woodmizer Accuset Guide

Accuset
Safety, Operation, Maintenance
& Parts Manual
ASET for ’97+ LT30/40/HD rev. A.00 - E.06
Safety is our #1 concern! Read and understand
all safety information and instructions before oper-
ating, setting up or maintaining this machine.
May 2000
Form #987

©2019
Printed in the United States of America, all rights reserved. No part of this man-
ual may be reproduced in any form by any photographic, electronic, mechanical
or other means or used in any information storage and retrieval system without
written permission from
Wood-Mizer
8180 West 10th Street
Indianapolis, Indiana 46214
California
Proposition 65 Warning
WARNING: Breathing gas/diesel engine exhaust exposes you to chemicals known to
the State of California to cause cancer and birth defects or other reproductive harm.
xAlways start and operate the engine in a well-ventilated area.
xIf in an enclosed area, vent the exhaust to the outside.
xDo not modify or tamper with the exhaust system.
xDo not idle the engine except as necessary.
For more information go to www.P65warnings.ca.gov.
WARNING: Drilling, sawing, sanding or machining wood products can expose you to
wood dust, a substance known to the State of California to cause cancer. Avoid inhaling
wood dust or use a dust mask or other safeguards for personal protection.
For more information go to www.P65Warnings.ca.gov/wood.
TOC

Table of Contents Section-Page
Table of Contents AS00doc032519 iii
SECTION 1 INSTALLATION PROCEDURE 1-1
1.1 Pre-Installation Procedure ......................................................................1-1
1.2 Sensor Installation (Rev. A.01+)............................................................1-3
1.3 Sensor Installation (Rev. A.00) ............................................................1-11
1.4 Wiring Preparation ...............................................................................1-17
1.5 Wiring Installation for Super Sawmills................................................1-21
1.6 Wiring Installation for Standard Sawmills ...........................................1-25
1.7 Accuset Final Installation .....................................................................1-29
SECTION 2 SETUP & OPERATION 2-1
2.1 Control Setup..........................................................................................2-1
Contrast Adjustment..............................................................2-2
Standard Sawmill Model Configuration (Rev. E.02+ Only).2-2
Startup Configuration ...........................................................2-2
Auto-Bump (Rev. E.O4+ Only).............................................2-6
Other Settings........................................................................2-7
Restore Factory Defaults ....................................................2-15
2.2 Mode Selection.....................................................................................2-16
2.3 Using Auto-Down Mode ......................................................................2-18
2.4 Using Auto-Up Mode...........................................................................2-20
2.5 Using Pattern Mode..............................................................................2-21
2.6 Using Reference Mode (Rev. B.00+ Only)..........................................2-23
SECTION 3 ACCUSET TROUBLESHOOTING 3-1
3.1 Common Problems .................................................................................3-1
3.2 Accuset Display Problems......................................................................3-4
Control Panel Replacement ..................................................3-4
Resetting the Accuset ............................................................3-5
3.3 Up/Down Control Lights........................................................................3-7
MOSFET Panel Test .............................................................3-9
Replacing the MOSFET Panel............................................3-12
3.4 Accuracy Problems...............................................................................3-13
3.5 Sensor LED Lights (Rev. D.02 - E.02 only) ........................................3-14
SECTION 4 REPLACEMENT PARTS 4-1
4.1 Accuset Kit, Complete............................................................................4-1
4.2 Sensor Assembly ....................................................................................4-2
Accuset Rev. E.01+.......................................................4-2
4.3 Sensor Assembly ....................................................................................4-4
Accuset Rev. A.01 - E.00...............................................4-4

iv AS00doc032519 Table of Contents
Table of Contents Section-Page
4.4 Sensor Assembly ....................................................................................4-7
Accuset Rev. A.00..........................................................4-7
4.5 Control Assembly...................................................................................4-9
Accuset Rev. E.03 - E.06...............................................4-9
4.6 Control Assembly.................................................................................4-11
Accuset Rev. B.00 - E.02.............................................4-11
4.7 Control Assembly.................................................................................4-13
Accuset Rev. A.00 - A.03.............................................4-13
4.8 Cover Assembly ...................................................................................4-15
INDEX I

Installation Procedure
Pre-Installation Procedure
Installation Procedure AS00doc032519 1-1
1
SECTION 1 INSTALLATION PROCEDURE
1.1 Pre-Installation Procedure
1. Remove the drive pulley/belt cover from the sawmill.
2. If applicable, disconnect the encoder cable from the existing Setworks control and
remove the encoder and mounting bracket from the sawmill.
3. Pre-2006 sawmills only: 1 Note the blade height indicator position on the inch scale and
remove the scale pointer assembly from the mill. Set the mounting hardware aside.
Remove the existing blade height scale assembly from the mill. Remove the scales from
the scale mounting bracket, then set the scales and mounting hardware aside.
NOTE: Sawmills manufactured after 11/00 have four
threaded holes in the mast. If your sawmill has the threaded
holes, skip to Sensor Installation (See Section 1.2). If your
sawmill does not have the threaded holes, continue with
this procedure.
4. Position the supplied template on the sawmill vertical mast tube 4 5/16” from the top of
the tube.
1 Sawmills prior to LT30 Rev. J8.01, LT40 Rev. J9.01, LT30 Super Rev. J3.07, LT40 Super Rev. J4.08, LT30HD Rev. J9.01,
LT40HD Rev. K1.01, LT30HD Super Rev. J8.08 and LT40HD Super Rev. J8.09. The scale mount and pointer assembly
will be replaced on these sawmills. Newer mills do not require replacement of the scale mount and pointer assembly.

Installation Procedure
Pre-Installation Procedure
1
1-2 AS00doc032519 Installation Procedure
See Figure 1-1.
5. Mark the locations indicated by the holes in the template on the mast tube.
NOTE: Accurate location is necessary for proper mechani-
cal and sensor operation.
6. Relocate the template 44 9/16” from the top of the mast tube and mark the two hole loca-
tions.
7. Use the #3 (7/32”) drill bit provided to drill holes through one wall of the mast tube at all
four locations.
8. Thread all four holes with the 1/4-20 tap provided.
FIG. 1-1
3H0816
NOTE: Measurements
are taken from top of
mast to top of template. Templ ate
Templ ate

Installation Procedure
Sensor Installation (Rev. A.01+)
Installation Procedure AS00doc032519 1-3
1
1.2 Sensor Installation (Rev. A.01+)
NOTE: The sensor mounting brackets were redesigned in
April 2001. See Section 1.3 if your mounting brackets do
not look like the ones shown below.
1. Install the magnet to the bracket with the provided #8-32 x 7/8” hex head bolts, flat wash-
ers and nylon lock nuts. Slide the magnet assembly onto the sensor (the assembly will be
secured later).
See Figure 1-2.
FIG. 1-2
3H0817-2C
#8-32 Hex Nylon
Lock Nut (2)
#8 SAE Flat
Washer (4)
Magnet Mounting
Bracket
Magnet
#8-32 x 7/8”
Hex Head Bolt (2)

Installation Procedure
Sensor Installation (Rev. A.01+)
1
1-4 AS00doc032519 Installation Procedure
2. Install the 3/8” ID grommet to the upper mount bracket and install to the top of the sensor.
See Figure 1-3.
FIG. 1-3
3H0873-1
Upper Mount
Bracket
3/8" ID Grommet
Top Of Sensor

Installation Procedure
Sensor Installation (Rev. A.01+)
Installation Procedure AS00doc032519 1-5
1
3. Install two of the provided 1/4” lock washers and 1/4-20 x 5/8” hex head bolts to the bot-
tom set of threaded holes in the mast. Thread the bolts about halfway into the holes. Slide
the slotted lower mounting bracket of the sensor assembly around the two bolts, behind
the lock washers. Slide the upper mounting bracket up or down as necessary so the
bracket holes align with the holes in the mast. Secure with the remaining two lock wash-
ers and hex head bolts. Tighten all four mounting bolts. Use large channel lock pliers on
the transducer nut to turn the asssembly so the label is viewable.
See Figure 1-4.
FIG. 1-4
3H0873-2B
Sensor Assembly
1/4-20 x 5/8"
Hex Head Bolts (4)
1/4" Split Lock
Washers (4)
Turn assembly to
read label

Installation Procedure
Sensor Installation (Rev. A.01+)
1
1-6 AS00doc032519 Installation Procedure
4. Pre-2006 sawmills only: Remove the blade height and quarter scales from the removed
scale mount bracket. Use the existing hardware to secure the scales to the provided
scale mount bracket.
See Figure 1-5.
Assemble the new scale mount bracket to the sawmill mast and secure the at the top with
the existing hardware. Leave the bottom loose until after the magnet assembly is
installed.
FIG. 1-5
3H0961-1
Bend tab up

Installation Procedure
Sensor Installation (Rev. A.01+)
Installation Procedure AS00doc032519 1-7
1
5. Install the sensor magnet mount block to the scale mount bracket using the four provided
#10-24 x 1/2" hex head bolts and flat washers. Check the area between the bracket and
block. If there is a gap, use the provided extra #10 washers as necessary to fill the gap.
This will prevent bending of the scale bracket when the mounting bolts are tightened.
6. Position the magnet assembly so the holes in the magnet mounting bracket align with the
holes in the magnet mount block.
7. Secure the magnet assembly to the mount block with the provided 1/4-20 x 3/4” hex head
bolts and flat washers. Adjust the assembly in the slotted holes so the magnet is centered
around the sensor rod.
See Figure 1-6.
FIG. 1-6
3H0817-5
#10-24 x 1/2”
Hex Head Bolt (4)
#10 SAE Flat
Washer (4)
Magnet
Assembly
Scale Mount
Bracket
Use extra #10 washers
as necessary to fill gap
between scale bracket and
magnet mount block
1/4-20 x 3/4”
Hex Head Bolt (2)
1/4” SAE Flat
Washer (2)
Magnet Mount Block

Installation Procedure
Sensor Installation (Rev. A.01+)
1
1-8 AS00doc032519 Installation Procedure
8. Pre-2006 sawmills only: Use the two provided #10-24 x 3/8" pan head screws and
self-locking hex nuts to secure the provided scale pointer to the new pointer mount plate.
Then, use existing hardware to secure the pointer mount plate to the sawmill.
See Figure 1-7.
Secure the bottom of the blade height scale assembly with the existing hardware. Leave
the nuts loose enough you can still move the scale assembly up or down. Adjust the
assembly until the blade height indicator shows the measurement noted before the old
scale assembly was removed. Tighten the mounting nuts.
Apply the appropriate decals supplied to the pointer mount plate.
9. Connect the transducer cable to the socket at the bottom of the sensor.
FIG. 1-7
3H0873-3
Pointer Mount
Plate
#10-24 Self-Locking
Hex Nuts (2)
Scale Pointer
#10-24 Pan
Head Screws (2)

Installation Procedure
Sensor Installation (Rev. A.01+)
Installation Procedure AS00doc032519 1-9
1
10. Install the lower sensor guard.
See Figure 1-8. Place the cover in position behind the holes and secure with two bolts,
lock washers and flat washers provided.
FIG. 1-8
3H0962-3
Lower sensor
cover
1/4-20 x 1/2" hex
head bolt, lock washer
and flat washer (2 each)

Installation Procedure
Sensor Installation (Rev. A.01+)
1
1-10 AS00doc032519 Installation Procedure

Installation Procedure
Sensor Installation (Rev. A.00)
Installation Procedure AS00doc032519 1-11
1
1.3 Sensor Installation (Rev. A.00)
NOTE: The sensor mounting brackets were redesigned in
April 2001. See Section 1.2 if your mounting brackets do
not look like the ones shown below.
1. Install the lower mount clamp (with large hole) flush with the threaded portion at the base
of the sensor. Use two of the provided 1/4-20 x 3/4” flat socket head bolts to secure a
mounting block to the clamp. Note the orientation of the sensor, mount clamp and mount-
ing block. The clamp and block should be oriented as shown to ensure proper assembly
to the sawmill. The sensor should be oriented so the specification label faces away from
sawmill bed. Use one of the provided 1/4-20 x 1” socket head bolts to secure the clamp to
the sensor.
See Figure 1-9.
FIG. 1-9
Sensor
Lower Mount
Clamp (Note Orientation)
Mounting Block
(Note Orientation)
1/4-20 x 3/4”
Flat Socket Head Bolts (2)
1/4-20 x 1”
Socket Head Bolt
3H0817-1C
Specification Label

Installation Procedure
Sensor Installation (Rev. A.00)
1
1-12 AS00doc032519 Installation Procedure
2. Install the magnet to the bracket with the provided #8-32 x 7/8” hex head bolts, flat wash-
ers and nylon lock nuts. Slide the magnet assembly onto the sensor (the assembly will be
secured later).
See Figure 1-10.
FIG. 1-10
3H0817-2C
#8-32 Hex Nylon
Lock Nut (2)
#8 SAE Flat
Washer (4)
Magnet Mounting
Bracket
Magnet
#8-32 x 7/8”
Hex Head Bolt (2)

Installation Procedure
Sensor Installation (Rev. A.00)
Installation Procedure AS00doc032519 1-13
1
3. Install the upper mount clamp (with small hole) at the top of the sensor. Use two of the
provided 1/4-20 x 3/4” flat socket head bolts to secure a mounting block to the clamp.
Note the orientation of the mount clamp and mounting block. The clamp and block should
be oriented as shown to ensure proper assembly to the sawmill. Use one of the provided
1/4-20 x 1” socket head bolts to secure the clamp to the sensor.
See Figure 1-11.
FIG. 1-11
Upper Mount
Clamp (Note Orientation)
Mounting Block
(Note Orientation)
1/4-20 x 1”
Socket Head Bolt
1/4-20 x 3/4”
Flat Socket Head Bolt (2)
3H0817-3

Installation Procedure
Sensor Installation (Rev. A.00)
1
1-14 AS00doc032519 Installation Procedure
4. Use four of the provided 1/4-20 x 3/4” flat socket head bolts to install the sensor assembly
to the threaded holes in the mast tube. Loosen the upper or lower clamp bolts to adjust
the mounts as necessary. While the clamps are loose, lower the sensor to allow access to
the lower mounting bolts. Reposition the sensor and retighten the clamp bolts after the
assembly is bolted to the mast.
See Figure 1-12.
FIG. 1-12
Sensor Assembly
1/4-20 x 3/4”
Flat Socket Head Bolts (4)
3H0817-4C
Loosen clamp bolts to move sensor
down to install lower bolts

Installation Procedure
Sensor Installation (Rev. A.00)
Installation Procedure AS00doc032519 1-15
1
5. Remove the blade height and quarter scales from the removed scale mount bracket. Use
the existing hardware to secure the scales to the provided scale mount bracket. Assem-
ble the new scale mount bracket to the sawmill mast, using existing hardware.
6. Install the sensor magnet mount block to the scale mount bracket using the four provided
#10-24 x 1/2" hex head bolts and flat washers. Check the area between the bracket and
block. If there is a gap, use the provided extra #10 washers as necessary to fill the gap.
This will prevent bending of the scale bracket when the mounting bolts are tightened.
7. Position the magnet assembly so the holes in the magnet mounting bracket align with the
holes in the magnet mount block.
8. Secure the magnet assembly to the mount block with the provided 1/4-20 x 3/4” hex head
bolts and flat washers.
See Figure 1-13.
FIG. 1-13
3H0817-5
#10-24 x 1/2”
Hex Head Bolt (4)
#10 SAE Flat
Washer (4)
Magnet
Assembly
Scale Mount
Bracket
Use extra #10 washers
as necessary to fill gap
between scale bracket and
magnet mount block
1/4-20 x 3/4”
Hex Head Bolt (2)
1/4” SAE Flat
Washer (2)
Magnet Mount Block

Installation Procedure
Sensor Installation (Rev. A.00)
1
1-16 AS00doc032519 Installation Procedure
9. Use the two provided #10-24 x 3/8" flat socket head screws and nylon lock jam nuts to
secure the provided clear scale pointer to the new pointer mount plate. Then, use existing
hardware to secure the pointer mount plate to the sawmill.
See Figure 1-14.
10. Apply the appropriate decals supplied to the pointer mount plate.
FIG. 1-14
Pointer Mount
Plate
#10-24 Hex
Nylon Lock
Jam Nut (2)
Scale Pointer
#10-24 Flat Socket
Head Screws
3H0817-6
