Winco 8500 Reference guide

Page 1 of 4
006060 Rev. 02 Date: 03/04/20 NCG
1. READ AND FOLLOW ALL DIRECTIONS.
2. NEVER stand on table or INJURY MAY OCCUR.
3. NEVER allow user to sleep unattended on table or INJURY MAY OCCUR.
4. NEVER leave an unconscious user unattended on table or INJURY MAY OCCUR.
5. DO NOT use table for transporting user in or with ANY type of vehicle or trailer. Winco tables have not been tested
or approved for use by an occupant in any type of vehicle or trailer.
6. NEVER leave an infant or child unattended on table or INJURY MAY OCCUR.
7. DO NOT put hands, feet or clothing into any openings when changing positions on table. Attendant MUST confirm
that user’s hands and feet are safe while changing table positions or INJURY MAY RESULT.
8. Periodically, recheck tightness of all nuts, bolts, and screws.
9. USE ONLY WINCO AUTHORIZED REPLACEMENT PARTS.
10. NEVER EXCEED the recommended weight capacity of 400 lbs. (181.4 kg).
11. SAVE THESE INSTRUCTIONS for future reference and training.
8500-8510
Treatment Table
CUSTOMER INSTRUCTIONS
Tools needed:
•Phillips-head screwdriver
•7/16” wrench (multiple size wrench included)
•Scissors or box cutter
•If using powered tools, always start hardware together by hand first and wear safety goggles
SEE “Parts Reference” (pg.3) for visual reference during assembly.
1. After checking your product for any shipping damage, table needs to be positioned upside-down on cardboard
or protective surface. Remove all packing material and hardware that was secured for shipping. Cut tape on
corners of box so that cardboard will lay flat while you assemble table.
2. You will find two Table Legs, in-between and attached to the Table Frame Rails. Pivot up the Table Legs
and install one (1) ¼-20 x 2 ½ machine screw through the outer, empty hole of the Table Frame Rails,
followed by hand threading (1) ¼-20 hex lock nut onto the screw, connecting each Table Leg to the frame.
NOTE: Each Table Leg has an Upper Leg Brace that need to align with two threaded holes in the wood
of the Upholstered Top.
3. Install (4) ¼-20 x 1-½” screws through (2) holes in each upper brace of the Table Leg, and into (2) threaded
holes (each end) in the wood of the Upholstered Top.
NOTE:Do not fully tighten at this time.
PLEASE READ AND FAMILIARIZE YOURSELF WITH ALL INSTRUCTIONS BEFORE PROCEEDING WITH ASSEMBLY
PLEASE READ AND FAMILIARIZE YOURSELF WITH ALL INSTRUCTIONS BEFORE USING THIS PRODUCT.
If you have trouble understanding these instructions, contact Winco Customer Service at [phone]
before attempting to use this product; otherwise injury may occur.
8500-8510 Weight Capacity = 400 lbs. (181.4 kg.)
Winco assumes no responsibility for damage or injury caused by improper assembly,
installation, use, or maintenance of these products.

Page 2 of 4
006060 Rev. 02 Date: 03/04/20 NCG
4. Place (4) ¼-20 x 1-½” carriage bolts into the (4) square holes through the Lower Leg Brace of the Table
Legs.Heads of screws should face the ends of table, for better appearance.
5. Install the Cross-brace.Welds on the Cross-brace must face down toward floor when the table is upright.
Attach with the (4) screws that you just installed on step 4 and secure with (4) ¼-20 nuts.
6. TIGHTEN ALL nuts & bolts.
7. Install the four (4) Glide Feet completely into the Threaded Inserts located on the bottom of the Table Legs.
Additional instructions for 8510 models ----- (8500 model go to step 11)
8. Attach the Face Slot Tube so that one hole is aligned with the center hole of the Upper Leg Brace (flat side of
Face Slot Tube faces table bottom). Position the opposite end of the Face Slot Tube over the 1” nylon
spacer and the hole in table bottom. Install two (2) 1-3/4” Panhead Phillips screws through both ends of the
Face Slot Tube, then tighten into the wood table bottom with a Phillips Head Screwdriver.
9. Install Face Paper Holder using (2) 1” “drywall-type” screws in pre-drilled holes on either side of Face Slot.
10. Install Face Paper Cutter on Table Frame Rail (where desired) opposite Face Paper Holder. Peel backing
from tape on back of cutter, press cutter firmly into place.
11. Using at least two people, turn table upright.
12. Place Paper Holder Rod through the (2) Paper Rod Clamps, (with paper roll in-between).
13. Adjust the (4) Glide Feet to level table.
Optional Shelf installation:
14. Double-sided tape has been installed on the Cross-brace.
15. Before removing paper on tape, “test fit” the shelf. Shelf should be approximately ¼” from edges of Lower
Leg Brace.
16. Once you are certain of where you will position the shelf, peel off the paper to expose adhesive.
17. Carefully position shelf in place on adhesive.
Vinyl Strap Adjustment – Should the vinyl strap on your Winco table need to be adjusted, unscrew the screw that
currently holds either side of it in place. Pierce another hole in the strap to give desired tension and re-insert
screw.
Wrinkles in Vinyl – Storage and shipping can cause wrinkles of the vinyl on your Winco table. This is normal.
Please allow 1-2 weeks at room temperature (approx. 70 degrees) to allow for vinyl to expand back to original
appearance.
Do not over tighten nuts and bolts. Periodically recheck all fasteners for tightness.
If the Optional Shelf and Reinforced Cross-brace have been ordered; make sure that the smooth
surface (side with tape) of the Reinforced Cross-brace will face upward (when the table is in the
upright position) prior to fastening to the Table Legs.
After peeling paper from adhesive tape:
Use damp sponge to moisten tape to allow shelf to be adjusted during install.
Once tape is dry shelf will stay in place.
After peeling paper from adhesive tape:
Use damp sponge to moisten tape to allow face paper cutter to be adjusted during install.
Once tape is dry face paper cutter will stay in place.

Page 3 of 4
006060 Rev. 02 Date: 03/04/20 NCG
Parts Reference
Visit our website www.wincomfg.com/product-documents/parts-lists for a complete parts list of your table or
call Customer Service at 1-800-237-3377 to request it by mail.
GENERAL CARE AND CLEANING:
Periodically inspect tightness of all screws, bolts, and nuts. Winco furnishings are built to provide durable reliable
service when properly cared for. In general, all our products should be cleaned, rinsed, and allowed to air dry. It is
important to note that disinfecting a product is not the same as cleaning the product. Disinfectants alone will not
provide adequate cleaning. They do not have grease or oil cutting properties to remove grime or hair and skin oils.
Over time, the appearance, feel, and performance of your upholstery may diminish if not cleaned properly.
CLEANING:
To remove grime, hair, and body oils, your furnishings should be cleaned with a mild soap and water solution and
a damp cloth on a regular basis. Avoid harsh detergents that could damage the finish of your product. If the
furnishing is disinfected with bleach, it MUST be wiped off using only clean water on a damp cloth and then be
allowed to air dry. Failure to rinse with clean water can result in a build-up of residues over time that can damage
your product.
1/4-20 x 2 ½ Machine Screw
and Lock Nut (Pre-Installed)
1/4-20 x 2 ½ Machine Screw
and Lock Nut (To Be Installed)
Table Frame Rail

Page 4 of 4
006060 Rev. 02 Date: 03/04/20 NCG
Design, appearance, parts, & construction are subject to change without notice
