Winco 8550 Reference guide

Page 1 of 4
006070 Rev. V Date 04/06/20 NCG
1. READ AND FOLLOW ALL DIRECTIONS.
2. NEVER stand on table or INJURY MAY OCCUR.
3. NEVER allow user to sleep unattended on table or INJURY MAY OCCUR.
4. NEVER leave an unconscious user unattended on table or INJURY MAY OCCUR.
5. DO NOT use table for transporting user in or with ANY type of vehicle or trailer. Winco tables have not been tested
or approved for use by an occupant in any type of vehicle or trailer.
6. NEVER leave an infant or child unattended on table or INJURY MAY OCCUR.
7. Periodically recheck tightness of all nuts, bolts, and screws.
8. DO NOT put hands, feet or clothing into any openings when changing positions on table. Attendant MUST confirm
that user’s hands and feet are safe while changing table positions or INJURY MAY RESULT.
9. USE ONLY WINCO AUTHORIZED REPLACEMENT PARTS.
10. NEVER EXCEED the recommended weight capacity of 400 lbs. (181.4 kg).
11. SAVE THESE INSTRUCTIONS for future reference and training.
8550
Recovery Couch
CUSTOMER INSTRUCTIONS
Tools needed:
•Phillips-head screwdriver
•7/16” wrench (multiple size wrench included)
•Scissors or box cutter
•Cardboard shipping container (stays under table during assembly to protect upholstery)
•If using powered tools, always start hardware together by hand first and wear safety goggles.
SEE “Parts Reference” (pg.3) for visual reference during assembly.
1. After checking your product for any shipping damage, table needs to be positioned upside-down on cardboard or
protective surface. Remove all packing material and hardware that was secured for shipping. Cut tape on corners of
box so that cardboard will lay flat while you assemble table.
2. You will find two Table Legs, in-between and attached to the Table Frame Rails. Pivot up the Table Legsand install
one (1) ¼-20 x 2 ½ machine screw through the outer, empty hole of the Table Frame Rails, followed by hand
threading (1) ¼-20 hex lock nut onto the screw, connecting each Table Leg to the frame.
NOTE: The table legs have braces that need to align with two threaded holes in the wood
of the Upholstered Top.
3. Install (4) ¼-20 x 1-½” screws through (2) holes in each Upper Leg Brace of the Table Legs, and into (2) threaded
holes (each end) in the wood of the Upholstered Top.
NOTE:Do not fully tighten at this time.
4. Place (4) ¼-20 x 1-½” carriage bolts into the (4) holes through the Lower Leg Brace of the Table Legs.
Heads of screws should face the ends of table, for better appearance.
PLEASE READ AND FAMILIARIZE YOURSELF WITH ALL INSTRUCTIONS BEFORE PROCEEDING WITH ASSEMBLY
PLEASE READ AND FAMILIARIZE YOURSELF WITH ALL INSTRUCTIONS BEFORE USING THIS PRODUCT.
If you have trouble understanding these instructions contact Winco Customer Service at [phone]
before attempting to use this product; otherwise injury may occur.
8550 Weight Capacity = 400 lbs. (181.4 kg.)
Winco assumes no responsibility for damage or injury caused by improper assembly,
installation, use, or maintenance of these products.

Page 2 of 4
006070 Rev. V Date 04/06/20 NCG
5. Align the Cross-brace (smoothest side up) with the (4) screws that you just installed on step 4,
and fasten with (4) ¼-20 nuts.
6. TIGHTEN ALL nuts and bolts at this time.
7. Install the four (4) Threaded Inserts with Glide Feet into the ends of the table legs.
8. Using at least two people, turn table upright.
9. Remove (1) of the white plastic caps on the Paper Rod and install into the (2) Paper Rod Clamps, replace cap.
Adjust (4) 5/16” Glide Feet to level table.
Optional Shelf installation:
10. Double-sided tape has been installed on the Reinforced Cross-brace.
11. Before removing paper on tape, “test fit” the shelf. Shelf should be approximately ¼” from edge of the
Lower Leg Brace of the Table Legs.
12. Once you are certain of where you will position the shelf, peel off the paper to expose adhesive.
13. Carefully position shelf in place on adhesive.
Vinyl Strap Adjustment – Should the vinyl strap on your Winco table need to be adjusted, unscrew the screw that
currently holds either side of it in place. Pierce another hole in the strap to give desired tension and re-insert screw.
Wrinkles in Vinyl – Storage and shipping can cause wrinkles of the vinyl on your Winco table. This is normal. Please
allow 1-2 weeks at room temperature (approx. 70 degrees) to allow for vinyl to expand back to original appearance.
If the Optional Shelf and Reinforced Cross-brace have been ordered; make sure that the smooth surface (side with
tape) of the Cross-brace will face upward (when the table is in the upright position) prior to fastening to Table Legs.
After peeling paper from adhesive tape:
Use damp sponge to moisten tape to allow shelf to be adjusted during install.
Once tape is dry shelf will stay in place.
Do not over tighten nuts and bolts. Periodically check all fasteners for tightness.

Page 3 of 4
006070 Rev. V Date 04/06/20 NCG
Parts Reference
GENERAL CARE AND CLEANING:
Periodically inspect tightness of all screws, bolts, and nuts. Winco furnishings are built to provide durable reliable service
when properly cared for. In general, all our products should be cleaned, rinsed, and allowed to air dry. It is important to
note that disinfecting a product is not the same as cleaning the product. Disinfectants alone will not provide adequate
cleaning. They do not have grease or oil cutting properties to remove grime or hair and skin oils. Over time, the
appearance, feel, and performance of your upholstery may diminish if not cleaned properly.
CLEANING:
To remove grime, hair, and body oils, your furnishings should be cleaned with mild soap and water solution, and a damp
cloth on a regular basis. Avoid harsh detergents that could damage the finish of your product. If the furnishing is
disinfected with bleach, it MUST be wiped off using only clean water on a damp cloth and then be allowed to air dry.
Failure to rinse with clean water can result in a build-up of residues over time that can damage your product.
1/4-20 x 2 ½ Machine Screw
and Lock Nut (Pre-Installed)
1/4-20 x 2 ½ Machine Screw
and Lock Nut (To Be Installed)

Page 4 of 4
006070 Rev. V Date 04/06/20 NCG
Design, appearance, parts, & construction are subject to change without notice
