woodmizer LT15WC E15 User manual

Wood-Mizer®
Safety, Installation,
Operation and Maintenance
LT15WC E15 rev. A1.09
LT15WC G25 rev. A1.09
Safety is our #1 concern! Read and understand
all safety information and instructions before oper-
ating, setting up or maintaining this machine.
Form #790
!

4 SW-07doc091522Table of Contents
Table of Contents Section-Page
SECTION 1 SAFETY INSTRUCTIONS 1-1
1.1 Safety Symbols.......................................................................................1-1
1.2 Blade Handling.......................................................................................1-2
1.3 Sawmill Setup.........................................................................................1-2
1.4 Sawmill Operation..................................................................................1-2
1.5 Sawmill Maintenance .............................................................................1-4
1.6 Safety Instructions ..................................................................................1-4
1.7 Belt Sizes ..............................................................................................1-12
1.8 Blade Sizes ...........................................................................................1-12
1.9 Cutting Capacity...................................................................................1-12
1.10 Engine/Motor Specifications ................................................................1-13
1.11 Noise Level...........................................................................................1-14
1.12 Sawdust Exhaust System Specifications ..............................................1-14
1.13 Overall Dimensions ..............................................................................1-15
1.14 Components..........................................................................................1-20
SECTION 2 SAWMILL ASSEMBLY 2-1
2.1 Mounting Parts of LT15WC Sawmills with Electric Motors.................2-1
2.2 Unpacking the Sawmill ..........................................................................2-7
2.3 Bed Frame Assembly .............................................................................2-8
2.4 Saw Head Assembly.............................................................................2-15
2.5 Manual Feed Rope Assembly...............................................................2-22
2.6 Power Feed Chain Assembly................................................................2-27
2.7 Auxiliary Bed Rail................................................................................2-32
2.8 Installation of the Fuel Hoses...............................................................2-33
SECTION 3 SETUP & OPERATION 3-1
3.1 Sawmill Setup.........................................................................................3-1
3.2 Replacing The Blade ..............................................................................3-9
3.3 Tensioning The Blade...........................................................................3-10
3.4 Tracking The Blade ..............................................................................3-11
3.5 Starting the Engine/Motor ....................................................................3-12
3.6 Loading, Turning and Clamping Logs .................................................3-13
3.7 Up/Down Operation .............................................................................3-16
3.8 Blade Guide Arm Operation.................................................................3-17
3.9 Blade Drive Operation..........................................................................3-18
3.10 Feed Operation .....................................................................................3-20
3.11 Cutting The Log ...................................................................................3-23
3.12 Edging...................................................................................................3-24
3.13 Blade Height Scale ...............................................................................3-24
3.14 Water Lube Operation ..........................................................................3-26
3.15 Transporting the Sawmill .....................................................................3-27

Table of Contents Section-Page
Table of Contents SW-07doc0915225
SECTION 4 MAINTENANCE 4-1
4.1 Wear Life................................................................................................4-1
4.2 Sawdust Removal ...................................................................................4-1
4.3 Carriage Track & Rollers .......................................................................4-1
4.4 Vertical Mast Rails .................................................................................4-2
4.5 Miscellaneous Lubrication .....................................................................4-2
4.6 Blade Wheel Belts ..................................................................................4-3
4.7 Brake Pads Adjustment ( Gas / Diesel Sawmills Only ) ........................4-4
4.8 Up/Down and Feed System ....................................................................4-4
4.9 Miscellaneous Maintenance ...................................................................4-8
4.10 Filling Blade Tensioner Cylinder with Oil.............................................4-8
4.11 LT15WC AC Safety Devices Inspection (Only CE Version) ..............4-10
4.12 LT15WC DC Safety Devices Inspection (Only CE Version) ..............4-12
SECTION 5 TROUBLESHOOTING GUIDE 5-1
5.1 Sawing Problems....................................................................................5-1
SECTION 6 SAWMILL ALIGNMENT 6-1
6.1 Pre-Alignment Procedures......................................................................6-1
6.2 Pre-Installation Procedure ......................................................................6-1
6.3 Blade Installation and Alignment...........................................................6-1
6.4 Blade Wheel Alignment .........................................................................6-2
6.5 Blade Guide Arm Alignment..................................................................6-7
6.6 Aligning The Blade Guides....................................................................6-9
6.7 Blade Deflection...................................................................................6-10
6.8 Blade Guide Vertical Adjustment ........................................................6-10
6.9 Blade Guide Spacing ............................................................................6-12
6.10 Horizontal Tilt Adjustment...................................................................6-13
6.11 Side supports ........................................................................................6-13
6.12 Blade Height Scale Adjustment............................................................6-14
6.13 Motor Drive Belt Adjustment...............................................................6-15
6.14 Track Roller Distance Adjustment .......................................................6-16
SECTION 7 MOTOR BRAKE 7-1
7.1 Motor Brake Maintenance......................................................................7-1

-1 G24doc091522
IMPORTANT! Read the entire Operator’s Manual before
operating the sawmill. Take notice of all safety warnings
throughout this manual and those posted on the machine.
Keep this manual with this machine at all times, regardless
of ownership.
!
