woodmizer BMT200 Guide

Dual Toothsetter
Safety, Operation, Maintenance
& Parts Manual
BMT200 Rev. A.02
BMT250 Rev. A.02
Safety is our #1 concern! Read and understand
all safety information and instructions before oper-
ating, setting up or maintaining this machine.
Form #1792

Active Patents assigned to Wood-Mizer, LLC
Wood-Mizer, LLC has received patents that protect our inventions which are a result of a dedication to
research, innovation, development, and design. Learn more at: woodmizer.com/patents
©2021 Wood-Mizer LLC
Printed in the United States of America, all rights reserved. No part of this manual may be reproduced in any form by
any photographic, electronic, mechanical or other means or used in any information storage and retrieval system with-
out written permission from
Wood-Mizer, LLC
8180 West 10th Street
Indianapolis, Indiana 46214

Table of Contents Section-Page
Table of Contents DSdoc030821 v
SECTION 1 INTRODUCTION 1-1
1.1 About This Manual.................................................................................................... 1-1
1.2 Getting Service .......................................................................................................... 1-1
1.3 Specifications ............................................................................................................ 1-1
1.4 Dimensions and Specifications.................................................................................. 1-1
SECTION 1 GENERAL SAFETY 2-1
1.1 Safety Symbols.......................................................................................................... 2-1
1.2 Safety Instructions ..................................................................................................... 2-1
Observe ALL Safety Instructions......................................................... 2-1
1.3 Electrical Lockout Procedures................................................................................... 2-1
SECTION 2 SETUP & OPERATION 3-1
2.1 Assembly ................................................................................................................... 3-1
Blade Support Arms ............................................................................ 3-1
Auto Feed Installation (Optional - AC Only)...................................... 3-3
Auto Feed Installation (Optional - DC Only) ..................................... 3-5
1.2 Dual Setter Calibration.............................................................................................. 1-1
Tooth Set Master Gauge Calibration.................................................. 1-1
Dual Setter Calibration....................................................................... 1-1
1.3 Operation ................................................................................................................. 1-7
Blade Installation/Setup..................................................................... 1-7
Manual Feed Operation.................................................................. 1-14
Auto Feed Operation........................................................................ 1-14
SECTION 2 MAINTENANCE 2-1
2.1 Routine Maintenance Schedule ................................................................................. 2-1
Every 2 Weeks ................................................................................ 2-1
Every 3 Months ................................................................................ 2-2
Clamp Adjustment ............................................................................... 2-2
Gauge Assembly Adjustment............................................................... 2-3
2.2 Safety Devices Inspection ......................................................................................... 2-4

Table of Contents Section-Page
vi DSdoc030821 Table of Contents
SECTION 3 REPLACEMENT PARTS 3-1
3.1 Dual Toothsetter (Complete)..................................................................................... 3-1
3.2 Dual Toothsetter Assembly ....................................................................................... 3-2
3.3 Base Housing Assembly............................................................................................ 3-3
3.4 Feed Drive Assembly ................................................................................................ 3-5
3.5 Blade Setters.............................................................................................................. 3-7
3.6 Blade Set Arm Assembly .......................................................................................... 3-9
3.7 Clamp Assembly ..................................................................................................... 3-11
3.8 Index Assembly....................................................................................................... 3-13
3.9 Blade Support Arm Assembly................................................................................. 3-15
3.10 Auto Feed Control, AC 120V (Optional)................................................................ 3-17
3.11 Auto Feed Control, AC 220V (Optional)................................................................ 3-19
3.12 Auto Feed Control, DC (Optional).......................................................................... 3-21
3.13 Auto Feed Control Panel, AC (Optional)................................................................ 3-23
3.14 Auto Feed Motor, AC (Optional) ............................................................................ 3-24
3.15 Auto Feed Motor, DC (Optional) ............................................................................ 3-25
3.16 Toothsetter Gauge Assembly .................................................................................. 3-26
SECTION 4 ELECTRICAL INFORMATION 4-1
4.1 Schematic, AC 120V................................................................................................. 4-1
4.2 Schematic, AC 220V................................................................................................. 4-3
4.3 Schematic, DC........................................................................................................... 4-5
4.4 Component Layout Diagrams (AC Only) ................................................................. 4-6
Front Panel, Control Box.................................................................... 4-6
Insert Panel, Control Box ................................................................... 4-6
4.5 Component Layout Diagrams (DC Only) ................................................................. 4-7
Front Panel, Control Box.................................................................... 4-7
4.6 Component List (AC Only) ....................................................................................... 4-8
4.7 Component List (DC Only) ....................................................................................... 4-9

Introduction
About This Manual 1
Introduction WM doc 3/8/21 1-1
SECTION 1 INTRODUCTION
1.1 About This Manual
This manual replaces any previous information received on your Wood-Mizer® equipment.
The information and instructions in this manual do not amend or extend the limited warranties for the equipment given at the
time of purchase.
1.2 Getting Service
For contact information, sales, service, parts, and additional manuals, sign into your account on https://woodmizer.com, or call
inside the USA: 1-800-553-0182 or from outside the USA: 317-271-1542
1.3 Specifications
Equipment specification are included in the Online Manuals, which are found at https://apps.woodmizer.com/Manuals/Manu-
als.aspx?parent=0.
1.4 Dimensions and Specifications
The overall dimensions and weight are listed below.
The Dual Toothsetter models are listed below.
The motor specifications are listed below.
The noise level of the operating BMT250 Dual Toothsetter is listed below.1
Length Width Height Weight
BMT200 74" (1880 mm) 116 3/4" (2965 mm) 16 1/2" (419 mm) 90 lbs. (41 kg)
BMT250 74" (1880 mm) 116 3/4" (2965 mm) 16 1/2" (419 mm) 105 lbs. (47.5 kg)
Model Voltage
Code 1
1 M - 1 x 110V; A - 1 x 230V.
Electrical
Standard Code 2
2 U - UL (60Hz); S - CE (50Hz).
Electrical
Package
Description
BMT200 --- --- --- Dual Toothsetter w/Manual Crank
BMT250 M U EP AC Automatic Dual Toothsetter (1 x 110V 60Hz)
BMT250 A S EP AC Automatic Dual Toothsetter (1 x 230V 50Hz)
BMT250 M U D DC Automatic Dual Toothsetter (1 x 110-230V
50/60Hz)
Motor Manufacturer Model Rated Output Rated Current Rated Speed
Electric Besel S.A.,
Poland SKh 63-4A2 0.16 HP (0.12 kW) 0.80A at 230V 0.45A at 400V 1380 RPM
Electric --- --- 1/5 HP --- 32 RPM
Model Noise Level
BMT250 dB (A)
1.The figures quoted are emission levels and are not necessarily safe working levels. Although there is a correlation between the emission and
exposure levels, this cannot be used reliably to determine whether or not further precautions are required. Factors that influence the actual level of
exposure of the workforce include the characteristics of the work room and the other sources of noise etc. i.e. the number of machines and other
adjacent processes. Also, the permissible exposure level value may vary from country to country. This information, however, will enable the user
of the machine to make a better evaluation of the hazards and risk.

Introduction
Dimensions and Specifications
1
1-2 WM doc 3/8/21 Introduction
The maximum electrical loads are listed below.
DANGER! Make sure all electrical installation, service and/or maintenance work is performed by a qualified electrician
and is in accordance with applicable electrical codes.
DANGER! It is recommended that a 30mA Ground Fault Interrupter (GFI) be used.
Dimensions of the Dual Setter are shown below.
Model Maximum Load
BMT250 (1 x 110V AC 60Hz) 6.8 Amps
BMT250 (1 x 220V AC 50/60Hz) 3.95 Amps
FIG. 1-1
TOP VIEW
FRONT VIEW
DS0002
116 3/4”
(2965 mm)
16 1/2”
(419 mm)
74”
(1880 mm)

General Safety WM doc 3/8/21 2-1
General Safety
Safety Symbols 1
SECTION 1 GENERAL SAFETY
1.1 Safety Symbols
The following symbols and signal words call your attention to
instructions concerning your personal safety. Be sure to
observe and follow these instructions.
DANGER! indicates an imminently hazardous situa-
tion which, if not avoided, will result in serious injury or
death.
WARNING! suggests a potentially hazardous situa-
tion which, if not avoided, could result in serious injury
or death.
CAUTION! refers to potentially hazardous situa-
tions which, if not avoided, may result in minor or mod-
erate injury or damage to equipment.
NOTICE indicates vital information.
1.2 Safety Instructions
OWNER/OPERATOR'S RESPONSIBILITY
The procedures listed in this manual may not include all
ANSI, OSHA, or locally required safety procedures. It is the
owner/operator’s responsibility and not Wood-Mizer LLC
to ensure all operators are properly trained and informed
of all safety protocols. Owner/Operators are responsible for
following all safety procedures when operating and perform-
ing maintenance to the equipment.
Observe ALL Safety Instructions
NOTICE Read the entire Operator's Manual before
operating this equipment.
Note all safety warnings throughout this manual and
those posted on the machine.
Be able to access this manual at all times while oper-
ating this equipment.
Read additional manufacturer’s manuals (motor) and
observe their applicable safety instructions.
Only persons who have read and understood the
entire operator's manual should operate this equip-
ment.
This equipment is not intended for use by or around
children.
It is the owner/operator's responsibility to comply with
all applicable federal, state, and local laws, rules, and
regulations regarding the ownership, operation, and
transporting your equipment.
WEAR SAFETY CLOTHING
WARNING! Secure all loose clothing and jewelry
before operating the equipment.
Always wear eye, ear, and foot protection when oper-
ating or servicing the equipment.
Wear hand protection while handling blades.
KEEP HANDS AWAY
DANGER! Remove power before clearing debris or
any other maintenance activity.
Shut off the equipment before changing the blade.
Ensure all guards are in place before operating.
WARNING! Avoid contact with any hot parts
(motors).
Allow the system to cool sufficiently before begin-
ning any service function, including debris
removal.
Avoid contact with sharp edges of the cutting blades.
Stay a safe distance from rotating members (shafts,
pulleys, fans, etc.) and ensure loose clothing or long
hair does not engage rotating members
KEEP SAFETY LABELS IN GOOD CONDITION
NOTICE Ensure that all safety decals are clean and
readable. Replace all damaged safety decals to pre-
vent personal injury or damage to the equipment. Con-
tact your local distributor, or call your Customer
Service Representative to order more decals.
If replacing a component that has a safety decal
affixed to it, ensure the new component also has the
safety decal affixed.
1.3 Electrical Lockout Procedures
RULES FOR USING LOCKOUT PROCEDURE
The equipment shall be locked out to protect against acciden-
tal or inadvertent operation when such operation could cause
injury to personnel. Do not attempt to operate any switch or
valve bearing a lock.
LOCKOUT PROCEDURES MUST BE USED DURING,
BUT NOT LIMITED TO:
Changing or adjusting blades
Unjamming operations
Cleaning
Mechanical repair
Electrical maintenance
Retrieval of tools/parts from work area
Activities where guards or electrical panel guard is open or
removed
MAINTENANCE HAZARDS INCLUDE, BUT NOT LIM-
ITED TO:
Blade contact
Pinch points
Kickbacks
Missiles (thrown blades/wood chips)
Electrical
FAILURE TO LOCKOUT MAY RESULT IN, BUT NOT
LIMITED TO:
Cut
Crush
Blindness
Puncture
Electrocution
Serious injury and death

2-2 WM doc 3/8/21 General Safety
General Safety
Electrical Lockout Procedures
1
Amputation
Burn
Shock
TO CONTROL MAINTENANCE DANGERS:
Lockout procedures must be followed (see OSHA regula-
tion 1910.147).
Never rely on machine stop control for maintenance safety
(emergency stops, on/off buttons, interlocks).
Do not reach into moving blades or feed systems. Allow all
coasting parts to come to a complete stop.
Electrical power supply and air supply must both be locked
out.
Where established lockout procedures cannot be used
(electrical troubleshooting or mechanical dynamic trouble-
shooting), alternative effective protective techniques shall
be employed which may require special skills and plan-
ning.
Always follow safe operations practices in the workplace.
EQUIPMENT LOCKOUT PROCEDURE
Lockout procedures per OSHA regulation 1910.147, appen-
dix A:
GENERAL
The following simple lockout procedure is provided to assist
owner/operators in developing their procedures so they meet
the requirements of OSHA regulation 1910.147. When the
energy isolating devices are not lockable, tagout may be
used, provided the owner/operator complies with the provi-
sions of the standard which require additional training and
more rigorous periodic inspections. When tagout is used and
the energy isolating devices are lockable, the owner/operator
must provide full operator protection (see OSHA regulation
1910.147, paragraph (c)(3)) and additional training and more
rigorous periodic inspections are required. For more complex
systems, more comprehensive procedures may need to be
developed, documented, and utilized.
PURPOSE
This procedure establishes the minimum requirements for the
lockout of energy isolating devices whenever maintenance or
servicing is done on machines or equipment. It shall be used
to ensure that the machine or equipment is stopped, isolated
from all potentially hazardous energy sources and locked out
before personnel perform any servicing or maintenance
where the unexpected enervation or start-up of the machine
or equipment or release of stored energy could cause injury.
COMPLIANCE WITH THIS PROGRAM
All personnel are required to comply with the restrictions and
limitations imposed upon them during the use of lockout. The
authorized personnel are required to perform the lockout in
accordance with this procedure. All operators, upon observ-
ing a machine or piece of equipment which is locked out to
perform servicing or maintenance shall not attempt to start,
energize, or use that machine or equipment.
SEQUENCE OF LOCKOUT
1. Notify all affected personnel that servicing or maintenance is
required on a machine or equipment and that the machine or
equipment must be shut down and locked out to perform the
servicing or maintenance.
2. The authorized employee shall refer to the company proce-
dure to identify the type and magnitude of the energy that the
machine or equipment utilizes, shall understand the hazards
of the energy, and shall know the methods to control the
energy.
3. If the machine or equipment is operating, shut it down by the
normal stopping procedure (depress the stop button, open
switch, close valve, etc.).
4. De-activate the energy isolating device(s) so that the
machine or equipment is isolated from the energy source(s).
5. Lock out the energy isolating device(s) with assigned individ-
ual lock(s).
6. Stored or residual energy (such as that in capacitors, springs,
elevated machine members, rotating flywheels, hydraulic sys-
tems, and air, gas, steam, or water pressure, etc.) must be
dissipated or restrained by methods such as grounding, repo-
sitioning, blocking, bleeding down, etc.
7. Ensure that the equipment is disconnected from the energy
source(s) by first checking that no personnel are exposed,
then verify the isolation of the equipment by operating the
push button or other normal operating control(s) or by testing
to make certain the equipment will not operate.
CAUTION! Return operating control(s) to neutral or
"off" position after verifying the isolation of the equip-
ment.
8. The machine or equipment is now locked out.
RESTORING EQUIPMENT TO SERVICE
When the servicing or maintenance is completed and the
machine or equipment is ready to return to normal operating
condition, the following steps shall be taken.
1. Check the machine or equipment and the immediate area
around the machine to ensure that nonessential items have
been removed and that the machine or equipment compo-
nents are operationally intact.
2. Check the work area to ensure that all personnel have been
safely positioned or removed from the area.
3. Verify that the controls are in neutral.
4. Remove the lockout devices and re-energize the machine or
equipment.
NOTE: The removal of some forms of blocking may
require re-enervation of the machine before safe
removal.
5. Notify affected personnel that the servicing or maintenance is
completed and the machine or equipment is ready for use.
PROCEDURE INVOLVING MORE THAN ONE PERSON
In the preceding steps, if more than one individual is required
to lock out the equipment, each shall place his own per-
sonal lock on the energy isolating devices.

Setup & Operation
Assembly
Setup & Operation DSdoc030821 3-1
3
SECTION 2 SETUP & OPERATION
2.1 Assembly
Place the setter on a table or workbench sturdy enough to support the weight of the
machine. Be sure there is enough room on either side of the setter to allow for the blade
to travel.
The unit will rest on the rubber feet on the bottom of the machine. If desired, the unit can
be bolted to the table through the holes provided in the bottom of the base frame.
Blade Support Arms
NOTE: The blade support arms supplied with the setter are capable of supporting most
blades up to 1 1/2" wide. An upgrade kit is available to increase the support arm capability
to support heavier blades (See Section 3.1).
See Figure 2-1. There are arm mounting locations at the right side, left side and rear of
the machine. Install the spacer bushings and one arm mount block at each location.
Secure each block with a provided 10mm lock washer and M10-1.5 x 80 hex head bolt.
NOTE: If setting very wide blades, you may need to exclude one or more of the spacers
from each location to ensure the blade is positioned properly in the clamp. If installing the
optional arm kit for heavier blades, replace the arm mounting blocks with the extension
arms. Install the long extension arms to the left and right positions and the short arm to
the rear position.
FIG. 2-1
DS0001-20
Spacer Bushings
(remove for wider blades)
Arm Mount Block
(replace with optional
extended block for
heavier blades)
10mm Split Lock WasherM10-1.5 x 80 Hex Head Bolt
Right-side
arm mount
Rear arm mount

Setup & Operation
Assembly
3-2 DSdoc030821 Setup & Operation
3
See Figure 2-2. Thread a blade support tube into the threaded holes in the three mount-
ing blocks. Assemble a blade support extension tube to each blade support tube.
NOTE: If installing the optional arm kit for heavier blades, assemble the blade support
extension tubes to the extended mounting arms.
Install at least one blade support guide to each support tube with two 1/4-20 x 1 1/2" hex
head bolts, flat washers, self-locking nut and wing nut. The position of the guides will be
adjusted later. Three guide assemblies are provided for each arm so you can setup for
different blade lengths without having to adjust the guide assembly.
FIG. 2-2
Blade Support
Tubes
1/4" Flat Washer (2)
1/4-20 x 1 ½"
Hex Head Bolt (2)
1/4-20 Self-
Locking Nut
1/4-20
Wing Nut
Blade Support
Tube (3)
Blade Support
Extension Tube (3)
Blade Support
Guide (9)
DS0001-15

Setup & Operation
Assembly
Setup & Operation DSdoc030821 3-3
3
Auto Feed Installation (Optional - AC Only)
The AC Auto Feed Option includes an electric motor and control to automate the setting
process.
See Figure 2-3. Before installing the Auto Feed, remove the manual feed crank handle.
Disassemble the bolt, lock washer and fender washer to remove the handle. Remove the
M10-1.25 x 20 hex head bolt, split lock washer and the shaft cover mounted to the left
side of the setter assembly. Remove the index cover and use the existing M10-1.25 x 20
hex head bolt and split lock washer to reinstall the shaft cover over the manual feed shaft.
FIG. 2-3
DS0001-16
Remove Shaft Cover
Remove bolt,
lock washer,
fender washer
and crank handle
Use M10-1.25 x 20 hex head bolt
and split lock washer to install shaft
cover over crank handle shaft
M10-1.25 x 20
hex head bolt and
split lock washer
Remove cover

Setup & Operation
Assembly
3-4 DSdoc030821 Setup & Operation
3
See Figure 2-4. Install two 5 x 5 x 25mm round end keys to the feed shaft and slide the
motor with the mount plate onto the feed shaft. Secure the motor to the setter base.
See Figure 2-5. Set the Auto Feed control box near the setter at a convenient operating
location. Secure the motor harness with wire ties as necessary.
Install the proximity sensor to the stop plate next to the setter index assembly. Make sure
the proximity sensor is approximately 2-3 millimeters from the index arm. Connect the
proximity sensor cable from the control box to the proximity sensor. Secure the cable to
the motor harness as necessary
Plug the power cord from the control box into a grounded receptacle. NOTE: The control
is equipped with an auto-voltage detect feature. Simply use an appropriate adaptor plug
FIG. 2-4
FIG. 2-5
DS0001-22B
M8-1.25 x 20 Hex
Head Bolt (4)
5 x 5 x 25mm
Round End Key (2)
5/16 Flat Washer (8)
M8 Hex Nylon Nut (4)
DS0001-19
2-3mm
Motor Harness
Auto Feed
Control Box
Proximity Sensor
Index Arm
Proximity Sensor Cable
Motor
Wire Tie

Setup & Operation
Assembly
Setup & Operation DSdoc030821 3-5
3
or modify the power cord to match your receptacle.
DANGER! For the user's safety, the power cord on this
product has a grounded plug. This power cord should only
be used with correctly grounded (3-hole) receptacles to
avoid electrical shock.
Auto Feed Installation (Optional - DC Only)
The DC Auto Feed Option includes an electric motor and control to automate the setting
process.
See Figure 2-6. Before installing the Auto Feed, remove the manual feed crank handle.
Disassemble the bolt, lock washer and fender washer to remove the handle. Remove the
M10-1.25 x 20 hex head bolt, split lock washer and the shaft cover mounted to the left
side of the setter assembly. Remove the index cover and use the existing M10-1.25 x 20

Setup & Operation
Assembly
3-6 DSdoc030821 Setup & Operation
3
hex head bolt and split lock washer to reinstall the shaft cover over the manual feed shaft.
FIG. 2-6
DS0001-16
Remove Shaft Cover
Remove bolt,
lock washer,
fender washer
and crank handle
Use M10-1.25 x 20 hex head bolt
and split lock washer to install shaft
cover over crank handle shaft
M10-1.25 x 20
hex head bolt and
split lock washer
Remove cover

Setup & Operation
Assembly
Setup & Operation DSdoc030821 3-7
3
See Figure 2-7. Remove the existing shaft end bolts from the setter. Install the feed
motor mount bracket around the feed shaft and secure with the provided shaft end bolts,
flat washers and existing nylon lock nuts. Leave the bolts slightly loose until the motor is
pinned to the feed shaft as described later.
See Figure 2-8. Install the motor side brackets to the feed motor and secure with eight
flanged hex head bolts.
FIG. 2-7
FIG. 2-8
DS0013-3
Feed Motor
Mount Bracket
DS0013-4
Feed Motor
Side Bracket (2)

Setup & Operation
Assembly
3-8 DSdoc030821 Setup & Operation
3
See Figure 2-9. Slide the sleeve and motor assembly onto the feed shaft and secure to
the motor mount bracket with four flat washers, lock washers, hex head bolts and
self-locking nuts. Leave the bolts slightly loose until the motor is pinned to the feed shaft
as described later.
See Figure 2-10. Use a 1/2" wrench on the front hex knob to rotate the motor shaft to
align the hole in the outer collar with the hole in the feed shaft. With the motor mount bolts
still loose, adjust the assembly if necessary until the holes line up exactly. Install the pro-
vided roll pin to secure the motor assembly to the shaft. Tighten the feed shaft end bolts
and motor mount bolts and install the motor top cover with two hex head bolts, flat wash-
ers and lock nuts.
FIG. 2-9
FIG. 2-10
DS0013-5
Sleeve
DS0013-6
Roll Pin
Turn hex knob to
rotate shaft and
align roll pin holes
Motor Cover

Setup & Operation
Assembly
Setup & Operation DSdoc030821 3-9
3
See Figure 2-11. Set the Auto Feed control box near the setter at a convenient operating
location. Connect the motor harnesses with two-pin connectors together. Secure the
motor harness with wire ties as necessary.
Install the proximity sensor to the stop plate next to the setter index assembly. Make sure
the proximity sensor is approximately 2-3 millimeters from the index arm. Secure the
cable to the motor harness as necessary.
Plug the power cord from the control box into a grounded receptacle. NOTE: The control
is equipped with an auto-voltage detect feature. Simply use an appropriate adapter plug
or modify the power cord to match your receptacle.
Connect the ground wire from the control box to one of the holes located on the back of
the setter base.
DANGER! For the user's safety, the power cord on this
product has a grounded plug. This power cord should only
be used with correctly grounded (3-hole) receptacles to
avoid electrical shock.
FIG. 2-11
DS0013-2B
2-3mm
Motor Harness
Ground Wire Sensor
Harness
Auto Feed
Control Box
Proximity Sensor
Index Arm

Dual Setter Calibration
1
1-1 WM doc 3/8/21
1.2 Dual Setter Calibration
WARNING! Always wear gloves and eye protection when handling bandsaw blades. Changing blades is safest when
done by one person! Keep all other persons away from area when coiling, carrying or changing a blade. Failure to do
so may result in serious injury.
For calibration and alignment videos, refer to your DVD shipped with this manual, or look online at
https://www.youtube.com/watch?v=eHWjGntODr8&ab_channel=Wood-Mizer
Tooth Set Master Gauge Calibration
The tooth set gauge accurately measures the set of any blade tooth. The gauge needs to be assembled and calibrated before
use.
See Figure 1-12. Insert the dial gauge assembly into the hole in the block housing. Clamp the calibrating pin
in position at the center of the dial gauge foot. Push the gauge assembly forward until the foot just touches
the pin and dial needle moves .005 to .010. Tighten the locking screw with the provided hex wrench (do not
overtighten). Loosen the dial lock on the gauge and rotate the dial face until the needle reads zero. Tighten
the dial lock.
Unclamp the calibrating pin from the set master gauge clamp by turning the clamp knob counterclockwise. With the pin not
clamped, the set master gauge needle should read between -.005 and -.010. If not, reclamp the pin, loosen the locking screw
and move the set master gauge assembly back so the foot does not contact the pin. Repeat the steps above until the dial nee-
dle reads zero with the calibrating pin clamped and between -.005 and -.010 without the pin clamped. This ensures the dial foot
extends beyond the clamp plate a slight amount and will read zero when the foot is aligned with the clamp plate.
Dual Setter Calibration
See Figure 1-14. Pull the blade clamp lever open and flip the index arm up. Turn the feed handle counter-
clockwise (or push and hold the Auto Feed option START - JOG button) to advance the setter until the setter
assemblies open.
FIG. 1-13
Calibrating Pin
(See Side View)
Locking Screw
Dial Gauge
Assembly
Dial Lock
SS0006-3
Clamp Plate
Clamp Knob
Gauge
Foot
Pin
SIDE VIEW

Dual Setter Calibration 1
WM doc 3/8/21 1-2
Loop the blade over the setter and position between the posts of the blade support guides. Place the blade between the clamp
rollers and between the setter blocks, resting on the blade height adjustment pins.
FIG. 1-15
DS0001-24
Place blade
between support
guide posts
Turn handle
counterclockwise
to advance setter
(or push and hold the Auto Feed
option START - JOG button)
Advance setter to open
setter assemblies Pull clamp
handle open
Flip index
arm up
Insert blade between
clamp rollers and
setter assemblies

Dual Setter Calibration
1
1-3 WM doc 3/8/21
See Figure 1-16. Place the set master gauge around the blade to measure tooth set. Turn the lock knob
counterclockwise to loosen and adjust the blade height rest pin up or down. Adjust so when the blade rests
on the pin, the gullet of the blade is just below the clamp plate. Retighten the lock knob.
See Figure 1-18. Slide the set master gauge assembly through the blade until a tooth set back toward the
gauge is positioned in front of the dial plunger.
FIG. 1-17
FIG. 1-19
SS0006-6
Lock Knob
Rest Pin
Read set
Tooth set back
toward gauge
SM0420-1
