Winco 5291 Reference guide

Page 1 of 4
006100 Revision Q Date 01-28-11 JWC
DO NOT LIFT OR CHANGE CHAIR POSITION BY USING THE LEGREST.
THIS COULD CAUSE INJURY TO USER OR DAMAGE TO THE RECLINE MECHANISM AND WILL VOID WARRANTY.
ALWAYS CHANGE POSITION FROM BACK OF CHAIR.
1. READ AND FOLLOW ALL DIRECTIONS.
2. NEVER use tray as a restraint.
3. DO NOT put hands, feet or clothing into any openings when changing positions on recliner. Attendant MUST
confirm that users hands and feet are safe while changing recliner positions or NJURY MAY RESULT.
4. Stay clear of the recline mechanisms.
5. Periodically, recheck tightness of all nuts, bolts and screws.
6. NEVER use the trays or chair arms or backrest or legrest as a seat; SERIOUS INJURY MAY OCCUR.
7. Chair MUST be in full upright position with casters locked when a patient enters or exits chair.
8. NEVER allow a patient to exit a reclined chair with position-lock engaged or SERIOUS INJURY MAY RESULT
9. Lock casters at all times, except when transporting chair.
10. Chair must ALWAYS be positioned on a level surface.
11. DO NOT use recliner for Transporting in or with ANY type of vehicle or trailer. Winco recliners have not been
tested or approved for use by an occupant in any type of vehicle or trailer.
12. Immediately remove from service; Any recliner with broken recline mechanisms, torn upholstery, or other
mechanical or visible damage.
13. USE ONLY WINCO AUTHORIZED REPLACEMENT PARTS.
14. NEVER EXCEED the recommended weight capacity of 450 lbs. (204.1 kg).
15. SAVE THESE INSTRUCTIONS for future reference and training.
5291-529S
XL Convalescent Recliner
CUSTOMER INSTRUCTIONS
Tools needed for assembly:
•Scissors to aid in removal of packing material
Install the Back:
1. After checking your product for any shipping damage, chair needs to be positioned upright on level surface.
Remove all packing material and hardware that was secured for shipping. Cut tape and plastic with scissors,
being careful not to damage upholstery.
2. Make sure footrest is in closed position & LOCK ALL CASTERS before installing chair back.
3. Remove the (2) Bow Tie Cotter Pins and the (2) Clevis Pins from the lower Back Frame Forks. DO NOT
LOOSE THESE PARTS, YOU WILL NEED THEM AGAIN!
PLEASE READ AND FAMILIARIZE YOURSELF WITH ALL INSTRUCTIONS BEFORE USING THIS PRODUCT.
If you have trouble understanding these instructions contact your dealer or Winco customer support, [phone]
before attempting to use this product; otherwise injury may occur.
5291-529S XL Weight Capacity = 450 lbs. (204.1kg)
PLEASE READ AND FAMILIARIZE YOURSELF WITH
A
LL INSTRUCTIONS BEFORE PROCEEDING WITH ASSEMBLY
Winco assumes no responsibility for damage or injury caused by the improper assembly, installation
or use of these products; or during assembly or maintenance of these products.

Page 2 of 4
006100 Revision Q Date 01-28-11 JWC
4. Using a second person to help; Position the Back Frame Forks over the Seat Frame and align holes.
HINT: If you do not have a helper; Rest the bottom of the Upholstered Back on the rear portion of the Upholstered
Seat and push the Back Assembly slightly forward to help steady the chair back.
5. Use (2) two of the Clevis Pins you previously removed; Insert a Clevis Pin through left or right Back Frame
Fork, BEING SURE CLEVIS PIN GOES THROUGH inside Back Frame Fork; THROUGH HOLE in Seat Rail
Tube and; THROUGH outside Back Frame Fork. Repeat for opposite side of chair.
6. Insert (2) two Bow Tie Cotter Pins into the ends of the (2) two Clevis Pins.
7. Remove the (2) Bow Tie Cotter Pins and the (2) Clevis Pins from the Back Support Struts.
8. Align the holes of the Back Support Struts (on back frame) with the holes in the Angle Brackets (on chair
frame) and insert the (2) two remaining Clevis Pins into these aligned holes.
9. Insert (2) two Bow Tie Cotter Pins into the ends of the (2) two Clevis Pins.
Failure to correctly install clevis pins connecting Back Frame fork holes
and Seat Frame Rail holes will cause back to operate poorly and may
cause in
j
ur
y
to the user or dama
g
e the chair and void warrant
y
.

Page 3 of 4
006100 Revision Q Date 01-28-11 JWC
Operation of the Chair:
10. This recliner has three (3) positions; UPRIGHT, SEMI-RECLINE, and RECLINE, which can be achieved by
user or attendant. The position lock bar can only be engaged or disengaged by attendant. Not all notches on
Position Lock Bar are used for this model chair. Only the 1st thru 4th notches can be used on the 5291 Recliner.
11. POSITION LOCK: Attendant may hold the chair in a reclined position by engaging the Position Lock. To
safely accomplish this, recline the chair to the 2nd or 3rd recline position and lower the position lock with your
hand until the notches on the Position Lock bars engage with the Position Lock Pins.
To release Position Lock, raise the Position Lock off of the Pins and return chair to upright position.
12. This chair is equipped with Total Lock casters. Stepping on the brake tab will lock the wheel and the swivel
mechanism of the caster for added safety and security.
13. Side panels can be removed, for ease of cleaning, by unscrewing three (3) thumb screws on the inside of
each panel.
To ensure proper operation of the reclining mechanism, lubricate all pivot points with a silicone type lubricant (or
lubricant approved by your facility) at least twice yearly. Periodically recheck tightness of all screws and bolts.
Wrinkles in Vinyl – Storage and shipping can cause wrinkles of the vinyl on your Winco chair. This is normal.
Please allow 1-2 weeks at room temperature (approx. 70 degrees) to allow for vinyl to expand back to original
appearance
Visit our website www.wincomfg.com/product-documents/parts-lists for a complete parts list catalog of your
chair or call Customer Service @ 1-800-237-3377 to request it by mail.
WARNING: Attendant must release Position Lock before patient can exit chair – If patient attempts to
exit chair with Position Lock engaged, SERIOUS INJURY MAY RESULT.
WARNING: Failure to release the Position Lock before changing positions will result in damage to the
chair and void the warranty.
Periodically recheck tightness of all screws and bolts, and never use the chair arms, backrest, legrest or
tray as a seat.
