Woodway Curve LTG User manual

CURVE LTG - Owners Manual
Owners Manual
08.30.23 OM-EN-V1
For The Long Run
woodway.com

08.30.23 OM-EN-V1
2
Copyright
The release of the operating instructions to third parties without the written permission of
WOODWAY is prohibited. Duplication in any manner and form - including excerpts - as well as
use and/or communication of the content are not permitted without written permission from
WOODWAY.
European Representative:
WOODWAY GmbH
Steinackerstr. 20
79576 Weil am Rhein
Germany
Tel.: + 49 (0) 7621-940 999-0
Fax.: + 49 (0) 7621-940 999-40
E-mail: [e-mail]
Web www.WOODWAY.de
Sales:
Tel.: [phone] - 940 999 - 10
E-Mail: [email protected]
Customer Service:
Tel.: [phone] - 940 999 - 14
E-Mail: [email protected]
Manufacturer:
WOODWAY USA, Inc.
W229 N591 Foster Ct.
Waukesha, WI 53186
USA
Tel.: [phone]
Fax.: [phone]
E-mail: [e-mail]
Web www.WOODWAY.com
EC REP
Note: If viewing this manual using Adobe Acrobat Reader, “Clicking” on the
Chapter Headers or any of the Sub-Chapter Headers in the Table of
Contents will take the reader to the desired chapter.
Clicking on the WOODWAY header at the top of the page will return the
reader to the Table of Contents.

08.30.23 OM-EN-V1 3
Table of Contents
1 Safety...............................................................7
1.1 Important Safety Instructions ........................................................ 7
1.2 Description of Warning Notices......................................................9
1.3 Safety Notices on Devices ..............................................................9
1.4 Personnel Qualifications and Responsibilities ............................... 10
1.5 Intended Use ............................................................................... 10
1.6 Unauthorized Modes of Operation ................................................ 11
2 Introduction ....................................................12
2.1 Operating Instructions Information .............................................. 12
2.2 Limitation of Liability ................................................................... 12
2.3 Replacement Parts....................................................................... 13
2.4 Customer Service and Nameplate Information ............................. 13
2.5 EC Declaration of Conformity ....................................................... 16
3 Transportation and Storage ...............................17
3.1 Safety Notices for Transportation................................................. 17
3.2 Flat Transportation ...................................................................... 17
3.3 Upright Transportation ................................................................ 17
3.4 Transportation with Carrying Poles.............................................. 18
3.5 Storage........................................................................................ 18
4 Dimensions and Technical Specifications .............18
4.1 Curve LTG Model..........................................................................19
4.2 Conditions for Use ....................................................................... 19
5 Setup and Placement ........................................19
5.1 General........................................................................................ 19
5.2 Preparation and Placement ......................................................... 20
5.3 Safe Fall Area .............................................................................. 21
6 Installation .....................................................21
6.1 Optional Tools.............................................................................. 21
6.2 Included Tools and Hardware ....................................................... 22
6.3 Unpacking ................................................................................... 23
6.4 Placement ................................................................................... 25
6.5 Main Chassis Assembly................................................................ 26
6.6 Control Console Assembly ........................................................... 31
6.6 Leveling Instructions ................................................................... 34
7 Product Description / Operation.........................35
7.1 Safety Equipment......................................................................... 35
7.2 For Your Safety............................................................................ 36
7.3 Practical Training ........................................................................ 37
7.3.1 Professional Consultation ........................................................ 37
7.3.2 Warm-Up and Cool Down.......................................................... 37
7.3.3 Proper Body Form ................................................................... 37
7.3.4 Training Frequency.................................................................. 38
7.3.5 Endurance Training................................................................ 38
7.3.6 Measuring Heart Rate 38

08.30.23 OM-EN-V1
4
7.3.7 Calculating Heart Rate Measurement.......................................................... 38
7.3.8 Heart Rate Monitors ................................................................................... 39
7.3.9 Applying the Chest Strap ............................................................................ 39
7.3.11 Before Each Use................................................................................ 40
7.3.12 Starting the Treadmill............................................................................. 40
8 Control Console ............................................................ 41
8.1 Control Console Overview............................................................................... 41
8.2 Description of Lower Control Console Buttons................................................. 42
8.3 Speed Indicators ..................................................................................42
8.4 Description of Side Control Console Buttons.................................................... 43
8.5 Program Selection and Setup.......................................................................... 44
8.5.1 Goal ......................................................................................................... 44
8.5.2 Interval .................................................................................................... 45
8.5.3 Custom..................................................................................................... 46
8.5.4 Track........................................................................................................ 48
8.5.5 Group/Circuit ........................................................................................... 49
8.5.6 Competition.............................................................................................. 51
9 Software Management ................................................... 53
10 Cleaning and Maintenance .............................................. 54
10.1 Cleaning ......................................................................................................... 54
10.2 Maintenance Intervals..................................................................................... 55
11 Warranty Information .................................................... 56
12 Troubleshooting............................................................ 58
12.1 Display Will Not Turn On................................................................................. 58
12.2 Running Surface Belt is Stuck/Difficult to Move............................................... 58
12.3 Squeaking Sounds .......................................................................................... 58
13 Cover Removal and Component Access ............................. 59
13.1 Bearing Maintenance: ..................................................................................... 60
13.2 Running Belt Adjustment: ............................................................................... 60
14 Battery Charging Option................................................. 63
15 Disposal ...................................................................... 63

08.30.23 OM-EN-V1 5

08.30.23 OM-EN-V1
6
My WOODWAY__________________________________ Arrived on __________________
Model Name Date
WOODWAY History
WOODWAY’s history begins in Germany in 1974. Willi Schoenberger, a technical director in
charge of planning a fitness center, noticed that the most important piece of equipment, the
treadmill, didn’t meet the most important requirements: a mechanically sound machine that is
designed to meet human needs.
He envisioned a comfortable walking surface that didn’t interfere with the natural
bio-mechanics of running or walking. Also, he wanted a transportation system which
eliminated the friction associated with conventional conveyor-belt treadmills.
After intensive research, and trial and error (and in cooperation with the Deutsche
Sporthochschule in Cologne, Germany), Willi developed and patented a very unique and
revolutionary treadmill design.
In 1975, WOODWAY GmbH was founded in Weil am Rhein, Germany. The name “WOODWAY” is
derived from the German “Waldweg” (“Wald” = wood and “Weg”= way), the feel of running on a
soft pine needle covered path in the forest.
In 1983, a manufacturing license was awarded to Sakai Medical, for the use of WOODWAY
technology in the Japanese marketplace.
In 1988, a U.S. license was granted to a small, well-established manufacturing company in
Waukesha,
Wisconsin. WOODWAY USA was formed when the U.S. incarnation of the WOODWAY was
developed and completed in 1990. WOODWAY USA is proud to be the primary manufacturer of
WOODWAY treadmills worldwide, exporting treadmills for international distribution, in addition
to serving our domestic customers and clients.
Today, WOODWAY’s design and manufacturing facilities in the United States, Germany, and
Japan make WOODWAY the largest specialized treadmill manufacturer in the world.
Constant enhancements in quality, design, and function are shared and implemented by all
three WOODWAY manufacturers.
As WOODWAY moves forward, attention to product quality, innovation, and customer service
are at the forefront of our efforts. Along with our treadmills, other products, services, and
strategic relationships are being developed so as to keep WOODWAY on the leading edge as
we meet fitness training, testing, and rehabilitation needs.

08.30.23 OM-EN-V1 7
1 Safety
1.1 Important Safety Instructions
The treadmills have been reliably designed, manufactured, and tested according to the latest
state of technology and are in safe and technically perfect condition. Nevertheless, the devices
can cause risk to persons and property if operated improperly.
For this reason, the operating instructions should be read completely and safety instructions
must be observed.
Warnings attached directly to the device must be observed and kept in a legible condition.
Inappropriate use will result in the rejection of any liability or guarantee claims by WOODWAY.
All WOODWAY treadmills are built to the specifications of and are intended for both
commercial and residential use.
Read all instructions and warnings before using the treadmill.
1. The treadmill is non-motorized. The user controls the speed, including the rate at which
the treadmill slows or comes to a stop. There is no motor on the treadmill, therefore there
is NO Emergency Stop pull cord or lanyard. The treadmill will come to a stop on its own.
It is imperative that all users familiarize themselves with the treadmill and its features.
2. The Curve LTG belt moves freely, by stepping on the rear-most part of the running surface
where it is rounded, there is a danger of falling, as the force of gravity can set the running
surface in motion. Always mount and dismount the running surface from either side
towards the rear of the treadmill, stepping on the lowest/flattest portion of the belt
curvature. Always use the handrails when mounting and dismounting the treadmill.
3. Do not use any adapters, or attachments not specified by the manufacture especially those
without grounding provisions. Doing so could potentially result in electrical shock.
4. Do not operate the treadmill outside or in damp / wet locations.
5. Do not soak the treadmill surfaces with any liquid; use a sprayer or damp cloth.
6. Keep ALL electrical components, away from water.
7. Do not place any open liquid containers on any part of the treadmill. The use of sport
bottles with close-able tops is acceptable.
8. Always keep the running surface clean and clear of obstructions.
To Reduce the Risk of Electric Shock!
• Do Not operate the Heart Rate Monitor Transmitter in conjunction with
an electrical heart Pacemaker. The transmitter may cause electrical
disturbances.
• Do Not soak or power spray the treadmill surfaces with any cleaners,
water or liquids.
• Do Not place any open liquid containers on any part of the treadmill.
The use of sports bottles with closeable tops is acceptable.
• Turn treadmill controls OFF prior to cleaning.
DANGER
!

08.30.23 OM-EN-V1
8
WARNING - To reduce the risk of injury to you and others:
• Set up and operate the treadmill on a solid, level surface.
• Use the treadmill only for its intended purpose as described in the manual.
• Keep all loose clothing and towels away from the running surface. It is also important that
shoe laces do not extend beyond the bottom of the shoe.
• Keep the area behind treadmill clear and at least 78” (2 m) from walls or furniture.
• Never let loose objects (e.g. balls) roll under the treadmill. They could be pulled into the device
during operation.
• Keep hands away from all moving parts.
• Never leave children unsupervised while on or near the treadmill.
• Inspect the treadmill for worn or loose components prior to use. Tighten or replace any worn
or loose components prior to use.
• WOODWAY treadmills are built to handle runners weighing up to 800 lbs. (360 kg) at speeds
between 0-4 MPH (0-6.5 km/h) and 400 lbs. (180 kg) at speeds greater than 4MPH (6.5 km/h).
• The treadmill running belt might not stop immediately if an object becomes caught in the belt
or rollers.
• WOODWAY recommends that facilities that have users who are elderly, are children, or have
health limitations, use a safety gantry harness. The manufacturer declines any liability for
personal injury and/or property damage which could have been avoided with the use of a
gantry harness system.
• Care should be taken when mounting and dismounting the treadmill. Never mount or dismount
the treadmill while the running belt is moving. Use the handrails whenever practical or
necessary.
• Wear proper athletic shoes with rubber or high-traction soles. Do not use shoes with heels or
leather soles. Ensure no stones are embedded in the profile of the soles.
• Allow several minutes to bring your heart rate into the training zone depicted in the manual.
Walk slowly after your workout to allow your body sufficient time to cool down and your heart
rate to decrease.
• The safety and integrity designed for the machine can only be maintained when the treadmill is
regularly examined for damage and/or wear and repaired if necessary. It is the sole
responsibility of the user/owner or facility operator to ensure that regular maintenance is
performed.
• Do not attempt to service your treadmill yourself without first contacting WOODWAY Service.
It is preferable that mechanics have successfully completed WOODWAY factory-authorized
service school or equivalent.
• Worn or damaged components should be replaced immediately or the treadmill should be
removed from service until the repair is made. Only manufacturer supplied or approved
components should be used to maintain and repair the treadmill. SAVE THESE INSTRUCTIONS

08.30.23 OM-EN-V1 9
1.2 Description of Warning Notices
Warning notices indicate potential hazards or safety risks. They are indicated in this manual by
a color-coded signal word panel (symbol with the appropriate signal word). All warning notices
have the same design and the same standardized content design.
Sample of a Warning Notice
Classification
1.3 Safety Notices on Devices
Replace the safety stickers if they become damaged or illegible.
Information relevant to the safety is identified on the device using the following stickers.
Use Care When Using the Non-Motorized Treadmill
Sticker located on the right rear corner cover:
Notice on free movement in the direction of the
arrow, and directions for mounting and dis-mounting
the treadmill.
Ensure Proper Health Condition Before Use
Sticker located on the front left corner cover:
Consult a physician before use and discontinue
training in case of health problems.
Replacement Sticker P/N - M1325
SIGNAL WORD
Warning Text, Type, and Source of Danger
Description of the consequences of ignoring the danger
• Measures, instructions, and forbidden actions to avoid the hazard.
• Further measures.
!
NOTICE
CAUTION
!
!DANGER
!WARNING
NOTICE or ATTENTION: (No Danger Symbol)
No risk of injury, pertinent information and
warning against material damage.
CAUTION: (with danger symbol) light
possibility of injury.
WARNING: (with danger symbol)
In a dangerous situation, serious accident pos-
sible with the possibility of injury or death.
DANGER: (with danger symbol)
In the event of an accident, immediate danger
of death or serious injury.

08.30.23 OM-EN-V1
10
1.4 Personnel Qualifications and Responsibilities
Representative: The representative is the person or company that is responsible for setting
up, using, and maintaining the device.
The representative of the treadmill is responsible for the regular maintenance and testing as
required by law. They are also obligated to provide adequate training/instruction to the
operating personnel. WOODWAY recommends the training be carried out by a trained and
authorized WOODWAY dealer or service partner.
1.5 Intended Use
The Curve LTG treadmill is non-motorized, it serves for training athletic running, to increase
stamina and physical fitness, and can be used for running or walking.
Please note that the Curve LTG listed in this manual is athletic training equipment, which
according to EU regulations are not to be used for medical applications.
The operating instructions are an integral part of the treadmill and are to be available to all
users at all times. The exact observance of the instructions is a prerequisite for the intended
use of the WOODWAY treadmill.
Danger due to Improper Use!
Improper handling of the device can lead to serious personal injury and
property damage.
• The device may only be operated by persons who have received instructions
from qualified service personnel.
• WOODWAY recommends the use of a training record for proof of instruction.
WARNING
!
WARNING
Danger due to Improper Use!
• Any improper use and/or other use of the device can lead to dangerous
situation with significant personal injury and/or property damage.
• Only use the treadmill for its intended use.
• Avoid excessive training, as this can lead to injury.
• Read and strictly adhere to all information in the operating instructions.
!
WARNING
Risk of Injury Through Risk of Falling!
• Familiarize yourself with treadmill operation and operating principles
before the first training.
• Always use the safety handrail when mounting and dismounting and
when starting training.
!
Claims to the manufacturer of any kind due to damage from improper use
are excluded.
The representative alone is liable for all damages resulting from improper
use.
ATTENTION

08.30.23 OM-EN-V1 11
1.6 Unauthorized Modes of Operation
The treadmill may only be used for the aforementioned intended use. Any additional uses may
result in serious personal injury and/or property damage.
The following restrictions and prohibitions must be strictly adhered to:
• Treadmill may not be used without prior instruction by qualified personnel.
• Children and animals may not use the device or be left near the device unattended.
• Use of the treadmill under the influence of alcohol, drugs and/or narcotics is prohibited.
• The treadmill is not intended to be used by persons weighing more than 800 lbs. (360
kg) when walking at speeds up to 4 mph, or more than 400 lbs. (180 kg) when running at
speeds exceeding 4 mph.
• Transportation of objects on the treadmill is not allowed.
• Walking surface is not suited for the use of running shoes with spikes or studs.
• It is forbidden to use the treadmill without its side rails or with walking poles.
• The operation of WOODWAY slat belt treadmills outside of the named ambient conditions
in the section “Setup & Installation” (temperature, humidity, air pressure) as well as
outdoors (i.e. outside of closed rooms) is not allowed.
• For people with health limitations or contraindications, the use of a treadmill without prior
consultation by a health care professional is prohibited.
• When stepping onto the treadmill, during walking exercises, and when stepping off of the
treadmill the safety instructions in this manual must be observed. Here, the following
restrictions apply:
• Never jump onto the moving belt
• Never jump off while the device is moving
• Never jump off of the front
• Never stop walking when the belt is moving
• Never turn around when the belt is moving
• Never walk sideways or backwards
WARNING
Unauthorized Use Can Cause Injury!
Using the treadmill in a manner not authorized by WOODWAY can be
potentially hazardous.
• Only use the device for its intended use as described in the manual.
• Do not use unauthorized replacement parts or accessories that could
interfere with the functionality or safety of the device.
• Always use the safety handrail when mounting and dismounting and
when starting training. Always mount the treadmill from the rear.
• If the device is damaged or not functioning properly, do not use until it
has been inspected and/or repaired by qualified and authorized
personnel
!

08.30.23 OM-EN-V1
12
2 Introduction
2.1 Operating Instructions Information
This manual provides information on the safe operation of the WOODWAY slat belt treadmill.
A condition for safe operation is compliance with all safety and operating instructions.
Read and Observe the Operating Instructions!
Observe the Instructions
WOODWAY accepts no liability for accidents, equipment damage, and consequences of
equipment failure that are a result of failure to follow the operating instructions. In addition,
local accident prevention regulations and general safety conditions for intended use of the
treadmill apply.
The manufacturer reserves the right to make technical changes in the context of improving the
performance properties and further development without prior notice. Illustrations are for
basic understanding and may differ from the actual design of the device.
Accessories from other suppliers have further safety regulations and guidelines which must
also be observed. WOODWAY accepts no liability for accidents, equipment damage, and
personal injury caused by the use of accessories from other suppliers.
2.2 Limitation of Liability
All information and instructions in this manual have been compiled in accordance with
applicable standards and regulations, the current state of technology, and our knowledge and
experience.
WOODWAY accepts no responsibility for damages resulting from:
• Disregarding the operating instructions
• Improper use
• Use by non-authorized persons
• Use of replacement parts which were not approved by WOODWAY
• Unauthorized modifications to the device or accessories
WOODWAY general terms and conditions and delivery conditions apply, as well as the legal
regulations valid at the time of contract conclusion.
CAUTION
Improper Operation Can Cause Accidents!
• Not using the treadmill as intended according to the manufacturer’s
instructions can cause accidents and equipment damage.
• These operating instructions must be completely read and understood
before using the treadmill.
• Keep these instructions close at hand for all users of the device.
!
Read these instructions carefully before beginning any work on
the treadmill. It is a part of the device and must be kept
accessible at all times and in the immediate vicinity of the
treadmill for operating and maintenance personnel.

08.30.23 OM-EN-V1 13
2.3 Replacement Parts
WOODWAY recommends the use of original replacement parts. Original replacement parts
have particular qualities and ensure reliable and safe operation.
• Developed for specific use with the device
• Manufactured for high quality and excellence
• Ensure the legal warranty period (excluding wear parts) or other reached agreements
Disposal: Wear parts are considered hazardous waste! After being replaced, wear parts must
be disposed of according to country-specific waste laws. For further information on disposal,
see
Disposal page 62
2.4 Customer Service and Nameplate Information
Contact Tel: [phone]
Fax: [phone]
E-Mail: [e-mail]
Web: www.WOODWAY.com
For faster processing of your request please have the following data and information available:
• Information on the name plate (specific model/serial number)
• An accurate description of the circumstances
• Customer number (if available)
• What action has already been taken
Servicing: The address of your local service center can be obtained from the manufacturer. Af-
ter repair or re-installation, the actions listed under “Preparation and Placement” (see Chapter
5.2 Page 19) are to be performed as during installation.
Name Plate:
Each WOODWAY treadmill receives a serial number during production. Depending on the year
of your model, it has an alphanumeric code with 7-8 characters or a numeric code with 9 digits.
The serial number can be found on the name plate, which is mounted on the rear of the display
or on the left front of the treadmill frame.
The name plate contains the device’s main technical details.
The treadmill range of functions is stated on the name plate and on the delivery note. Refer to
the nameplate data during service calls.
The use of NON-original replacement parts may change the characteristics
of the device and interfere with the safe use!
WOODWAY does not accept liability for damages resulting from this.
NOTICE
WOODWAY USA, Inc.
W229 N591 Foster Ct.
Waukesha, WI 53186
USA

08.30.23 OM-EN-V1
14
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC RF Radiation Exposure Statement Caution: To maintain compliance with the FCC’s RF
exposure guidelines, place the product at least 20cm from nearby persons.
Operation frequency: 2402MHz ~ 2480MHz
Max. Output Power: -5.18dBm
This device complies with FCC’s radiation exposure limits set forth for an uncontrolled
environment.

08.30.23 OM-EN-V1 15
If this manual has been printed, write the Serial Number, Model Number and Model Code in the
spaces below, as they will be needed when contacting the WOODWAY service department.
Serial Number: _________________________________
Model Number: _________________________________
Model Code ____________________________________
1) Device CE symbol with number of the notified body if applicable, and Year Manufactured.
2) Serial Number, Model Number, and Model Code Number
3) WOODWAY’s ® Logo and address
4) 2D Universal Identification Code for internal product classification
5) Do Not Discard Warning
6) Note to read and observe operating instructions
7) Accuracy and usage classifications, and enclosure rating (IEC-60529), ACCURACY: A
USAGE: S, ENCLOSURE: IP2X
8) Patent notice

08.30.23 OM-EN-V1
16
2.5 EC Declaration of Conformity

08.30.23 OM-EN-V1 17
3 Transportation and Storage
3.1 Safety Notices for Transportation
Check the treadmill for damage upon arrival. Also check and compare supplied accessories
with the corresponding delivery note.
The manufacturer is not liable for damages and missing parts if this information was not
recorded in writing on the delivery note upon delivery of the unit. Damage or defects must be
reported to the carrier and to the responsible WOODWAY dealer immediately.
WOODWAY Service If necessary, transport or relocation can be organized and carried out by
authorized WOODWAY service partners.
For further information please contact WOODWAY Customer Service.
3.2 Flat Transportation
The Curve LTG treadmill can be transported, partially or fully assemble on a flat surface using
a commercial grade transport dolly that is 30”x18”.
NOTE: Side covers MUST be removed before setting the unit on the dolly to avoid cover
damage
3.3 Upright Transportation
For narrow transport routes it is possible to transport the treadmill vertically (e.g. narrow
door width or for climbing stairs). For this, handrails and side panels must be removed.
When transporting in an upright position, the device must be additionally secured against
accidental tipping or rolling since the center of gravity is not in the middle of the device.
WARNING
Risk of Injury by machine Falling or Falling Over!
Improper transportation of the device may lead to it falling over and causing
injury or equipment damage.
• Only transport in compliance with the safety regulations.
• Only use the supplied carrying tubes for transport.
• Never lift the device using the railing or protective coverings.
• Ensure stable center of gravity and steadiness during transportation.
!

08.30.23 OM-EN-V1
18
3.4 Transportation with Carrying Poles
Four lift bars (round steel tubes) are
included as treadmill accessories. The
lift bars can be inserted into the Front
and Back Ports (1) located at each end
of the treadmill frame . The side panels
and railings can be removed to facilitate
transport.
3.5 Storage
The device may only be stored in closed, dry rooms. It is absolutely necessary to prevent
contact with moisture (rain, fog, etc.)
The following environmental conditions are prescribed for transportation and storage:
• Temperature: 0°F to 120°F (-18°C to +49°C)
• Relative humidity: 20-95% (not condensed)
• Air pressure: 700–1060 hPa
4 Dimensions and Technical Specifications
Note: Curve LTG treadmills have no drive motor. The display system is powered by an
enclosed generator.
Note: This equipment is not intended for use in damp locations.
An Optional Charging Cord is available through WOODWAY Parts/Service Department to help
keep the display charged in times of extended non-use. WOODWAY Part Number - 30-010175
Running Surface
Slats
Drive System
Overall Dimensions
Mass/Weight
Standard Display (Self Powered)
Power Requirements
Variable Resistance
16.6” X 61.8” (42.2 cm X 157.0 cm)
60 Rubber on plastic composite
98 Roller Bearings and 12 Guide Rollers
34” W X 74” L X 72” H (86 X 189 X 184 cm)
296.8 lbs. (134.6 kg)
Standard Display Board: Displays - Speed, Time, Energy,
Group/Circuit Mode, Lap, Heart Rate (When paired with
a smart device)
N/A (Optional Charging cord 12V, 1.5A)
N/A

08.30.23 OM-EN-V1 19
4.1 Curve LTG Model
4.2 Conditions for Use
5 Setup and Placement
5.1 General
Ensure that the conditions applicable to basic safety and health requirements are met, and that
Chapter 1 “Safety” has been read and understood.
Read owners manual instructions completely before installation.
Before using the unit, operational and functional safety systems are to be tested, including
correct installation and operator instructions.
Check immediately upon delivery for any signs of transportation damage and immediately
report any damages to the transport company and WOODWAY.
ParametersDescription
Ambient Temperature
Relative Humidity
Enclosure Rating
50F to 104(10C to 40C)
20-95% (not condensed)
IP2x
Installing after Storage or Transport
The formation of condensation on the cooled electronic parts may cause the
treadmill to malfunction and damage to the electronics.
• Before installing after storage or transport, the treadmill must stand at
room temperature for approximately 3 hours to become acclimated.
ATTENTION

08.30.23 OM-EN-V1
20
5.2 Preparation and Placement
Due to the heavy weight of the device, it is recommended to install the treadmill as close to its
final location as possible.
The following further instructions for installation are to be observed:
• When installed on upper floors, the device must be placed as far as possible in a corner
of the room so that sufficient stability is guaranteed. The structure of the building must be
checked in advance.
• The treadmill should not be installed close to a radiator or other heat source.
• Due to moving parts on the underside, the device must not be placed directly on thick or
high-pile carpeting. In this case, a mat should be placed under the device. This will
prevent lint from entering into the treadmill and at the same time reduce carpet wear.
• WOODWAY has appropriate mats available. For more information, call WOODWAY
customer service.
• With larger devices, particular attention must be paid to the ceiling/floor load capacity
at the installation site. This must be higher than the total weight (device weight plus the
dynamic weight of a running person) and approved by an authorized authority with the
treadmill representative.
Prepare a Stable Surface
Before the device is installed, the surface must be prepared. The total
weight of the device (with all the accessories and options) is to be
considered.
• Prepare a stable and sturdy surface.
• Only install the device on a level, stable, and sufficiently sturdy surface.
If necessary, install an additional base plate/floorboard.
ATTENTION
The WOODWAY Curve LTG fitness treadmill uses Metric screws, bolts and
nuts for fastening and assembly.
NOTICE
