Winco 7100 Series Reference guide

Page 1 of 4
006265 Rev H Date 11-10-11 JWC
1. READ AND FOLLOW ALL DIRECTIONS.
2. Caster locks should be used to hold chart cart in place.
3. NEVER place cart on a table, stand or other objects; Cart could fall; INJURY MAY OCCUR.
4. NEVER leave cart in front of a door; During emergency, cart could block or hinder evacuation.
5. DO NOT allow children to play with cart; Cart could tip and INJURY MAY OCCUR.
6. Periodically, recheck tightness of all nuts, bolts and screws.
7. Cart should ALWAYS be positioned on level surface.
8. NEVER stand or ride on cart; This could damage cart; INJURY MAY OCCUR.
9. DO NOT use cart in or with ANY type of vehicle or trailer.
10. DO NOT attach objects to chart cart; Cart can tip over and INJURY MAY OCCUR.
11. Immediately remove from service; Any chart cart with broken or missing parts, or other signs of damage.
12. USE ONLY WINCO AUTHORIZED REPLACEMENT PARTS.
13. SAVE THESE INSTRUCTIONS for future reference and training.
Ring Binder Carts
7100-7200-7300 Series
Models 7100-7150-7160-7200-7240-7300
CUSTOMER INSTRUCTIONS
Tools needed:
Scissors or box cutter
1. After checking your product for any shipping damage; Remove all packing material and hardware that was
secured for shipping. Cut tape and plastic with scissors.
CASTER INSTALLATION
2. Lay cart on side, on a carpeted (or similar) level surface to protect paint finish.
3. Insert caster stems into ends of cart legs until they snap into place. (FIG.1)
PLEASE READ AND FAMILIARIZE YOURSELF WITH
A
LL INSTRUCTIONS BEFORE PROCEEDING WITH ASSEMBLY
PLEASE READ AND FAMILIARIZE YOURSELF WITH ALL INSTRUCTIONS BEFORE USING THIS PRODUCT.
If you have trouble understanding these instructions contact your dealer or Winco customer support, [phone]
before attempting to use this product; otherwise injury may occur.
Winco assumes no responsibility for damage or injury caused by the
improper assembly, installation or use of these products.
FIG 1

Page 2 of 4
006265 Rev H Date 11-10-11 JWC
PARTS LIST & REFERENCE GUIDE
Items Included with Cart: Qty. Part number
(A) 3” Twin-Wheel Caster, Black 4 400270
(B) 1” Black Caster Insert 4 702270
FOR ALL OTHER PARTS/QUESTIONS – PLEASE CALL WINCO CUSTOMER SERVICE [phone]
( 7160 Shown Here)
A B
