Wesco WS2355KU User manual

Cordless Oscillation Tool EN
WS2355KU
(CMT18W)
2

1 2 3
45
67
8

Fig.A1 Fig.A2
Fig.A3 Fig.B
Fig.C Fig.D
Fig.E1 Fig.E2
Fig.F Fig.G
Fig.I
Fig.H
3
2
2
5
4
1
1
ON OFF
100%
0%

Fig.A1 Fig.A2
Fig.A3 Fig.B
Fig.C Fig.D
Fig.E1 Fig.E2
Fi
g.F Fig.G
Fig.I
Fi
g.H
3
2
2
5
4
1
1
ON OFF
100%
0%

5
EN
PRODUCT SAFETY
WARNING: Some dust created by power sanding,
sawing, grinding, drilling and other construction
activities contains chemicals known to the state
of California to cause cancer, birth defects or other
reproductive harm. Some examples of these chemicals
are:
• Lead from lead-based paints;
• Crystalline silica from bricks and cement and
other masonry products;
• Arsenic and chromium from chemically-treated
lumber.
Your risk from these exposures varies, depending on
how often you do this type of work. To reduce your
exposure to these chemical: work in a well ventilated
area, and work with approved safety equipment, such as
those dust masks that are specially designed to filter out
microscopic particles.
WARNING: This product can expose you to
chemicals including lead and Di(2-ethylhexyl)
phthalate (DEHP) which are known to the State
of California to cause cancer and birth defects or
other reproductive harm. For more information go to
www.P65Warnings.ca.gov.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING: Read all safety warnings, instructions, illustrations and specifications
provided with this power tool. Failure to follow all
instructions listed below may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk
of electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase
the risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools may
result in serious personal injury.
b) Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached
to a rotating part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from

6EN
moving parts. Loose clothes, jewellery or long hair can
be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of a second.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be
repaired.
c) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting
the power tool accidentally.
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
e) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused
by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a hazardous
situation.
h) Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
5) BATTERY TOOL USE AND CARE
a) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with
another battery pack.
b) Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
c) When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause burns
or a fire.
d) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or burns.
e) Do not use a battery pack or tool that is damaged or
modified. Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire, explosion or risk
of injury.
f) Do not expose a battery pack or tool to fire
or excessive temperature. Exposure to fire or
temperature above 130 °C may cause explosion.
g) Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
range specified in the instructions. Charging
improperly or at temperatures outside the specified
range may damage the battery and increase the risk of
fire.
6) SERVICE
a) Have your power tool serviced by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the power tool is
maintained.
b) Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
SAFETY INSTRUCTION FOR CUTTING
1. Hold the power tool by insulated gripping
surfaces, when performing an operation where
the cutting accessory may contact hidden wiring.
Cutting accessory contacting a “live” wire may make
exposed metal parts of the power tool “live” and could
give the operator an electric shock.
2. Use clamps or another practical way to secure and

7
EN
support the workpiece to a stable platform. Holding
the work by hand or against your body leaves it unstable
and may lead to loss of control.
SAFETY WARNINGS FOR BATTERY PACK
a) Do not dismantle, open or shred battery pack.
b) Do not expose battery pack to heat or fire. Avoid
storage in direct sunlight.
c) Do not short-circuit a battery pack. Do not store
battery packs haphazardly in a box or drawer
where they may short-circuit each other or be
short-circuited by other metal objects. When battery
pack is not in use, keep it away from other metal objects,
like paper clips, coins, keys, nails, screws or other
small metal objects, that can make a connection from
one terminal to another. Shorting the battery terminals
together may cause burns or fire.
d) Do not remove battery pack from its original
packaging until required for use.
e) Do not subject battery pack to mechanical shock.
f) In the event of battery leaking, do not allow the
liquid to come in contact with the skin or eyes. If
contact has been made, wash the affected area
with copious amounts of water and seek medical
advice.
g) Observe the plus (+) and minus (–) marks on the
battery back and equipment and ensure correct
use.
h) Do not use any battery pack which is not designed
for use with the equipment.
i) Keep battery pack out of the reach of children.
j) Seek medical advice immediately if a cell or battery
has been swallowed.
k) Always purchase the battery pack recommended
by the device manufacturer for the equipment.
l) Keep battery pack clean and dry.
m) Wipe the battery pack terminals with a clean dry
cloth if they become dirty.
n) Battery pack needs to be charged before use.
Always use the correct charger and refer to the
manufacturer’s instructions or equipment manual
for proper charging instructions.
o) Do not leave battery pack on prolonged charge
when not in use.
p) After extended periods of storage, it may
be necessary to charge and discharge the
battery pack several times to obtain maximum
performance.
q) Battery pack gives its best performance when it is
operated at normal room temperature 20°C ± 5°C
(68°F ± 9°F ).
r) When disposing of battery packs, keep battery
packs of different electrochemical systems
separate from each other.
s) Recharge only with the charger specified by
manufacture. Do not use any charger other
than that specifically provided for use with the
equipment. A charger that is suitable for one type of
battery pack may create a risk of fire when used with
another battery pack.
t) Retain the original product literature for future
reference.
u) Use only the battery pack in the application for
which it was intended.
v) Remove the battery pack from the equipment when
not in use.
w) Dispose of properly.
SAFETY WARNINGS FOR BATTERY CHARGER
Information for radiated emission
This device complies with Canadian ICES-001.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.
WARNING: Changes or modifications to this unit not
expressly approved by the party responsible for
compliance
could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.

8EN
• Consult the dealer or an experienced radio/TV
technician for help.
SYMBOLS
To reduce the risk of injury, user must read
instruction manual
Warning
Wear ear protection
Wear eye protection
Wear dust mask
Batteries may enter water cycle if disposed
improperly, which can be hazardous for
ecosystem. Do not dispose of waste
batteries as unsorted municipal waste.
Do not burn
Li-Ion battery, battery must be recycled
POSITEC Inc. has established a partnership with
the RBRC Corporation to recycle any Positec
batteries with the RBRC-call2recycle seal. For
environmental protection, please do not discard
batteries in the trash. After the batteries’
life cycle is ended, then please call 1-800-
822-8837 for a free service that will properly
dispose of the battery.

9
EN
COMPONENT LIST
1. Tool-less accessory clamping lever
2. On/off switch
3. Battery pack release button
4. Battery pack
5. Variable speed control
6. Venting slot
7. LED light
8. Flange
TECHNICAL DATA
Type WS2355KU (2355 - designation of machinery, representative of cordless multi- function tool)
Voltage 20V Max*
No load speed 5000-20000/min
Oscillations angle 3.0°
Machine weight 2.65lbs
Battery capacity (WS9970) 2.0Ah Li-ion
Charger Input (WS9924U) 120V~60Hz, 55W
Charger Output 20 V 2.0A
Charging time 1hr
Charger Protection class /II
* Voltage measured without workload. Initial battery voltage reaches maximum of 20 volts. Nominal voltage is 18 volts.
ACCESSORIES
Battery pack (WS9970) 1
Charger (WS9924U) 1
1-1/8’’ (28mm) standard end cut blade 1
1-1/4” (32mm) standard end cut blade 1
Rigid scraping blade 1
Sanding pad 1
Sanding paper (60 grit) 4
Sanding paper (80 grit) 4
Sanding paper (120 grit) 4
We recommend that you purchase your accessories listed in the above list from the same store that sold you the tool. Refer to
the accessory packaging for further details. Store personnel can assist you and offer advice.

10 EN
OPERATION INSTRUCTIONS
NOTE: Before using the tool, read the instruction book carefully.
INTENDED USE
The power tool is intended for sawing and separating
wooden materials, plastic, plaster, non-ferrous metals and
fasteners (e.g. nails and clamps) as well as for working on
soft wall tiles and for dry grinding of small surfaces. It is
especially suitable for working close to edges and for flush
cutting.
ASSEMBLY
1. MOUNTING THE ACCESSORIES
WARNING: Before mounting or replacing
application tools or accessories, remove the
battery pack. This preventative safety measure
eliminates danger from accidentally starting the power
tool.
WARNING: For all work or when changing
accessories, always wear protective gloves.
Avoid danger of injury from the sharp edges of the
accessories. Accessories can become very hot while
working, presenting danger of burns!
WARNING: To reduce the risk of injury, do not let
the sharp side of the accessory face back toward
the user’s hand.
The tool free system makes you change the accessories
without using an allen key.
- Mounting the end cut blade (See Fig. A1-A3)
1) Flip the tool-less accessory clamping lever forward
to the open position.
2) Rotate the lever counterclockwise to loosen the
flange.
3) Insert the blade onto the accessory Interface, then
press down the flange with finger to keep blade
temporarily secure.
4) Rotate the lever clockwise until accessory is
tightened securely.
5) Flip lever back down.
6) Return lever to seated position.
- Mounting the rigid scraping blade
Follow the steps of mouting the end cut blade.
2. MOUNTING THE SANDING PAPER (SEE FIG. B)
1) Mount the sanding pad following the steps of
mounting the end cut blade.
2) Align the sanding paper and press it onto the
sanding pad by hand.
3) Firmly press the power tool with the sanding
paper against a flat surface and briefly switch the
power tool on. This provides for good adhesion and
prevents premature wear.
4) If one point has become worn, pull off the sanding
paper, turn it 120° and place it on again.
BEFORE PUTTING INTO OPERATION
1. CHARGING THE BATTERY
NOTE:
a) Do not use any charger other than that specifically
provided for use with the equipment.
b) If the battery pack is very hot you must remove your
battery pack from the charger and allow time for the
battery to cool down before recharging.
c) The battery in your new tool is not charged when it
leaves the plant. Therefore it must be full charged
before using the first time
d) Please charge the battery to reach full or no less
than half charge before storage. If the tool will not
be used for long periods of time, charge the battery
every 3-6 months Charging procedure.
CHARGING PROCEDURE (SEE FIG. C)
1) Connect the battery charger to the power supply and
the indicator light should turn to green.
2) Slide the charger base on the battery pack to make
connections and the indicator light will turn red to
show that the charging has started.
3) When charging is completed, the light will turn to
green. The pack is now fully charged, unplug the
charger and remove the battery pack.
WARNING: When battery charge runs out
after continuously use or exposure to direct
sunlight or heat, allow time for the tool to cool down
before re-charging to achieve the full charge.
Charging indicator
Light Status
Red ON Charging
Green ON Fully charged
2. CHECKING THE POWER CONDITION OF BATTERY
PACK (SEE FIG. D)
The battery level can be known from the battery
indicator light by pressing the button beside the lights.
3. TO REMOVE THE BATTERY PACK (SEE FIG. E1)
Depress the battery pack release button firmly first and
then slide the battery pack out from your tool.

11
EN
4. TO INSTALL THE BATTERY PACK (SEE FIG. E2)
Slide the fully charged battery pack onto the tool with
sufficient force until it clicks into position.
OPERATION
1. ON/OFF SWITCH (SEE FIG. F)
To start the machine, push the On/Off switch forward so
that the “1” mark is indicated on the switch.
To switch off the machine, push the On/Off switch toward
the rear so that the “O” mark is indicated on the switch.
2. VARIABLE SPEED CONTROL (SEE FIG. G)
Select oscillation frequency (speed) while the motor is
running.
The variable speed control can be used to set the optimum
oscillating frequency according to the accessories used and
the respective application.
High oscillation frequency: Sanding, sawing, rasping and
polishing stone and metal.
Low oscillation frequency: Polishing varnishes.
3. LED LIGHT (SEE FIG. H)
The LED light allows you to keep a clear view under less
illuminated circumstances. To turn on the light simply press
the on/off switch. When you release the on/off switch, the
light will be off.
4. SELECTING AN APPLICATION TOOL (SEE FIG. I)
Please observe the application tools intended for your
machine. Do not use these application tools are not intended
for this machine.
WORKING HINTS FOR YOUR CORDLESS
RECIPROCATING SAW
1. If your power tool becomes too hot, especially when
used at low speed, set the speed to maximum and
run it with no load for 2-3 minutes to cool the motor.
Avoid prolonged usage at very low speeds. Always
keep the blade sharp.
2. Always ensure the work-piece is firmly held or
clamped to prevent movement.
3. Any movement of the material may affect the quality
of the cutting or sanding finish.
4. Start your tool before working and turn it off only
after you stop working.
5. Do not start sanding without having the sandpaper
fitted.
6. Do not allow the sandpaper to wear away , it will
damage the sanding pad. The guarantee does not
cover sanding pad wear and tear.
7. Use coarse grit paper to sand rough surfaces,
medium grit for smooth surfaces and fine grit for
finishing surfaces. If necessary, first make a test run
on scrap material.
8. Excessive force will reduce the working efficiency
and cause motor overload. Replacing the accessory
regularly will maintain optimum working efficiency.
MAINTAINACE
Remove the battery pack from the tool before carrying
out any adjustment, servicing or maintenance.
Your power tool requires no additional lubrication or
maintenance.
There are no user serviceable parts in your power tool.
Never use water or chemical cleaners to clean your power
tool. Wipe clean with a dry cloth. Always store your power
tool in a dry place. Keep the motor ventilation slots clean.
Keep all working controls free of dust. Occasionally you may
see sparks through the ventilation slots. This is normal and
will not damage your power tool.
Remove the battery pack from the tool if the tool is not used
for more than 24 hours.
For Battery tools
The ambient temperature range for the use and storage of
tool and battery is 0oC (44.6oF) - 45oC (113oF).
The recommended ambient temperature range for the
charging system during charging is 0oC (44.6oF)-40oC
(104oF).

12 EN
APPLICATION
WARNING: The sawing teeth are very sharp. Do not touch during mounting and application. The workpiece
must be clamped tightly before it is cut.
Pic Description Application
Sawing
Universal Metal/Wood End Cut Blade Wood, plastic, fiberglass, nails, non-ferrous
metals, thin sheet metal, hardened fillers
Standard Wood End Cut Blade Wood, plastic, drywall
Precision Wood Cut Blade Wood, soft plastics
Sanding
Sanding Pad (Perforated) Wood, plastic, hardened fillers
Scraping
Rigid Scraper Blade Old paint, hardened adhesives, caulk, carpet
NOTE: When plunging and sawing use a slight pendulum motion, to allow sufficient chip removal. The saw blade lasts
longer if the wear is distributed evenly. To ensure an even distribution, loosen the saw blade, rotate it and retighten
firmly.
Cut/Sand with a constant movement and light pressure. Heavy pressure does not increase the cut/removal rate - the
accessory merely wears faster. Excessive use and heat build up drastically reduces the life of saw blades.

13
EN
FCC Part 15
Supplier’s Declaration of Conformity
Product Description: Battery charger
Model Number: WS9924U
Trade Name: WESCO
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.
Responsible Party :
Positec USA, Inc.
10130 Perimeter Parkway, Charlotte, NC 28216 USA
Tel.: [phone]
Fax: [phone]
