Xerox DocuPrint N4525 User manual

XEROX
DOCUPRINT N4525
NETWORK LASER PRINTER
QUICK NETWORK INSTALL GUIDE

Xerox DocuPrint®N4525
Network Laser Printer
Quick Network Install Guide
721P56640
September 2000

© 2000 by Xerox Corporation. All rights reserved.
Copyright protection claimed includes all forms and matters of copyrightable material
and Information now allowed by statutory or judicial law or hereinafter granted,
including without limitation, material generated from the software programs which are
displayed on the screen such as styles, templates, icons, screen displays, looks, etc.
Xerox®, The Document Company®, the digitized X, Phaser®, and all Xerox products
mentioned in this publication are trademarks of Xerox Corporation®. Product and
trademarks of other companies are also acknowledged.
Changes are periodically made to this document. Changes, technical inaccuracies, and
typographic errors will be corrected in subsequent editions. Technical updates will be
included in subsequent editions.
Printed in the United States of America

Quick Network Install Guide iii
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Additional information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
How to use this document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Windows 95/98 Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Quick install steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Windows NT 4.x Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Quick install steps (Microsoft TCP/IP protocol) . . . . . . . . . . . . . . . . . . . . 6
Quick install steps (Xerox TCP/IP Port Monitor). . . . . . . . . . . . . . . . . . . . 8
Quick install steps (DLC/LLC protocol) . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Quick install steps (AppleTalk protocol) . . . . . . . . . . . . . . . . . . . . . . . . . 12
Windows 2000 Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Quick install steps (Microsoft TCP/IP protocol) . . . . . . . . . . . . . . . . . . . 14
Quick install steps (Xerox TCP/IP Port Monitor). . . . . . . . . . . . . . . . . . . 16
Quick install steps (DLC/LLC protocol) . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Quick install steps (AppleTalk protocol) . . . . . . . . . . . . . . . . . . . . . . . . . 21
Macintosh EtherTalk Network . . . . . . . . . . . . . . . . . . . . . . . . 23
Quick install steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Novell NetWare 3.1x, 4.1x, 5.x Networks. . . . . . . . . . . . . . . 24
Quick setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Advanced setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
UNIX Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Quick install steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

iv DocuPrint N4525 Network Laser Printer
Internet Printer Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Configure your web browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Appendix A: Print the Configuration Sheet. . . . . . . . . . . . . 30
For DocuPrint networked printers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Appendix B: Set an IP Address . . . . . . . . . . . . . . . . . . . . . . 31
For DocuPrint networked printers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Quick Network Install Guide 1
Introduction
The purpose of this document is to provide an experienced Systems
Administrator with information for setting up the DocuPrint N4525
printer on the various networks indicated.
Requirements
In general, the requirements needed for printer connection and setup
include:
■A workstation with the appropriate operating system software
installed for that station.
■A working knowledge of your network.
Additional information
Additional information may be found in on-line help and electronic
documentation supplied with your printer. This documentation may
include an Advanced Features and Troubleshooting Manual on the
DocuPrint N4525 printer software CD-ROM.

2DocuPrint N4525 Network Laser Printer
How to use this document
This document has been arranged to get the printer set up on your
network quickly and with minimum reading.
1. Review the Table of Contents.
2. Find the Network Operating Systems (NOS), which pertains to
your network.
3. Go to the page indicated and perform the procedure. The
procedure may point you to one or more of the Appendices
located in the back of this document.
4. Once these procedures are finished it is recommended you print a
Test Print.
5. Check the print job for print-quality. If print-quality problems
exist, use the Troubleshooting section of your printer’s Advanced
Features and Troubleshooting Manual to correct the problem.
DocuPrint printers come with an embedded web server. If you want to
monitor or administer your printer using your standard web browser
software, perform the procedures in the section entitled Internet
Printer Services.

Quick Network Install Guide 3
Windows 95/98 Network
Quick install steps
1. Insert your printer’s CD-ROM into your computer’s CD-ROM
drive. If your PC is set to autorun, a CD Navigator Utility should
automatically start. If it does not start, then:
a. Click Start and Run.
b. In the Run window, type: <CD drive>:\SETUP32.EXE.
2. Select your desired language from the available list.
Printer driver installation
3. Install the printer drivers for your printer. Within CD Navigator,
select Printer Drivers, and then select Install N4525 Printer
Drivers.
Note
The Xerox TCP/IP Port Monitor has not been installed yet. It
is necessary to temporarily install the printer drivers to an
alternate port. A local port, such as LPT1, is recommended.
4. Run the TCP/IP Port Monitor Setup program located on your
printer’s CD-ROM:
a. Click Start and Run.
b. In the Run window, type: <CD drive>:\instal\utility\Tcp Ip
Port Monitor\Windows 9x\<language>\setup.exe.
5. On the first dialog box, select Install/Upgrade Port Monitor and
click OK.
Port monitor installation
6. The installation process automatically copies the files to the
system directory. When this process is completed, a dialog box
appears that reads: The Xerox TCP/IP Port Monitor was
successfully installed. To add or remove ports, select the ports
tab in your printer properties.
7. Click OK.

4DocuPrint N4525 Network Laser Printer
Adding a port
8. To add a TCP/IP port, open the Printer Properties dialog box for
the printer you would like to attach the new TCP/IP port.
a. Click Start, scroll to Settings, and click Printers.
b. Click your right-mouse button on the printer to which you
want to attach the new TCP/IP port, and select Properties.
9. Select the Details tab, and click the Add Port button.
10. In the Add Port dialog box, select Other.
11. From the list of available printer port monitors, select the Xerox
TCP/IP Port, and then click the OK button.
12. At this point, you enter the Xerox TCP/IP Printer Port Wizard.
The wizard guides you step-by-step through the process of:
a. Choosing a name for the new port.
b. Identifying a printer by its DNS Name or IP Address.
c. (Alternatively) Identifying a printer using the automatic
Printer Discovery feature.
Click Next to proceed with the port installation.
13. The wizard verifies the port name and printer address, and
automatically configures the remaining port settings for you. Any
errors detected in printer identification displays a dialog box
requesting Additional Information.
In the Add Xerox TCP/IP Port window:
a. Under Enter a Port Name, enter a unique name for the port
being added.
b. Under Enter a printer name or IP address, enter the printer’s
host name or IP Address.
c. Click Next.
Note
To locate Xerox printers on your local area network, select
Auto Printer Discovery, and then click Refresh. The Xerox
TCP/IP Port Monitor searches the network for Xerox printers
and displays them in a list. Select your desired printer from
the list and click OK.

Quick Network Install Guide 5
14. After all the port settings have been configured and verified, a
Completing dialog box appears summarizing all of the settings.
You have the opportunity to change any of the settings by clicking
the Back key. Otherwise, click the Finish key to complete the port
setup.
15. Click OK to exit from Printer Properties. This completes the
installation of the Xerox TCP/IP Port.

6DocuPrint N4525 Network Laser Printer
Windows NT 4.x Network
Introduction
Your printer can be installed on a Windows NT network using one of
four methods:
■Microsoft TCP/IP protocol
■Xerox TCP/IP Port Monitor
■DLC/LLC protocol
■AppleTalk protocol
The Preliminary Steps given below must be accomplished for all
printers regardless of the method that is being used. Then, the Quick
Install Steps detail the installation process corresponding to the
method selected.
The CentreWare DP program on your Printer Management Software
CD-ROM can also be used to monitor and configure the printer.
Preliminary steps
1. Print the Configuration Sheet. Details are in this document in
Appendix A: Print the Configuration Sheet. Retain this page for
reference.
2. Check the Configuration Sheet and verify that both the desired
protocol and connector are enabled.
3. Proceed to the Quick Install Steps for the installation method
selected.
Quick install steps (Microsoft TCP/IP protocol)
1. At the Desktop, right-mouse-click the Network Neighborhood
icon and select Properties.
2. Click on the Protocols tab and verify that the TCP/IP protocol has
been loaded.
3. Select the Services tab and verify that Microsoft TCP/IP Printing
is loaded.

Quick Network Install Guide 7
4. If this software is not present, install it using the documentation
provided by Microsoft, and then return to this document.
5. Open the Control Panel and double-click the Printers icon.
6. Double-click Add Printer; the Add Printer Wizard starts.
7. Verify that My Computer is selected and click Next>.
8. Click Add Port.
9. From the list that appears, select LPR Port.
10. Click New Port. This opens up the Add LPR compatible printer
window.
11. Type the IP address of your printer and a printer name of up to 31
characters (no spaces).
12. Select OK. The Wizard returns you to the previous dialog. Verify
that the new IP address you entered is in the list and is correct.
The check box to the left of the address must be checked; if it is
not, check it, and then select Next>.
13. Insert your printer’s CD-ROM into your computer’s CD-ROM
drive and click Have Disk.
14. Click the Browse button and select the directory containing the
Windows NT drivers.
15. Select the *.INF file.
16. Click Open. The Wizard returns you to the previous dialog. Verify
that the path and filename are correct and click OK.
17. At the next dialog, enter a name for the printer and select whether
you want that printer to be the default. Click Next>.
18. If the printer is not shared, click Next>. To share the printer, enter
a Share Name, check the share checkbox, and then click Next>.
19. At the next dialog, it is recommended that you print a Test Print.
Click Finish.
20. Wait for the Test Print to print. A new dialog asks for
confirmation of the Test Print; click Yes.
21. Send a print job to the printer.
22. Check the print job for print-quality. If print-quality problems
exist, use the print-quality section of your printer’s Advanced
Features and Troubleshooting Manual to correct the problem.

8DocuPrint N4525 Network Laser Printer
23. If your print job did not print, see the Troubleshooting section for
your operating system in the Advanced Features and
Troubleshooting Manual to correct the problem.
Note
Printers connected to a Windows NT network with the
TCP/IP protocol enabled, can use a web browser to monitor
and configure your printer. Refer to the section in this
document entitled Internet Printer Services.
Note
For installing or managing multiple printers on a Windows
NT network with the TCP/IP protocol enabled, you can use
the Xerox CentreWare MC snap-in to Microsoft Management
Console. Refer to the Xerox CentreWare MC User Guide.
Quick install steps (Xerox TCP/IP Port Monitor)
1. Insert your printer’s CD-ROM into your computer’s CD-ROM
drive. A CD Navigator Utility should automatically start. If it does
not start, then:
a. Click Start and Run.
b. In the Run window, type: <CD drive>:\SETUP32.EXE.
2. Select your desired language from the available list.
Printer driver installation
3. Install the printer drivers for your printer. Within CD Navigator,
select Printer Drivers, and then select Install N4525 Printer
Drivers.
Note
The Xerox TCP/IP Port Monitor has not been installed yet. It
is necessary to temporarily install the printer drivers to an
alternate port. A local port, such as LPT1, is recommended.

Quick Network Install Guide 9
4. Run the TCP/IP Port Monitor Setup program located on your
printer’s CD-ROM:
a. Click Start and Run.
b. In the Run window, type: <CD drive>:\instal\utility\Tcp Ip
Port Monitor\Windows NT4\<language>\setup.exe.
5. On the first dialog box, select Install/Upgrade Port Monitor and
click OK.
Port monitor installation
6. The installation process automatically copies the files to the
system directory. When this process has been completed, a dialog
box appears that reads: The Xerox PCP/IP Port Monitor was
successfully installed. To add or remove ports, select the ports
tab in your printer properties.
7. Click OK.
Adding a port
8. To add a TCP/IP port, open the Printer Properties dialog box for
the printer you would like to attach the new TCP/IP port.
a. Click Start, scroll to Settings, and click Printers.
b. Click your right-mouse button on the printer to which you
want to attach the new TCP/IP port, and select Properties.
9. Select the Ports tab, and click the Add Ports button.
10. From the list of available printer port monitors, select the Xerox
TCP/IP Port, and then click the New Port button.
11. At this point, you enter the Xerox TCP/IP Printer Port Wizard.
The wizard guides you step-by-step through the process of:
a. Choosing a name for the new port.
b. Identifying a printer by its DNS Name or IP Address.
c. (Alternatively) Identifying a printer using the automatic
Printer Discovery feature.
Click Next to proceed with the port installation.
12. The wizard verifies the port name and printer address, and
automatically configures the remaining port settings for you. Any
errors detected in printer identification displays a dialog box
requesting Additional Information.

10 DocuPrint N4525 Network Laser Printer
In the Add Xerox TCP/IP Port window:
a. Under Enter a Port Name, enter a unique name for the port
being added.
b. Under Enter a printer name or IP address, enter the printer’s
host name or IP Address.
c. Click Next.
Note
To locate Xerox printers on your local area network, select
Auto Printer Discovery, and then click Refresh. The Xerox
TCP/IP Port Monitor searches the network for Xerox printers
and displays them in a list. Select your desired printer from
the list and click OK.
13. After all the port settings have been configured and verified, a
Completing dialog box appears summarizing all of the settings.
You have the opportunity to change any of the settings by clicking
the Back key. Otherwise, click the Finish key to complete the port
setup.
14. Click OK to exit from Printer Properties. This completes the
installation of the Xerox TCP/IP Port.
Quick install steps (DLC/LLC protocol)
1. At the Desktop, right-mouse-click the Network Neighborhood
icon and select Properties.
2. Click on the Protocols tab and verify that the DLC/LLC protocol
has been loaded.
3. If this software is not present, install it using the documentation
provided by Microsoft, and then return to this document.
4. Open the Control Panel and double-click the Printers icon.
5. Double-click Add Printer; the Add Printer Wizard starts.
6. Verify that My Computer is selected and click Next>.
7. Click Add Port.
8. Select the Hewlett-Packard Network Port in the Available Print
Monitors box and click OK.
9. Enter a unique name for the port to be used in the area provided.

Quick Network Install Guide 11
10. Choose the Port Address from the list of ports.
11. Click Timers and verify that the Job Based connection is selected,
and then click OK.
12. Click OK. The Wizard returns you to the previous dialog. Verify
the new port name you entered is in the list and correct. The
check box to the left of the port name must be checked if it is not,
check it, and then select Next>.
13. Insert your printer’s CD-ROM into your computer’s CD-ROM
drive and click Have Disk.
14. Click the Browse button and select the directory containing the
Windows NT drivers.
15. Select the *.INF file, then click Open.
16. The Wizard returns you to the previous dialog. Verify the path
and filename are correct and click OK.
17. At the next dialog, enter a name for the printer and select whether
you want that printer to be the default, and then click Next>.
18. If the printer is not shared, click Next>. To share the printer, enter
a Share Name, check the share checkbox, and then click Next>.
19. At the next dialog, it is recommended that you print a test page.
Click Finish.
20. Wait for the Test Print to print. A new dialog asks for
confirmation of the test print, click Yes.
21. Send a print job to the printer.
22. Check the print job for print-quality. If print-quality problems
exist, use the print quality section of your printer Advanced
Features and Troubleshooting Manual to correct the problem.
23. If your print job did not print, see the Troubleshooting section for
your operating system in the Advanced Features and
Troubleshooting Manual to correct the problem.

12 DocuPrint N4525 Network Laser Printer
Quick install steps (AppleTalk protocol)
1. At the Desktop, right-mouse-click the Network Neighborhood
icon and select Properties.
2. Click the Protocolstab and verify that the AppleTalk protocol has
been loaded.
3. If the AppleTalk software is not present, install it using the
documentation provided by Microsoft, and then return to this
document.
4. Open the Control Panel and double-click the Printers icon.
5. Double-click Add Printer; the Add Printer Wizard starts.
6. Verify that My Computer is selected and click Next>.
7. Click Add Port.
8. Select the AppleTalk Printing Devices and click New Port.
9. Click Ethernet and select the device.
10. Choose your printer device from the list, then click OK.
11. Click OK. The Wizard returns you to the previous dialog. Verify
that the port name you entered is in the list and is correct. The
check box to the left of the port name must be checked; if it is not,
check it, and then select Next>.
12. Insert your printer’s CD-ROM into your computer’s CD-ROM
drive and click Have Disk.
13. Click the Browse button and select the directory containing the
Windows NT drivers: <CD Drive>:\instal\winnt40, and then
click Open.
14. Select the *.INF file, then click OK.
15. The Wizard returns you to the previous dialog. Verify that the
path and file name are correct and click OK.
16. At the next dialog, enter a name for the printer and select whether
you want that printer to be the default, and then click Next>.
17. If the printer is not shared, click Next>. To share the printer, enter
a Share Name, check the share checkbox, and then click Next>.
18. At the next dialog it is recommended that you print a Test Print.
Click Finish.

Quick Network Install Guide 13
19. Wait for the Test Print to print. A new dialog asks for
confirmation of the Test Print; click Yes.
20. Send a print job to the printer.
21. Check the print job for print-quality. If print-quality problems
exist, use the print-quality section of your printer’s Advanced
Features and Troubleshooting Manual to correct the problem.
22. If your print job did not print, see the Troubleshooting section for
your operating system in the Advanced Features and
Troubleshooting Manual to correct the problem.

14 DocuPrint N4525 Network Laser Printer
Windows 2000 Network
Introduction
Your printer can be installed on a Windows 2000 network using one of
four methods:
■Microsoft TCP/IP protocol
■Xerox TCP/IP Port Monitor
■DLC/LLC protocol
■AppleTalk protocol
The Preliminary Steps given below must be accomplished for all
printers regardless of the method that is being used. Then, the Quick
Install Steps detail the installation process corresponding to the
method selected.
The CentreWare DP program on your Printer Management Software
CD-ROM can also be used to monitor and configure the printer.
Preliminary steps
1. Print the Configuration Sheet. Details are in this document in
Appendix A: Print the Configuration Sheet. Retain this page for
reference.
2. Check the Configuration Sheet and verify that both the desired
protocol and connector are enabled.
3. Proceed to the Quick Install Steps for the installation method
selected.
Quick install steps (Microsoft TCP/IP protocol)
1. At the Desktop, right-mouse-click the My Network Places icon
and select Properties.
2. Right-mouse-click the Local Area Connection icon inside the
Network and Dial-up Connections window. Select Properties.
3. Select the General tab and verify that Internet Protocol (TCP/IP)
is loaded.
