Wimius K5 User manual
LANGUAGE
Germany
Espanol
Français
English 01-16
17-34
35-50
51-67
68-87
日本語
Italian
68-87
ENENENEN 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54
55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72
73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90
91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108
CONTENT
Warning and Safety Precautions------------------------------------------------------------
Accessory and Projector Structure---------------------------------------------------------
Remote Structure-------------------------------------------------------------------------------
Focus and Keystone Correction-------------------------------------------------------------
Connecting with WiFi---------------------------------------------------------------------------
Connect with Bluetooth Speaker------------------------------------------------------------
Other Connections------------------------------------------------------------------------------
Installing the Projector-------------------------------------------------------------------------
Main Functions of the Menu------------------------------------------------------------------
FAQ-------------------------------------------------------------------------------------------------
1
2
3
4
5
6
7
8
9
10
ENEN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54
55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72
73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90
91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108
Warnings
Safety Precautions
Accessories
Thank you for purchasing WiMiUS K5 wifi bluetooth video projector. Please read this
manual carefully before you use the projector.
We sincerely hope this projector can make your life more colorful.
1.High brightness lamp! Please don’t look directly into the lamp.
2.Adjusting the contrast, brightness and focal length according to different input signals is
the key to make the picture clear; otherwise, the picture will be blurred.
3.There is high voltage inside the projector. It is forbidden to open the cover and touch the
internal parts of the machine.
1. Clean
When clean this projector, please pull out the power cable. Use a wet cloth to clean, don’t
use any detergent that may damage the unit.
2. Accessory
Please use our recommended accessory. Or it will damage the projector.
3. Correct environment
Do not place the projector in a wet environment, like damp basement or near the swimming
pool, etc.
4. Ventilation
The ventilation is equipped for the projector to work stably. Do not put anything around the
vents. Or it will cause the projector heating up.
5. Power
Please make sure the power is within the required power range.
6. Thunder
For thunder day, please unplug the power cable from the projector.
7. Repair
Due to high voltage inside, please do not open or try to repair the projector by yourself.
Please ask a professional technician to repair the projector.
8. Keep away from heat device
Please make sure the projector is far away from any heat devices which will damage the
projector.
Projector*1
Projector case *1
Lens Cover*1
Remote Controller*1
Power Cable*1
AV Cable*1
Projector Support Base*1
User Manual*1
ENEN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54
55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72
73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90
91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108
Projector Overview
Lens IR Receiver
Power cable Socket
Projector*1 AV Cable*1 Power Cable*1
Remote Controller*1 User Manual*1 Projector Support Base*1
ENEN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54
55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72
73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90
91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108
1.3.5mm audio output
2.AV port
3.HDMI port
4. USB port*2
5.IR receiver
6.Speaker
7. Ventilation inlet
Control Panel
Power/Return Indicator Light
Menu/Up
Right/Volume-
OK Button
Left/Volume+
Source/Down
Keystone correction knob
Manual Focus
Note: please refer to the product appearance, this figure is for reference only.
Control Panel
ENEN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54
55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72
73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90
91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108
1.3.5mm audio output
2.AV port
3.HDMI port
4. USB port*2
5.IR receiver
6.Speaker
7. Ventilation inlet
Support Base thread
Tripod Stand thread
Power Button Menu
Mute
Enter
Forward
Return
Volume+
Home/Play
Backward
Arrow Keys
Source
Volume-
Remark: The adjustable support base can assure the max projection angle by
15°, The best display effect will be obtained by projection angle of 0°~ 8°.
Note:
1.While using the remote control, point it toward IR receiver.
2.The remote control doesn’t come with the battery, required 2*AAA batteries.
3.To avoid battery leakage corrision, please take the batteries out if not use it for
a long time.
Remote control
ENEN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54
55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72
73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90
91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108
Two steps to get clear images:
1.Adjust the keystone correction to make picture rectangle.
☆Optimum projection distance: 2.5m
Model No.: K5
Specifications
Projection size chart
Focus and Keystone Correction
Imaging System LCD
1.2-6.0m
16.8M full color
±15°
16:9 /4:3
3.5mm audio out
Projection distance
Color
Keystone Correction
Aspect Ratio
Output Interface
Light source LED
36-200”
Native 1280*720,
Support 1080P Full HD
AV\USB\HDMI
110-240V~50/60HZ
1.2kg
Projection size
Resolution
Input Interface
Power:
Projector Weight
Distance Screen size
1.2m
2.5m
3.5m
5.0m
6.0m
36’’
70’’
100’’
160’’
200’’
ENEN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54
55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72
73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90
91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108
2.Adjust the focus ring to make the picture clear.
Focus
Keystone Correction
Focus ring
Incorrect installation Incorrect installationCorrect installation
ENEN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54
55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72
73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90
91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108
Note: It is normal when sharpness in the central, blur in the 10% edge for the lcd
projector, due to the keystone correction function.
Before using the projector to play videos, please press“S”through remote control
and choose the corresponding signal source to confirm.
Wireless Connection
PS:
1.The fluency of screen mirroring with wireless connection will be affected by the
network environment. A bandwidth of 100Mbit or more is recommended when
using screen mirroring. Make sure your mobile device is closed to the projector
when using wireless connection. A distance within 1 meter is recommended.
2.Because of HDCP limit, when connecting with smartphone, it can’t display
netflix, hulu and disney.
Connecting with Smartphones and Ipad
Signal source menu operation
Trapezoid correction
ENEN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54
55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72
73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90
91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108
Method 1: Setting with cellular data
1.Turn on the projector, select “Screen Mirroring” as the input source.
It will enter the interface of Screen Mirroring for iOS system. See below.
2.Go to the settings of your iOS mobile device and connect it to the Wi-Fi of
RKcast-XXXXXX (password: 12345678). Please ignore the exclamation mark before it.
3.Swipe up the screen of your iOS mobile device, then tap Screen
Mirroring/AirPlay Mirroring and search for the projector.
For iOS system
192.168.XX.XX DIVICE RKcast-XXXXXX
ENEN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54
55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72
73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90
91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108
Method 2: Setting with Home Wifi
1.Select RKcast-XXXXXX from the searching results to connect.
Wi-Fi of RKcast-XXXXX (password: 12345678)
2.Visit 192.168.XX.XX (please put in the IP showed on the screen) from a browser on your
mobile device, tap WiFi AP >Scan, select your router’s Wi-Fi and enter the right password,
then tap Connect to continue.
3.Your router' s Wi-Fi will be displayed on interface of Screen. See below.
4.Get back to the Wi- Fi setting of your iOS mobile device, then connect it to the same
router's Wi-Fi.
Mi 10
ENEN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54
55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72
73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90
91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108
Method 1: Setting with cellular data
1.Turn on the projector, select “Screen Mirroring” as the Input Source, then choose Android
on the projector interface of Screen Mirroring for Android System.
Method 2: Setting with Home Wifi
2.Turn on the Wi-Fi Switch in your Android device.
3.Select RKcast-XXXXXX from the searching results to connect. Password is 12345678.
4.Activate Multi-Screen function in your Android device and then it will work.
1.Select RKcast-XXXXXX from the searching results to connect.
Wi-Fi of RKcast-XXXXX (password: 12345678)
2.Visit 192.168.XX.XX(please put in the IP showed on the screen) from a browser on your
mobile device, tap WiFi AP >Scan, select your router’s Wi-Fi and enter the right password,
then tap Connect to continue.
To activate this function, your android device must support Multi-Screen/Wireless display.
Names may differ from different devices.
5.Swipe up the screen of your iOS mobile device and tap “Screen Mirroring” to search for
the projector, then select RKcast-XXXXX from the searching results to connect.
For Android System
ENEN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54
55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72
73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90
91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108
4.Get back to the Wi- Fi setting of the android phone, then connect it to the same router's
Wi-Fi.
5.Activate Multi-Screen function in your Android device to search for the projector, then
select RKcast-XXXXX from the searching results to connect.
Go into the Menu--Sound---Audio output, under “Static” model to search the bluetooth
device.
3.Your router' s Wi-Fi will be displayed on interface of Screen. See below.
Connecting with Bluetooth Speaker
Mi 10
ENEN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54
55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72
73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90
91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108
①Connect projector with PC by HDMI cable.
②Choose the media signal channel :“HDMI”
PS: To connect with macbook, an external HDMI to type C cable is needed.
Here has the setting in the laptop when connecting the projector （Fn+ F* [function key]）
Connecting with Sound bar
①Use the 3.5mm audio cable to connect with sound bar.
②Turn on the projector and the sound bar. Then it will work.
③More details, please contact seller at [email protected].
Connecting with PC, TV stick ect. via HDMI port
Laptop DVD Player
Via HDMI Cable（Not Included）
Computer
Audio Output
Device List: gearch device
EDIFIER R1700BT
BTP-P33
Static
MENU
ENEN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54
55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72
73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90
91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108
Connecting with DVD
①Use the AV cable coming with the projector to connect with DVD.
②Turn on the projector and DVD player.
USB Multimedia Connecting
①Insert the USB drive to corresponding interface.
②Choose the video or picture to play.
PS: the projector only supports USB 2.0 stick, and 1080P 30FPS video.
the USB Drive file system must to be FAT32/NTFS, no exFAT
Multimedia File Specification
Image Format
Doesn’t support: Dolby AC3/AAC, DTS, WMA, DivX, VC1, RM, RMVB, FLV, etc
Video Format (Bit Rate up to 30~40 Mbs)
Doesn’t support:MSVC/CRAM, MP42, GMC, IV32, RLE, cvid, RV20, DivX, RM, RMVB,
VC1, FLV, etc
Audio Format
Support
JEPG, PNG, BMP
File extgension
.jpg/.png/.bmp
Support
MPEG1, MPEG2, LPCM,
File extension
.avi/.ts/.dat/.vob/.wmv/.mkv/.mp3/.mp4/.m4a
Support
MPEG1, MPEG2, H.263, H.264,
AVS, VC1, MJPEG, RV30, RV40,
HEVC
File extension
.dat/.ts/.mp4/.mpg/mpeg/.avi/.mkv/.mov/.as-
f/.flv/.3gp/.3gpp/.tp
ENEN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54
55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72
73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90
91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108
Ceiling mount hole
Ceiling mount
There is a hole in the bottom of the projector for ceiling mount.
Picture Menu
Installing the projector
Main Function of the Menu
ENEN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54
55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72
73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90
91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108
Picture Mode
Color temperature
Aspect Ratio
Noise Reduction
Projection Mode
Zoom
Menu included
Standard/soft/vivid/ user
medium/warm/User/Cool
Auto/4:3/16:9
Off/Low/Middle/High/Default
Front/Rear/Front on Ceiling/
Rear on ceiling
75%-100%
Function
To adjust the “Contrast/Brightness/Col-
or/Sharpness/Tint” of the image
To adjust the color temperature
(red/green/blue)
Aspect ratio let you configure how
images are displayed
Reduce the image’s noise,make clear
flip the image according to the
placement
Adjust the image size(horizontal and
Vertical) while playing
Important Notices:
Picture Mode: Only under mode “ User” we could change the Contrast/Brightness/Col-
or/Sharpness of the picture.
Sound Menu
Sound
Sound Mode
Balance
Auto volume
Audio output
Menu included
Standard/music/movie/Sports/User
-50 to +50
Off/Auto
Static/Auto/Off
Adjust the sound mode
Balance the 2 pcs bulti-in speaker
Adjust the volume
Function
Choose the Bluetooth mode,
connect the extra speaker
ENEN
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54
55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72
73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90
91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108
Note:
In the Sound mode “User” interface, you can adjust the “Treble/Bass” of the image by using
the +- button on the remote control in the “0-100” range.
Audio Output, you can search the external speaker to connect via the static mode.
Sleep Timer: You can use this function to set the sleep time of the projector. Time adjustment
range "OFF/10min/20min/30min/60min/90min/120min/180min/240min"
Time Menu
Option Menu
Other manuals for K5
1
Table of contents
Languages:
Other Wimius Projector manuals
