Winmate W04FA3S-EHT1 User manual

E-Series HMI
Freescale® Cortex® A9 i.MX6 Dual Core, 1 GHz
Elegant Design
W04FA3S-EHT1
W07FA3S-EHT1
W10FA3S-EHH2
R15FA3S-EHC3
W15FA3S-EHA2
User Manual
Version 1.5
Android 6.0
9152111I100W

USER MANUAL CONTENTS
- 2 -
CONTENTS
PREFACE.................................................................................................................. - 4 -
ABOUT THIS USER MANUAL................................................................................... - 11 -
CHAPTER 1: INTRODUCTION .................................................................................. - 13 -
1.1 Product Features..........................................................................................- 13 -
1.2 Package Contents.........................................................................................- 14 -
1.3 Description of Parts...................................................................................... - 15 -
1.3.1 E-Series HMI 4.3”...............................................................................- 15 -
1.3.2 E-Series HMI 7”..................................................................................- 16 -
1.3.3 E-Series HMI 10.1”.............................................................................- 17 -
1.3.4 E-Series HMI 15”................................................................................- 18 -
1.3.5 E-Series HMI 15.6”............................................................................. - 19 -
CHAPTER 2: GETTING STARTED .............................................................................. - 21 -
2.1 Powering On.................................................................................................- 21 -
2.1.1 AC Adapter Components...................................................................- 21 -
2.1.2 Power Considerations ....................................................................... - 22 -
2.1.3 Connecting the Power....................................................................... - 23 -
2.2 Connector Pinouts .......................................................................................- 24 -
2.2.1 DC Input Connector...........................................................................- 24 -
2.2.2 Serial Port Connector ........................................................................- 24 -
2.2.3 USB 2.0 Connector.............................................................................- 25 -
2.2.4 USB OTG Connector...........................................................................- 25 -
2.2.5 CANBUS Connector............................................................................- 26 -
2.2.6 LAN (RJ45) Connector........................................................................- 26 -
2.2.7 Micro HDMI Connector .....................................................................- 27 -
2.3 Turning On and Off the HMI Device.............................................................- 27 -
2.4 Configuring Serial Port Settings ...................................................................- 28 -
CHAPTER 3: OPERATING THE DEVICE...................................................................... - 31 -
3.1 Operating System.........................................................................................- 31 -
3.2 Multi-Touch..................................................................................................- 32 -
3.3 System Settings............................................................................................- 33 -
3.3.1 Set up the Device...............................................................................- 33 -

USER MANUAL CONTENTS
- 3 -
3.3.2 Home Screen .....................................................................................- 33 -
3.3.3 Quick Settings....................................................................................- 35 -
3.4 Ethernet .......................................................................................................- 37 -
3.4.1 Configuring Ethernet .........................................................................- 38 -
3.4.2 Checking Ethernet Settings ...............................................................- 39 -
3.5 Winmate® Home Manager (WHM) .............................................................- 40 -
3.5.1 How to Lock Applications ..................................................................- 40 -
3.5.2 How to Unlock Applications ..............................................................- 43 -
3.5.3 How to Change Password..................................................................- 44 -
CHAPTER 4: SOFTWARE INSTALLATION ..................................................................- 46 -
4.1 Android Debug Bridge (ADB) Driver Installation ......................................... - 46 -
4.1.1 Disabling Driver Signature on Windows 8.........................................- 47 -
4.1.2 ADB Driver Installation ......................................................................- 51 -
4.2 Installing Android Debug Bridge (ADB)........................................................- 55 -
4.2.1 Installing Android Debug Bridge (ADB) .............................................- 55 -
4.2.2 Using Android Debug Bridge (ADB)................................................... - 56 -
4.3 Downloading Image Tool .............................................................................- 57 -
4.4 OTA Update Guide .......................................................................................- 57 -
4.5 OS Image Update Guide...............................................................................- 61 -
CHAPTER 5: MOUNTING.........................................................................................- 63 -
5.1 Cable Mounting Considerations ..................................................................- 63 -
5.2 Safety Precautions ....................................................................................... - 63 -
5.3 Mounting Guide...........................................................................................- 64 -
5.3.1 VESA Mount.......................................................................................- 64 -
5.3.2 Panel Mount......................................................................................- 65 -
CHAPTER 6: TECHNICAL SUPPORT ..........................................................................- 67 -
6.1 Introduction .................................................................................................- 67 -
6.1.1 Winmate Download Center...............................................................- 67 -
6.2 Problem Report Form ..................................................................................- 68 -
APPENDIX A: PRODUCT SPECIFICATIONS ................................................................- 70 -

USER MANUAL PREFACE
- 4 -
PREFACE
Copyright Notice
No part of this document may be reproduced, copied, translated, or transmitted in
any form or by any means, electronic or mechanical, for any purpose, without the
prior written permission of the original manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their
respective owners.
Disclaimer
We reserve the right to make changes, without notice, to any product, including
circuits and/or software described or contained in this manual in order to improve
design and/or performance. We assume no responsibility or liability for the use of
the described product(s) conveys no license or title under any patent, copyright, or
masks work rights to these products, and make no representations or warranties
that these products are free from patent, copyright, or mask work right
infringement, unless otherwise specified. Applications that are described in this
manual are for illustration purposes only. We make no representation or guarantee
that such application will be suitable for the specified use without further testing or
modification.
Warranty
Our warranty guarantees that each of its products will be free from material and
workmanship defects for a period of one year from the invoice date. If the customer
discovers a defect, we will, at his/her option, repair or replace the defective product
at no charge to the customer, provide it is returned during the warranty period of
one year, with transportation charges prepaid. The returned product must be
properly packaged in its original packaging to obtain warranty service. If the serial
number and the product shipping data differ by over 30 days, the in-warranty
service will be made according to the shipping date. In the serial numbers the third
and fourth two digits give the year of manufacture, and the fifth digit means the
month (e. g., with A for October, B for November and C for December).
For example, the serial number 1W16Axxxxxxxx means October of year 2016.

USER MANUAL PREFACE
- 5 -
Customer Service
We provide a service guide for any problem by the following steps: First, visit the
website of our distributor to find the update information about the product. Second,
contact with your distributor, sales representative, or our customer service center
for technical support if you need additional assistance.
You may need the following information ready before you call:
Product serial number
Software (OS, version, application software, etc.)
Description of complete problem
The exact wording of any error messages
In addition, free technical support is available from our engineers every business
day. We are always ready to give advice on application requirements or specific
information on the installation and operation of any of our products.

USER MANUAL PREFACE
- 6 -
Advisory Conventions
Four types of advisories are used throughout the user manual to provide helpful
information or to alert you to the potential for hardware damage or personal injury.
These are Notes, Important, Cautions, and Warnings. The following is an example of
each type of advisory.
NOTE:
A note is used to emphasize helpful information
IMPORTANT:
An important note indicates information that is important for you to
know.
CAUTION/ ATTENTION
A Caution alert indicates potential damage to hardware and explains
how to avoid the potential problem.
Une alerte d’attention indique un dommage possible à l’équipement et
explique comment éviter le problème potentiel.
WARNING!/ AVERTISSEMENT!
An Electrical Shock Warning indicates the potential harm from electrical
hazards and how to avoid the potential problem.
Un Avertissement de Choc Électrique indique le potentiel de chocs sur
des emplacements électriques et comment éviter ces problèmes.
ALTERNATING CURRENT / MISE À LE TERRE!
The Protective Conductor Terminal (Earth Ground) symbol indicates the
potential risk of serious electrical shock due to improper grounding.
Le symbole de Mise à Terre indique le risqué potential de choc
électrique grave à la terre incorrecte.

USER MANUAL PREFACE
- 7 -
Safety Information
WARNING! / AVERTISSEMENT!
Always completely disconnect the power cord from your chassis
whenever you work with the hardware. Do not make connections
while the power is on. Sensitive electronic components can be
damaged by sudden power surges. Only experienced electronics
personnel should open the PC chassis.
Toujours débrancher le cordon d’alimentation du chassis lorsque
vous travaillez sur celui-ci. Ne pas brancher de connections lorsque
l’alimentation est présente. Des composantes électroniques sensibles
peuvent être endommagées par des sauts d’alimentation. Seulement
du personnel expérimenté devrait ouvrir ces chassis.
CAUTION/ATTENTION
Always ground yourself to remove any static charge before touching
the CPU card. Modern electronic devices are very sensitive to static
electric charges. As a safety precaution, use a grounding wrist strap at
all times. Place all electronic components in a static-dissipative surface
or static-shielded bag when they are not in the chassis.
Toujours verifier votre mise à la terre afin d’éliminer toute charge
statique avant de toucher la carte CPU. Les équipements
électroniques moderns sont très sensibles aux décharges d’électricité
statique. Toujours utiliser un bracelet de mise à la terre comme
précaution. Placer toutes les composantes électroniques sur une
surface conçue pour dissiper les charge, ou dans un sac anti-statique
lorsqu’elles ne sont pas dans le chassis.

USER MANUAL PREFACE
- 8 -
Safety Precautions
For your safety carefully read all the safety instructions before using the
device. Keep this user manual for future reference.
Always disconnect this equipment from any AC outlet before cleaning.
Do not use liquid or spray detergents for cleaning. Use a damp cloth.
For pluggable equipment, the power outlet must be installed near the
equipment and must be easily accessible.
Keep this equipment away from humidity.
Put this equipment on a reliable surface during installation. Dropping it
or letting it fall could cause damage.
The openings on the enclosure are for air convection and to protect the
equipment from overheating.
CAUTION/ATTENTION
Do not cover the openings!
Ne pas couvrir les ouvertures!
Before connecting the equipment to the power outlet make sure the
voltage of the power source is correct.
Position the power cord so that people cannot step on it. Do not place
anything over the power cord.
If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient over-voltage.
Never pour any liquid into an opening. This could cause fire or electrical
shock.
Never open the equipment. For safety reasons, only qualified service
personnel should open the equipment.
All cautions and warnings on the equipment should be noted.

USER MANUAL PREFACE
- 9 -
*Let service personnel to check the equipment in case any of the following
problems appear:
oThe power cord or plug is damaged.
oLiquid has penetrated into the equipment.
oThe equipment has been exposed to moisture.
oThe equipment does not work well or you cannot get it to work
according to the user manual.
oThe equipment has been dropped and damaged.
oThe equipment has obvious signs of breakage.
Do not leave this equipment in an uncontrolled environment where the
storage temperature is below -20°C (-4°F) or above 60°C (140°F). It may
damage the equipment.
CAUTION/ATTENTION
Use the recommended mounting apparatus to avoid risk of injury.
Utiliser l’appareil de fixation recommandé pour éliminer le risque
de blessure.
WARNING! / AVERTISSEMENT!
Only use the connection cords that come with the product. When
in doubt, please contact the manufacturer.
Utiliser seulement les cordons d’alimentation fournis avec le
produit. Si vous doutez de leur provenance, contactez le
manufacturier.
WARNING!/ AVERTISSEMENT!
Always ground yourself against electrostatic damage to the
device.
Toujours vérifier votre mise à la terre afin que l’équipement ne se
décharge pas sur vous.
Cover workstations with approved anti-static material. Use a wrist
strap connected to a work surface and properly grounded tools and
equipment.
Use anti-static mats, heel straps, or air ionizer for added protection.
Avoid contact with pins, leads, or circuitry.
Turn off power and input signals before inserting and removing
connectors or test equipment.
Keep the work area free of non-conductive materials, such as ordinary
plastic assembly aids and Styrofoam.
Use filed service tools, such as cutters, screwdrivers, and vacuum
cleaners that are conductive.
Always put drivers and PCB’s component side on anti-static foam.

USER MANUAL PREFACE
- 10 -
Important Information
Federal Communications Commission Radio Frequency Interface
Statement
This device complies with part 15 FCC rules.
Operation is subject to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a class "B"
digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
him own expense.
EC Declaration of Conformity
This equipment is in conformity with the requirement of the
following EU legislations and harmonized standards. Product
also complies with the Council directions.
Electromagnetic Compatibility Directive (2014/30/EU)
EN55024: 2010 EN 55022: 2010 Class B
oIEC61000-4-2: 2009
oIEC61000-4-3: 2006+A1: 2007+A2: 2010
oIEC61000-4-4: 2012
oIEC61000-4-5: 2014
oIEC61000-4-6: 2013
oIEC61000-4-8: 2010
oIEC61000-4-11: 2004
EN55022: 2010/AC:2011
EN61000-3-2:2014
EN61000-3-3:2013
Low Voltage Directive (2014/35/EU)
EN 60950-1:2006/A11:2009/A1:2010/A12:2011/ A2:2013

USER MANUAL ABOUT THIS USER MANUAL
- 11 -
ABOUT THIS USER MANUAL
This User Manual provides information about using the Winmate® E-Series HMI. This
User Manual applies to the E-Series HMI –W04FA3S-EHT1, W07FA3S-EHT1,
W10FA3S-EHH2, R15FA3S-EHC3 and W15FA3S-EHA2.
The documentation set for the E-Series HMI with Freescale® Cortex® A9 i.MX6 Dual Core
provides information for specific user needs, and includes:
E-Series HMI User Manual –contains detailed description on how to use the HMI
device, its components and features.
E-Series HMI Quick Start Guide - describes how to get the HMI up and running.
NOTE:
Some pictures in this guide are samples and can differ from actual
product.
Document Revision History
Version
Date
Note
1.0
25-Jul-2016
Initial release
1.1
16-Nov-2016
Revise formatting
1.2
8-Mar-2017
Add 4.3” HMI
1.3
19-Jun-2017
Add Micro HDMI connector for 7”, 10.1”
and 15” HMI
1.4
15-Dec-2017
Update OS to Android 6.0
1.5
25-Jan-2018
Add 15”, R15FA3S-EHC3
Add 4.2.2 Using Android Debug Bridge

USER MANUAL CHAPTER 1 INTRODUCTION
- 12 -
INTRODUCTION
This chapter gives you product overview,
describes features and hardware
specification. You will find all accessories
that come with the HMI in the packing list.
Mechanical dimensions and drawings
included in this chapter.

USER MANUAL CHAPTER 1 INTRODUCTION
- 13 -
CHAPTER 1: INTRODUCTION
Congratulations on purchasing Winmate® E-Series HMI. Winmate® continues developing
new generation of Human Machine Interfaces for Industry 4.0 and Internet of Things
(IoT). Our E-Series HMI runs on Android 6.0 / Linux operating system that allows
installing the latest applications (APPs). Thereby wide customization possibilities are
available to satisfy the needs of industrial automation.
There is one USB 2.0 onboard to connect mouse or keyboard, USB OTG for system
updates and micro SD card for data logging, backup or data storage. System memory of
1 GB ensures stable operation of applications.
With mounting clips for panel mounting there is no need to drill holes in a fixture. This
saves you the time for mounting and guarantee aesthetic look of the wall after the unit
gets removed.
1.1 Product Features
Winmate® E-Series HMI features:
Freescale® Cortex® A9 i.MX6 Dual Core 1 GHz
Projected Capacitive (P-CAP) Multi-Touch
Fanless cooling system and Ultra-low power consumption
Front IP65 water and dust proof, rear IP22
Optional PoE (Data and Power in a single cable)
Mounting clips for quick Installation
Elegant design for room booking, access control and room information
applications
Support OS
oAndroid 6.0 (Default)
oUbuntu 16.04 (Optional)
oLinux Kernel 3.0.35,QT 5.4 Browser (Optional)

USER MANUAL CHAPTER 1 INTRODUCTION
- 14 -
1.2 Package Contents
Carefully remove the box and unpack your device. Please check if all the items listed
below are inside your package. If any of these items are missing or damaged contact us
immediately.
Standard factory shipment list:
*Package content may vary based on your order.
HMI Device
Quick Start Guide
(Hardcopy)
User Manual
(Hardcopy)
User Manual &
Driver CD
Varies by product
specifications
9152111I101C
9152111I100W
9171111I102P
AC Adapter
(12V/ 50W)
Power Cord
2 pin Terminal
Block
Mounting Clips and
Screws
7” HMI – 4 pcs
10.1” HMI – 8 pcs
15.6” HMI – 10 pcs
922D050W12VA
Varies by country
94J602G020K0
82111E240400

USER MANUAL CHAPTER 1 INTRODUCTION
- 15 -
1.3 Description of Parts
This section describes appearance, connectors’ layout and mechanical dimensions of E-
Series HMI. Notice that this is a simplified drawing and some components are not
marked in detail. Please contact our sales representative if you need further product
information.
1.3.1 E-Series HMI 4.3”
Unit: mm
№
Description
№
Description
①
USB OTG
④
LAN/ Optional PoE
②
USB 2.0
⑤
12-24V DC in (Power jack)
③
RS485

USER MANUAL CHAPTER 1 INTRODUCTION
- 16 -
1.3.2 E-Series HMI 7”
Unit: mm
№
Description
№
Description
①
Mini USB Console
(Linux use)
⑥
CANBUS
②
Micro SD
⑦
Micro HDMI
③
LAN/ Optional PoE
⑧
USB 2.0
④
USB OTG
⑨
12V DC in (Phoenix type)
⑤
RS-232/422/485

USER MANUAL CHAPTER 1 INTRODUCTION
- 17 -
1.3.3 E-Series HMI 10.1”
Unit: mm
№
Description
№
Description
①
Mini USB Console
(Linux use)
⑥
CANBUS
②
Micro SD
⑦
Micro HDMI
③
LAN/ Optional PoE
⑧
USB 2.0
④
USB OTG
⑨
12V DC in (Phoenix type)
⑤
RS-232/422/485

USER MANUAL CHAPTER 1 INTRODUCTION
- 18 -
1.3.4 E-Series HMI 15”
Unit: mm
№
Description
№
Description
①
Mini USB Console
(Linux use)
⑤
RS-232/422/485
②
Micro SD
⑥
CANBUS
③
LAN/ Optional PoE
⑦
USB 2.0
④
USB OTG
⑧
12V DC in (Phoenix type)

USER MANUAL CHAPTER 1 INTRODUCTION
- 19 -
1.3.5 E-Series HMI 15.6”
Unit: mm
№
Description
№
Description
①
Mini USB Console
(Linux use)
⑥
CANBUS
②
Micro SD
⑦
Micro HDMI
③
LAN/ Optional PoE
⑧
USB 2.0
④
USB OTG
⑨
12V DC in (Phoenix type)
⑤
RS-232/422/485

USER MANUAL CHAPTER 2 GETTING STARTED
- 20 -
GETTING STARTED
This chapter tells you important
information on power supply, adapter
and precautions tips. Pay attention to
power considerations.
