WOPET FT70 Plus User guide

QUICK OPERATION GUIDE
Castle Automatic Feeder
Model: FT70 & FT70 Plus

DISPLAY OVERVIEW:
Buzzer
Time Setting Icon
Indicator
Number Increase/ Decrease
Meal Number
Manual
Recording
Lock
Timing/Portions
Battery Level Icon
Setting/Save/Unlock
Return/Cancel
1

BUTTONS OVERVIEW:
NOTE: Will lock automatically after 2 min of inactivity. Hold for 2s to unlock.
Button Description
Set /Save
Unlock button
Return /
Cancel button
Number
Increase button
Number
Decrease button
Manual button
Recording button
Press to save and move to the next step.
Operable Mode Function
Press and hold for 2s to lock/unlock other buttons and screen.
Return to the previous step.
Return to interface after setting up.
Press to increase the value.
Press to decrease the value.
[Must be Unlocked] Press to feed 1 portion.
[Must be Unlocked] Hold for 3s and start recording after
a beep is heard {max 10s}.
Recoding saved after a double beep is heard.
2

SCREEN PANEL INTRODUCTION:
3
ICON Function of ICON
Lock Hold button for 2 seconds to unlock.
Locks automatically after 2 min of inactivity.
Clock indicator
Battery Level
Meal
Note: when flashing, press button to set up/ modify the
current time.
Flash Indicates:
Powered by adapter or battery.
Local time.
Timing
【24-hours format】
Number of meals.
Lights up when running on battery power.
Turns red to indicate low battery.

INSTRUCTION MANUAL:
4
Clock icon flashes when powered as shown in fig.(01).
[If Screen is Locked]
Press and hold for 2s to unlock screen as shown in fig.(02).
STEP 1 — Setting Current Time
Note:
00:00 00:03
fig.(01) fig.(02)
Example: 9:00AM = 9:00; 10:00PM = 22:00 More as below:
12-hour Clock 24-hour Clock Comparison Chart
00:00
(Midnight)
(Midnight)
(noon)
(End of the day)
00:00
(Beginning of the day)
01:00AM
02:00AM
03:00AM
04:00AM
05:00AM
06:00AM
07:00AM
08:00AM
09:00AM
10:00AM
11:00AM
12:00AM
01:00
01:00PM
02:00PM
03:00PM
04:00PM
05:00PM
06:00PM
07:00PM
08:00PM
09:00PM
10:00PM
11:00PM
12:00PM
13:00
02:00
14:00
03:00
15:00
04:00
16:00
05:00
17:00
06:00
18:00
07:00
19:00
08:00
20:00
09:00
21:00
10:00
22:00
11:00
23:00
12:00
24:00
TIP: Please note the conversion between 24-hour format and 12-hour format.
After setting hour, press to move
to set the “minute” of the time. press
to set the “minute”. Press
to save.
[ Must be Unlocked ]
Press to set the “hour”of the time.
The two hour digits flash, press
to set the “hour”.
STEP 1.1— HOUR SETTING
Note:
Press to modify if needed.
08:00
[ Must be Unlocked ]
STEP 1.2— MINUTE SETTING
08:30

Press to set the “hour”
of the time, Press
to set the “hour”. Press
to move to set the“ minute”
of the time. Press to
save.
5
Press then "1" flashes
to set up the first meal.
Press to modify if needed.
Note:
Press to set up portion
then press button to save.
STEP 2 —Setting Meal
STEP 2.1 STEP 2.2 STEP 2.3
Press to move to set other meals.
Repeat above step to set up meal
time and portion.
STEP 2.4
00:00 10:00 P-:02
11:00

7
Press to modify local time,
feeding time and portion if needed.
Press to return to interface when setting
up as shown in fig.(01).
(Numbers NOT displayed when portion set to 0
as shown in fig.(02)).
Press to return to interface when
setting up, press for 2s to lock the
screen, the lock icon will display.
(Note: Locks automatically after 2 min
of inactivity).
Lock:
STEP 3 —Return to Interface
STEP 4 — Locking & Unlocking
STEP 3.1 STEP 3.2
08:45 08:45 09:00
Press and hold for 2s to unlock the
screen, the lock icon will disappear.
Unlock:
09:05
fig.(01) fig.(02)
09:05

Hold for 3s and start recording after
a beep is heard (max 10s).
8
Press to feed 1 portion.
[ Must be Unlocked ]
STEP 5 —Recording
[ Must be Unlocked ]
Double beep indicates recording is saved.
STEP 6 —Manual Feed
09:25
09:30
Press and hold and at the
same time for 3s until a beep is heard.
[ Must be Unlocked ]
STEP 7 —Reset to Factory Default
09:30
