WURM DOC-XP User manual

DOC-XP
Measurement and monitoring module
for 4 temperatures
DOC-XP_V1.2_PI_2019-04_EN Subject to technical changes Page 1 of 4
Front view
Features
Individually selectable temperature sensor for each measuring point:
- TRK277, K243: measurement range -45…+65°C
- DGF: measurement range 0…+150°C
Alarm with alarm delay time for overtemperature or undertemperature
Avoiding false alarms (to deactivate monitoring, e.g. when defrosting or when cold locations are
switched off)
Collective alarm relay
Simple parameter settings
Plug-in screw terminals
Large data memory for temperature list
Connection to the Wurm system through a Wurm CAN communication bus (C-BUS) and
FRIGODATA XP

DOC-XP
Measurement and monitoring module
for 4 temperatures
Page 2 of 4 Subject to technical modifications DOC-XP_V1.2_PI_2019-04_EN
Writing conventions
Symbol
Meaning
CAUTION
Avoid the described hazard: otherwise minor or medium physical injury or
damage to property will result.
WARNING
Avoid the described hazard: otherwise there is danger from electric voltage
that could lead to death or serious physical injury.
For your safety
For safe operation and to avoid personal injury and equipment damage through operator error, always
read these instructions, become familiar with the device, and follow all safety instructions on the
product and in this document, as well as the safety guidelines of Wurm GmbH & Co. KG Elektronische
Systeme. Keep these instructions ready to hand for quick reference and pass them on with the device
if the product is sold.
Wurm GmbH & Co. KG Elektronische Systeme accepts no liability in case of improper use or use for
other than the intended purpose.
Target group
These instructions are intended for "service technicians".
Intended use
The DOC-XP is a measurement and monitoring module for 4 temperatures.
WARNING
Danger to life from electric shock and/or fire!
Switch off the power to the entire plant when
carrying out installation, wiring or removal
work. Otherwise a mains voltage and/or external voltage may still be present even if
the control voltage is switched off. Always remove both power plugs (L and N).
Only qualified electricians are permitted to wire the device.
Use only the correct tools for all work.
Check all wiring after connection.
Take note of the maximum loads on all connections.
Never expose the device to moisture, for example due to condensation or cleaning
agents.
Take the device out of operation if it is faulty or damaged and is therefore
compromising safe operation.
Do not open the device.
Do not attempt to repair the device yourself. If the device requires repairs, send it in
with an exact description of the fault.
Wurm Infocenter
paperless info
Software revisions and validity of documentation
Software version
V1.2
2019-04
Documentation status
Any software versions not listed are special solutions for individual projects and are not described in detail in this document.
This document automatically ceases to be valid if a new technical description is issued.
Manufacturer: Wurm GmbH & Co. KG Elektronische Systeme, Morsbachtalstraße 30, D-42857 Remscheid
For further information, see our website at www.wurm.de

DOC-XP
Measurement and monitoring module
for 4 temperatures
DOC-XP_V1.2_PI_2019-04_EN Subject to technical changes Page 3 of 4
Circuit diagram
C-BUS interface K1 = alarm relay
temperature sensor monitoring
Open = active
Closed = inactive
Installing and connecting
WARNING
Danger to life from electric shock and/or fire!
Switch off the power to the entire plant when carrying out installation, wiring or removal
work. Otherwise a mains voltage and/or external voltage may still be present even if the
control voltage is switched off. Always remove both power plugs (L and N).
This device is designed for top-hat rail
installation. The housing has standard
dimensions and is also suitable for installation in
fuse boxes and distribution cabinets.
The devices can be positioned next to one
another without gaps.
53
106
90
58

DOC-XP
Measurement and monitoring module
for 4 temperatures
Page 4 of 4 Subject to technical modifications DOC-XP_V1.2_PI_2019-04_EN
Place the device with the upper guide edge on
the top-hat rail.
Then press the device gently downward until it
engages with the fastening safety catch on the
top-hat rail.
For wiring of the data lines, we recommend the use of standard telephone lines 2x2x0.8ø up to
lengths of 100m. The shielding must be grounded in the control cabinet.
For cable lengths from 100m to 400m, shielded lines with braided sheathing should be used.
For sensor extensions, it is recommended that sheathed cable be laid.
Cable length
Cross section
Up to 100m
0.75mm²
Up to 400m
1.5mm²
Technical data
Power supply
230V~, +10% / -15%, approx. 5VA
Temperature sensor
4 x TRK277, DGF or K243
Digital inputs
4 x potential-free, monitoring inactive
Output relay
1 x alarm, changeover contact, 230V~, 4(2)A
Central unit
Single-chip microcomputer, data memory and quartz clock with
5000h power reserve
Monitoring system
Monitoring of connected sensors, self-monitoring of data memory
and microcomputer
Communication
3-wire CAN bus interface with integrated power supply,
galvanically isolated
Dimensions
(WxHxD) 106 x 90 x 58mm (DIN 43880)
Fastening
Top-hat rail TH 35-15 or TH 35-7.5 (DIN EN 60715)
Ambient temperature
Operation: 0...+55°C, storage: -25...+70°C
Weight
About 450g
CE conformity
−2014/30/EU (EMC Directive)
−2014/35/EU (Low Voltage Directive)
EAC conformity
−TR CU 004/2011
−TR CU 020/2011
RoHS II
Valid from
Version 1.2
NOTICE
You can find more information about the device in the Wurm Infocenter.
