Wimius Q2 User manual
Q2 Projector
USER MANUAL
EN English Pxx-xx
DE Deutsch Pxx-xx
FR Français Pxx-xx
ES Español Pxx-xx
IT Italiano Pxx-xx
JP 日本語 Pxx-xx
EN
1
CONTENT
PACKAGE LIST · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·2
PRODUCT STRUCTURE · · · · · · · · · · · · · · · · · · · · · · · · · 3
REMOTECONTROL· · · · · · · · · · · · · · · · · · · · · · · · · · · ·4
IMAGE ADJUSTMENT · · · · · · · · · · · · · · · · · · · · · · · · · · 5
1.Focus Adjustment · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 5
2.Projection Mode · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 5
3.Keystone Correction · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 5
4.Zoom Mode· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 7
5.Brightness Adjustment · · · · · · · · · · · · · · · · · · · · · · · · · · · · 7
6.Other Setting· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 8
SETTING UP THE PROJECTOR · · · · · · · · · · · · · · · · · · · · · 9
WIRELESS CONNECTION · · · · · · · · · · · · · · · · · · · · · · · · 10
1.For IOS System (Airplay) · · · · · · · · · · · · · · · · · · · · · · · · · · · · 10
2.For Android System(Miracast)· · · · · · · · · · · · · · · · · · · · · · · · 11
3.Eshare · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 11
BLUETOOTH SETTINGS · · · · · · · · · · · · · · · · · · · · · · · · · 12
Connect Bluetooth Speakers· · · · · · · · · · · · · · · · · · · · · · · · · · 12
SIGNAL LINES CONNECTION · · · · · · · · · · · · · · · · · · · · · · 12
1.USB Multimedia Connecting · · · · · · · · · · · · · · · · · · · · · · · · · 12
2.Connecting with Laptop· · · · · · · · · · · · · · · · · · · · · · · · · · · · 13
3.Connecting with MacBook or Mac Book Air · · · · · · · · · · · · · · · 13
4.Connecting with Sound bar · · · · · · · · · · · · · · · · · · · · · · · · · 13
5.Connecting with re TV Stick· · · · · · · · · · · · · · · · · · · · · · · · · 13
6.Connecting with XBOX/PS4· · · · · · · · · · · · · · · · · · · · · · · · · · 13
LANGUAGE SETTING · · · · · · · · · · · · · · · · · · · · · · · · · · 14
OTHER SETTING · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 14
DATE AND TIME SETTING · · · · · · · · · · · · · · · · · · · · · · · · 15
ABOUT US · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 16
FAQ · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 16
EN
2
PACKAGE LIST
WiMiUS Q2 Projector Remote Control
Power Cable HDMI to Mini HDMI Cable
AC to USB-A Cable Projector Steady
User Manual
EN
3
PRODUCT STRUCTURE
Lens
Lens
HDMI IN
IR
DC-IN
USB
Power ON/OFF
Audio OUT
Volume
Touch Screen
Menu (with lock screen function)
Homepage
Return
EN
4
REMOTECONTROL
IR Mute
Switch to
mouse control
Home
Menu
VOL+/-
OK
Airplay
Eshare
Directions
Return
Note: Install 2 pieces of AAA batteries(not included) into the remote
before using.
EN
5
IMAGE ADJUSTMENT
1.Focus Adjustment
2.Projection Mode
Auto Keystone Correction
3.Keystone Correction
Slide pinion on the left of the device to adjust sharpness.
Select [Settings ] menu -- Select [ Projection] -- Select [Projection Mode],
Press the arrow key to select and press “OK” to confirm the projection
position.
There have 4 modes: Rotate Rear Ceiling / Rear / Front / Rotate Ceiling.
Select [Settings] menu -- Select [Projection] -- Select [Keystone
Correction]--Select [Auto Keystone Correction], and press “OK” to
conrm.
the projector can auto adjust the vertical plane to get the rectangle
image. The tilted angle doesn’t exceed ±30°.
EN
6
Manual Keystone Correction
Initial Angle Correction
Select [Settings] menu -- Select [Projection] -- Select [Keystone
Correction]--Select [Manual Keystone Correction], press “OK” to pick the
point you want to adjust at rst, and then press the button " ▶ " or " ▼ " to
set the value (Horizontal and Vertical ±30°) needed as shown below.
Place the device on the horizontal plane and press the OK to correct it.
Don’t move the device during the correction.
EN
7
4.Zoom Mode
5.Brightness Adjustment
There has 2 modes of Aspect Ratio: 16:9 or 4:3.
Select [Settings] menu -- Select [Projection] -- Select [Zoom Mode],the
projection screen can be zoomed 50%~100%, Press the button " ◀ ▶ " to
set the value needed.
Select [Settings] menu -- Select [ Projection] -- Select [Brightness
Adjustment], press " ◀ " or " ▶ "to adjust the brightness you need.
EN
8
6.Other Setting
Pointer Speed
Prevention of Accidental Contact
Select [Settings] menu -- Select [ Projection] -- Select [Pointer Speed],
press " ◀ " or " ▶ "to adjust the mouse pointer move speed you need.
Select [Settings] menu -- Select [Projection] -- Select [Prevention
of Accidental Contact], to choose the time period you need, prevent
accidental operation.
EN
9
SETTING UP THE PROJECTOR
Select The Input Signal Source
Choose the “Source” on the home page, select the desired input signal
source (USB/HDMI/AV)
The device will detect the USB stick automatically, need to confirm
whether to open.
When playing a video, you can press the " " button, to set the sound
and mode of playback.
EN
10
WIRELESS CONNECTION
1.For IOS System (Airplay)
Attention: Your device and the projector should be in the same Home
WiFi.
1.Turn on the Network setting of projector.
2.Choose your Home WiFi to connect and enter the right password, then
click “Link”, please wait 3 seconds to establish the connection. Once
connected, it will remember the password of the connected WiFi. (or turn
on the Hotspot of projector directly)
3.Turn on the WiFi setting of your mobile device, then connect to the same
Home WiFi (or the Hotspot of projector)
4.Then click “Airplay” on the smartphone
5.Select“Projector-7935”from the search results to connect.
6.Succeed.
EN
11
2.For Android System(Miracast)
3.Eshare
Attention: Your device and the projector should be in the same Home
WiFi.
1.Turn on the Network setting of the projector.
2.Choose your Home WiFi to connect and enter the right password, then
click “Link”, please wait 3 seconds to establish the connection. Once
connected, it will remember the password of the connected WiFi.
3.Turn on the WiFi setting of your mobile device, then connect to the same
Home WiFi
4.Then click “Miracast” on the smartphone
5.Select“Projector-7935”from the search results to connect.
6.Succeed.
Note: the Hotspot can’t support Android devices.
Use your phone as the wireless mouse, keyboard, remote control,
transform the way you control and engage with large-screen devices.
1.Connect your device to Home WiFi
2.Vist “http://192.168.43.1:8000” with a web browser or scan the QR-code to
download app.
3.Launch Eshare and click “Projector-7935”to connect.
EN
12
BLUETOOTH SETTINGS
SIGNAL LINES CONNECTION
Connect Bluetooth Speakers
1.USB Multimedia Connecting
1.Turn on your Bluetooth Speaker.
2.Turn on the [ Bluetooth Settings] of your projector
3.Select your Bluetooth speaker to connect.
4.Succeed.
WiMiUS Q2 projector has 3 interfaces, HDMI ports/USB ports/3.5mm
headphone output. Please select the correct connecting port to connect
your device (PC, Phone, DVD Player, Sound bar, USB, PS4,etc.)
For USB devices, no need to choose the signal source. The machine will
detect them automatically.
•Select the icon at the top right corner of the home page
Note: Support USB drive storage capacity max. To 32GB, and HDD storage
capacity max to 1TB.
EN
13
2.Connecting with Laptop
3.Connecting with MacBook or Mac Book Air
4.Connecting with Sound bar
5.Connecting with Fire TV Stick
6.Connecting with XBOX/PS4
•Connect the projector with PC by HDMI cable.
•Choose the media signal channel :“HDMI”.
Choose the media signal channel :“HDMI”.
•Use a Type-C to HDMI adapter to connect your MacBook, or a Mini
Display to HDMI adapter to connect with your MacBook Air (adapter not
included).
•Use the 3.5mm audio cable coming with the projector to connect with
sound bar.
•Turn on the projector and the sound bar(choose AUX mode).
•For more details, please contact the seller at [email protected].
•Plug the TV stick into the HDMI port of the projector.
•Choose the media signal channel :“HDMI”.
•Choose the media signal channel :“HDMI”.
•Use HDMI cable to connect to XBOX/PS4.
Audio
out
AUX
port
EN
14
LANGUAGE SETTING
OTHER SETTING
Choose Language
Application Setting
Factory Reset Setting
Input Selector
•There has more than 50 languages for choose, English, French, German,
Italian, Spanish, Japanese, ect.
•In the other settings menu, you can nd the "Application Setting" option,
click it to view all installed applications and congure them.
•reset and delete all data
•Choose the keyboard to install according to your own needs and habits.
EN
15
Developer Opinions
DATE AND TIME SETTING
•It is mainly provided for developers to use during software development
and debugging of devices. Normally it is turned off by default.
Setting Function
Timezone Selection Set the time of your location
Time format Selection 12/24 Hour
Date format Selection Set the date format
Automatically Determine Auto/Manual
EN
16
ABOUT US
About Function
About the machine The detail information of the device
Local upgrade Update via USB
Online upgrade Update Online
FAQ
1.No image on the screen.
a.Is the channel set-up correct?
b.Is there an input signal?
c.Is the input cable plugged well?
d.Under PC mode, is the refresh rate > 75KHz?
2.Blue screen no picture and no sound.
Input device doesn't connect well with the projector.
3.Picture right, no sound.
a.Please turn off the Dolby of the input device, and then it will have sound.
b.The decode system of the video is not supported by the projector.
EN
17
4.Auto-off after working for a while.
a.The projector ventilation is blocked.
b.The voltage is not stable.
c.The over-heat protection system.
5.WiFi connection is not stable?
a.Please check whether the network of your phone is well.
b.Make the distance of phone and projector within 1 meter.
6.Not compatible with your Bluetooth speaker?
a.The projector may not be compatible with some kinds of Bluetooth
speakers.
and tell us the brand and model of your Bluetooth speaker.
7.Black spot on the picture
8.When turning on the power switch, the indicator light does not work.
a.The power might not be connected well.
b.Check the over-heat protection system.
9.Can't play the movies.
a.The format of the video is right?
b.Files are broken?
c.Device broken?
10.Can't access the website successfully to download the application?
Please contact us immediately at our after-sales email address:
appeared during your application download.
FCC Statement
FCC STATEMENT :
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received, including interference that may
cause undesired operation.
Warning: Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
20cm between the radiator & your body.
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation,
Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject
to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme
aux CNR d’Innovation, Sciences et Développement économique Canada applicables
aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions
suivantes :
(1) L' appareil ne doit pas produire de brouillage;
(2) L' appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d' en compromettre le fonctionnement.
This equipment complies with IC exposure limits set forth for an uncontrolled environment.
This equipment shall be installed and operated with minimum distance 20cm between the
radiator & body.
Table of contents
Other Wimius Projector manuals
