BUILT-IN MODULAR WARMERS
(12”x 27” WITH AUTOMATIC WATER FILL)
12”X27” BUILT-IN MODULAR WARMERS WITH AUTOFILL
I T E M N O .
Features
• All models have the automatic water fill
system that maintains the proper water level
in each pan through the use of a water sensor
and solenoid valve.
• These warmers are able to accommodate four
1/3-size pans up to 6” deep in each well.
• Each well is one-piece, deep-drawn, stainless
steel construction for maximum strength
and durability.
• Fully insulated for greater efficiency.
• A one-inch diameter drain manifold (DM)
is provided with each warmer to allow for
a single drain connection at the left or right
front corner.
• Individual thermostats (T) with positive-off
position give these warmers maximum versatility
on each well.
• Wellslok allows for quick and easy installation in
stainless steel countertops.
• The MOD series warmers are designed for wet
operation only.
• The MOD series Warmers are Underwriters
Laboratories, Inc. LISTED and meet the National
Sanitation Foundation and Canadian standards.
• A one-year warranty against defects covers
parts and labor.
WE L L S M A N U F A C T U R I N G
R A I S I N G T H E S T A N D A R D
WELLS
WELLS MANUFACTURING COMPANY
2 ERIK CIRCLE, PO BOX 280, VERDI, NV 89439 U.S.A. • USA PHONE: [phone] • FAX: [phone]
FOR ORDERS ONLY: [phone] • FAX: [phone] • www.wellsbloomfield.com
A SPECIALTY EQUIPMENT COMPANY • 2000 WELLS MANUFACTU RING • PRINTED IN THE U.S.A. • 8/00 • REV(A) • PART NO. 300748
NOTE: Specifications are subject to change without notice. See installation instructions prior to
installing the unit. This document is not for installation purposes. The Drain Manifold with
Valve (1 inch FPT) is supplied
WE L L S M A N U F A C T U R I N G
WELLS
MODELS
MOD-427TDM/AF, MOD-527TDM/AF
B U I LT- I N M O D U L A R WA R M E R S
W I T H A U TO M AT I C WAT E R F I L L
MOD-427TDM/AF AND MOD-527TDM/AF
E L E C T R I C A L S P E C I F I C AT I O N S :
DIMENSIONS:
C
RR
R
LISTED STD.4 E6070
E6070
INCH
(MM)
Wells 12” x 27” Built-in Modular Warmers with AutoFill easily meet your volume needs, designed
with 33% more capacity than the standard modular warmers. Water Fill System automatically maintains
water at the proper level in all pans at all times, enabling you to serve fresh hot food to every customer
throughout the day.
Specifications
Temperature Settings: OFF/LO to HI
Weights: Lbs. KG
MOD-227 series:
Installed 49 22
Shipping 65 29
MOD-327 series:
Installed 71 32
Shipping 90 41
MOD-427 series:
Installed 97 44
Shipping 112 51
MOD-527 series:
Installed 116 53
Shipping 136 62
Accessories / Options
Wellslok Extension Kit, designed for installation in a
variety of countertops up to 1” thick, refer to installation
instructions, 22593
Drain Screen, 21709
Optional 72” Wiring, thermostatically
controlled warmers, priced per well
(standard length is 24”)
MOD-427TDM/AF
MOD-427TDM/AF 208 4960 14.5 14.5 9.8 23.8 NONE
MOD-427TDM/AF 240 6600 17.8 17.8 11.3 27.5 NONE
MOD-527TDM/AF 208 6200 19.5 14.6 14.6 29.8 NONE
MOD-527TDM/AF 240 8250 22.1 16.9 16.9 34.4 NONE
MODELS VOLTS WATTS AMPS PER LINE PHASE 3 AMPS SINGLE POWER
PHASE SUPPLY CORD
L1 L2 L3
MINIMUM CLEARANCE REQUIRED FROM ALL
UNITS TO THE NEAREST SURFACE.
BACK SIDE BOTTOM FRONT
1 1 6 3/4 6
(25) (25) (171) (152)
(248)
9 3/4
(44)
1 3/4
(197)
7 3/4
(356)
14
(356)
14
(159)
6 1/4
(457)
18
(776)
30 9/16
(57)
2 1/4
(1461)
57 1/2
CONNECTION
WATER LINE
1/4'' FPT
OF MANIFOLD
EACH END
1'' FPT
CONNECTION
1'' CONDUIT
MODEL
MOD-427TDM/AF
MODEL
MOD-527TDM/AF
(57)
2 1/4
(248)
9 3/4
(44)
1 3/4
(197)
7 3/4
(1816)
71 1/2
(776)
30 9/16
(889)
35
(159)
6 1/4
(356)
14
(356)
14
CONNECTION
1'' CONDUIT
OF MANIFOLD
EACH END
1'' FPT
CONNECTION
WATER LINE
1/4'' FPT

WELLS MANUFACTURING COMPANY
2 ERIK CIRCLE, PO BOX 280, VERDI, NV 89439 U.S.A. • USA PHONE: [phone] • FAX: [phone]
FOR ORDERS ONLY: [phone] • FAX: [phone] • www.wellsbloomfield.com
A SPECIALTY EQUIPMENT COMPANY • 2000 WELLS MANUFACTU RING • PRINTED IN THE U.S.A. • 8/00 • REV(A) • PART NO. 300748
NOTE: Specifications are subject to change without notice. See installation instructions prior to
installing the unit. This document is not for installation purposes. The Drain Manifold with
Valve (1 inch FPT) is supplied
WE L L S M A N U F A C T U R I N G
WELLS
MODEL
MOD-227TDM/AF
B U I LT- I N M O D U L A R WA R M E R
W I T H A U T O M AT I C WAT E R F I L L
M O D - 2 2 7 T D M / A F E L E C T R I C A L S P E C I F I C AT I O N S :
DIMENSIONS:
C
RR
R
LISTED STD.4 E6070
E6070
INCH
(MM)
MOD-227TDM/AF 208 2480 6.0 6.0 10.3 11.9 NONE
MOD-227TDM/AF 240 3300 6.9 6.9 11.9 13.8 NONE
MODELS VOLTS WATTS AMPS PER LINE PHASE 3 AMPS SINGLE POWER
PHASE SUPPLY CORD
L1 L2 L3
MINIMUM CLEARANCE REQUIRED FROM ALL
UNITS TO THE NEAREST SURFACE.
BACK SIDE BOTTOM FRONT
1 1 6 3/4 4 1/8
(25) (25) (171) (105)
(248)
9 3/4
(44)
1 3/4
(197)
7 3/4
(749)
29 1/2
(57)
2 1/4
(776)
30 9/16
(457)
18
(159)
6 1/4
(356)
14
CONNECTION
1'' CONDUIT
OF MANIFOLD
EACH END
1'' FPT
CONNECTION
WATER LINE
1/4'' FPT
WELLS MANUFACTURING COMPANY
2 ERIK CIRCLE, PO BOX 280, VERDI, NV 89439 U.S.A. • USA PHONE: [phone] • FAX: [phone]
FOR ORDERS ONLY: [phone] • FAX: [phone] • www.wellsbloomfield.com
A SPECIALTY EQUIPMENT COMPANY • 2000 WELLS MANUFACTU RING • PRINTED IN THE U.S.A. • 8/00 • REV(A) • PART NO. 300748
NOTE: Specifications are subject to change without notice. See installation instructions prior to
installing the unit. This document is not for installation purposes. The Drain Manifols with
Valve (1 inch FPT) is supplied
WE L L S M A N U F A C T U R I N G
WELLS
MODEL
MOD-327TDM/AF
B U I LT- I N M O D U L A R WA R M E R
W I T H A U T O M AT I C WAT E R F I L L
M O D - 3 2 7 T D M / A F E L E C T R I C A L S P E C I F I C AT I O N S :
DIMENSIONS:
C
RR
R
LISTED STD.4 E6070
E6070
INCH
(MM)
MOD-327TDM/AF 208 3720 10.3 10.3 10.3 17.9 NONE
MOD-327TDM/AF 240 4950 11.9 11.9 11.9 20.6 NONE
MODELS VOLTS WATTS AMPS PER LINE PHASE 3 AMPS SINGLE POWER
PHASE SUPPLY CORD
L1 L2 L3
MINIMUM CLEARANCE REQUIRED FROM ALL
UNITS TO THE NEAREST SURFACE.
BACK SIDE BOTTOM FRONT
1 1 6 3/4 4 1/8
(25) (25) (171) (105)
(44)
1 3/4
(248)
9 3/4
(197)
7 3/4
(356)
14
(159)
6 1/4
(889)
35
(776)
30 9/16
(57)
2 1/4
(1105)
43 1/2
CONNECTION
WATER LINE
1/4'' FPT
OF MANIFOLD
EACH END
1'' FPT
CONNECTION
1'' CONDUIT

WELLS MANUFACTURING COMPANY
2 ERIK CIRCLE, PO BOX 280, VERDI, NV 89439 U.S.A. • USA PHONE: [phone] • FAX: [phone]
FOR ORDERS ONLY: [phone] • FAX: [phone] • www.wellsbloomfield.com
A SPECIALTY EQUIPMENT COMPANY • 2000 WELLS MANUFACTU RING • PRINTED IN THE U.S.A. • 8/00 • REV(A) • PART NO. 300748
NOTE: Specifications are subject to change without notice. See installation instructions prior to
installing the unit. This document is not for installation purposes. The Drain Manifold with
Valve (1 inch FPT) is supplied
WE L L S M A N U F A C T U R I N G
WELLS
MODEL
MOD-227TDM/AF
B U I LT- I N M O D U L A R WA R M E R
W I T H A U T O M AT I C WAT E R F I L L
M O D - 2 2 7 T D M / A F E L E C T R I C A L S P E C I F I C AT I O N S :
DIMENSIONS:
C
RR
R
LISTED STD.4 E6070
E6070
INCH
(MM)
MOD-227TDM/AF 208 2480 6.0 6.0 10.3 11.9 NONE
MOD-227TDM/AF 240 3300 6.9 6.9 11.9 13.8 NONE
MODELS VOLTS WATTS AMPS PER LINE PHASE 3 AMPS SINGLE POWER
PHASE SUPPLY CORD
L1 L2 L3
MINIMUM CLEARANCE REQUIRED FROM ALL
UNITS TO THE NEAREST SURFACE.
BACK SIDE BOTTOM FRONT
1 1 6 3/4 4 1/8
(25) (25) (171) (105)
(248)
9 3/4
(44)
1 3/4
(197)
7 3/4
(749)
29 1/2
(57)
2 1/4
(776)
30 9/16
(457)
18
(159)
6 1/4
(356)
14
CONNECTION
1'' CONDUIT
OF MANIFOLD
EACH END
1'' FPT
CONNECTION
WATER LINE
1/4'' FPT
WELLS MANUFACTURING COMPANY
2 ERIK CIRCLE, PO BOX 280, VERDI, NV 89439 U.S.A. • USA PHONE: [phone] • FAX: [phone]
FOR ORDERS ONLY: [phone] • FAX: [phone] • www.wellsbloomfield.com
A SPECIALTY EQUIPMENT COMPANY • 2000 WELLS MANUFACTU RING • PRINTED IN THE U.S.A. • 8/00 • REV(A) • PART NO. 300748
NOTE: Specifications are subject to change without notice. See installation instructions prior to
installing the unit. This document is not for installation purposes. The Drain Manifols with
Valve (1 inch FPT) is supplied
WE L L S M A N U F A C T U R I N G
WELLS
MODEL
MOD-327TDM/AF
B U I LT- I N M O D U L A R WA R M E R
W I T H A U T O M AT I C WAT E R F I L L
M O D - 3 2 7 T D M / A F E L E C T R I C A L S P E C I F I C AT I O N S :
DIMENSIONS:
C
RR
R
LISTED STD.4 E6070
E6070
INCH
(MM)
MOD-327TDM/AF 208 3720 10.3 10.3 10.3 17.9 NONE
MOD-327TDM/AF 240 4950 11.9 11.9 11.9 20.6 NONE
MODELS VOLTS WATTS AMPS PER LINE PHASE 3 AMPS SINGLE POWER
PHASE SUPPLY CORD
L1 L2 L3
MINIMUM CLEARANCE REQUIRED FROM ALL
UNITS TO THE NEAREST SURFACE.
BACK SIDE BOTTOM FRONT
1 1 6 3/4 4 1/8
(25) (25) (171) (105)
(44)
1 3/4
(248)
9 3/4
(197)
7 3/4
(356)
14
(159)
6 1/4
(889)
35
(776)
30 9/16
(57)
2 1/4
(1105)
43 1/2
CONNECTION
WATER LINE
1/4'' FPT
OF MANIFOLD
EACH END
1'' FPT
CONNECTION
1'' CONDUIT

BUILT-IN MODULAR WARMERS
(12”x 27” WITH AUTOMATIC WATER FILL)
12”X27” BUILT-IN MODULAR WARMERS WITH AUTOFILL
I T E M N O .
Features
• All models have the automatic water fill
system that maintains the proper water level
in each pan through the use of a water sensor
and solenoid valve.
• These warmers are able to accommodate four
1/3-size pans up to 6” deep in each well.
• Each well is one-piece, deep-drawn, stainless
steel construction for maximum strength
and durability.
• Fully insulated for greater efficiency.
• A one-inch diameter drain manifold (DM)
is provided with each warmer to allow for
a single drain connection at the left or right
front corner.
• Individual thermostats (T) with positive-off
position give these warmers maximum versatility
on each well.
• Wellslok allows for quick and easy installation in
stainless steel countertops.
• The MOD series warmers are designed for wet
operation only.
• The MOD series Warmers are Underwriters
Laboratories, Inc. LISTED and meet the National
Sanitation Foundation and Canadian standards.
• A one-year warranty against defects covers
parts and labor.
WE L L S M A N U F A C T U R I N G
R A I S I N G T H E S T A N D A R D
WELLS
WELLS MANUFACTURING COMPANY
2 ERIK CIRCLE, PO BOX 280, VERDI, NV 89439 U.S.A. • USA PHONE: [phone] • FAX: [phone]
FOR ORDERS ONLY: [phone] • FAX: [phone] • www.wellsbloomfield.com
A SPECIALTY EQUIPMENT COMPANY • 2000 WELLS MANUFACTU RING • PRINTED IN THE U.S.A. • 8/00 • REV(A) • PART NO. 300748
NOTE: Specifications are subject to change without notice. See installation instructions prior to
installing the unit. This document is not for installation purposes. The Drain Manifold with
Valve (1 inch FPT) is supplied
WE L L S M A N U F A C T U R I N G
WELLS
MODELS
MOD-427TDM/AF, MOD-527TDM/AF
B U I LT- I N M O D U L A R WA R M E R S
W I T H A U T O M AT I C WAT E R F I L L
MOD-427TDM/AF AND MOD-527TDM/AF
E L E C T R I C A L S P E C I F I C AT I O N S :
DIMENSIONS:
C
RR
R
LISTED STD.4 E6070
E6070
INCH
(MM)
Wells 12” x 27” Built-in Modular Warmers with AutoFill easily meet your volume needs, designed
with 33% more capacity than the standard modular warmers. Water Fill System automatically maintains
water at the proper level in all pans at all times, enabling you to serve fresh hot food to every customer
throughout the day.
Specifications
Temperature Settings: OFF/LO to HI
Weights: Lbs. KG
MOD-227 series:
Installed 49 22
Shipping 65 29
MOD-327 series:
Installed 71 32
Shipping 90 41
MOD-427 series:
Installed 97 44
Shipping 112 51
MOD-527 series:
Installed 116 53
Shipping 136 62
Accessories / Options
Wellslok Extension Kit, designed for installation in a
variety of countertops up to 1” thick, refer to installation
instructions, 22593
Drain Screen, 21709
Optional 72” Wiring, thermostatically
controlled warmers, priced per well
(standard length is 24”)
MOD-427TDM/AF
MOD-427TDM/AF 208 4960 14.5 14.5 9.8 23.8 NONE
MOD-427TDM/AF 240 6600 17.8 17.8 11.3 27.5 NONE
MOD-527TDM/AF 208 6200 19.5 14.6 14.6 29.8 NONE
MOD-527TDM/AF 240 8250 22.1 16.9 16.9 34.4 NONE
MODELS VOLTS WATTS AMPS PER LINE PHASE 3 AMPS SINGLE POWER
PHASE SUPPLY CORD
L1 L2 L3
MINIMUM CLEARANCE REQUIRED FROM ALL
UNITS TO THE NEAREST SURFACE.
BACK SIDE BOTTOM FRONT
1 1 6 3/4 6
(25) (25) (171) (152)
(248)
9 3/4
(44)
1 3/4
(197)
7 3/4
(356)
14
(356)
14
(159)
6 1/4
(457)
18
(776)
30 9/16
(57)
2 1/4
(1461)
57 1/2
CONNECTION
WATER LINE
1/4'' FPT
OF MANIFOLD
EACH END
1'' FPT
CONNECTION
1'' CONDUIT
MODEL
MOD-427TDM/AF
MODEL
MOD-527TDM/AF
(57)
2 1/4
(248)
9 3/4
(44)
1 3/4
(197)
7 3/4
(1816)
71 1/2
(776)
30 9/16
(889)
35
(159)
6 1/4
(356)
14
(356)
14
CONNECTION
1'' CONDUIT
OF MANIFOLD
EACH END
1'' FPT
CONNECTION
WATER LINE
1/4'' FPT
