WIN Enterprises PL-8000 Series User manual

User’s Manual
WIN Enterprises, Inc. May, 2009
1
User’s Manual
Version 1.0
PL-8000
Networking Appliance
1U Rack-mount Intel® EP80579 Network Appliance with 8 x
GbE, SATA, CF, LCM
[email protected] [phone]

User’s Manual
WIN Enterprises, Inc. May, 2009
2
© Copyright 2008. All Rights Reserved
Manual Edition 1.0, May, 2009
This document contains proprietary information protected by copyright. All rights are reserved; no
part of this manual may be reproduced, copied, translated or transmitted in any form or by any means
without prior written permission of the manufacturer.
The content of this document is intended to be accurate and reliable; the original manufacturer assumes
no responsibility for any inaccuracies that may be contained in this manual. The original
manufacturer reserves the right to make improvements to the products described in this manual at any
time without prior notice.
Trademarks
IBM, EGA, VGA, XT/AT, OS/2 and PS/2 are registered trademarks of International business Machine
Corporation
Award is a trademark ofAward Software International, Inc
Intel is a trademark of Intel
RTL is a trademark of Realtek
VIA is a trademark of VIATechnologies, Inc
Microsoft, Windows, Windows NT and MS-DOS are either trademarks or registered trademarks of
Microsoft Corporation
All other product names mentioned herein are used for identification purpose only and may be
trademarks and/or registered trademarks of their respective companies
Limitation of Liability
While reasonable efforts have been made to ensure the accuracy of this document, the manufacturer
and distributor assume no liability resulting from errors or omissions in this document, or from the use
of the information contained herein.
For more information on PL-8000 or other WIN products, please visit our website
http://www..win-ent.com .
For technical supports or free catalog, please send your inquiry to
[email protected] .

User’s Manual
WIN Enterprises, Inc. May, 2009
3
Table of Contents
Chapter 1. General Information...............................................................................5
1.1 Introduction........................................................................................................5
1.2 Specifications.....................................................................................................5
1.3 Ordering Information.........................................................................................6
1.4 Packaging...........................................................................................................7
1.5 Precautions.........................................................................................................7
1.6 System Layout ...................................................................................................9
1.7 Board Dimensions............................................................................................10
Chapter 2. Connector/Jumper Configuration.........................................................11
2.1 Connector/Jumper Location and Definition.....................................................11
2.2 Connector and Jumper Setting.........................................................................13
2.3 CompactFlashTM Card Socket Pin Define........................................................24
Chapter 3. Optional GbE Module & Riser Card Setting .......................................25
3.1 R137A: Ethernet module with four GbE Copper ............................................25
3.2 R119: Ethernet module with two GbE Copper and two GbE SFP ..................26
3.3 R120: Ethernet module with four GbE SFP ....................................................27
3.4 R121: Ethernet module with two GbE Copper or SFP....................................28
3.5 R122: Ethernet module with four GbE Copper ...............................................29
3.6 R143: Riser card for expansion module PCI-E x4...........................................30
3.7 R144: Riser card for PCI-E x4 add-on card (PCI-E x16 connector) ...............30
Chapter 4. BIOS Setup...........................................................................................26
4.1 Quick Setup......................................................................................................31
4.2 Entering the CMOS Setup Program.................................................................32
4.3 Menu Options...................................................................................................33
4.4 Advanced Menu...............................................................................................34
4.5 PCIPnP Menu...................................................................................................47
4.6 Boot Menu .......................................................................................................49
4.7 Security Menu..................................................................................................51
4.8 Chipset Menu...................................................................................................53
4.9 Exit Menu .......................................................................................................56
Chapter 5. Utility & Driver Installation.................................................................58
5.1 Operation System Supporting..........................................................................58

User’s Manual
WIN Enterprises, Inc. May, 2009
4
5.2 System Driver Installation ...............................................................................58
5.3 LAN Driver Installation...................................................................................59
Appendix A: Programming the Watchdog Timer ..................................................60
Appendix B: LAN Bypass Function......................................................................63
Appendix C: Programming the GPIO....................................................................64
Appendix D: System Resources.............................................................................66
Appendix E: Cable Development Kit....................................................................70

User’s Manual
WIN Enterprises, Inc. May, 2009
5
Chapter 1. General Information
1.1 Introduction
The PL-8000 is a 1U rack-mounted hardware platform designed for network
service applications. Built with Intel® Embedded IA components warranteed
for longevity, the PL-8000 supports the Intel® EP80579 Integrated SoC with
QuickAssist security accelerator. Compared against three chip solutions,
Intel® EP80579 offers more application specific performance in less space
with the PL-8000.
The platform supports SoC core speed that ranges from 600Mhz to 1.2 GHz,
high bandwidth DDRII DIMM slot with memory up to 2GB and a full set of VPN
functions such as encryption, hashing and public/private key generation. In
order to provide the best network performance and best utilization, the
powerful storage interfaces include one 3.5" SATA HDD and CompactFlash™.
This platform affords five GbE Copper and max to 8 GbE Ethernet ports via
PCI-E by 1 or by 4 on front-panel. To prevent network problems when the
platform shuts down, PL-8000 supports one segment of LAN bypass function
through WDT and GPIO pin definitions. The front panel also has one USB 2.0
port, one RJ-45 console port and LED indicators that monitor power and
storage device activities for local system management, maintenance and
diagnostics. In addition, the PL-8000 supports two PCI-E by4 slot, and is
RoHS, FCC and CE compliant.
1.2 Specification CPU Intel® EP80579 Integrated Processor (Tolapai)
supports 600/1066/1200 MHz processors
Chipset Intel® EP80579 (Tolapai)
Front Side Bus 1333/1066/800MHz FSB
Processor System
BIOS AMI®BIOS
Technology Un-buffered and Non-ECC DDR2
800/667/533/400 MHz memory
Memory
Capacity Up to 2GB with 1 SO-DIMM socket
Expansion Expansion Slots one PCI-E x4 slot for expansion module
one PCI-E x4 golden finger for expansion
module (via optional Riser Card,R143)
Ethernet GbE Ethernet Support max 8 GbE ports (4 GbE via optional
expansion module)

User’s Manual
WIN Enterprises, Inc. May, 2009
6
LAN bypass two pairs bypass
HDD one internal 3.5” SATA HDD bayStorage
Compact Flash
Socket
one CompactFlashTM Type I/II
USB one USB2.0
one internal 5x2 pin header
I/O
Serial one RJ45 Console port (COM1)
one internal 5x2 pin header (COM2)
Power Supply Watt ATX power supply
Form Factor 1U rack-mount
LCD Module one 16x2 LCM
Keypad Four buttons keypad
LED one Power LED (Green)
one HDD LED (Yellow)
one Status LED (Green/Yellow via
programmable GPIO)
Dimension（W x D
x H）
440mm (W) x 270mm (D) x 44mm (H)
(17.3” W x 10.7” D x 1.7” H)
Operating
Temperature
Operating: 0 ~ 40°C ( 32 ~ 104°F )
Mechanical and
Environment
Humidity 10 ~ 85% relative humidity, non-operating,
non-condensing
Weight 1pc/CTN, 5.2kgs, 59cm(W) x 43.2cm(D) x 15.9cm(H)
Certification CE/FCC
1.3 Ordering Information
We offer the following accessories for the PL-8000 appliance.
PL-8000A 1U Rackmount Intel EP80579 network system, application Tolapai
600MHz onboard, 5 GbE, SATA, CF, support bypass (CB-7970A)
PL-8000C 1U Rackmount Intel EP80579 network system, application Tolapai
1.2GHz onboard, 8 GbE, SATA, CF, support bypass (CB-7970C +
R137A)
PL-8000E 1U Rackmount Intel EP80579 network system, embedded Tolapai
1.2GHz onboard, 7 GbE, SATA, CF, PCI-Ex4 slot, support bypass
(CB-7970E + R137A)
R119A Expansion module with 2 RJ45 GbE ports and 2 SFP ports, Intel

User’s Manual
WIN Enterprises, Inc. May, 2009
7
82571EB
R120A Expansion module with 4 SFP GbE ports, Intel 82571EB
R121A Expansion module with 2 SFP ports, Intel 82571EB
R121B Expansion module with 2 RJ45 GbE ports, Intel 82571EB
R122A Expansion module with 4 RJ45 ports, Intel 82571EB
R137A Expansion module with 4 RJ45 ports, Intel 82573L
R143 Riser card for Expansion module (PCI-E x4)
R144 Riser card for PCI-E x4 add-on card (standard PCI-E x16 connector)
DK001 Cable development kit
1.4 Packaging
Check that the following items have been included in the package before
installation.
1. PL-8000 Appliance
2. Quick Installation Guide (Optional)
3. Cables (Optional)
4. CD-ROM that contains the following folders:
(1) Manual
(2) System Driver
(3) Ethernet Driver
(4) Utility Tools
If any item of above is missing or damaged, please contact your dealer or
retailer from whom you purchased the PL-8000. Keep the box and carton
when you probably ship or store PL-8000 in near future. After you unpack the
goods, inspect and make sure the packaging is intact. Do not plug the power
adapter to the appliance of PL-8000 if you already find it appears damaged.
Note: Keep the PL-8000 in the original packaging until you start installation.
1.5 Precautions
Please make sure you properly ground yourself before handling the PL-8000
appliance or other system components. Electrostatic discharge can be easily
damage the PL-8000 appliance.
Do not remove the anti-static packing until you are ready to install the PL-8000
appliance.

User’s Manual
WIN Enterprises, Inc. May, 2009
8
Ground yourself before removing any system component from it protective
anti-static packaging. To ground yourself, grasp the expansion slot covers or
other unpainted parts of the computer chassis.
Handle the PL-8000 appliance by its edges and avoid touching its
components.

User’s Manual
WIN Enterprises, Inc. May, 2009
9
1.6 System Layout
PL-8000 Front Side
PCI-E slot & Expansion
Module (optional)
HDD bay
CPU
DDR2
SO-DIMM
Power supply CF card

User’s Manual
WIN Enterprises, Inc. May, 2009
10
1.7 Board Dimensions

User’s Manual
WIN Enterprises, Inc. May, 2009
11
Chapter 2. Connector/Jumper Configuration
2.1 Connector/Jumper Location and Definition

User’s Manual
WIN Enterprises, Inc. May, 2009
12
Connector Define Connector Define
CN1 SATA1 Connector CN21 Giga LAN RJ45 Connector
CN2 LED Pin Header CN22 Giga LAN RJ45 Connector
CN3 FAN Connector(+12V) CN23 Giga LAN RJ45 Connector
CN4 FAN Connector(+12V) CN24 Giga LAN RJ45 Connector
CN5 FAN Connector(+12V) CN25 COM1 RJ45 Connector
CN6 SATA0 Connector
(co-layout with CF)
CN26 USB0 Connector
CN7 RESET Pin Header CN27 +12V Power jack
CN8 GPO Pin Header CN28 PCI-Ex4 Gold Finger(WIN)
CN9 4P Power Connector (Output) CN29 LAN-Switch SLOT
CN11 LPC Pin Header CN31 USB Header
CN12 COM2 Box Header CN32 ATX SWITCH
CN13 PCIEx4 SLOT(WIN) CN33 LCM Keypad control
CN14 KB/MS Pin Header CN34 LCM connector
CN15 ATX Connector JP1 Reset or Lan Bypass with
Watchdog
CN16 SPI Pin Header JP3 CLEAR CMOS
CN18 GPI Pin Header JP4 LAN Bypass
CN19 LED
CN20 Giga LAN RJ45 Connector

User’s Manual
WIN Enterprises, Inc. May, 2009
13
2.2 Connector and Jumper Setting
CN1/CN6:SATA Connector
Pin Signal
1 Ground
2 TXP
3 TXN
4 Ground
5 RXN
6 RXP
7 Ground
CN2 :LED Pin Header
Pin Define(C1) Define(C2) Define(C3)
1 NC NC +3.3V
2 NC NC BYPASS#
3 NC NC +3.3V
4 NC NC GND
5 +3.3V +3.3V +3.3V
6 GND GND SATA#
7 NC NC SIO-GPO7
8 NC NC SIO-GPO6
9 +3.3V +3.3V SIO-GPO5
10 SATA# SATA# SIO-GPO4
11 LAN1_100# GPO19 GPO19
12 LAN1_1G# GPO18 GPO18
13 +3.3V GPO25 GPO25
14 LAN1_ACT# GPO24 GPO24
15 LAN2_100# GPO28 GPO28
16 LAN2_1G# GPO27 GPO27
17 +3.3V LAN1_LNK LAN1_LNK
18 LAN2_ACT# LAN1_ACT LAN1_ACT
19 LAN3_100# LAN2_LNK LAN2_LNK
20 LAN3_1G# LAN2_ACT LAN2_ACT
21 +3.3V LAN3_LNK LAN3_LNK

User’s Manual
WIN Enterprises, Inc. May, 2009
14
22 LAN3_ACT# LAN3_ACT LAN3_ACT
23 LAN4_100# LAN4_LNK LAN4_LNK
24 LAN4_1G# LAN4_ACT LAN4_ACT
25 +3.3V LAN5_LNK LAN5_LNK
26 LAN4_ACT# LAN5_ACT LAN5_ACT
CN 3 /4 /5 :FAN Connector
Pin Define
1 Ground
2 +12V
3 Speed Detect
CN7: Reset Pin Header
Pin Define
1 Reset #
2 GND
CN8: GPO Pin Header
Pin Define Pin Define
1 GPO4- 2 GPO4+
3 GPO5- 4 GPO5+
5 GPO6- 6 GPO6+
7 GPO7- 8 GPO7+
9 Ground 10 VCC

User’s Manual
WIN Enterprises, Inc. May, 2009
15
CN9: Auxiliary HDD Power Connector
Pin Assignment
1 +12V
2 Ground
3 Ground
4 +5V
CN11: LPC Connector
Pin Define Pin Define
1 +3.3V 2 AD 0
3 AD 1 4 AD 2
5 AD 3 6 Frame#
7 PCIRST# 8 +5V
9 CLOCK 10 NC
11 Ground 12 Ground
CN12 :COM2 Box Header
Pin Define Pin Define
1 DCD# 6 DSR#
2 RXD# 7 RTS#
3 TXD# 8 CTS#
4 DTR# 9 RI#2
5 Ground 10 NC

User’s Manual
WIN Enterprises, Inc. May, 2009
16
CN13: PCI-Ex4 SLOT(WIN)
Pin Define Pin Define
B1 +12V A1 GND
B2 +12V A2 +12V
B3 +12V A3 +12V
B4 GND A4 GND
B5 SMCLK A5 +3.3V
B6 SMDAT A6 +3.3V
B7 GND A7 Pull down
B8 +3.3V A8 +3.3V
B9 NC A9 +3.3V
B10 +3.3V_Stand
by
A10 +3.3V
B11 WAKE# A11 PE_RESET#
B12 Power good A12 GND
B13 Gnd A13 CLK
B14 TXP0 A14 CLK#
B15 TXN0 A15 GND
B16 GND A16 RXP0
B17 +5V A17 RXN0
B18 GND A18 GND
B19 TXP1 A19 +5V
B20 TXN1 A20 GND
B21 GND A21 RXP1
B22 GND A22 RXN1
B23 TXP2 A23 GND
B24 TXN2 A24 GND
B25 GND A25 RXP2
B26 GND A26 RXN2
B27 TXP3 A27 GND
B28 TXN3 A28 GND
B29 GND A29 RXP3
B30 GPIO23 A30 RXN3
B31 GPIO27 A31 GND
B32 GND A32 GPIO28

User’s Manual
WIN Enterprises, Inc. May, 2009
17
CN14:KB/MS Pin Header
Pin Define Pin Define
1 KCLK 2 MCLK
3 KDAT 4 MDAT
5 NC 6 NC
7 PS2_GND 8 PS2_GND
9 PS2_VCC 10 PS2_VCC
CN15:ATX Power Connector
Pin Define Pin Define
11 +3.3VSB 1 +3.3VSB
12 NC 2 +3.3VSB
13 Ground 3 Ground
14 Ground 4 +5VSB
15 Ground 5 Ground
16 Ground 6 +5VSB
17 Ground 7 Ground
18 NC 8 NC
19 +5VSB 9 NC
20 +5VSB 10 +12VSB
CN16 :SPI Pin Header
Pin Define Pin Define
1 +3.3V 2 GND
3 CS# 4 SCLK
5 MISO 6 MOSI
7 NC 8 FLASH_IO

User’s Manual
WIN Enterprises, Inc. May, 2009
18
CN17 :Parallel Box Header
Pin Define Pin Define
1 STROBE 14 AUTOFD
2 PD0 15 ERR
3 PD1 16 INT
4 PD2 17 SLCTIN
5 PD3 18 Ground
6 PD4 19 Ground
7 PD5 20 Ground
8 PD6 21 Ground
9 PD7 22 Ground
10 ACK* 23 Ground
11 BUSY 24 Ground
12 PE 25 Ground
13 SLCT 26 Ground
CN18: GPI Pin Header
Pin Define
1 GPI0
2 GPI1
3 GPI2
4 GPI3
5 Ground
CN19 :LED (1U)
Pin Define Pin Define
1 Power_LED+ 2 Power_LED-
3 SATA_LED+ 4 SATA_LED-
4 State_LED+ 6 State_LED-

User’s Manual
WIN Enterprises, Inc. May, 2009
19
CN20~CN24:Gigabit LAN connector
Pin Define
1 MDI0+
2 MDI0-
3 MDI1+
4 MDI2+
5 MDI2-
6 MDI-
7 MDI3+
8 MDI3-
LED:
D2 : Link/Activity LED
Link Green
Activity Blinking
D1 : Bi-Color Speed LED
10 Mbps Off
100 Mbps Yellow
1000Mbps Green
CN25:COM1 RJ45 Connector
Pin Define
1 CTS#
2 DTR#
3 TXD#
4 GPIO56
5 Ground
6 RXD#
7 DSR#
8 RTS#

User’s Manual
WIN Enterprises, Inc. May, 2009
20
CN26 : USB0 Connector
Pin Define
1 +5V
2 Data0-
3 Data1+
4 Ground
CN27 : +12V Power jack
Pin Define
1 +12V
2 GND
3 GND
CN28 : PCI-Ex4 Gold Finger (WIN)
Pin Define Pin Define
B1 +12V A1 GND
B2 +12V A2 +12V
B3 +12V A3 +12V
B4 GND A4 GND
B5 SMCLK A5 +3.3V
B6 SMDAT A6 +3.3V
B7 GND A7 Pull hi to 3.3V
B8 +3.3V A8 +3.3V
B9 NC A9 +3.3V
B10 +3.3V_Standby A10 +3.3V
B11 WAKE# A11 PE_RESET#
B12 Power good A12 GND
B13 Gnd A13 CLK
B14 TXP0 A14 CLK#
B15 TXN0 A15 GND
B16 GND A16 RXP0
B17 +5V A17 RXN0
B18 GND A18 GND
