Whalen WMFP41AE-13 User manual

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2018-09-05 Rev. 0001-C
50" Media Fireplace
Stock # WMFP41AE-13
# WMFP41AE-13E
ADULT ASSEMBLY REQUIRED
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our customer service number and have your instructions
and parts list ready to provide the model name, part name or factory number:
866-942-5362
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
www.whalenstyle.com
Or e-mail your request to [e-mail]
LOT NUMBER:
DATE PURCHASED: / /

2
QUALITY GUARANTEE
We are confident that you will be delighted with your Whalen Furniture purchase.
Should this product be defective in workmanship or materials or fail under normal use, we will
repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is
designed to meet your highest expectations. We guarantee that you will immediately see the value of
our fine furniture.
This warranty gives you specific legal rights and you may also have other rights which vary from
State to State.
Customer Service: 866-942-5362
8:30 a.m. - 4:30 p.m., PST, Monday to Friday
www.whalenstyle.com
MANUFACTURER: Whalen Furniture Manufacturing
CATALOG: 50" Media Fireplace
MODEL #: WMFP41AE-13 / WMFP41AE-13E
MADE IN CHINA
THIS UNIT IS NOT INTENDED FOR USE WITH CRT TVS. USE ONLY WITH FLAT
PANEL TVS AND AUDIO/VIDEO EQUIPMENT MEETING RECOMMENDED SIZE AND WEIGHT
LIMITS. NEVER USE WITH LARGER/HEAVIER THAN RECOMMENDED FLAT PANEL TVS OR
EQUIPMENT. TO AVOID INSTABILITY, PLACE FLAT PANEL TV IN THE CENTER OF THE UNIT; THE
BASE OF THE TELEVISION MUST BE ABLE TO REST ON THE SUPPORTING SURFACE OF THE
UNIT WITHOUT OVER-HANGING THE EDGES. IMPROPERLY POSITIONED FLAT PANEL TVS, OR
FLAT PANEL TVS INCLUDING OTHER EQUIPMENT THAT EXCEED RECOMMENDED SIZE AND
WEIGHT LIMITS COULD FALL OFF OR BREAK THE UNIT, CAUSING POSSIBLE SERIOUS INJURY.
M A X I M U M R E C O M M E N D E D W E I G H T L O A D S
FITS UP TO MOST 50” FLAT PANEL TVs
MAXIMUM LOAD 135 lb. (61.2 kg)
MAXIMUM LOAD 50 lb. (22.7 kg)
PLACE TV BEHIND THE STOPPER

3
IMPORTANT
Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non-
abrasive surface. You will need the parts identified on page 4 and 5 of this instruction manual.
NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH DOWELS. EXCESS GLUE CAN BE WIPED
OFF WITH DAMP CLOTH.
Insert the Dowel at least half way by tapping lightly with a rubber mallet, IF NECESSARY.
CAM LOCK SYSTEM OPERATION
HOW THE KNOCK DOWN (KD) ASSEMBLY SYSTEM WORKS
1. Screw the Cam Bolt into the threaded inserts on the panel. Connect both panels together; making sure Cam
Bolt goes into the pre-drilled hole on the end of panel for Cam Lock.
2. Insert the Cam Lock into the pre-drilled large hole on the panel. Make sure the arrow on the face of Cam
Lock faces out and points towards Cam Bolt.
3. Take a Phillips screwdriver and rotate the Cam Lock clockwise to lock the Cam Bolt in place.
4. Plug the Cam Lock Cover into the cross slot of the Cam Lock to conceal the Cam.
You are now ready to assemble the KD unit.
XX
FINAL
1 2 43

4
Parts and Hardware List
Please read completely through the instructions and verify that all listed parts and hardware are present
before beginning assembly.
A- Top Panel (Qty. 1) B- Center Shelf (Qty. 1) C- Bottom Panel (Qty. 1)
D- Upper Side Panel E- Upper Front Panel F- Left Lower Side Panel
(Qty. 2) (Qty. 2) (Qty. 1)
G- Right Lower Side Panel H- Left Lower Front Panel I- Right Lower Front Panel
(Qty. 1) (Qty. 1) (Qty. 1)
J- Middle Crossbar Assembly K- Bottom Front Molding L- Bottom Front Stretcher
(Qty. 1) (Qty. 1) (Qty. 1)
M- Bottom Back Stretcher (Qty. 1) N- Back Panel (Qty. 1)

5
Parts and Hardware List
Please read completely through the instructions and verify that all listed parts and hardware are present
before beginning assembly.
O- Stop Rail (Qty. 1) Fireplace Insert (Qty. 1)
(1) Cam Lock (2) Cam Bolt (3) M8 x 30 mm Wood Dowel
(Qty. 45+2 extra) (Qty. 45+2 extra) (Qty. 36+1 extra)
(4) M8 x 20 mm Wood Dowel (5) M3.5 x 12 mm Flat Head Screw (6) M4 x 25 mm Screw
(Qty. 4+1 extra) (Qty. 4+1 extra) (Qty. 10+1 extra)
(7) M4 x 50 mm Screw (8) M3.5 x 15 mm Washer Head Screw (9) Metal Bracket
(Qty. 8+1 extra) (Qty. 16+1 extra) (Qty. 2)
(10) Cam Lock Cover (Qty. 12+1 extra) Glue (Qty. 2)
Touch-up Pen (Qty. 1) Tipping Restraint Hardware Kit (Qty. 2)
(Included in plastic bag)
Tools required: Phillips screwdriver and rubber mallet (not provided).

6
Assembly Instructions
1. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a
carpeted floor or the empty carton to avoid any scratch.
2. Securely screw the Cam Bolts (2) into the designated small holes on the Top Panel (A), Bottom Panel
(C) and Lower Side Panels (F and G) using a Phillips screwdriver.
2
A
C
F
G
Cam Bolt
(18 used in this step)
②

7
Assembly Instructions
3. Securely screw the Cam Bolts (2) into the designated small holes on the Front Panels (E, H and I).
H
I
E
E2
Cam Bolt
(10 used in this step)
②

8
Assembly Instructions
4. Securely screw seventeen Cam Bolts (2) into the designated small holes on the Center Shelf (B) on both
sides.
2
B
B
Cam Bolt
(17 used in this step)
②

9
Assembly Instructions
5. Glue two 30 mm Wood Dowels (3) into the inner holes of the Middle Crossbar Assembly (J) and attach
it to the Center Shelf (B) by engaging three Cam Locks (1) (Refer to page 3 on Cam Lock system
operation supplement).
B
J
3
1
3
Cam Lock
(3 used in this step)
①
M8 x 30 mm Wood Dowel
(2 used in this step)
③

10
Assembly Instructions
6. Attach the Bottom Back Stretcher (M) to the Bottom Panel (C) with two 30 mm Wood Dowels (3) and
three Cam Locks (1).
3
3
1
1
C
M
Cam Lock
(3 used in this step)
①
M8 x 30 mm Wood Dowel
(2 used in this step)
③

11
Assembly Instructions
7. Attach the Left Lower Front Panel (H) to the Left Lower Side Panel (F) with two 30 mm Wood Dowels
(3) and three Cam Locks (1).
8. Repeat the same procedure to combine the Right Lower Front Panel (I) with the Right Lower Side Panel
(G) together.
F
G
H
I
1
1
3
3
3
Cam Lock
(6 used in this step)
①
M8 x 30 mm Wood Dowel
(4 used in this step)
③

12
Assembly Instructions
9. Attach the Left Lower Side Panel (F) to the Bottom Panel (C) and Bottom Back Stretcher (M) with
three 30 mm Wood Dowels (3) and three Cam Locks (1).
10. Repeat the same procedure to attach the Right Lower Side Panel (G) at the opposite end.
C
1
G
I
F
H
M
M8 x 30 mm Wood Dowel
(6 used in this step)
③
Cam Lock
(6 used in this step)
①

13
Assembly Instructions
11. Fasten the Lower Front Panels (H and I) to the Bottom Panel (C) with four 50 mm Screws (7).
7
7
I
H
C
M4 x 50 mm Screw
(4 used in this step)
⑦

14
Assembly Instructions
12. Attach the Bottom Front Stretcher (L) to the Bottom Panel (C) with two 30 mm Wood Dowels (3) and
three Cam Locks (1).
C
1
L
Cam Lock
(3 used in this step)
①
M8 x 30 mm Wood Dowel
(2 used in this step)
③

15
Assembly Instructions
13. Fasten the Bottom Front Stretcher (L) to the Lower Side Panels (F and G) with four 50 mm Screws (7).
7
7
C
L
M4 x 50 mm Screw
(4 used in this step)
⑦

16
Assembly Instructions
14. Glue four 20 mm Wood Dowels (4) into the inner holes on the Bottom Front Molding (K) and attach it
to the Bottom Front Stretcher (L) with eight 25 mm Screws (6).
L
K
6
4
6
K
L
M4 x 25 mm Screw
(8 used in this step)
⑥
M8 x 20 mm Wood Dowel
(4 used in this step)
④

17
Assembly Instructions
15. Glue six 30 mm Wood Dowels (3) into the inner holes on the vertical panels (F, G, H and I). Position
the Center Shelf (B) onto the inserted Wood Dowels (3) and fasten it in place with four Cam Locks (1).
G
BI
F
H
M8 x 30 mm Wood Dowel
(6 used in this step)
③
Cam Lock
(4 used in this step)
①

18
Assembly Instructions
16. Attach one Upper Front Panel (E) to one Upper Side Panel (D) with two Cam Locks (1) and one Wood
Dowel (3).
17. Repeat the same procedure to combine the other Upper Front Panel (E) with the remainder Upper Side
Panel (D).
D
E
1
3
M8 x 30 mm Wood Dowel
(2 used in this step)
③
Cam Lock
(4 used in this step)
①
x 2

19
Assembly Instructions
18. Attach the Upper Side Panel assemblies to the Top Panel (A) with six 30 mm Wood Dowels (3) and six
Cam Locks (1).
A
E
ED
D
Cam Lock
(6 used in this step)
①
M8 x 30 mm Wood Dowel
(6 used in this step)
③

20
Assembly Instructions
19. Glue six 30 mm Wood Dowels (3) into the inner holes of the Center Shelf (B). Position the Upper
Panels (D and E) onto the inserted Wood Dowels (3) and secure them in place with four Cam Locks (1).
D/E
B
D
E
E
D
A
B
M8 x 30 mm Wood Dowel
(6 used in this step)
③
Cam Lock
(4 used in this step)
①
