WIKA A-AS-1 User manual

Operating instructions
Betriebsanleitung
Mode d'emploi
Manual de instrucciones
D
GB
F
E
LED-Aufsteckanzeige, Typen A-AS-1, WUR-1
LED attachable indicator, models A-AS-1, WUR-1
LED attachable indicator model A-AS-1
Acheur emboîtable LED, types A-AS-1, WUR-1
Indicador LED acoplable, modelos A-AS-1, WUR-1

D
GB
F
E
WIKA operating instructions attachable indicator models A-AS-1, WUR-1
2437704.05 10/2012 GB/D/F/E
2
© 2007 WIKA Alexander Wiegand SE & Co. KG
All rights reserved. / Alle Rechte vorbehalten.
WIKA® is a registered trademark in various countries.
WIKA® ist eine geschützte Marke in verschiedenen Ländern.
Prior to starting any work, read the operating instructions!
Keep for later use!
Vor Beginn aller Arbeiten Betriebsanleitung lesen!
Zum späteren Gebrauch aufbewahren!
Lire le mode d'emploi avant de commencer toute opération !
A conserver pour une utilisation ultérieure !
¡Leer el manual de instrucciones antes de comenzar cualquier trabajo!
¡Guardar el manual para una eventual consulta!
Operating instructions models A-AS-1, WUR-1 Page 3 - 22
Betriebsanleitung Typen A-AS-1, WUR-1 Seite 23 - 42
Mode d‘emploi types A-AS-1, WUR-1 Page 43 - 62
Manual de instrucciones modelos A-AS-1, WUR-1 Página 63 - 82

GB
WIKA operating instructions attachable indicator, models A-AS-1, WUR-1 3
2437704.05 10/2012 GB/D/F/E
Contents
Contents
1. General information 4
2. Safety 5
3. Specications 8
4. Design and function 11
5. Transport, packaging and storage 11
6. Commissioning, operation 12
7. Maintenance and cleaning 18
8. Faults 18
9. Dismounting, return and disposal 19
Appendix 1: EC Declaration of conformity for model A-AS-1 21
Appendix 2: EC Declaration of conformity for model WUR-1 22
Declarations of conformity can be found online at www.wika.com.

GB
WIKA operating instructions attachable indicator, models A-AS-1, WUR-14
2437704.05 10/2012 GB/D/F/E
1. General information
1. General information
■
The LED attachable indicator described in these operating instructions has been
manufactured using state-of-the-art technology. All components are subject to strin-
gent quality and environmental criteria during production. Our management system is
certied to ISO 9001 and ISO 14001.
■
These operating instructions contain important information on handling the instru-
ment. Working safely requires that all safety instructions and work instructions are
observed.
■
Observe the relevant local accident prevention regulations and general safety regula-
tions for the instrument's range of use.
■
The operating instructions are part of the product and must be kept in the immediate
vicinity of the instrument and readily accessible to skilled personnel at any time.
■
Skilled personnel must have carefully read and understood the operating instructions,
prior to beginning any work.
■
The manufacturer's liability is void in the case of any damage caused by using the
product contrary to its intended use, non-compliance with these operating instruc-
tions, assignment of insuciently qualied skilled personnel or unauthorised modica-
tions to the instrument.
■
The general terms and conditions contained in the sales documentation shall apply.
■
Subject to technical modications.
■
Further information:
- Internet address: www.wika.de / www.wika.com
- Relevant data sheet: AC 80.09, PE 87.20
- Application consultant: Tel.: [phone]
Fax: [phone]
E-mail: [e-mail]

GB
WIKA operating instructions attachable indicator, models A-AS-1, WUR-1 5
2437704.05 10/2012 GB/D/F/E
1. General information / 2. Safety
Explanation of symbols
WARNING!
... indicates a potentially dangerous situation which can result in serious
injury or death if not avoided.
CAUTION!
... indicates a potentially dangerous situation which can result in light
injuries or damage to the equipment or the environment if not avoided.
Information
… points out useful tips, recommendations and information for ecient and
trouble-free operation.
2. Safety
WARNING!
Before installation, commissioning and operation, ensure that the appropri-
ate instrument has been selected in terms of measuring range, design and
specic measuring conditions.
Non-observance can result in serious injury and/or damage to the equip-
ment.
Further important safety instructions can be found in the individual chapters
of these operating instructions.
2.1 Intended use
The LED attachable indicator is used for the on-site display of pressure
values. The LED
attachable indicator is tted between the pressure transmitter
and the output wiring.
The LED attachable indicator has been designed and built solely for the intended use
described here, and may only be used accordingly.
The technical specications contained in these operating instructions must be observed.
Improper handling or operation of the instrument outside of its technical specications
requires the instrument to be taken out of service immediately and inspected by an
authorised WIKA service engineer.

GB
WIKA operating instructions attachable indicator, models A-AS-1, WUR-16
2437704.05 10/2012 GB/D/F/E
2. Safety
Handle LED attachable indicators with the required care (protect from humidity, impacts,
strong magnetic elds, static electricity and extreme temperatures, do not insert any
objects into the instrument or its openings). Plugs and sockets must be protected from
contamination.
If the instrument is moved from a cold into a warm environment, the formation of conden-
sation may result in the instrument malfunctioning. Before putting it back into operation,
wait for the instrument temperature and the room temperature to equalise.
The manufacturer shall not be liable for claims of any type based on operation contrary
to the intended use.
WARNING!
Do not use this instrument in safety or emergency-stop devices. Incorrect
use of the instrument can result in injury.
2.2 Personnel qualication
WARNING!
Risk of injury if qualication is insucient!
Improper handling can result in considerable injury and damage to equip-
ment.
The activities described in these operating instructions may only be carried
out by skilled personnel who have the qualications described below.
Skilled personnel
Skilled personnel are understood to be personnel who, based on their technical training,
knowledge of measurement and control technology and on their experience and knowl-
edge of country-specic regulations, current standards and directives, are capable of
carrying out the work described and independently recognising potential hazards.
2.3 Special hazards
WARNING!
For hazardous media such as oxygen, acetylene, ammable or toxic gases
or liquids, and refrigeration plants, compressors, etc., in addition to all
standard regulations, the appropriate existing codes or regulations must
also be followed.
Do not use this instrument in safety or emergency-stop devices. Incorrect
use of the instrument can result in injury.

GB
WIKA operating instructions attachable indicator, models A-AS-1, WUR-1 7
2437704.05 10/2012 GB/D/F/E
2. Safety
WARNING!
Observe the working conditions in accordance with chapter 3 "Specica-
tions".
CAUTION!
■
Observe standard regulations and safety rules for electrical, low-power
and high-power systems, especially any country-specic safety regula-
tions.
■
Design the wiring particularly carefully when connecting to other devices
(e.g. a PC). Under certain circumstances, internal connections in third-
party devices (e.g. GND connected to the safety earth) can lead to
impermissible voltages.
2.4 Labelling/safety marks
Product label
Explanation of symbols
CE, Communauté Européenne
Instruments bearing this mark comply with the relevant European
directives.
Model
Output signal
Power supply
Pin assignment
For an explanation of
symbols, see below
S# Serial no.
P# Product no.

GB
WIKA operating instructions attachable indicator, models A-AS-1, WUR-18
2437704.05 10/2012 GB/D/F/E
Specications Models A-AS-1, WUR-1
Indication
■
Principle 7-segment LED, red, 4-digit, character size 7 mm
■
Indication range -999 ... 6000
■
Accuracy ≤ 0.5 % of span ±1 digit
Housing material ABS
Scaling adjustment
■
Menu-driven programming via external control keys
■
Adjustable measuring range
■
Freely-selectable decimal point
■
Programmable pressure units: bar, psi, kg/cm2, MPa, kPa
■
Zero point, freely adjustable in the range ±10 % of span
Input signal
■
A-AS-1 4 ... 20 mA, 2-wire (power supply from current loop,
6 V voltage drop)
0.1 ... 10.1 V; 3-wire
0.1 ... 5.1 V; 3-wire
■
WUR-1 4 ... 20 mA; 2-wire (power supply from current loop,
6 V voltage drop)
0 ... 10 V; 3-wire
0 ... 5 V; 3-wire
Output signal
■
A-AS-1 Analogue current signal is connected through directly
(4 ... 20 mA, 0 ... 10 V or 0 ... 5 V, voltage: oset ≤ 100 mV)
■
WUR-1 Analogue current signal is connected through directly
(4 ... 20 mA, 0.1 ... 10.1 V or 0.1 ... 5.1 V, voltage: oset ≤ 100 mV)
Max. permissible input ±40 mA (short-term)
±DC 40 V (short-term)
Power supply UB+ DC 16 ... 30 V for 4 ... 20 mA
DC 15 ... 30 V for 0 ... 10 V
DC 10 ... 30 V for 0 ... 5 V
Inuence of supply voltage < 0.1 % of span/10 V
3. Specications
3. Specications

GB
WIKA operating instructions attachable indicator, models A-AS-1, WUR-1 9
2437704.05 10/2012 GB/D/F/E
Specications Models A-AS-1, WUR-1
Switching output Individually adjustable via external control keys
■
Number 2 x NPN open-collector (with bayonet connector: 1 x NPN
open-collector)
Galvanically-isolated switching outputs for 4 ... 20 mA
■
Function Normally open, normally closed
■
Adjustment Freely-adjustable in the range 1 ... 99 % of span
■
Temperature error < 0.1 % of span/10 K
■
Accuracy ≤ 0.5 % of span ±1 digit
■
Max. switching current 300 mA
■
Display of switch status LED
■
Response time < 15 ms
■
Hysteresis 0.5 % (xed)
Permissible temperature ranges
■
Ambient -30 ... +85 °C
■
Storage -30 ... +85 °C
■
Compensated -20 ... +80 °C
Temperature error < 0.1 % of span/10 K
CE-mark EMC directive 2004/108/EC, EN 61326 emission
(group 1, class B) and interference immunity (industrial
application)
Ingress protection IP 65 to IEC 60529
Shock resistance 100 g to IEC 60068-2-27 (mechanical shock)
Vibration resistance 5 g at 10 ... 2,000 Hz to IEC 60068-2-6 (vibration at
resonance)
Electrical safety
■
Short-circuit resistance Sig+ to 0V (short-term)
■
Reverse polarity protection UB+ to 0V (short-term)
Weight 50 g
3. Specications
For further specications see WIKA data sheet AC 80.09, PE 87.20 and the order documentation.

GB
WIKA operating instructions attachable indicator, models A-AS-1, WUR-110
2437704.05 10/2012 GB/D/F/E
3. Specications
Dimensions in mm
Output
Bayonet connector,
4-pin
Output
Cable outlet with
3 m length
Output
M12 x 1; 5-pin circular connector
Input
Connection socket for M12 x 1;
4-pin circular connector
Input
Connection socket for
bayonet connector; 4-pin
Front-view version
Output
Bayonet connector;
4-pin
Output
Cable outlet with
3 m length
Output
circular connector
M12 x 1; 5-pin
Input
Connection socket
for M12 x 1; 4-pin
circular connector
Top-view version
Input
Connection socket
for bayonet con-
nector; 4-pin

GB
WIKA operating instructions attachable indicator, models A-AS-1, WUR-1 11
2437704.05 10/2012 GB/D/F/E
4. Design and function / 5. Transport, packaging and storage
4. Design and function
4.1 Description
■
Model A-AS-1: Universal LED attachable indicator
■
Model WUR-1: LED attachable indicator for UHP applications
4.2 Scope of delivery
■
LED attachable indicator
■
68 mm mounting nut
■
75 mm mounting nut
■
Sealing
■
Operating instructions
Cross-check the scope of delivery with the delivery note.
5. Transport, packaging and storage
5.1 Transport
Check the LED attachable indicator for any damage that may have been caused by
transport.
Obvious damage must be reported immediately.
5.2 Packaging
Do not remove packaging until just before mounting.
Keep the packaging as it will provide optimum protection during transport (e.g. change in
installation site, sending for repair).
5.3 Storage
Permissible conditions at the place of storage:
Storage temperature: -30 ... +85 °C
Avoid exposure to the following factors:
■
Direct sunlight or proximity to hot objects
■
Mechanical vibration, mechanical shock (putting it down hard)
■
Soot, vapour, dust and corrosive gases
■
Potentially explosive environments, ammable atmospheres

GB
WIKA operating instructions attachable indicator, models A-AS-1, WUR-112
2437704.05 10/2012 GB/D/F/E
Input 2-wire
Current version
3-wire
Voltage version
Connection socket for M12 x 1; 4-pin circular connector
1 Power supply UB+, Sig+Power supply UB+
2 -- --
3 Power supply 0V, Sig-Power supply 0V, Sig-
4 -- Signal Sig+
Connection socket for bayonet connector; 4-pin
A Power supply UB+, Sig+Power supply UB+
B -- Signal Sig+
C -- --
D Power supply 0V, Sig-Power supply 0V, Sig-
5. Transport, packaging and storage / 6. Commissioning, operation
Store the LED attachable indicator in its original packaging in a location that fulls the
conditions listed above. If the original packaging is not available, pack and store the
instrument as described below:
1. Wrap the instrument in antistatic plastic lm.
2. Place the instrument, along with shock-absorbent material, in the packaging.
3. If stored for a prolonged period of time (more than 30 days), place a bag containing a
desiccant inside the packaging.
WARNING!
Before storing the instrument (following operation), remove any residual
media. This is of particular importance if the medium is hazardous to health,
e.g. caustic, toxic, carcinogenic, radioactive, etc..
6. Commissioning, operation
6.1 Electrical connection
The electrical connections to the LED attachable indicator cannot be
rotated. Rotating the tted indicator could lead to damage to the indicator
and/or the pressure transmitter.
Connection to the pressure transmitter (input)
The input connector of the LED attachable indicator connects directly to the output of the
pressure transmitter.

GB
WIKA operating instructions attachable indicator, models A-AS-1, WUR-1 13
2437704.05 10/2012 GB/D/F/E
Output 2-wire
Current version
3-wire
Voltage version
Circular connector M12 x 1; 5-pin
1Power supply UB+, Sig+Power supply UB+
2Switching output, out1 Switching output, out1
3Power supply 0V, Sig-Power supply 0V
Switching output ground, Sig-
4Switching output ground
(potential-free)
Signal Sig+
5Switching output, out2 Switching output, out2
Cable outlet
red Power supply UB+, Sig+Power supply UB+
black Power supply 0V, Sig-Power supply 0V
Switching output ground, Sig-
yellow Switching output ground
(potential-free)
Signal Sig+
brown Switching output, out1 Switching output, out1
orange Switching output, out2 Switching output, out2
Bayonet connector; 4-pin
APower supply UB+, Sig+Power supply UB+
BSwitching output ground
(potential-free)
Signal Sig+
CSwitching output, out1 Switching output, out1
DPower supply 0V, Sig-Power supply 0V
Switching output ground, Sig-
6. Commissioning, operation
Instrument connection (output)
Use the LED attachable indicator with shielded cable, and, if the lines are longer than
30 m or leave the building, earth the shield at least at one end of the cable.

GB
WIKA operating instructions attachable indicator, models A-AS-1, WUR-114
2437704.05 10/2012 GB/D/F/E
6. Commissioning, operation
6.2 Functions
Overview
■
Selection of the physical pressure unit
■
Positioning the decimal point
■
Setting the smallest display value
■
Setting the largest display value
■
Setting the switch points for output 1
■
Setting the switch functions for output 1
■
Setting the switch points for output 2
■
Setting the switch function for output 2
■
Input of the zero point oset
Key functions
Setting the switching points and switching functions
Change the unit to the left
Change the unit to the right
Input of zero point oset
Conguration
6.3 Conguration
Fitting the LED attachable indicator to the pressure transmitter.
Button 1 Button 2 Button 3
If, during the conguration, no keys are
pressed for 10 seconds, the instrument will
automatically revert to the menu level one
level up. After a further 60 seconds without
any operation of the keys, the instrument
will restart itself. Unsaved changes will
be lost.
+
+

GB
WIKA operating instructions attachable indicator, models A-AS-1, WUR-1 15
2437704.05 10/2012 GB/D/F/E
6. Commissioning, operation
Indication Unit
dP
Select unit
Conrm
di.Lo
Set the decimal point
Conrm
Set the smallest display
value
Conrm
di.Lo
Setting the largest
display value
Conrm
Set the display
■
Simultaneously press and hold buttons 1 and 3 for ve seconds. The indicator
switches to "UNIT".
■
Using buttons 2 and 3, select the required unit.
■
Conrm the unit set, using button 1. The display reverts to "UNIT".
■
Briey press button 1 in order to bring up the menu point "dP" (decimal point).
■
Using buttons 2 and 3, select the required position for the decimal point.
■
Conrm the position set using button 1. The display reverts to "dP".
■
Briey press button 1 in order to bring up the menu point "di.Lo" (display low).
■
Using buttons 2 and 3, set the display value to be either 4 mA or 0.1 V
■
Conrm the value set using button 1. The display reverts to "di.Lo".
■
Briey press button 1 in order to bring up the menu point "di.Hi" (display high).
■
Using buttons 2 and 3, set the display value to be either 20 mA or 10.1 V
■
Conrm the value set using button 1. The display reverts to "di.Hi".
■
By pressing button 1 briey, the settings are saved. A successful 'Save' is signalled by
the display switching o briey.
5 s

GB
WIKA operating instructions attachable indicator, models A-AS-1, WUR-116
2437704.05 10/2012 GB/D/F/E
6. Commissioning, operation
Indication SP1
out1
SP2
out2
Setting switching points and switching functions
■
Press and hold button 1 for two seconds. The display changes to "SP1".
■
Using buttons 2 and 3, select the required switch point for switching output 1.
■
Conrm the unit set, using button 1. The display reverts to "SP1".
■
Briey press button 1 in order to bring up the menu point "out1".
■
Using buttons 2 and 3, select the required switch function for switching output 1.
o = always o on = always on
no = normally open nc = normally closed
■
Conrm the switch function set, using button 1. The display reverts to "out1"
■
Briey press button 1 in order to bring up the menu point "SP2".
■
Using buttons 2 and 3, select the required switch point for switching output 2.
■
Conrm the unit set, using button 1. The display reverts to "SP2".
■
Briey press button 1 in order to bring up the menu point "out2".
■
Using buttons 2 and 3, select the required switch function for switching output 2.
o = always o on = always on
no = normally open nc = normally closed
■
Conrm the switching function set using button 1. The display reverts to "out2".
Set switching point 1
Conrm
Select switching
function 1
Conrm
Set switching point 2
Conrm
Select switching
function 2
Conrm
2 s

GB
WIKA operating instructions attachable indicator, models A-AS-1, WUR-1 17
2437704.05 10/2012 GB/D/F/E
6. Commissioning, operation
■
By pressing button 1 briey, the settings are saved. A successful 'Save' is signalled by
the display switching o briey.
Select unit
Using buttons 2 and 3, select the required unit.
If a unit is skipped during the selection, display in these units is not possible.
Input the Zero Oset (oset)
The zero oset enables an adjustment of the display value shown on the display. Through
the adjustment of the display value, the matching of the unit to specic applications is
possible.
The value input is subtracted from the measured value, i.e. the characteristic curve is
shifted, in parallel, to the zero point.
The zero point oset has no inuence on the analogue output signal from
the LED attachable indicator.
Indication OFFS
Displace the zero point
Conrm
■
Simultaneously press and hold buttons 1 and 2 for ve seconds. The display changes
to "OFFS" (oset).
■
Using buttons 2 and 3, set the required zero point oset (permissible range ±10 % of
the indication range).
■
Conrm the zero point oset using button 1. The display reverts to "OFFS".
■
By briey pressing button 1, the display value will be shown once more.
The LED attachable indicator for pressure transmitters with voltage outputs are factory
preset with the output signals 0.1 ... 5.1 V or 0.1 ... 10.1 V. To operate the LED attachable
indicator with pressure transmitters with 0 ... 5 V or 0 ... 10 V output signals, an appropri-
ate zero point adjustment should be carried out.

GB
WIKA operating instructions attachable indicator, models A-AS-1, WUR-118
2437704.05 10/2012 GB/D/F/E
7. Maintenance and cleaning / 8. Faults
7. Maintenance and cleaning
7.1 Maintenance
This LED attachable indicator is maintenance-free.
Repairs must only be carried out by the manufacturer.
7.2 Cleaning
CAUTION!
■
Prior to cleaning, disconnect the LED attachable indicator from the
power supply.
■
Clean the instrument with a moist cloth.
■
Electrical connections must not come into contact with moisture.
For information on returning the instrument see chapter 9.2 "Return".
8. Faults
If the instrument detects any fault conditions, the corresponding error code will be
displayed.
The following error codes are dened:
Error Causes Measures
Err.1
Measuring range
exceeded
■
Input signal too high
■
Pressure transmitter defec-
tive/not suitable.
■
Short-circuit in the connec-
tion cabling of the pressure
transmitter
■
The error message will reset itself
as soon as the input signal is
once more within the permissible
limits.
■
Check the pressure transmitter
and the instrument conguration
(e.g. input signal).
Err.2
Measured value below
permissible range
■
Input signal too low, or
negative
■
Pressure transmitter defec-
tive/not suitable.
■
Short-circuit in the connec-
tion cabling of the pressure
transmitter
■
The error message will reset itself
as soon as the input signal is
once more within the permissible
limits.
■
Check the pressure transmitter
and instrument conguration

GB
WIKA operating instructions attachable indicator, models A-AS-1, WUR-1 19
2437704.05 10/2012 GB/D/F/E
Error Causes Measures
Err.3
Indication range
exceeded
■
Scaling incorrect
■
The error message will be reset
once the display value is once
more < 9999.
Err.4
Under the indication
range
■
Scaling incorrect
■
The error message will reset itself
once the display value is once
more within the permissible limits.
CAUTION!
If faults cannot be eliminated by means of the measures listed above,
the LED attachable indicator must be shut down immediately, and it must
be ensured that signal is no longer present, and it must be prevented
from being inadvertently put back into service. In this case, contact the
manufacturer. If a return is needed, follow the instructions given in chapter
9.2 "Return".
9. Dismounting, return and disposal
WARNING!
Residual media in dismounted instruments can result in a risk to persons,
the environment and equipment.
Take sucient precautionary measures.
9.1 Dismounting
Disconnect the LED attachable indicator from the power supply. For plug connections,
loosen the threaded connection and pull apart.
9.2 Returns
WARNING!
Absolutely observe the following when shipping the instrument:
All instruments delivered to WIKA must be free from any kind of hazardous
substances (acids, leachate, solutions, etc.).
When returning the instrument, use the original packaging or a suitable transport package.
8. Faults / 9. Dismounting, return and disposal

GB
WIKA operating instructions attachable indicator, models A-AS-1, WUR-120
2437704.05 10/2012 GB/D/F/E
To avoid damage:
1. Wrap the instrument in antistatic plastic lm.
2. Place the instrument, along with shock-absorbent material, in the packaging. Place
shock-absorbent material evenly on all sides of the transport packaging.
3. I f possible, place a bag containing a desiccant inside the packaging.
4. Label the shipment as transport of a highly-sensitive measuring instrument.
Information on returns can be found under the heading “Service” on our
local website.
9.3 Disposal
Incorrect disposal can put the environment at risk.
Dispose of instrument components and packaging materials in an environmentally
compatible way and in accordance with the country-specic waste disposal regulations.
9. Dismounting, return and disposal
