Wimius K1 User manual
Table of Contents
Safety Precautions-------------------------------------------------------------
Accessories----------------------------------------------------------------------
Product Overview--------------------------------------------------------------
Remote Control and Spec---------------------------------------------------
Projection Size Chart and Installation-------------------------------------
Operating Instructions---------------------------------------------------------
Connecting with Smartphones and iPad----------------------------------
Connecting with Bluetooth Speaker----------------------------------------
Other Connections-------------------------------------------------------------
Main Menu Function-----------------------------------------------------------
FAQ and Contact ---------------------------------------------------------------
02
03
04
06
07
08
11
14
15
16
20
ENEN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99
Warnings
Thank you for your purchase with WiMiUS K1 video projector. Please read this
manual carefully before using the projector.
If you have questions about the projector, please contact us at
We sincerely hope this projector can make your life more colorful.
High brightness lamp! Don't look straight into the lens when the projector is on.
Safety Precautions
1. Clean
When clean this projector, please pull out the power cable. Use a wet cloth to clean,
don’t use any detergent that may damage the unit.
2. Accessory
Please use our recommended accessory. Or it will damage the projector.
3. Correct environment
Do not place the projector in a wet environment, like damp basement or near the
swimming pool, etc.
4. Ventilation
The ventilation is equipped for the projector to work stably. Do not put anything
around the vents. Or it will cause the projector heating up. To ensure the stability of
heat dissipation, please open the height bracket in the bottom of the projector
before starting.
5. Power
Please make sure the power is within the required power range.
6. Thunder
For thunder day, please unplug the power cable from the projector.
7. Repair
Due to high voltage inside, please do not open or try to repair the projector by
yourself. Please ask a professional technician to repair the projector.
8. Keep away from heat device
Please make sure the projector is far away from any heat devices which will
damage the projector.
EN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99
Accessories
Projector x 1
Remote Control x 1
Projector Case x 1 Power Cable x 1
AV Cable x 1 HDMI Cable x 1
User Manual x 1
Lens Cover x 1
Lens Cloth x 1
USER MANUAL
Website:www.wimius.com
K1 PROJECTOR
EN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99
12 13 1514
3 4 5 6 7
8 9 10
11
21
Product Overview
1.Level-Stand Adjustment 8. USB port
2.IR receiver 9. AV port
3.Focus Lens 10. HDMI 2 port
4.Power port 11. Built-in Speaker
5.IR for remote control 12. Cooling window
6.3.5mm audio output 13. Focus
7.HDMI 1 port 14. Switch of removable dust cover
15. Removable dust cover
EN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99
3 421
1 2 3 4 5 6 7
1. Keystrokes（picture 1）
2. Rating label
3. Projector mount holes
4. Level-stand adjustment
1. Power Key
2. Exit
3. OK Key
4. Up Key
5. Down Key
6. Left Key
7. Right Key
(picture 1)
EN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99
1. Power
2. Source
3. Arrow keys
4. Menu
5. Homepape
6. Volume +
7. Volume -
8. Mute
9. Picture flip
10. Confirmation key
(Play and Pause)
11. Return
12. Previous (Video)
13. Next (Video)
Note:
1.While using the remote control, point it toward IR receiver.
2.To avoid battery leakage corrosion, please take the batteries out if not use it
for a long time.
Remote Control
9
1
2
3
4
5
6
7
8
10
11
12
13
EN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99
Model No: K1
Imaging System
Light Source
Color
Projection Distance
Projection Size
Aspect Ratio
Keystone Correction
Screen Size
35’’
50’’
72’’
100’’
120’’
180’’
300’’
Distance
1.5m
1.75m
2.4m
3.3m
3.9m
5.5m
7.0m
LCD
LED
16.8M Full Color
1.5-7m
50-300”
16:9 /4:3
±50° Digital
Power
Dimension
Resolution
Input Interface
Zoom Function
Output Interface
Project Weight
AC100-240V/50-60Hz
26*23*11CM
Native 1920*1080 Full HD
HDMI*2/AV/ USB*2/
AUDIO OUT
50%-100%
AUDIO OUT
≈ 2.22kg
Please allow ± 3% to the image sizes in the table above. If the distance is less
than min data and more than max data, the image could be blurry.
①We provide a screw in the packaging, there is a screw hole at the bottom of
the projector, you can install it to lift the base of the projector on the plate to get
a better projection angle. See below(1).
②For Ceiling mount, there are 4 holes at the bottom of the projec-
tor(M5*16mm). Please slowly rotate it out first. See below(2)(3).
★Optimum projection distance: 3m
Specifications
Projection Size Chart
Projector Installation
EN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99
Note: The hanging bracket is an accessory that is not supplied.
1.Getting Started
• To get better watching experience,please use it in dark or semi-dark room.
• Please use the projector carefully, dropping or crashing may damage parts or
result in blurred images and abnormal displaying.
①Remove the lens cap, connect the projector with the power through power
supply cable, it starts work.
② Then boot screen appears, like the picture.
Operating Instructions
EN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99
2.Focus and Keystone Correction
(1)Adjust the keystone correction first.
How to Use Projection Settings
Select the settings icon in the upper right corner of the main interface, and
then press the "OK" key on the remote control to enter the settings interface and
select "Projection Image Setting". After entering the interface, select the mode
you want in the projection settings, then adjust the keystone as you want.
①Vertical Keystone
When you choose “Keystone Advanced: Front”, then you can ajust Manual
Keystone (Vertical )between : ±50°, just press the button to set the value.
EN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99
（2）Focus Adjustment
②Horizontal Keystone
When you choose “Keystone Advanced Side”, you can set “4-point Keystone”as
your need: Horizontal Value ±64, Vertical Value from±36
Just click “OK” button to pick the point you want adjust at first, and then presse
the button " " or "▼ " to set the value needed as shown below.
Turn the trackwheel clockwise to bring the trackwheel to the end, then slowly
rotate the trackwheel counterclockwise. At the same time, carefully observe the
pixels on the screen. When the image particles are the clearest (Subjed to the
middle of the image), the pixels on the screen are the best focus of the lens.
EN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99
Focusing dial
Note: This projector support only Wireless Connection, wired connection is not
possible.
（3）Connect input devices and then choose signal source
button to choose corresponding signal source ( HDMI1, HDMI2,
AV,etc)
Connecting with Smartphones and iPad
P.S: The fluency of screen mirroring with wireless connection will be affected by
the network environment. A bandwidth of 100Mbit or more is recommended
when using screen mirroring. Make sure your mobile device is closed to the
projector when using wireless connection. A distance within 1 meter is recom-
mended.
Just operate through the remote control: Press “ ” and then press
" " or " ▲ ▼ " to choose the corresponding signal input channel,
then press "OK’’ to confirm.
EN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99
iOS Cast
Attention: Your device and the projector should be in the same Home
WiFi.
Setting with Home Wi-Fi
1.Turn on the WiFi Setting of projector.
2.Choose your Home WiFi to connect and enter the right password, then click
“Done”to Connect, please wait 3-5 seconds to establish the connection. Once
connected, it will remember the password of the connected WiFi.
3.Turn on the WiFi setting of your IOS mobile device, then connect it the same
Home WiFi as the projector.
4.Then click“IOS Cast” as the Input Source of your projector.
5.Swipe up the screen of your iOS mobile device and tap “Screen Mirroring” to
search for the projector, then select“WiMiUS-K1Projector”from the searching
results to connect.
6.Succeed.
How to Use WiFi Settings
Select the settings icon in the upper right corner of the main interface, and then
press the "OK" key on the remote control to enter the settings interface and
select "WiFi Setting".
For IOS System
EN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99
Miracast
To activate this function, your android device must support Multi-Screen/Wire-
less Display. Name of “Multi-Screen” may vary depending on various brands of
Android devices.
1.Turn on the projector, select “Miracast” as the Input Source.
2.Turn on the “Multi-Screen/Wireless Display” of your Android device.
3.Select “WiMiUS-K1Projector”from the searching results to connect.
4.Succeed.
For Android System
Method 1: Setting with mobile internet
EN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99
Miracast
1.Turn on your Bluetooth Speaker.
2.Turn on the Bluetooth Setting of your projector.
3.Seclect your Bluetooth speaker to connect.
4.Succeed.
Compatible with Bluetooth speakers, Bluetooth Headphones, iPhone
Airpods,Bluetooth Earbuds,Bluetooth Earphones.
Connecting with Bluetooth Speaker
1.Turn on the WiFi Setting of your projector.
2.Choose your Home WiFi to connect and enter the right password, then click
“Done” to Connect, please wait 3-5 seconds to establish the connection. Once
connected, it will remember the password of the connected WiFi.
3.Turn on the WiFi setting of your Android mobile device, then connect the same
Home WiFi as the projector.
4.Select “MiraCast” as the Input Source of your projector.
5.Swipe up the screen of your Android mobile device and tap "Wireless Display"
（or trun on it in your setting）to search for the projector, then select
“WiMiUS-K1 Projector” from the searching results to connect.
6.Succeed.
Method 2: Setting with Home Wi-Fi.
If any questions during connection, email us at
EN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99
①. Connect projector with PC by HDMI cable.
②. Choose the media signal channel :“HDMI”
Note: For the “Office Suite” option, you can play, demo PPT files.
For the USB devices, no need to choose the signal source. The machine will
detect them automatically.
①. Select the required category “movie”, "music", "photo" or "Office Suite" in the
main interface, and press the “OK”key on the remote control to enter the
corresponding category.
②. According to the programs to choose :“photos”“music”“movie” or “Office
Suite”.
③. Choose the file you want to play, press the key “OK” to play or pause the file.
(You cannot enter the required category without connecting a USB disk.)
2.USB Multimedia Connecting
1.Connecting with PC
①Choose the media signal channel :“HDMI”
②Use a Type-C to HDMI adapter to connect your MacBook, or a Mini Display to
HDMI adapter to connect with your MacBook Air (adapter not included).
3.Connecting with MacBook or Mac Book Air
①Use the AV cable coming with the projector to connect with sound bar.
②Turn on the projector and the sound bar.
③More details, please contact seller at [email protected]
4.Connecting with Sound bar
①Use the AV cable coming with the projector to connect with DVD.
②Turn on the projector and DVD player.
5.Connecting with DVD
Other connections
EN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99
①Plug the TV stick into HDMI port of the projector.
②Choose the media signal channel :“HDMI”
P.S: It only supports 1080P TV stick, not 4K TV stick.
Picture Mode
Picture Mode
Aspect Ratio
Note: If the menu icon is gray, it means that this option is not adjustable.
Press "Menu" button on the remote twice to switch from 16:9 and 4:3.
Menu included
Standard/Soft-
/User/Vivid
16:9/4:3
4 image mode to adjust the
“Brightness/Contrast/Satura-
tion/Sharpness” of the
image:0-50
Aspect ratio let you configure
how images are displayed
Function
If you want to make the projection screen full screen during video/picture
playback, you can press the “ ” button on the projector or remote control.
Press “ ” and then select the setting on the remote control to make some
personal settings.
6.Connecting with Amazon fire TV Stick
①Choose the media signal channel :“HDMI”
②Use HDMI cable connect to XBOX/PS4
7.Connecting with XBOX/PS4
Warm tips:
1.Picture Mode
Only when you play the video，you can set the “Picture Mode”.
Main Menu Function
Picture Mode
Picture Mode
Brightness
Contrast
Saturation
Hue
Sharpeess
Standard
50
50
50
50
50
TvSetting
Sound Mode
EN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99
2.Sound Mode
3. Projection Image Setting
Only when you play the video，you can set the “Sound Mode”.
Sound Mode
Sound Mode
Menu included
Standard/News/Music/Mov-
ie/Sports/User
Adjust the mode of sound
Function
Sound Mode
Sound Mode
120Hz
500Hz
1.5KHz
5KHz
10KHz
News
35
40
65
60
30
EN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99
4. System Update
Projection
Projection Mode
Keystone Advanced
Keystone
Advanced
Digital Zoom
Menu included
Front-Desktop /
Rear-Desktop /
Front-Ceiling /
Rear-Ceiling
Front-Adjust Manual
Keystone
Side-4-point
Keystone
Reduce Display
100%-50%
Choose the projection methods,-
flip the image
Adjust Vertical Keystone±50°
Adjust Horizontal Keystone:
4-point Keystone value：
horizontal ±64 vertical±36
Reduce the size of image size
Function
System Update
Online Update
Local Update
Restore Factory
Menu included
Online Update
Local Update
Reset
Update the system Online
Update offline
Restore all settings to their
factory settings
Function
EN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99
5. Other Setting
6. About the version of system
Other Setting
Power On Option
Language Setting
Sleep Timer
Menu included
Direct/Standby
English, French,
German, Italian,
Spanish, Japanese.20
several languages
OFF/10min/20min/30
min/60min/120min
Choose the mode of Power On
Choose a language
Set the sleep time of the projector
Function
EN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99
Table of contents
Other Wimius Projector manuals
