WOPET Chimp 7L User manual

WOpet Chimp 7L Automatic Pet Feeder
INSTRUCTIONS
F04

【CONTENTS】
…………………………………………………………1
………………………………………………………………6
………………………………………………………………12
………………………………………………………………13
Feeder appearance
Feeder assembling
Function setting
……………………………………………………………11
Feeder cleaning
Important notes
FCC warnings
…………………………………………………………4

Please read these instructions carefully before use
Thank you for choosing this WOpet intelligent product. In order
to guarantee your personal and material safety, please read
these instructions carefully before using our product. Under no
circumstances shall WOPET be liable to pay compensation or
damages to any person for any loss, injury, or damage, unless it's
explicitly stipulated in law, whatsoever occasioned by this product
or as a result of not following the items and conditions and
precautions laid in these instructions.

Feeder appearance
Feeder specification
14.8inch
3.5inch
13.8inch
8.8inch 1
Desiccant Compartment
(Detachable & Desiccant Not Included）
2.75inch

2
Product name: WOpet Chimp 7L Automatic Pet Feeder
Product size: 14.8 X 13.8 X 8.8inch
Net weight: 2.9 KG
Barn reserves: 7L
Product materials: ABS
Adapter parameters: Input: 110-220V, 50/60HZ, 0.6A
Output: 5.0V, 2000mA

REC key
Feeding key
Schematic diagram of the key panel
3
SET key
Microphone
Up key
Down key

Feeder assembling
Connect the adapter
4
Power cord slot
Power switch
Power outlet
Battery compartment
As shown in the picture, place the power cord into the bottom
slot to prevent the feeder from losing power during movement.
Set the bottom power switch to "I".
You can also use batteries to ensure that the feeder can work
normally when there’s power outage. (3 new D cell, alkaline batteries.
BATTERIES NOT INCLUDED)

5
Put the feeder upside down, and align the two clasps on the
feeding tray with the slot on the base, and gently push it down
until it is firmly clamped in place. (Slide it upward to remove the tray)
Assemble the feeding tray
Assemble the food bucket
1
Align the four clips on the feeder inner wall with the four grooves
on the edge of the food bucket. (Disassemble it by puling it out)
1
Assemble the top cover
Rotate the top cover clockwise until it is locked. The top cover
can be lifted up by turning it counterclockwise.
1
Place the feeder upright, and put the stainless steel bowl in the tray.
2

Function setting
6
Power on
Set the current time
Plug-in the feeder, and check the bottom power switch is on.
1
Press the "set" key until the LCD backlight lights up, and release
it. It will now enter the setting mode, and the first digit of the
hour number starts to flash.
1
When the power is on, the green light flashes, which indicates
that the power is normal. (You can also use batteries in case
of power outage)
2
Press the "up" or "down" key to set the required number. After
this digit is set, press the "set" key to move the cursor to
enter the second digit of the hour number.
2

7
The setting of the minutes is the same as setting the hours.
3
Note: The machine uses a 24-hour clock system.

8
Set feeding schedule
The feeding setting includes the feeding amount and the feeding
time.
1
Press the "set" key to enter the feeding setting of the first meal.
At this time, the meal number labeled as the first meal "①" tarts
to flash.
2
Press the "up" or "down" key to set the “Copies”. This “Copies”
represents the servings of each meal.
3
After setting the number of servings, press the "set" key to move
the cursor to set the feeding time of the first meal. The setting
method is the same as setting the current time.
4
Note: The maximum number is 8.

9
After finishing setting the first meal, press the "set" key to
move the cursor to enter the settings of the second meal "②".
Follow the same steps as setting the first meal.
5
Repeat to set feeding schedules for the other meals.
6
Note: The set value will be saved after the LCD backlight goes
off, and the device will enter the lock screen state. If you
want to set it again, you need to press the "set" key to
unlock the device.

10
Cancel feeding schedule
Record
In the setting state, when there is no operation for more than
8 seconds, the LCD backlight will turn off and exit the setting.
1
Press and hold the "REC" key; when the alarm LED is on, it will
make one "beep" sound.
1
At this time, speak loudly to the device's microphone, and it
will input your voice.
2
Just release the "REC" key to stop, and the device will make
two "beep" sound to prompt the end of the recording.
3
Or long-press the "set" key and exit the setting after the LCD
backlight goes out.
2
Rotate the top cover clockwise until it is locked. The top cover
can be lifted up by turning it counterclockwise.
Note: If you want to cancel the feeding of a meal, you just
need to set the “Copies” number to 0.
Note: The recording time should not exceed 10 seconds. If
the recording is not good or needs to be re-recorded,
just press the "REC" key again to record.

11
Manual feeding
In the un-setting state (LCD backlight is off), press and hold
the "feeding" key for 3 seconds to feed. It will dispense one
serving each time.
1
Restore factory settings
In the setting state (LCD backlight is on), press and hold the
"REC" key for 3 seconds. All settings will be cleared, and the
feeder will be restored to factory settings and restart automatically.
1
Turn off the Feeder, unplug the power adapter, and take
out the batteries before cleaning.
1
The top cover, food bucket, and food plate can be disassembled
to clean. Please use clean water or a soft detergent to clean. After
cleaning, It is necessary to wait for the device to dry before use.
2
The base and the exterior parts of the feeder body can be
wiped with a dry cloth.
DO NOT PUT THEM INTO THE WATER FOR CLEANING.
3
Feeder cleaning

Important notes
12
Low power reminder: The red alarm light will flash when the
battery power is low. Please replace the battery in time for
normal use.
Only for indoor use. It is best to keep the feeder against a wall
to prevent the pet from knocking it down.
Please check whether there is enough food in the feeder and
add it when required.
If not going to use the feeder for a long time, please take out
the batteries to avoid any electrolyte leakage.
When the red alarm light is on constantly, the equipment has
malfunctioned. Please check the status of the feeder.

13
FCC warnings
WARNING:
Changes or modifications to this unit not expressly approved.
Non-compliance could void the user's authority to operate
the equipment.
NOTE:
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.

14
This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Shielded interface cables must be used with the equipment in order
to comply with the limits for a digital device pursuant to Subpart B
of Part 15 of FCC Rules. Specifications and designs are subject to
change without any notice or obligation on the part of the
manufacturer.
Reorient or relocate the receiving antenna.
Increase the distance between the equipment and receiver.
Connect the equipment into an outlet on a different circuit from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
