Weinmann Homecare MEDUCORE Easy Setup guide

MEDUCORE Easy
Automatic external defibrillator
Device nos. 1000 to 1340 from device no. 1341 with ILCOR 2005
Service and Repair instructions
MEDUCORE Easy with Battery-Pack
MEDUCORE Easy with Rechargeable Battery-Pack

2
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . 3
1. Overview . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2. Description of Equipment . . . . . . . . . . . . . . 5
2.1 Intended use . . . . . . . . . . . . . . . . . . . 5
2.2 Scope of application . . . . . . . . . . . . . . 5
2.3 User qualification . . . . . . . . . . . . . . . . 5
2.4 Functional description . . . . . . . . . . . . . 6
3. Cleaning and disinfecting instructions . . . . . 8
4. Checking the device . . . . . . . . . . . . . . . . . . 9
4.1 Testing parts needed . . . . . . . . . . . . . . 9
4.2 Preparations for testing . . . . . . . . . . . . 10
4.3 Entering the device data . . . . . . . . . . 10
4.4 Checking the devices self testing . . . . . 10
4.5 Checking the volume levels . . . . . . . . . 11
4.6 Testing the ECG detection, current input,
shock button and shock output . . . . . . . 11
4.7 Checking the procedure display
and capacitor discharge . . . . . . . . . . 12
4.8 Checking the info-button
and reading contact . . . . . . . . . . . . . 13
4.9 Checking the status LEDs . . . . . . . . . . 13
4.10 Checking the condition of the exterior,
the equipment and the accessories . . . . 14
4.11 Checking the IRDA interface and the
software version . . . . . . . . . . . . . . . . 15
4.12 Checking the maintenance and safety
related check (SRC) stickers . . . . . . . . 15
4.13 Preparing a device for dispatch
following repair . . . . . . . . . . . . . . . . 15
4.14 Documentation . . . . . . . . . . . . . . . . . 17
5. Maintenance . . . . . . . . . . . . . . . . . . . . . . 18
5.1 Intervals . . . . . . . . . . . . . . . . . . . . . 18
5.2 Check the Battery/Rechargeable Battery. 18
5.3 Renew maintenance sticker . . . . . . . . . 19
5.4 Disposal . . . . . . . . . . . . . . . . . . . . . 20
6. Safety related check according to
§6 Medicinal products and Users ordinance . 21
6.1 General . . . . . . . . . . . . . . . . . . . . . 21
6.2 Execution . . . . . . . . . . . . . . . . . . . . 21
6.3 Testing devices . . . . . . . . . . . . . . . . . 21
6.4 Replace SRC sticker . . . . . . . . . . . . . 21
6.5 Documentation . . . . . . . . . . . . . . . . . 21
7. Malfunctions and Rectification . . . . . . . . . . . 22
8. Repair information and repair instructions . . 24
8.1 General . . . . . . . . . . . . . . . . . . . . . 24
8.2 Tools and facilities . . . . . . . . . . . . . . 24
8.3 Discharge high voltage capacitor
and open up device . . . . . . . . . . . . . 25
8.4 Opening the device . . . . . . . . . . . . . 27
8.5 Exchange the device lids . . . . . . . . . . 27
8.6 Close the device . . . . . . . . . . . . . . . 28
8.7 Exchanging the capacitor . . . . . . . . . . 29
8.8 Replace the Real Time Clock batteries . . 29
8.9 Replacing the main circuit board . . . . . 30
8.10 Exchanging pad plug cable . . . . . . . . 32
8.11 Exchanging the speaker . . . . . . . . . . . 32
8.12 Exchange encasing, upper part . . . . . . 33
8.13 Exchanging encasing, lower part . . . . . 33
9. Replacement parts . . . . . . . . . . . . . . . . . . . 34
10. Tools and testing devices . . . . . . . . . . . . . . . 38
10.1 General tools . . . . . . . . . . . . . . . . . . 38
10.2 Special tools . . . . . . . . . . . . . . . . . . 38
10.3 Software . . . . . . . . . . . . . . . . . . . . . 38
10.4 Testing devices . . . . . . . . . . . . . . . . . 38
11. Technical data . . . . . . . . . . . . . . . . . . . . . . 39
12. Technical Changes . . . . . . . . . . . . . . . . . . . 43
12.1 Device: MEDUCORE Easy . . . . . . . . 43
12.2 Software . . . . . . . . . . . . . . . . . . . . 43
13. Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
13.1 Repairs and maintenance protocol . . . . 44
13.2 Test record "Safety related check in
accordance with §6 of the MP BetreibV
(German Medicinal Products and Users
Ordinance)". . . . . . . . . . . . . . . . . . . 45
© Copyright WEINMANN GmbH & Co. KG.
The content and presentation are copyright protected and may only be used by authorised WEINMANN Service Partners in
the course of their service operations. The content must not be reproduced or passed on to third parties. The complete documents
must be returned on termination of the cooperation with WEINMANN.

Introduction 3
Introduction
WEINMANN has been developing,
manufacturing and marketing emergency medical
devices for oxygen and inhalation therapy for
decades.
The aim of this service and repair manual is to
bring you to an expert level on the
MEDUCORE Easy, allowing you to understand the
operation, technology and repairs of the device. In
combination with the training, that you have already
completed for WEINMANN, you now belong to
the “trained, informed, experts”, thereby allowing
you to give your customers professional help and
repair malfunctions independently and in
accordance with the operation manual illustrated
you have the possibility of making functional
checks and if necessary carrying out repairs as
shown in the service and repair manual.
In case of warranty claims all devices are to be sent
to WEINMANN.
In order to handle warranty or goodwill requests
we will require you to submit proof of purchase
(invoice) of the customer.
Repair and maintenance work must be performed
by WEINMANN or knowledgeable, well trained
specialists.
They are responsible for all repairs carried out and all
associated warranties!
When performing maintenance, only genuine
WEINMANN replacement parts ought to be used.
Please consider:
Your customers puts trust in your capabilities just as
much as you trust in WEINMANN.
Note:
Please use the operation manual for the following information about MEDUCORE Easy:
• Safety instructions
•Preparing the device for use
• Operation
• Cleaning and disinfecting while in use
• Warranty
Please note that the operation of devices with and without ILCOR 2005 is different.

4Overview
1. Overview
1Info-button
7Loudspeaker
4Display field: “You can now
touch the patient“
3Display field: “Stand clear of
the patient!”
2Device lid
8LEDs
12 Battery compartment
5Socket for electrode plug
9Carrying handle
10 Shock key
Underside of device:
11 Display:
Shock preperation
17 Battery-Pack/
Rechargeable
Battery-Pack
(optional)
16 Self sticking
defibrillation electrodes
19 Emergency set 20 CD-ROM with software EasyView
6Infra red interface
18 Battery charger
(only in Rechargeable-Pack model)
Underside of device:
13 Maintenance sticker
14 SRC sticker
(only in Germany)
15 Device plaque

Description of Equipment 5
2. Description of Equipment
2.1 Intended use
The MEDUCORE Easy is an automatic external
defibrillator (AED). It has been devised to assist the
user in the resuscitation of patients who show
symptoms of acute cardiovascular arrest (pulseless
ventricular tachycardia pVT or ventricular fibrillation
VF).
The MEDUCORE Easy guides the user through the
resuscitation process with the help of acoustic and
optical instructions. The device conducts an ECG
analysis on patients and, if necessary, makes
preparations for the delivery of an electric shock. The
delivery of a shock is carried out directly by the user,
after the device has prompted to do so.
Only use the device MEDUCORE Easy for the
purposes described below.
2.2 Scope of application
The MEDUCORE Easy has been devised for
application in the heart/lung resuscitation (HLR) of
patients from upwards of 20 kg body weight at the
emergency’s location.
2.3 User qualification
The MEDUCORE Easy may only be used by persons
who hold documented proof of the following
qualifications:
• Training in fundamental, life saving emergency
care including the application of automatic
defibrillators.
• Instructions for the application of the
MEDUCORE Easy carried out by an
WEINMANN authorized person.

6Description of Equipment
2.4 Functional description
The MEDUCORE Easy is compact, light and
ergonomic. The acoustic and optical user instructions
make the operation of the device, to a great extent,
self explanatory.
Persons with a nominal medical knowledge, after a
short instruction, can therefore be in the position to
operate a defibrillator in the case of a heart lung
resuscitation.
Optical and acoustic userguide The acoustic and optical user instructions are made up
of display fields and spoken orders.
After opening the device lid the user is led by
MEDUCORE Easy with the help of detailed spoken
orders through a step by step resuscitation process.
During this process a green and red display field light
up, indicating in which phase of the resuscitation the
patient may be touched or not touched (traffic light
principle).
Metronome function
(only for devices with ILCOR 2005) An activated metronome function gives off an acoustic
metronome signal at a frequency of 100 beats per
minute during the HLR-pause. Carry out the cardiac
massage in rhythm with audible signal tone.
After 30 signal tones a spoken announcement is
issued “Give 2 breaths now” You will now have time
to carry out 2 respiratory sequences, before “Give 30
chest compressions now” is announced and 30 signal
tones are given.
This ordered sequence repeats itself, until the HLR
pause comes to an end and the red display field
(“Stand clear of the patient”) lights up.
If the info button is pressed during the HLR pause, the
info announcement is made. The metronome continues
to run in the background but without an audible tone.
ECG-recording and analysis As soon as the electrodes are placed on the bare
upper body of the patient, the device will
automatically begin with the recording and analysis of
the ECG. The ECG recording and analysis will
continue until the electrodes are removed from the
patient or as soon as the lid of the MEDUCORE Easy
is closed, which results in the device being switched
off.

Description of Equipment 7
Defibrillation If the ECG analysis indicates defibrillation (pulseless
ventricular tachycardia pVT or ventricular fibrillation
VF), the MEDUCORE Easy prepares to deliver a
shock. Afterwards the device instructs the user to
administer a shock.
For other heart rhythms, the device informs the user that
they should carry out a heart-lung revival.
Application documentation The MEDUCORE Easy saves ECG and event data.
The data could later be used e.g. in the follow-up of
treatment. For this, use the documentation and
configurations software EasyView.
Self testing The MEDUCORE Easy initiates a self test at regular
intervals and after every time it is switched on. The
device status is shown via light diodes on its front side.
Self test results can be requested via the documentation
and configuration software EasyView and saved onto
a PC.

8Cleaning and disinfecting instructions
3. Cleaning and disinfecting instructions
Warning!
• The Battery/Rechargeable Battery Pack must be
removed from MEDUCORE Easy before
cleaning.
• Never immerse the MEDUCORE Easy in any
disinfectant or any other liquid. Only carry out
disinfection by wiping over the surface. This can
otherwise lead to damage of the device and
consequently endanger users and patients.
The MEDUCORE Easy can be kept properly clean by
simply wiping to disinfect. Please observe the users
instruction for the disinfectant selected. We
recommend that you wear suitable gloves when
disinfecting the equipment (e.g. household or
disposable gloves).
We recommend that you use TERRALIN disinfectant,
which is available from the Schülke & Mayr
Company, Robert-Koch-Str. 2, D-22851 Norderstedt
(Internet: www.schuelkemayr.de).

Checking the device 9
4. Checking the device
Important!
The device must undergo the following tests after every
repair and every maintenance according to WM 40006,
and the results must be entered into the test records.
Additionally the test can be used for fault finding in the
device.
If you detect errors or deviations from defined values
in the course of your final testing you must not redeploy
MEDUCORE Easy before these errors have been
eliminated.
You can determine possible causes of such errors and
recommended countermeasures by referring to
chapter "7. Malfunctions and Rectification" on
page 22.
We recommend that you generally keep the following
ready for use:
• Emergency-Set WM 15460
• Battery-Pack WM 40155
• Rechargeable Battery-Pack WM 40150
• Electrodes, packed WM 40116
Important!
The electrodes have a limited shelf life. Please make a
note of the expiry date on the packaging.
4.1 Testing parts needed
• Fully charged Rechargeable battery Pack or
Battery-Pack
• Defibrillator-Tester (see also 10.4, page 38)
• IR-Adapter WM 22498
•PC with installed software EasyView WM 40192
• Multimeter, Measuring range up to 20 A
• Battery adapter WM 40008
• Test line MEDUCORE Easy WM 40454

10 Checking the device
4.2 Preparations for testing
1. Boot up PC.
2. Start the PC software.
Overview of software versions:
•EasyView
Reading, editing and saving usage data,
modifying device settings.
•EasyView-Service
Works like EasyView, facility for programming the
serial number.
•EasyView-Light
Works like EasyView; device settings cannot be
modified.
4.3 Entering the device data
Enter the serial number of the device (Device-No.) and
the manufacturing date into the test records.
4.4 Checking the devices self testing
1. Insert rechargeable or Battery-Pack.
2. Open the device lid.
Request:
–The device is giving off a short double peeping
tone.
– All LEDs light up briefly.
– The device announces clearly and completely
the spoken order “This device will assist you.”.
– The green status LED lights up.
3. Close the device lid.
EasyView
EasyView-Service
EasyView-Light

Checking the device 11
4.5 Checking the volume levels
1. Ensure that the volume setting is on "automatic". To
do so, connect the device to EasyView and cor-
rect the setting if necessary.
2. Open the device lid.
3. Create a sound directly over the microphone of
the MEDUCORE Easy, by scratching on the en-
casing for example.
The microphone in the MEDUCORE Easy can be
found between the analysis triangle and pentagon.
Request:
–The volume of the repeated and clearly spoken
order increases.
4.6 Testing the ECG detection, current input, shock button
and shock output
Preparation of the MEDUCORE Easy
1. Connect the rechargeable battery adapter, cur-
rent measuring device and rechargeable battery
or battery pack as illustrated.
2. Install the rechargeable battery adapter in the
MEDUCORE Easy.
Preparation of the defibrillator tester The defibrillator tester emulates a patient impedance
of 50 Ω.
1. Connect MEDUCORE Easy test line WM 40454
to the defibrillator tester as illustrated.
2. Connect the defibrillator tester to a power supply
(battery or mains plug).
3. Switch on the defibrillator tester (sliding switch
POWER in position I).
A self-test is performed. The main menu appears
in the display (Main Menu 1).
Microphone
Main Menu 1
ENRG SYNC PEAK WAVE more

12 Checking the device
4. Press the arrow button under ENERG.
The indicator for the Energy Modus appears in the
display.
5. To simulate venticular fibrillation: Press the arrow
button under WAV until VFIB appears in the
display.
Performing the test 1. Open the lid of the device.
2. Plug the defibrillator tester electrode plug into the
device.
Requirement:
– The device detects ventricular fibrillation and
after a maximum of 10 sec clearly gives the
spoken message "Shock required".
3. The device prepares to give the shock.
Requirement:
– The current consumption of the device is be-
tween 6 A and 12 A.
4. Note the current consumption in the test report.
5. After the spoken message: "Press the flashing
shock key", activate this.
Requirement:
– The shock is triggered by activation of the
shock button.
–The shock is given. The device clearly gives the
spoken message "Shock was delivered".
– The energy discharged is between
168 J ± 10 % (Low Energy). The value is
shown in the display of the defibrillator tester.
Note:
Only the testing of the "Low Energy" shock is necessary.
If it is also required to test the "High Energy", the energy
must be 298 J ± 10 %.
In this case, ventricular fibrillation must be set on the
defibrillator tester as described above. Return to the main
menu via esc.
4.7 Checking the procedure display and capacitor discharge
Note:
Do not press the shock key during this test!
1. Simulate ventricular fibrillation with the defibrilla-
tor-tester (Signal Vfib).
Energy --- J
WAV> ECG90 PLAY HDR esc
Energy --- J
WAV> VFIB PLAY HDR esc
Energy 162 J
WAV> VFIB PLAY HDR esc

Checking the device 13
2. The device makes a clear spoken order “Stand
clear of the patient” and “Analyzing”.
Request:
– All of the LEDs in the red triangle light up.
– The device continues to give spoken orders,
during which all the LEDs on the shock key
arrow are lit up in red.
– All of the LEDs around the shock key flash red.
3. After approx. 15 seconds it is announced that
“Shock was not delivered”.
Request:
– The capacitor is discharged with an audible
sound.
4. Simulate f = 60 bpm with the defibrillator-tester
Sinus EKG.
Request:
– All of the LEDs in the green pentagon light up.
4.8 Checking the info-button and reading contact
1. While the green pentagon is lit up, press the info-
button.
Request:
– The device announces a spoken order similar
to “Device has been in use for…in total
1 shock since device startup”.
2. Pull the electrode plug out of the device.
3. Close the device lid.
Request:
– The device cuts short any spoken order,
extinguishes all process LED lights and leaves
only the green status LED blinking.
– No new spoken order is made.
4.9 Checking the status LEDs
Open the device lid to turn the device on.
Request:
–All of the three Status-LEDs, (red, green, yellow)
light up.
Info-button

14 Checking the device
4.10 Checking the condition of the exterior, the equipment and the
accessories
1. Firstly, carry out a visual test of everything.
Requests:
• Encasing
– Encasing not scratched and without blemishes
– Encasing completely screwed on
– Front film and sticker stuck down firmly and
correctly on the lid
– Labelling OK?
– The loudspeaker opening is free from dirt.
• Electrode connection
– Undamaged
– In working order
• Push buttons
– Undamaged
– Working correctly
• Lid
– Lid not scratched and without blemishes
– Lid is correctly attached, easy to open and
closes firmly
– Functions open, close, switch on are ok.
• Inner part
– The socket for the electrode plug is free from
dirt.
• Rechargeable Battery-Pack
– Completely charged
• Battery-Pack
– Check expiry date (see device sign Battery-
Pack). Insert new Battery-Pack if necessary.
–If the expiry date is not yet reached, then check
the level of charging. Insert battery, open and
close device lid. The green LED must flash; the
yellow LED should not flash.
If these parts have been delivered, check:
• Defibrillation electrodes WM 40116 available.
Check expiry date, if necessary replace.
• Rechargeable Battery-Pack WM 40150
available.
• Battery-Pack WM 40155 available.
• Emergency set WM 15460 available.

Checking the device 15
4.11 Checking the IRDA interface and the software version
1. Check that the interface is working correctly by
retrieving the device data.
Request:
All the device data are displayed.
2. Ensure that a PCB with the latest device software
is installed in the device. This can be done by
comparing the software version displayed with
table (see "12.2 Software" on page 43).
If the software version is no longer current, replace
the PCB with an up-to-date one as described in
section 8.9 and enter the device number as
described.
4.12 Checking the maintenance and safety related check (SRC)
stickers
Check that the maintenance and SRC stickers are
affixed correctly (SRC sticker applies only to
Germany). If repairs have been carried out, then you
should replace the stickers with new ones.
4.13 Preparing a device for dispatch following repair
Conditions The Programme EasyView must be started up and
the PC infrared interface or the infrared adapter
must be aligned with the infrared interface of the
MEDUCORE Easy (see chapter “Operation” in
the PC-software operating instructions EasyView
WM 16880).
Execution 1. Insert Rechargeable Battery or Battery-Pack.
2. Open the device lid.
3. Read off the charge status of the battery pack and
compare it with the value specified in the test
record.
Depending on the Battery-Pack capacity
displayed proceed as follows:
• Capacity is > 50%:
– The Battery-Pack is OK.
• Capacity is < 50%:
– Inform your customer about the charging
level.

16 Checking the device
– Recommend that your customer regularly
checks the charging level.
–Recommend that your customer replaces the
Battery-Pack in good time.
• Capacity is < 15%:
– Inform your customer about the charging
level.
– Recommend that your customer regularly
checks the charging level.
– Offer your customer a new Battery-Pack.
–Recommend that your customer replaces the
Battery-Pack as soon as possible.
• Capacity is < 8%:
– Inform your customer about the charging
level.
– Offer your customer a new Battery-Pack.
– Point out to your customer that the Battery-
Pack should be replaced immediately for
safety reasons.
4. Set the date and time with the help of the
EasyView (see chapter “Operation“ in the operat-
ing instructions for the PC-Software EasyView
WM 16880).
After exchanging the printed circuit
board, if no customer parameter are
known 1. Delete the memory.
2. Enter serial number (Device-No.) (see "4.3 Enter-
ing the device data" on page 10).
After exchanging the printed circuit
board, if customer parameter are
known 1. Programme customer parameter.
2. Delete the memory.
3. Check the selected language version.
Request:
– EasyView-Service must display the selected
language version without any error messages.
Note:
To continue testing, the volume must be set to
"automatic".
Completion 1. Close the device lid.
2. Remove Rechargeable Battery or Battery-Pack
3. To unload the internal remaining charge, open
and close the device lid again.

Checking the device 17
4.14 Documentation
Note down the points 4.3 to 4.12 as well as the test
date and tester number in the test records.

18 Maintenance
5. Maintenance
Note:
After all maintenance and repair work the device must be
tested, as described in chapter „4. Checking the
device“on page 9.
5.1 Intervals
As a preventative maintenance measure every 6 years
the device must be fully checked:
The points of maintenance are as follows:
• Testing for completeness (see chapter 4.10,
page 14)
• Visual test (see chapter 4.10, page 14)
– Mechanical damage
– Electrode connections
– Labelling
• Check the charge levels on the Battery/
Rechargeable Battery (see chapter 5.2, page 18)
• Replace internal battery (see chapter 8.8,
page 29)
• Final check in accordance with test directive
WM 40006 (see chapter 4., page 9)
• Renew maintenance sticker
In Germany a safety related check (SRC) must be
conducted within a statutory limit of 2 years in
accordance with §6 Medicinal Products and Users
Ordinance.
5.2 Check the Battery/Rechargeable Battery.
Conditions The Programme EasyView must be started up and
the PC infrared interface or the infrared adapter
must be aligned with the infrared interface of the
MEDUCORE Easy (see chapter ”Operation“ in
the PC-software operating instructions EasyView
WM 16880).

Maintenance 19
Execution 1. Insert Rechargeable Battery or Battery-Pack
2. Open the device lid.
3. Read off the level of charge of the Battery-Pack
and note in the test records.
Depending on the Battery-Pack capacity
displayed proceed as follows:
• Capacity is > 50%:
– The Battery-Pack is OK.
• Capacity is < 50%:
– Inform your customer about the charging
level.
– Recommend that your customer regularly
checks the charging level.
–Recommend that your customer replaces the
Battery-Pack in good time.
• Capacity is < 15%:
– Inform your customer about the charging
level.
– Recommend that your customer regularly
checks the charging level.
– Offer your customer a new Battery-Pack.
–Recommend that your customer replaces the
Battery-Pack as soon as possible.
• Capacity is < 8%:
– Inform your customer about the charging
level.
– Offer your customer a new Battery-Pack.
– Point out to your customer that the Battery-
Pack should be replaced immediately for
safety reasons.
If required, replace the Battery or charge
Rechargeable Battery
5.3 Renew maintenance sticker
Renew the maintenance sticker (current year
+ 6 years) sticking it to the underside of the device.
• Replace the old maintenance sticker with one
carrying the newly entered data. Cut out the
correct month using a ticket puncher or the point
of some nail scissors. Stick the new maintenance
sticker on the underside of the device.
Maintenance sticker

20 Maintenance
5.4 Disposal
Device
Do not dispose of the device as domestic waste. To
dispose of the device properly, please contact a
licensed and certified electronic waste recycler.
Names and addresses can be obtained from your
Environmental Officer or municipal authorities.
Disposal of batteries
Do not dispose of spent batteries in the domestic
waste. Please either contact WEINMANN or or your
official local public disposal authorities.
