Winix ZERO 4 User manual

WINIX ZERO 4 AIR PURIFIER
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
USER MANUAL

USER MANUAL WINIX ZERO 4 AIR PURIFIER
Page 2
CONTENTS.............................................................................................................2
4-STAGE AIR PURIFICATION ................................................................................3
CONTROLS.............................................................................................................4
WHERE TO USE.....................................................................................................5
INSTALLING FILTERS ............................................................................................6
SAFETY AND CAUTIONS.......................................................................................8
INITIAL OPERATION...............................................................................................9
AUTO & SLEEP.....................................................................................................10
MANUAL & TIMER ................................................................................................11
PLASMAWAVE®& AIR QUALITY INDICATOR .....................................................12
FILTER CARE .......................................................................................................13
PARTICLE SENSOR CARE ..................................................................................17
CLEANING CARE .................................................................................................18
FREQUENTLY ASKED QUESTIONS ...................................................................19
SAFETY INSTRUCTIONS.....................................................................................20
PRODUCT WARRANTY .......................................................................................21
CONTENTS

USER MANUAL WINIX ZERO 4 AIR PURIFIER
Page 3
Light sensor
PlasmaWave
Control Panel / Display Panel
Particle sensor
Power cord with plug
(This product is suitable
for 220-240V only.) Front panel
1
2
3
4
User ManualUnit
True HEPA
4-STAGE AIR PURIFICATION

USER MANUAL WINIX ZERO 4 AIR PURIFIER
Page 4
Air Outlet Vent
Reset Button
press the RESET button
for at least 5 seconds.
Fan Speed Indicator
Indicates the
current fan speed.
Timer Indicator
If timer has been set, the
LED light indicates the set
time of operation.
Air Quality Indicator
Color-coded LED indicates one of
three levels of air quality.
Mode Button
Press to cycle through and set
the desired mode of operation
(Auto, Sleep).
Fan Speed Button
Enables Manual operation of the
unit. Press to cycle through and
set the desired fan speed (Low,
Medium, High, Turbo).
Light Sensor
Detects the
amount of
ambient light
within the
environment,
to adjust the
brightness
of the LED
indicators.
Timer Button
Press to cycle
through and set
desired length of
operation (1hr,
4hr, 8hr,[NO
TIMER])
Change Filter Indicator
LED light indicates when it is
PlasmaWave Indicator
Indicates whether
PlasmaWave is enabled or
disabled.
PlasmaWave Button
Enables or disables
PlasmaWave .
Power Button
Turns the unit on
CONTROLS

USER MANUAL WINIX ZERO 4 AIR PURIFIER
Page 5
Allow 30 - 45cm of space between TVs, radios, and other electronic products electromagnetic interference from
certain electronics may cause product malfunction.
Place indoors away from direct sun light direct exposure may cause product malfunction or failure.
Only place on hard, at surfaces imsy or slanted surfaces may result in abnormal noise and vibrations.
30~45 cm 10 cm
Follow these instructions to reduce the risk of serious injury or death and
to reduce risk of damaging the unit.
Do not use around mist or fumes from
industrial oil or around large quantities of
metallic dust.
Do not place around heating elements.
Do not install in any sort of motor or
transport vehicle (trucks, boats, ships,
etc.).
Do not place in an area with excessive
amounts of noxious gases.
Do not place near any ammable materials
(aerosols, fuel, gases etc.).
Do not have unit facing into wind or draft.
Do not place below any electrical outlet. Do not place in excessively humid areas
where unit may become wet.
WHERE TO USE

USER MANUAL WINIX ZERO 4 AIR PURIFIER
Page 6
This product comes with all required lters. The protective plastic wrap must be removed from the lter before use.
• Operating the unit without removing the plastic wrap may result in product failure.
• Unplug and make sure the unit is turned o󰀨 before installing lter.
1. Remove the front panel by grasping its upper
edge and gently pulling forward.
2. Remove the lters from the unit, they are protect-
ed inside a plastic wrap
3. Remove lters from protective plastic wrap.
• Operating the unit without removing lters from
plastic wrap may cause abnormal noise, deforma-
tion, or re as a result of overheating.
NOTE : Refer to pages 13 - 15 for details on how to replace lters.
INSTALLING FILTERS

USER MANUAL WINIX ZERO 4 AIR PURIFIER
Page 7
4. Install the lters until they t securely in place.
Filters must be installed in this order:
3 True HEPA Filter (rear)
2 Deodorization lter (middle)
1 Pre-lter (front)
• To install the Pre-lter, insert bottom tabs into the
slots on either side of the lower part of the unit,
then rotate upward to insert the upper tabs into
the slots at the top part of the unit until sides audi-
bly click into place.
5. Replace the front panel by rst inserting the latch
at the bottom edge into the base of the unit, then
rotate the panel upward toward the top of the unit
until the magnets pull the lid closed.
6. When to service and replace lter:
Filter Indicator Light When to service When to replace
1 Pre-lter none Clean once every 14 days Permanent
2 Deodorization lter
Can NOT be WASHED Lasts up to 12 months
3 True HEPA lter
• Intervals between lter replacement may vary depending on environment.
• For optimal use, Pre-lter can be cleaned once every 14 days which can extend the life of other lters.

USER MANUAL WINIX ZERO 4 AIR PURIFIER
Page 8
Before operating this equipment, carefully read and follow these safety cautions
Ensure lters are inserted before running unit
running unit without lters can shorten the units life and cause electric shock or injury.
Be sure foreign objects are NOT inserted into the vents on the unit
objects can include pins, rods, and coins.
Do not touch any part of the interior of the unit with wet hands
the high voltage may cause electric shock.
Ensure unit intake and outlet vents do not become blocked
blockage may lead to increased internal termperatures causing product failure and derformation.
Do not use the unit as a step stool or place heavy objects on it
personal injury may occur or product failure and deformation.
Follow these instructions to reduce the risk of serious injury or death and
to reduce risk of damaging the unit.
Do not pull on the power cord when
unplugging the unit
Do not tie or knot power cord when unit is
in operation
If the unit becomes submerged in water,
unplug it and contact customer service
Do not unplug or move the unit while in
operation
Do not plug additional appliances into the
same outlet or power supply
Do not touch the plug with wet hands
Unplug unit when not in operation for
extended periods of time
Cord can become damaged by forcefully
bending, pulling, twisting, bundling,
pinching or placing heavy objects on it
• If the supply cord is damaged, it must be replaced by a special cord or assembly available from the manufac-
turer or its service agent.
• This appliance is not intended for use by a person (including children) with reduced physical sensory or men-
tal capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
SAFETY AND CAUTIONS

USER MANUAL WINIX ZERO 4 AIR PURIFIER
Page 9
1. Insert the power cord into an electrical outlet.
2. Press the ‘Power’ button.
NOTE : During the rst 30 seconds of power up, the Air Quality Indicator will cycle through Blue, Amber and Red
colors. The Particle Sensors take approximately 30 seconds to gauge the air quality in the environment, after
which normal operation will begin.
3. By default, when the unit rst powers on, the mode
will be set to Auto with PlasmaWave®enabled.
• When in Auto mode, the fan speed will be auto-
matically adjusted according to the environments
air quality.
• PlasmaWave® works to remove harmful airborne
contaminants.
NOTE :
• In Auto mode, as the indoor air quality improves, the fan speed will automatically be reduced to Low.
• When the unit is running, you may hear a chirping or buzzing sound. The sound is from large particles pass-
ing through PlasmaWave®, it is normal and does not signify product failure. To disable PlasmaWave®, see
page 12.
INITIAL OPERATION

USER MANUAL WINIX ZERO 4 AIR PURIFIER
Page 10
Auto Mode
Enables auto operation based on the unit’s air quality Particle Sensor.
1. Press the Mode button to select Auto mode.
• The LED ‘Auto’ light will indicate when Auto mode
is activated, and operation will begin.
NOTE : When in Auto mode the fan speed is automatically adjusted according to the indoor air quality. As the
indoor air quality improves, the fan speed will automatically be reduced. If the indoor air quality decreases, the
fan speed will automatically increase.
Sleep Mode
1. Press the Mode button to select Sleep mode.
• The LED ‘Sleep’ light will indicate when Sleep
mode is activated, and operation will begin.
NOTE :
• When Sleep mode is selected, the fan speed is automatically set to Low. The fan speed can be manually
changed by pressing the Fan Speed button, changing the unit into manual mode.
• When Sleep Mode is activated, the Air Quality Indicator LED light is disabled.
AUTO & SLEEP

USER MANUAL WINIX ZERO 4 AIR PURIFIER
Page 11
Manual Mode (setting fan speed)
Users can opt to manually set the fan speed to Low, Medium, High, or Turbo.
1. Press the Fan Speed button to set the desired fan
speed.
NOTE : When Manual Mode is selected, Auto Mode is automatically disabled.
Timer
The timer can be set to let the unit run for a specied period of time.
1. Press the Timer button to select the desired length
of time.
• When the Timer LED light will indicate the select-
ed length of operation.
• Every time the Timer button is pressed, The Timer
LED light will cycle through the settings, (1hr, 4hr,
8hr, [NO TIMER]).
MANUAL & TIMER

USER MANUAL WINIX ZERO 4 AIR PURIFIER
Page 12
PlasmaWave®
By default, PlasmaWave® is enabled whenever the unit is powered on.
1. Press the Plasmawave button, when the unit is
on, to enable or disable this feature.
NOTE :
• In Auto mode, as the indoor air quality improves, the fan speed will automatically be reduced to Low.
• When the unit is running, you may hear a chirping or buzzing sound. The sound is from large particles pass-
ing through PlasmaWave®, it is normal and does not signify product failure.
Air Quality Indicator
When on, the LED light will indicate the current indoor air quality according to three levels: BLUE (good), AMBER
(fair), RED (poor).
Air Quality Indicator
NOTE : Air quality level is displayed on the indicator, based on the Particle Sensors. Depending on the immediate
environment, the indicator may change frequently in color or stay the same for lengthy periods of time.
PLASMAWAVE®& AIR QUALITY INDICATOR

USER MANUAL WINIX ZERO 4 AIR PURIFIER
Page 13
Know The Filters
When the Check Filter indicator LED is on, it is time to replace both the True HEPA and Deodorization lters.
Filter Indicator Light When to service When to replace
1 Pre-lter none Clean once every 14 days Permanent
2 Deodorization lter
Can NOT be WASHED Lasts up to 12 months
3 True HEPA lter
• Intervals between lter replacement may vary depending on environment.
• For optimal use, Pre-lter can be cleaned once every 14 days which can extend the life of other lters.
NOTE :
• The lters’ life varies depending on the level of pollutants in the air. The more dust present in the environ-
ment, the more dust accumulates in the lters, shortening the life.
• If the lters are heavily soiled or have a bad odour, or if the fan strength is signicantly weakened, replace
lters even if the Change Filter indicator has not yet turned on.
FILTER CARE

USER MANUAL WINIX ZERO 4 AIR PURIFIER
Page 14
Removing Filters
Turn the unit power o󰀨 before removing lters.
1. Remove the front panel by grasping its upper
edge and gently pulling forward.
2. Press on the Pre-lter tabs near the top of the l-
ter, release and remove.
3. Pull out the Deodorization lter and True HEPA
Filter.
Preparing New Filters
1. Remove replacement lters from protective plas-
tic wrap.
• Operating the unit without removing lters from
plastic wrap may cause abnormal noise, deforma-
tion, or re as a result of overheating.
NOTICE :
• For optimal performance, only Winix lters should be used with this unit.

USER MANUAL WINIX ZERO 4 AIR PURIFIER
Page 15
Replacing Filters
1. Insert the True HEPA Filter rst, then the Deodor-
ization lter.
2. Insert the Pre-lter.
• Insert bottom tabs of the Pre-lter into the slots on
either side of the lower part of the unit, then rotate
upward to insert the upper tabs into the slots at
the top part of the unit until sides audibly click into
place.
3. Replace the front panel by rst inserting the latch
at the bottom edge into the base of the unit, then
rotate the panel upward toward the top of the unit
until the magnets pull the lid closed.
Resetting The Unit
1. After replacing the lters, turn the power back on
and then use a thin object, such as a paper clip, to
press the RESET switch for 5 seconds.

USER MANUAL WINIX ZERO 4 AIR PURIFIER
Page 16
Cleaning the lter
Intervals between lter cleaning may vary depending on the air quality.
1. Use a vacuum cleaner or soft brush to clean the
Pre-lter. If it is excessively soiled, rinse in room
temperature water.
• Do not use detergent or soap.
• Allow the lter to dry for 24 hours or more before
using.
• If the pre-lter becomes damaged or in any way needs replacement: Please contact your local dealer
NOTICE :
• Do not use benzene, alcohol, or other volatile uids, which may cause damage or discoloration.
• The Pre-lter is reusable after cleaning, ensuring it is completely dry.
• Do not use hot water over 40oC or volatile uids such as paint thinner.
• After washing the lter, allow it to dry completely in a well ventilated area. Otherwise, it may develop a bad
odour.

USER MANUAL WINIX ZERO 4 AIR PURIFIER
Page 17
Particle Sensors Care
For optimal performance of the Particle Sensor, which detects airborne dust and ultrane particles, clean it every two
months. Clean it more frequently when the unit is running in a place with high dust levels.
1. Open the Particle Sensor cover.
2. Use a damp cotton swab to wipe the lens and in-
take area of the Particle Sensor.
• To clean the sensor area, use only water. Do not
use volatile substances such as alcohol or ace-
tone
3. Wipe away any remaining moisture with a dry cot-
ton swab.
4. Close the Particle Sensor cover.
• The Particle Sensors cover may be cleaned using
a vacuum cleaner
PARTICLE SENSOR CARE

USER MANUAL WINIX ZERO 4 AIR PURIFIER
Page 18
Cleaning the Exterior & Interior
1. Wipe with a soft damp cloth using room tempera-
ture water. Afterwards, wipe it down with a clean
dry cloth.
• To keep unit in peak condition, clean every 1-2
months.
2. Open the front panel and clean the interior with a
vacuum cleaner.
• For optimal performance, clean every 1-2 months.
NOTICE :
• When cleaning the unit, always unplug the power cord rst and then wait until the unit has cooled down.
• Never disassemble, repair, or modify this unit yourself.
• Do not use ammable sprays or liquid detergents.
• Do not allow children to clean or maintain the unit.
• Before cleaning or maintaining, ensure unit is unplugged.
CLEANING CARE

USER MANUAL WINIX ZERO 4 AIR PURIFIER
Page 19
FREQUENTLY ASKED QUESTIONS
Problem Check / Actions to take
It does not turn on at all. • Is the plug securely attached to the outlet?
• Make sure the outlet has power going to it, and ensure the plug
is secured.
• Is there a power outage?
• Check to see if other lights and electrical equipment are
working and try again.
It doesn’t work in Auto Mode. • Has Auto Mode been selected?
• Press the Mode button until Auto Mode is selected.
• Is the sensor blocked or clogged?
• Wipe Odour Sensor with wet cloth, then dry.
It vibrates and makes a lot of noise. • Is it running on a slanted or uneven surface?
• Move the unit to a hard, at, even area of the oor.
The power plug and outlet feel hot. • Is the plug securely plugged in?
• Make sure the plug is properly plugged into the outlet.
There is a strange smell. • Is it being used in a place with a lot of smoke, dust, or odours?
• Clean the air intakes on either side and clean the pre-lter.
• Clean or change the lter.
The fan strength is weak. The unit is not purifying the air. • Is the Check Filter indicator light on?
• Change the lters as required.
The display panel is dim. • Is the Light Sensor blocked by debris?
• When Auto Mode is on, Sleep Mode is automatically activated
when the Light Sensor detects that the room is dark.
UNIT SPECIFICATIONS
Model Name AUS-1050AZBU
Power Voltage 220 - 240 V, 50 / 60 Hz
Power Rate 35 W
Recommended room capacity 38.2 m2
Weight 7 kg
Dimensions 380 mm(W) x 208 mm(D) x 600 mm(H)
Replacement Filter FILTER GI, item : 1712-0090-01
• The exterior, design, and product specications may be changed without prior notice to improve product performance.

USER MANUAL WINIX ZERO 4 AIR PURIFIER
Page 20
Thank you for purchasing a Winix air purier. This product is for household use only.
IMPORTANT CAUTIONS FOR USING YOUR AIR PURIFIER
WARNING : Follow the instructions in this manual to reduce the risk of electric shock, short circuit, and/or re.
• Do not repair or modify the unit unless specically recommended in this manual. All other repairs should be
completed by a qualied technician.
• Do not use if the power cord or plug is damaged or the connection to the wall outlet is loose.
• Use AC 220 - 240 V only.
• Do not damage, break, forcefully bend, pull, twist, bundle, coat, pinch, or place heavy objects on the power cord.
• Periodically remove dust from the power plug. This will reduce the risk of shock due to humidity build up.
• If the power plug is damaged, it must be replaced by the manufacturer or a qualied technician.
• Remove the power plug from the outlet before cleaning the unit. When removing the power plug, grasp by hold-
ing the plug itself, never hold by the cord.
• Remove the power plug from the outlet when not in use.
• Do not handle the power plug with wet hands.
• Do not operate the unit when using indoor smoke-generating insecticides.
• Do not clean unit with benzene or paint thinner. Do not spray insecticides on the unit.
• Do not use the unit where it is humid or where the unit may become wet, such as the bathroom.
• Do not insert ngers or foreign objects into air intake or outlet.
• Do not use the unit near ammable gases. Do not use near cigarettes, incense, or other spark-creating items.
• Unit will not remove carbon monoxide emitted from heating appliances or other sources.
IMPORTANT PRECAUTIONS FOR USING YOUR AIR PURIFIER
• Do not block the intake or outlet vents.
• Do not use near hot objects, such as a stove.
• Do not use where the unit may come into contact with steam.
• Do not use the unit on its side.
• Keep away from products that generate oily residue, such as a deep fryer.
• Do not use detergent to clean the unit.
• Do not operate without a lter.
• Do not wash and reuse the True HEPA Filter or the Deodorization lter.
• Hold the handle on the back of the unit to transport.
• Do not hold by the front panel.
SAFETY INSTRUCTIONS
