source evaluated by UL 61010-1 or 61010-2-201 power
supply only.
oFourni par la source SELV évaluée uniquement par l'alimentation UL 61010-1
or 61010-2-201.

4 5 6 V1.3 / 2022-03-29
Refer to illustration below for correct wiring.
Behavior of fault alarm relay (can be triggered by configurable events power
failure or port link down):
Relay contact is closed if the device is powered-off.
Relay contact is open if the device is powered-on and no alarm conditions exist (neither
Power Failure Alarms nor Port Link Loss Alarms are activated (Web menu Warnings 
Fault Relay Alarm).
Relay contact closes if any of an activated alarm condition happens.
9. Communication Connections
Switch IE-SW-AL012M-8GT-4GESFP is equipped with:
8 x 10/100/1000BASE-T(X) Ethernet ports (Auto MDI-X)
4 x 100/1000BASE-X Ports (SFP Slots)
Please only use cables suitable for the respective type of communication and ensure that
signals are protected from possible interference.
9.1 10/100/1000BASE-T(X) RJ45 Ports
The 10/100/1000BASE-T(X) ports located on Ethernet Switch’s front panel are used to
connect to Ethernet-enabled devices. Below we show pinouts for both MDI (NIC-type) ports
and MDI-X (HUB/Switch-type) ports. Auto MDI-X ensures that both wiring-schemes are
supported (Automatic crossover function).
10/100/1000BASE-T(X) RJ45 Pinouts
8-Pin RJ45
Port
10/100BASE-T(X) MDI/MDI-X 1000BASE-T MDI/MDI-X
Pin No. MDI port MDI-X port Pin No. MDI port MDI-X port
1 TD+(transmit) RD+(receive) 1 BI_DA+ BI_DB+
2 TD-(transmit) RD-(receive) 2 BI_DA- BI_DB-
3 RD+(receive) TD+(transmit) 3 BI_DB+ BI_DA+
4 Not used Not used 4 BI_DC+ BI_DD+
5 Not used Not used 5 BI_DC- BI_DD-
6 RD-(receive) TD-(transmit) 6 BI_DB- BI_DA-
7 Not used Not used 7 BI_DD+ BI_DC+
8 Not used Not used 8 BI_DD- BI_DC-
9.2 100/1000BASE-X SFP fiber optic port
The 100/1000BaseSFP type slots require either a 100BaseSFP or a 1000BaseSFP fiber
transceiver (mini-GBIC) to work properly. Please only use SFP modules and cables that are
compatible with each other to establish an optical connection.
LC-Port Pinouts: LC-Port to LC-Port Cable Wiring
For a LC-Port with separate Transmit and Receive Port please remember to connect the
Tx (transmit) port of Device-1 to the Rx (receive) port of Device-2, and the Rx (receive) port of
Device-1 to the Tx (transmit) port of Device-2.
9.3 RS232 Console Port
The RS232 Interface with RJ45 connector can be used to access the switch console for
configuration. Additional it can be applied with external Backup/Restore module IE-EBR-
MODULE-RS232-ALM (Article no. 2682610000).
Pinouts Serial
Console Port:
10. User Management
10.1 Device Access (Login to Web Interface)
The Web interface of the Switch can be accessed via following factory default settings:
IP address / Netmask: 192.168.1.110 / 255.255.255.0
User name: admin
Password: Detmold
Connect the PC to any Ethernet port of the managed Switch and set the PC’s IP address to a
free one of range 192.168.1.0 / 255.255.255.0
Start a web browser and enter the IP address of the connected Switch into the browser’s
address line (http://192.168.1.110). After the appearance of prompt (login) enter the login
credentials. After confirmation of your input with "OK" the home page of the switch will be
displayed.
10.2 Reset Button (Behavior of Factory Default Settings)
Pressing < 5 seconds: Reboot the switch (Warm Start) and sets IP to Factory Default IP.
Pressing >= 5 seconds: Resets the switch configuration to Factory Default Settings.
Note: Behavior of reset button can be configured in the Web Interface (Menu Factory Default).
11. LED Indicators
The front panel of the Ethernet Switch contains several LED indicators. The function of each
LED is described in the table below.
12. Disposal Information
Observe the notes for proper disposal of the
product. You can find the notes here:
www.weidmueller.com/disposal.
13. Specifications
Technology
Ethernet Standards
IEEE 802.3 for 10BASE-T
IEEE 802.3u for 100BASE-TX and 100BASE-FX
IEEE 802.3ab for 1000BASE-T
IEEE 802.3z for 1000BASE-X
IEEE 802.3x for flow control
IEEE 802.3az Energy-Efficient Ethernet
IEEE 802.3ad for port trunk with LACP
IEEE 802.1D for STP (Spanning Tree protocol)
IEEE 802.1w for RSTP (Rapid Spanning Tree protocol)
IEEE 802.1s for MSTP (Multiple Spanning Tree Protocol)
IEEE 802.1p for Class of Service
IEEE 802.1Q for VLAN Tagging
IEEE 802.1X for Authentication
IEEE 802.1AB for LLDP (Link Layer Discovery Protocol)
Processing Type Store and Forward
MAC Table size 8K
Packet buffer size 4 Mbit
Backplane bandwidth 24 Gbps
Jumbo frame support Up to 9.6 kBytes
Interfaces
RJ45 Ports 8 x 10/100/1000BASE-
T(X) auto negotiation speed, F/H duplex
mode and auto MDI/MDI-X connection
Fiber optic ports 4 x 100/1000BASE-X SFP slots
RS232 Console Port RS232 Interface with RJ45 connector for Console access and
useable with external Backup/Restore module
LED Indicators PWR1, PWR2 (Power), Fault (Relay), Ring Master, Ring
Status, Port Link/Activity and Speed
Relay Contact Max. 1A @ 24 V DC for Power Failure and Port Link Loss
Power
Input Voltage 24 V DC (12 - 48 V DC), 2 redundant inputs
Power Consumption (typ.) 13.0 Watts
Connection Removable 6-pin terminal block, Wiring cable 12-24AWG
Overload Current Protect. Present
Reverse Polarity Protect. Present
Physical Characteristics
Housing IP30 protection, metal
Dimension (W x H x D) 54.3 x 145.1 x 108.3 mm (2.13 x 5.71 x 4.26 inch.)
Weight 762 g
Installation DIN-rail
Environmental conditions
Operating Temperature -40 to 75°C (-40 to 167°F)
Storage Temperature -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity 5 to 95% (non-condensing)
Operating Altitude Up to 2000 m
Regulatory Approvals
Safety UL 61010-1; UL 61010-2-201
EMC
EN 55032, EN 55024, FCC Part 15 Subpart B Class A,
IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV,
IEC 61000-4-3 RS: 80 MHz to 1 Ghz: 3 V/m,
IEC 61000-4-4 EFT: Power: 1 kV; Signal: 1 kV,
IEC 61000-4-5 Surge: Power: 0.5 kV; Signal: 1 kV,
IEC 61000-4-6 CS: 3 Vrms
Shock IEC 60068-2-27
Free Fall IEC 60068-2-31
Vibration IEC 60068-2-6
MTBF
Time 551.478 hrs
Database Telcordia SR332
Warranty
Time Period 5 years
Contact Information
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 26, 32758 Detmold / Germany
Phone [phone], Fax [phone]
E-Mail [e-mail], Internet www.weidmueller.com
LED Color Status Description
PWR1 Green On Power is supplied to power input PWR1.
PWR2 Green On Power is supplied to power input PWR2.
R-MSTR
(Ring Master) Green On Is Ring Master of an enabled O-Ring.
Ring Green On O-Ring redundancy is enabled.
Blinking Ring structure is broken (No redundancy).
FAULT Amber On Fault Relay indication for Power failure and
Port link loss.
LNK/ACT
(Ports G1–G8) Green
On Port link is active.
Off Port link is inactive.
Blinking Data is transmitted.
10/100/1000M
(Ports G1–G8)
Green /
Amber
Green Port speed is set to 1000 Mbps.
Amber Port speed is set to 100 Mbps.
Off Port speed is set to 10 Mbps.
LNK/ACT (SFP
Ports G9 -G12) Green On Port link is active.
Blinking Data is transmitted.
