Winco augustine Installation guide

PLEASE DO NOT DISCARD THIS MANUAL! KEEP FOR FUTURE REFERENCE AND TRAINING
PATENT PENDING
OWNER’S OPERATING &
MAINTENANCE MANUAL

Copyright 2014, WINCO MFG., LLC
2
IMPORTANT!
PLEASE READ THIS ENTIRE MANUAL BEFORE USING RECLINER. DO NOT INSTALL, MAINTAIN OR OPERATE
THIS EQUIPMENT WITHOUT READING AND FOLLOWING THIS MANUAL. OTHERWISE INJURY AND/ OR DAMAGE
MAY RESULT.
THE INFORMATION CONTAINED IN THIS MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE. PHOTOS ARE
REPRESENTATIVE OF THE PRODUCT AND MAY VARY SLIGHTLY FROM ACTUAL PRODUCTION MODELS.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE!
NO PART OF THIS MANUAL MAY BE DUPLICATED IN ANY FORM WITHOUT THE PRIOR WRITTEN CONSENT OF
WINCO MFG, LLC. UNAUTHORIZED DUPLICATION MAY RESULT IN CIVIL PROSECUTION TO THE MAXIMUM
EXTENT ALLOWED BY LAW.
TABLE OF CONTENTS
IMPORTANT SAFETY INFORMATION........................................................................................3-5
ASSEMBLY INSTRUCTIONS......................................................…..............................................6-7
ATTENDANT OPERATING INSTRUCTIONS............................................................…...............8-11
OCCUPANT OPERATING INSTRUCTIONS...............................................................................12-13
GENERAL MAINTENANCE...............................................……..................................................14-15
SPECIFICATIONS........................................................................................................................16
AUGUSTINE CHAIR OPTIONS...................................................................................................17
ARM COVER OPTION INSTRUCTIONS.....................................................................................18-20
CONTACT & WARRANTY INFORMATION..........................................................…....BACK COVER
Winco assumes no responsibility for damage or injury caused by the improper assembly,
installation, use or maintenance of this product.
Products with the following markings are intended for commercial use only.
SYMBOLS
TYPE BAPPLIED PART
FOLLOW INSTRUCTIONS DC VOLTAGE
GENERALWARNING SIGN PINCH POINT
WARNING SIGN
CENTRAL-LOCKING
BRAKE
SYMBOLFOR MANUFACTURER

Copyright 2014, WINCO MFG., LLC
3
IMPORTANT - PLEASE READ
FOR PRODUCTS WITH POWERED OPTIONS (Heat, Massage, etc...)
IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE INSTRUCTIONS
(Read all instructions before using this product.)
When using an electrical appliance, basic precautions should always be followed, includ-
ing the following:
DANGER - To reduce the risk of electric shock always unplug this product from the electrical outlet before cleaning,
maintenance or servicing.
WARNING:
1. Unplug this product from the electrical outlet when not in use.
2. Supervision should be provided when using this product.
3. Use this product only for its intended use as described in this manual.
4. Do not use attachments not recommended by the manufacturer.
5. Never operate this product if it has a damaged cord or plug, if it is not working properly, if it has been dropped or
damaged, or dropped into water, contact an authorized Winco service center for instructions.
6. DO NOT carry or pull this product by power supply cord or use the cord as a handle.
7. Keep the cord away from heated surfaces.
8. Do not use outdoors.
9. To disconnect, turn all controls to the "off" position, then remove plug from outlet. Pull plug only to remove cord.
10. Clean switch with a damp cloth only – Warranty will be VOID if liquid is introduced into switch mechanism.
11. Extension cords are not recommended.
12. DO NOT roll recliner or other equipment over cord.
13. This product is for use on a nominal 120-volt circuit and has a three-pin plug. If the plug does not fit into the outlet,
contact a certified electrician to install the proper outlet. DO NOT MODIFY THE PLUG IN ANY WAY. No adapter
should be used with this product.
14. For an added level of safety; Winco recommends the use of a 120 volt GFCI (ground fault circuit interrupter) out-
let.
15. Keep children away from extended foot support (or other similar parts).
DANGER:
i. Never insert pins, or attach other metallic fasteners into/onto any part of this chair.
ii. Do not use this product if the covering shows signs of deterioration, such as checking, blistering, or cracking.
iii. KEEP DRY - Do not operate in a wet or moist condition or environment.
WARNING:
i. Long term, continuous exposure to heat may cause burns. It is recommended that skin in contact with heated
area be checked for redness and blistering during long term usage. Do not use on an infant, invalid or incapaci-
tated person. Do not use on insensitive skin or on a person with poor blood circulation. If you are uncertain if you
should use this product, please consult your physician about the use of heat and massage.
ii. Do Not Crush/Pinch heating elements or wiring.

Copyright 2014, WINCO MFG., LLC
4
For Heat & Heat and Massage Chairs
This equipment is marked with the industry recognized symbol
indicating it is a “Class II Double-Insulated” device as defined by IEC 60601-1. As such, it does NOT require a three conductor power cord (i.e. one
with a ground connection) for safety purposes. While the equipment can be safely operated with no ground connection, a three conductor power
cord is provided to satisfy customer expectations for typical equipment configuration. Devices qualifying as double insulated require different testing
& examination procedures than “Class I Grounded” devices. If your facility requires the product to be tested, be sure to follow testing & examination
procedures for “Class II Double-Insulated” devices.
ISOLATION DIAGRAM FOR HEAT & MASSAGE SYSTEM
Area Insulation Type
A Basic Operational
B Double Insulated/Reinforced
C Double Insulated/Reinforced
D Double Insulated/Reinforced
E Double Insulated/Reinforced
F Double Insulated/Reinforced
G Inlet FE pin only connects to inlet & pad
IMPORTANT - PLEASE READ

Copyright 2014, WINCO MFG., LLC
5
IMPORTANT - PLEASE READ
BASIC SAFETY PRECAUTIONS:
1. READ AND FOLLOW ALL DIRECTIONS.
2. DO NOT put hands, feet, or clothing into any openings when changing positions on recliner. Attendant MUST con-
firm that users arms, legs, hands and feet are clear while changing recliner positions or SERIOUS INJURY MAY
OCCUR.
3. Remove or move chair accessories out of the way of patients legs (ie. over-lap table & pivot table) when reclining/
changing position of patient.
4. LOCK casters at all times when chair is staionary. UNLOCK casters when moving/transporting chair.
5. STAY CLEAR of the recliner mechanisms when operating chair.
6. DO NOT use recliner for transporting in or with ANY type of vehicle or trailer. Winco recliners have not been tested
or approved for use by an occupant in any type of vehicle or trailer.
7. NEVER use the chair arms or backrest, or tables as a seat; SERIOUS INJURY OR DAMAGE MAY OCCUR.
8. Periodically check the tightness of all nuts, bolts and screws.
9. Immediately REMOVE FROM SERVICE any recliner with broken recline mechanisms, torn upholstery, and/or other
mechanical or visible damage.
10. USE ONLY WINCO AUTHORIZED REPLACEMENT PARTS.
11. NEVER EXCEED the recommended weight capacity.
12. This chair is NOT intended nor suitable for patient transport.
This section intentionally left blank

Copyright 2014, WINCO MFG., LLC
6
ASSEMBLY INSTRUCTIONS
BACK ASSEMBLY INSTRUCTIONS:
1. Lock casters by pushing down the central-lock lever located at the
rear of chair. (See Lock/Unlock Casters pg.8)
IMPORTANT:
• Keep objects and persons clear of the chair before performing
step 2.
2. Pull one of the recline levers (A), located on either side of the
chair, until fully extended to bring the recline mechanism (B) into
its upright position.
NOTE: Legrest is spring loaded and will be rapidly released into
the recline position when recline lever is pulled.
3. Release the recline lever and push legrest in, to its stored
position.
PREPARATION:
1. Carefully examine your product for any damage. Inspect all components.
IF DAMAGE IS EVIDENT, REFUSE SHIPMENT, & CONTACT FREIGHT CARRIER OR WINCO IMMEDIATELY.
2. Remove all packaging material that was secured for shipping.
3. Carefully remove the product from the carton.
4. Save all boxes and packaging material until after you have assembled your product and have verified that all com-
ponents are functioning properly.
2
1
A
REAR BRAKE ASSEMBLY INSTRUCTIONS:
This chair is shipped with the central-locking casters in the LOCKED
position.
To assemble the REAR central-lock lever:
1. Loosen thumb screw and slide the lever (A) onto the "HEX" por-
tion of the bar.
2. Tighten thumb screw (B).
3. Lift UP on the lever to UNLOCK the central-locking casters.

Copyright 2014, WINCO MFG., LLC
7
6
ASSEMBLY INSTRUCTIONS
BACK ASSEMBLY INSTRUCTIONS:
4. Hold the rear apron up, exposing the mounting brackets (A). Lift the
upholstered back by its sides while aligning the mounting brackets
with the recline mechanism (B).
WARNING:
• Keep hands clear of connection points or injury may occur
IMPORTANT:
• We recommend two people be used for step 4
• Be careful not to tear or puncture vinyl.
5. Slide the back onto the recline mechanism until the middle hole of
the mounting bracket (A) is aligned with the middle hole of the recline
mechanism (B).
6. Install knobs (A) (tethered to back) and tighten to a secure fit.
7. Ensure that the rear apron rests OVER the rear brace of chair.
IMPORTANT:
• Test to ensure the back has been properly installed by pulling up
on the back. The back should remain securely in place.
5
7
4

Copyright 2014, WINCO MFG., LLC
8
CASTER OPERATION: Lock/Unlock
This chair features two types of casters, rigid and central-locking.
The front two casters are rigid casters. They are NOT designed to swivel
in order to facilitate stable straight steering.
The rear two casters are central-locking casters. They are designed to
swivel 360°. When central-lock is engaged, caster wheels will NOT roll
and caster will NOT swivel.
From the REAR of chair
1. TO LOCK REAR CASTERS: Press down on central-lock lever (A).
Lever will lock into position.
2. TO UNLOCK REAR CASTERS: Lift up with foot on central-lock lever
(A). Lever will return to the unlocked position.
WARNING:
• Ensure central locking brake is engaged at all times, particularly
BEFORE seating an occupant in chair, and when occupant is
exiting the chair.
• Ensure casters are UNLOCKED BEFORE moving or transporting
chair.
• Never operate brakes without proper footwear. "Closed toe"
shoes are recommended for operation of brake mechanism.
From the FRONT of chair (OPTIONAL FEATURE)
3. TO LOCK REAR CASTERS: Push in on the side of the central-lock
lever labeled "UNLOCKED" (3A). Lever will lock into position &
"LOCKED" will be visible (4A).
4. TO UNLOCK REAR CASTERS: Push in on the side of the central-
lock lever labeled "LOCKED" (4A). Lever will lock into position &
"UNLOCKED" will be visible (3A).
IMPORTANT:
• Push "UNLOCKED" to LOCK
• Push "LOCKED" to UNLOCK
• The visible label indicates the current state of the chair casters.
WARNING:
• Ensure central locking brake is engaged at all times, particularly
BEFORE seating an occupant in chair, and when occupant is
exiting the chair.
• Never operate brakes without proper footwear. "Closed toe"
shoes are recommended for operation of brake mechanism.
2
1
ATTENDANT OPERATING INSTRUCTIONS
4
3

Copyright 2014, WINCO MFG., LLC
9
ATTENDANT OPERATING INSTRUCTIONS
RECLINE CHAIR FROM ATTENDANT POSITION:
Attendant should be positioned on the RIGHT or LEFT side of chair
1. While occupant is seated in the chair, use one hand to operate the
recline lever, located on either side of chair, to activate the legrest
into its raised position.
NOTE: Activate the legrest by pulling the recline lever (A) 1/2 way
out. To recline the back, fully extend the recline lever (A).
2. To operate the infinite back positioning, after occupant's feet have
been raised, use one hand to operate the recline lever (A) and the
other hand to push on the upholstered back (B) until desired position
or maximum recline has been reached.
Release recline lever (A) to maintain position.
IMPORTANT:
• Do NOT force the back of chair up or down without fully extend-
ing either of the two recline levers, this can damage the chair.
2
RETURN CHAIR UPRIGHT FROM ATTENDANT POSITION:
Attendant should be positioned on the RIGHT or LEFT side of chair
1. While occupant is reclined in the chair, attendant should use one
hand to operate the recline lever (A), located on either side of chair,
while using the other hand to pull up on back (B).
Release the recline lever (A) once the back has fully returned to the
upright position.
NOTE: To return the back to the upright position, fully extend the
recline lever (A). Once the cack is returned to the upright position,
release the handle and push the legrest closed.
2. Attendant should use one hand to push down on the legrest (A) until
it locks into its stored position.
NOTE: The recline lever does NOT have to be used to return legrest
to its stored position.
WARNING:
• Attendant should NOT use foot to return the legrest to it's stored
position. Damage to mechanism and upholstery may occur.
2
1A
A
1A

Copyright 2014, WINCO MFG., LLC
10
ATTENDANT OPERATING INSTRUCTIONS
SEAT REMOVAL AND REPLACEMENT:
TO REMOVE THE SEAT:
1. Fully recline the chair back. (See previous page for instruction.)
2. Pull up on the front of the seat until it releases (A), then pull seat out
away from the front of the chair (B).
WARNING:
• Seat is tethered to chair frame. Do not forcefully pull on seat
Chairs equipped with heat and massage:
• DO NOT attempt to unplug wires.
• UNPLUG power cord from power source BEFORE seat removal,
cleaning, or servicing of chair.
• ENSURE all wiring for seat is clear of all moving parts of
the mechanism before, during, and after re-installation of
seat.
TO INSTALL THE SEAT:
3. With the chair back fully reclined, slide the upholstered seat along
mechanism until it stops (A), then press down on the front of the seat
until it locks into position (B).
IMPORTANT: Ensure the side aprons of the seat are positioned out-
side of mechanism and do NOT interfere with seat installation.
4. Verify the seat has been correctly installed by carefully pulling up on the
front and back of the seat. Seat should be secure and not move.
WARNING:
• Attendant should NOT attempt to seat an occupant after seat has
been re-installed without first verifying the seat has been installed
correctly or serious injury may occur.
3
2
This section intentionally left blank

Copyright 2014, WINCO MFG., LLC
11
SIDE-TABLE OPERATION: (OPTIONAL FEATURE)
1. TO RAISE TABLE: Grasp center of table and gently lift into place.
Side-table will lock into place with an audible "click" once fully
extended.
WARNING:
• DO NOT lean or sit on side tables.
• DO NOT use table for support or assistance when exiting or
entering the chair.
• Keep hands and objects clear of the moving parts of the table
mechanism.
IMPORTANT:
• Side-tables have been rated for a MAXIMUM weight capacity of
20 lbs. (9.0 kg)
2. TO STORE: Lift up on the lever located under the side-table and
lower to its stored position.
WARNING:
• Keep hands and objects clear of the moving parts of the table
mechanism.
2
1
ATTENDANT OPERATING INSTRUCTIONS
PIVOT-TABLE OPERATION: (OPTIONAL FEATURE)
TO POSITION THE TABLE:
1. Loosen the adjustment knob (A) and swing away or place in the "lap"
position.
2. Tighten adjustment knob (A) to secure position.
WARNING:
• DO NOT lean or sit on pivot-tables.
• DO NOT use table for support or assistance when exiting or entering
the chair.
IMPORTANT:
• Pivot-tables have been rated for a MAXIMUM weight capacity of
20 lbs. (9.0 kg)
TO REMOVE THE TABLE:
3. Loosen the adjustment knob (A) 2 full turns and lift up on pivot-table.
3
1

Copyright 2014, WINCO MFG., LLC
12
OCCUPANT OPERATING INSTRUCTIONS
RECLINE WHILE IN THE SEATED POSITION:
1. While seated in the chair, pull back on either of the recline levers (A),
located on either side of chair, to activate the legrest into the recline
position.
NOTE: Activate the legrest by pulling the recline lever (A) 1/2 way
out. To recline the back, fully extend the recline lever (A).
2. To operate the infinite back positioning, pull back on the recline lever
and adjust the upholstered back angle by pushing back with your
body until desired angle has been reached.
Release recline lever (A) when you have achieved the desired angle
to lock the back into position.
WARNING:
• DO NOT push or pull legrest to maneuver chair.
• DO NOT stand or sit on the legrest.
• DO NOT place hands, legs, or feet under seat, mid-ottoman, or
legrest.
• Stay clear of recline mechanism when operating chair.
2
1
RETURN TO THE SEATED POSITION:
1. To return the back to the full upright position pull back on either of
the recline levers while sitting upright in the chair.
Release the recline lever once the back has fully returned to the
upright position.
NOTE: To return the back to the upright position, fully extend the
recline lever (A). Once the cack is returned to the upright position,
release the handle and push the legrest closed.
2. Press down on the legrest with legs/feet until it locks into place.
NOTE: The recline lever does NOT have to be used to return legrest
to its stored position.
A
A
1A
2

Copyright 2014, WINCO MFG., LLC
13
OPTIONAL HEAT & MASSAGE OPERATION:
Control is located on the inside of right arm of chair. (Right is determined - as if sitting in the chair)
Heating: (Heating elements are located in the seat & back of chair)
Push HEAT button - See indicator light on switch
3 Lights = High Heat / Bright Light
2 Lights = Medium Heat / Med Light
1 Lights = Low Heat / Dim Light
No Light = HEAT OFF
Allow 5-8 minutes for back and seat to warm to desired setting.
Heat will automatically shut off after approximately 60 minutes. (Timer resets each time switch is pressed)
Massage option: (The massage option uses 4 separate motors located in the backrest of the chair. Two in the lower
backrest, and two in the middle (upper) backrest.
Push MASSAGE button
1X = Lower Back / Low Intensity
2X = Lower Back / High Intensity
3X = Upper & Lower Back / Low Intensity
4X = Upper & Lower Back / High Intensity
5X = Alternating Upper & Lower Back
6X = MASSAGE OFF
Massage will automatically shut off after approximately 15 minutes. (Timer resets each time switch is pressed)
TROUBLESHOOTING:
• With system disconnected from power source, use a DAMP CLOTH ONLY to clean switch, wiring or power pack
(located under seat frame).
• If there is no heat or massage or flashing light on the switch - check power cord connections to wall outlet AND
connection of power cord to power pack unit under chair.
• If switch displays a flashing light; Disconnect from wall, check all accessible wire connectors under chair for
possible loose connections, then re-plug into wall and test again.
• If system still does not work contact Winco customer service: 1-800-237-3377.
OCCUPANT OPERATING INSTRUCTIONS
CORD STORAGE:
(Models with Heat-HT or Heat & Massage-HM)
To prevent tripping on cord, damage to cord, or damage to recliner, the
power cord should be coiled and stored in the "Hook & Loop" fastener
provided BEFORE moving chair or whenever heat & massage is not in
use.
HEAT
MASSAGE
HEAT ONLY
OR

Copyright 2014, WINCO MFG., LLC
14
GENERAL MAINTENANCE
GAS SPRING RELEASE ADJUSTMENT:
If recline levers fail to operate properly, adjust the gas spring using the
instructions below.
1. Recline back of chair.
(See pg. 9 "Recline Chair From Attendant Position")
2. Return legrest to stored position.
3. Remove the seat (A) and position as shown (B).
(See pg. 10 "Seat Removal")
WARNING:
• Seat is tethered to chair frame. Do not forcefully pull on seat.
Chairs equipped with heat and massage:
• UNPLUG power cord from power source BEFORE removing seat,
cleaning, cleaning or servicing chair.
• Chairs equipped with heat and massage - DO NOT attempt to
unplug wires.
• ENSURE all wiring for seat is clear of all moving parts of the
mechanism before, during, and after re-installation of seat.
4. Locate the gas spring and loosen the nut on the gas spring using an
11/16" wrench.
5. Remove the opposite end of gas spring by removing the cotter & clevis
pin.
Proceed to step 6 or 7 depending on the necessary adjustment.
IMPORTANT:
• DO NOT allow button on end of cylinder to depress while performing
this task.
4
3A
5
3B

Copyright 2014, WINCO MFG., LLC
15
GENERAL CARE & CLEANING:
• REGULARLY lubricate pivot points on the recline mechanism with a lubricant approved by your facility. Periodically
position the chair back into full recline position to keep the gas cylinder lubricated.
• Periodically inspect tightness of all screws, bolts, and nuts.
• Winco furnishings are built to provide durable reliable service when properly cared for. In general all of our products
should be 1) Cleaned 2) Rinsed 3) Allowed to air dry. It is important to note that disinfecting a product is not the
same as cleaning the product. Disinfectants alone will not provide adequate cleaning, they do not have grease or oil
cutting properties to remove grime or hair and skin oils. Over time, the appearance and feel and performance of your
upholstery may diminish if not cleaned properly
CLEANING:
Remove grime, hair and body oils; Your furnishings should be cleaned with mild soap & water solution and a damp cloth
on a regular basis (especially where skin & hair make contact with upholstery). Avoid harsh detergents that could dam-
age the upholstery or finish of your recliner. If the furnishing is disinfected with bleach, it MUST be wiped off using only
clean water on a damp cloth and then be allowed to air dry. Failure to rinse upholstery with clean water can result in a
build-up of residues over time that can dry out the upholstery and cause changes to the look and feel of the upholstery
and eventually can lead to cracking.
WARNING:
• When seat is removed, use caution cleaning in and around mechanisms. Keep hands clear of pinch points &
metal edges or injury may occur. Disconnect power (Chairs w/ HM or HT option) when cleaning chair.
6 7
GENERAL MAINTENANCE
GAS SPRING RELEASE ADJUSTMENT: (continued)
Chair will not recline:
6. If chair will NOT recline when left or right recline levers are pulled,
rotate the gas spring clockwise (A) half (1/2) of a revolution (or 180°).
Chair reclines without the use of recline levers:
7. If the chair reclines without the use of recline levers, rotate the gas
spring counter-clockwise (B) half (1/2) of a revolution (or 180°).
8. After adjustment; Replace Clevis Pin and Bow-Tie Cotter Pin.
9. Pull the recline lever (A) and push back on the chair back (B) to
check for proper adjustment. Repeat above steps as needed until
correct release action is achieved. Then TIGHTEN HEX NUT (that
you loosened in step 5).
IMPORTANT:
• Make sure all bow tie cotter pins are securely inserted in all
clevis pins.
WARNING:
• Failure to securely insert the bow tie cotter pins into the clevis
pin could cause the clevis pins to fall out and result in injury, or
damage to the chair.
A
9

Copyright 2014, WINCO MFG., LLC
16
Seat Height ..........................19.75"
Seat Width (arm to arm)..........25.75"
Overall Height .........................45.75"
Overall Width............................34.5"
(With OPTIONAL Trays Up).....45.5"
Maximum Weight Capacity....500 lbs.
AUGUSTINE RECLINER SPECIFICATIONS
Specifications
Back Height Above Seat.......28.5"
Seat Depth............................20.75"
Weight ..................................181lbs.
Overall Length.......................40"
Overall Length Reclined........76"

Copyright 2014, WINCO MFG., LLC
17
This section intentionally left blank
BE...........................Central Front Brake
AUGUSTINE RECLINER OPTIONS
Heat & Massage
HM .....................................Heat & Massage
HT ..............................................Heat ONLY
FACTORY INSTALLED ONLY
IV Pole & Attachment
IV................................ IV Pole &Attachment
Accessory Holder
Available on LEFT, RIGHT, or BOTH sides
Side-Table
Available on LEFT, RIGHT, or BOTH sides
(Also available with Wood Finish)
Central Front Brake
Pivot-Table
Available on LEFT, RIGHT, or BOTH sides
(Marine Board Only)
ARMREST COVERS
AIRX.................ARMREST COVER RIGHT
AILX....................ARMREST COVER LEFT

Copyright 2014, WINCO MFG., LLC
18
ARMREST COVER OPTION INSTRUCTIONS
1 2
4
3
7
This section intentionally left blank
65
Installing Armrest Covers with Side Tables:
1. Raise the side table by grasping the center
of the table and gently lift into place.
2. Locate large square opening in cover and
position over the side table. Stretch the
opening over the side table and slide over
side table.
3. Fit the front portion of the Armrest cover
over the front of the arm. Pull down tight
for best fit.
4. Fit the rear portion of the Armrest cover
over the rear of the arm.
5. Smooth wrinkles.
6. Make sure openings align with release
handle.

Copyright 2014, WINCO MFG., LLC
19
ARMREST COVER OPTION INSTRUCTIONS
Installing Armrest Covers with Pivot Tables:
1. Loosen pivot table knob.
2. Remove pivot table by pulling straight up
on pivot table.
3. Find pivot table opening in armrest cover
located in the upper front portion of the
armrest cover.
4. Place pivot table opening over pivot table
bracket and fit armrest cover over the front
portion of the arm.
5. Fit the rear portion of the Armrest cover
over the rear of the arm.
6. Gently insert pivot table into bracket.
7. Tighten knob.
1
5
6 7
43
2

Copyright 2014, WINCO MFG., LLC
20
ARMREST COVER OPTION INSTRUCTIONS
Installing Armrest Covers with IV Poles:
1. Using a Phillips screw driver, remove the
top screw mounting the IV bracket to the
arm and loosen the bottom screw enough
to allow the bracket to move. (Be care-
ful not to allow the bracket to damage the
vinyl)
2. Fit the armrest cover over the rear of the
arm and pull tight.
3. Use the Phillips screw driver to punch a
hole in the armrest cover in line with the
top mounting hole for the IV bracket.
4. Reattach the bracket using the screw
that was removed in step 1. Tighten both
screws.
2
3 4
1
This section intentionally left blank
