XAPP979 (v1.0) February 26, 2007 www.xilinx.com 1
© 2007 Xilinx, Inc. All rights reserved. All Xilinx trademarks, registered trademarks, patents, and further disclaimers are as listed at http://www.xilinx.com/legal.htm. PowerPC is
a trademark of IBM Inc. All other trademarks and registered trademarks are the property of their respective owners. All specifications are subject to change without notice.
NOTICE OF DISCLAIMER: Xilinx is providing this design, code, or information "as is." By providing the design, code, or information as one possible implementation of this feature,
application, or standard, Xilinx makes no representation that this implementation is free from any claims of infringement. You are responsible for obtaining any rights you may
require for your implementation. Xilinx expressly disclaims any warranty whatsoever with respect to the adequacy of the implementation, including but not limited to any warranties
or representations that this implementation is free from claims of infringement and any implied warranties of merchantability or fitness for a particular purpose.
Summary This application note describes how to build a reference system for the On-Chip Peripheral Bus
Inter IC (OPB IIC) core using the IBM PowerPC™ 405 Processor (PPC405) based embedded
system in the ML403 Embedded Development Platform. The reference system is Base System
Builder (BSB) based.
An IIC primer is given and an OPB IIC register reference is provided. The Xilinx Microprocessor
Debugger (XMD) commands are used for verifying that the OPB IIC core operates correctly.
Several software projects illustrate how to configure the OPB IIC core, set up interrupts, and do
read and write operations. Some of the software projects interface the OPB IIC to the
MicroChip 24LC04B serial EEPROM with an IIC interface, while others interface to the
TotalPhaseAardvark Adapter, whichprovidesIICmaster andslavefunctionality.The procedure
for using ChipScope™ to analyze OPB IIC functionality is provided. The steps used to build a
Linux kernel using MontaVista are listed. Simulation output files for analyzing basic IIC
transactions are provided.
Included
Systems This application note includes one reference system:
www.xilinx.com/bvdocs/appnotes/xapp979.zip
The project name used in xapp979.zip is ml403_ppc_opb_iic.
Required
Hardware/Tools Users must have the following tools, cables, peripherals, and licenses available and installed:
•Xilinx EDK 8.2.02i
•Xilinx ISE 8.2.03
•Xilinx Download Cable (Platform Cable USB or Parallel Cable IV)
•Monta Vista Linux v2.4 Development Kit
•Modeltech ModelSim v6.1d
•ChipScope v8.2
Application Note: Embedded Processing
XAPP979 (v1.0) February 26, 2007
Reference System: OPB IIC Using the
ML403 Evaluation Platform
Author: Paul Glover, Ed Meinelt, Lester Sanders
R

Introduction
XAPP979 (v1.0) February 26, 2007 www.xilinx.com 2
R
Introduction This application note accompanies a reference system built on the ML403 development board.
Figure 1 is a block diagram of the reference system.
The system uses the embedded PowerPC (PPC) as the microprocessor and the OPB IIC core.
IIC Primer
Figure 2 shows components on an IIC bus.Two IIC masters and three IIC slaves are shown.
The master is responsible for setting up transactions. This includes generating the clock on
SCL and defining which slave is involved in the communication, with an address field, and
which component is transmitting and which component is receiving. Some components are
slave only, while others can transition between master and slave operation.
Figure 3 shows the START and STOP conditions. A START condition is a falling edge on SDA
when SCL is high. A STOP condition is a rising edge on SDA when SCL is high. During data
transfer, the data line is stable on SDA when SCL is high. Data transitions on SDA when SCL
is low. Note that the START and STOP conditions are special conditions, violating the rule that
data cannot transition while SCL is high.
Figure 1: OPB IIC Reference System Block Diagram
Figure 2: IIC Bus
Figure 3: Start and Stop Conditions
PowerPC™
405 Processor
OPB
INTC OPB UART 16550
PLB
DDR PLB BRAM
OPB
IIC
OPB
PLB
X979_01_022307
S1S2
M1 M2
S3
X979_02_022307
SCL SDA
X979_03_022307
SDA
Start Stop
SCL

Introduction
XAPP979 (v1.0) February 26, 2007 www.xilinx.com 3
R
Figure 4 shows the format of the data transfer of two bytes on the IIC bus, beginning with the
START (S) condition and ending with the STOP (P) condition, bounded by an idle IIC (F) bus.
After a START condition, an eight bit field is transmitted containing a 7 bit address and a single
Read/Write (R/W) bit. This 8 bit address/direction field is followed by an Acknowledge bit. After
the address/data field, an eight bit data field is followed by an acknowledge bit (A). The last 8-
bit data field is followed by a not acknowledge bit (A). This is followed by the STOP condition
(P).
A single message can contain multiple start conditions, or a repeated start, without intervening
STOP conditions.
In this data transfer, there are two acknowledge bits and one Not Acknowledge on the IIC bus.
The distinction between a Not Acknowledge and a No Acknowledge is that Not Acknowledge
occursafter a master has read a bytefrom a slave and a NoAcknowledgeoccurs after a master
has written a byte to a slave.
A synchronized SCL is generated with its LOW period determined by the device with the
longest low period and its HIGH period determined by the device with the shortest HIGH
period.
Figure 5 shows the data transfer on the IIC bus, beginning with the START condition and
ending with the STOP condition.
Figure 4: Data Transfer on the IIC Bus
Figure 5: Generic Data Transer on the IIC Bus
SDA
Slave
Address
FAAR/WSPF
SCL X979_04_012907
DataDataA
12 127893- 89
Acknowledgment
signal from slave Acknowledgment
signal from receiver
Byte complete;
interrupt within slaveClock linesheld low while
interruptsare serviced
S
or
SR
Sr
or
P
P
Sr
X979_05_022307
START or
repeated START
condition
STOP or
repeated START
condition
MSB
SCL
SDA
ACKACK

Reference System Specifics
XAPP979 (v1.0) February 26, 2007 www.xilinx.com 4
R
Figure 6 shows the acknowledge bit on the IIC bus.
Figure 7 shows bus arbitration of two masters. The IIC bus is a multi-master bus. Masters
monitor the IIC bus to determine if the bus is active. The bus is inactive when SCL and SDA are
high for a bus free period tBUF of 1.3 us (FAST) or 4.7 us (STD). If two or more masters
monitoring the IIC bus determine that the bus is free and begin a bus transaction
simultaneously, the IIC bus is arbitrated to determine which master owns the bus. The IIC is a
wired AND bus. This means that the bus is HIGH unless any component is driving it LOW.
Masters monitor the bus even after they have started a transaction as the master. If a master is
not driving the IIC bus low and the bus is low, the master knows that another master is driving
the IIC bus. If a master cannot get the SDA or SCL to go high it loses arbitration. When a master
loses arbitration, it stops transmission. The master driving the bus with the last low when the
other master(s) drives high becomes the master of the bus.
Reference
System
Specifics
In addition to the PowerPC405 processor and OPB IIC, this system includes DDR and BRAM
memory on the PLB, and a UART and interrupt controller on the OPB. Figure 1 provides the
block diagram. Table 1 provides the address map of the ML403 XC4VFX12. This is in the
system.mhs.
Figure 6: Acknowledge on the IIC Bus
Figure 7: Arbitration of two Masters
12 89
Clock pulse for
acknowledgment
S
X979_06_012907
START
condition
Not acknowledge
Acknowledge
Dataoutput
by transmitter
Dataoutput
by receiver
SCL from
master
Master 1
Master 2
SDA
SCL
SX979_07_012907

Reference System Specifics
XAPP979 (v1.0) February 26, 2007 www.xilinx.com 5
R
ML403 XC4VFX12 Address Map
OPB IIC Registers
Table 2 provides the register map for the OPB IIC core.
Table 3 provides a description of the OPB IIC control register.
Table 1: ML403 XC4VSX12 System Address Map
Peripheral Instance Base Address High Address
PLB_DDR DDR_SDRAM_32Mx64 0x00000000 0x03FFFFFF
OPB UART16550 RS232_Uart_1 0x40400000 0x4040FFFF
OPB INTC opb_intc_0 0x41200000 0x4120FFFF
PLB BRAM plb_bram_if_cntlr_0 0xFFFF8000 0xFFFFFFFF
OPB IIC IIC_EEPROM 0x40800000 0x4080FFFF
Table 2: OPB IIC Registers
Register Address
Device Global Interrupt Enable C_BASEADDR + 0x01C
Interrupt Status Register C_BASEADDR + 0x020
Interrupt Enable Register C_BASEADDR + 0x028
Software Reset Register C_BASEADDR + 0x040
Control Register C_BASEADDR + 0x100
Status Register C_BASEADDR + 0x104
Transmit FIFO C_BASEADDR + 0x108
Receive FIFO C_BASEADDR + 0x10C
Slave Address Register C_BASEADDR + 0x110
Transmit FIFO Occupancy C_BASEADDR + 0x114
Receive FIFO Occupancy C_BASEADDR + 0x118
Ten Bit Slave Address Register C_BASEADDR + 0x11C
Receive FIFO Programmable Depth Interrupt Register C_BASEADDR + 0x120
General Purpose Output C_BASEADDR + 0x124
Table 3: OPB IIC Control Register
Bit(s) Name Description
0- 24 Reserved Reserved.
25 GC_EN General Call Enable. Setting this bit High allows the OPB IIC to respond to a
general call address.
26 RSTA
Repeated Start. Writing a “1” to this bit generates a repeated START condition
on the bus if the OPB IIC Bus Interface is the current bus Master. Attempting a
repeatedSTARTatthewrongtime,if the bus is ownedby another Master, results
in a loss of arbitration. This bit is reset when the repeated start occurs. This bit
must be set prior to writing the new address to the Tx FIFO or DTR.

Reference System Specifics
XAPP979 (v1.0) February 26, 2007 www.xilinx.com 6
R
Status Register (SR)
This register contains the status of the OPB IIC Bus Interface. All bits are cleared upon reset.
Table 4 provides a definition of the status register.
27 TXAK
Transmit AcknowledgeEnable. Thisbit specifiesthe valuedrivenontothe SDA
line during acknowledge cycles for both Master and Slave receivers.
Because Master receivers indicate the end of data reception by not
acknowledging the last byte of the transfer, this bit is used to end a Master
receiver transfer. As a slave, this bit must be set prior to receiving the byte to no
acknowledge.
28 TX
Transmit/Receive Mode Select. This bit selects the direction of Master/Slave
transfers. This bit does not control the Read/Write bit that is sent on the bus with
the address. The Read/Write bit that is sent with an address must be the LSB of
the address written into the transmit FIFO.
29 MSMS
Master/Slave Mode Select. When this bit is changed from 0 to 1, the OPB IIC
Bus Interface generates a START condition in Master mode. When this bit is
cleared, a STOP condition is generated and the OPB IIC Bus Interface switches
to Slave mode. When this bit is cleared by the hardware, because arbitration for
the bus has been lost, a STOP condition is not generated.
30 Tx FIFO
Reset Transmit FIFO Reset.This bit must be set if arbitration is lost or if a transmit error
occurs to flush the FIFO.
31 EN OPB IIC Enable. This bit must be set before any other CR bits have any effect.
Table 4: Status Register Bit Definitions
Bit(s) Name Description
0 - 23 N/A Reserved.
24 Tx_FIFO_
Empty Transmit FIFO empty. This bit is set High when the transmit FIFO is empty.
25 Rc_FIFO_
Empty Receive FIFO empty. Thisis set High when the receiveFIFO is empty.
26 Rc_FIFO_
Full Receive FIFO full. This bit is set High when the receive FIFO is full. This bit is set only when all sixteen locations in the FIFO are full,
regardless of the value written into Rc_FIFO_PIRQ.
27 Tx_FIFO_F
ull Transmit FIFO full. This bit is set High when the transmit FIFO is full.
28 SRW Slave Read/Write. WhentheIIC Bus Interfacehas been addressedas
a Slave (AAS is set), this bit indicates the value of the read/write bit
sent by the Master. This bit is only valid when a complete transfer has
occurred and no other transfers have been initiated. A “1” indicates
Master reading from Slave. A “0” indicates Master writing to Slave.
29 BB Bus Busy. This bit indicates the status of the IIC bus. This bit is set
when a START condition is detected and cleared when a STOP
condition is detected.
Table 3: OPB IIC Control Register (Contd)
Bit(s) Name Description

Reference System Specifics
XAPP979 (v1.0) February 26, 2007 www.xilinx.com 7
R
Table 5 provides a register description of the Interrupt Status register.
30 AAS Addressed as Slave. When the address on the IIC bus matches the
Slave address in the Address Register (ADR), the IIC Bus Interface is
being addressed as a Slave and switches to Slave mode. If 10-bit
addressing is selected this device will only respond to a 10-bit address
or general call if enabled. This bit is cleared when a stop condition is
detected or a repeated start occurs.
31 ABGC Addressed By a General Call. This bit is set high when another
master has issued a general call and the general call enable bit is set
high, CR(1) = ’1’.
Table 5: Interrupt Status Register
Bit Name Description
24 TFHE Transmit FIFO Half Empty
25 NAAS Not Addressed as Slave
26 AAS Addressed as Slave
27 BNB Bus is not Busy
28 RFF Receive FiFO Full
29 TFE Transmit FIFO Empty
30 TE/STC Transmit Error/Slave Transmit Complete
31 AL Arbitration Lost
Table 4: Status Register Bit Definitions (Contd)
Bit(s) Name Description

Reference System Specifics
XAPP979 (v1.0) February 26, 2007 www.xilinx.com 8
R
Configuring the OPB IIC Core
Figure 8 shows how to specify the values of IIC generics in EDK. To access the dialog box in
the figure, double click on the OPB IIC core in the EDK System Assembly View..
Microchip 24LC04
The Microchip Technology 24LC04B-I/ST with 4-KB EEPROM is provided on the ML403 board
to store non-volatile data. The EEPROM write protect is tied off on the board to disable its
hardware write protect. The IIC bus is extended to the expansion connector to allow additional
devices to be added to the IIC bus.
Figure 9 shows IIC Bus Devices on the ML403.
Figure 9: ML403 IIC Bus
The 24LC04 is organized as two blocks of 256 bytes. It has a page write buffer of up to 16
bytes. The 24LC04 operates as an IIC slave. The 24LC04 accepts a control byte which
contains control code, block select, and Read/Write fields shown in Figure 10. The control code
Figure 8: Specifying the Values of OPB IIC Generics in EDK
X979_08_012907
XC4VSX12
FPGA Microchip
24LC04B
I/O
Expansion
Header
X979_09_022307
SCL
SDA

ML403 Board Information
XAPP979 (v1.0) February 26, 2007 www.xilinx.com 9
R
is ‘1010 for read and write operations. The A2, A1 bits are dont cares. The A0 bit is used by the
master device to select which of the two 256-word blocks of memory are accessed. The
24LC04 write transactions are either a byte write or a page write. The page write begins the
same as the byte write but instead of generating a stop condition the master transmits up to 16
data bytes to the 24LC04B. The 24LC04 supports current address, random, and sequential
read operations.
ML403 Board
Information According to the MicroChip 24L024B data sheet, the ML403 board has a low-level output
current (IOL) of 3.0 mA at a VCC of 2.5v. The ML403 boards are shipped in the configuration
shown in Figure 11. The board must be modified for this design to work correctly. Replace the
10K Ohm R70 and R71resistors with 833 or 1K Ohm resistors. See Answer Record 24049 for
additional information.
Figure 10: 24LC04 Control Byte Allocation
Slave
Address
AR/W
S
A01
X979_10_012907
010A2A1
Figure 11: ML40x Schematic for IIC Connections
24LC04B - I / ST
VCC2V5
IIC_SCL
IIC_SDA
A0
A1
A2
A3
VCC
WP
SCL
SDA
TSSOPSU9
1
2
3
4
8
7
6
5
R71
10k
R70
10k
C280
0.1 µF
1
2
1
2
X979_11_022307

ML403 Board Information
XAPP979 (v1.0) February 26, 2007 www.xilinx.com 10
R
The resistors are located on the board as shown in Figure 12.
Figure 12: ML40x Resistors
X979_12_022307

ML403 Board Information
XAPP979 (v1.0) February 26, 2007 www.xilinx.com 11
R
If additional IIC devices are connected to the bus via the expansion header as shown in
Figure 13, insert additional pull-up resistors on the external signals connected at pins 31 and
32. The resistor values are dependent on the voltage.
Figure 13: Expansion Header
NC
FPGA_PROM_CPLD_TMS
FPGA_PROM_CPLD_TCK
EXPANSION_TDO
CPLD_TDO
GPIO_LED_N
GPIO_SW_N
GPIO_LED_C
GPIO_SW_C
GPIO_LED_W
GPIO_SW_W
GPIO_LED_S
GPIO_SW_S
GPIO_LED_E
GPIO_SW_E
GPIO_LED_0
GPIO_LED_1
GPIO_LED_2
GPIO_LED_3
NC
NC
10
11
12
13
14
15
16
17
18
1
2
3
4
5
6
7
8
9
19
20
21
22
23
24
25
26
27
28
29
30
31
32
IIC_SCL
VCC2V5
Level
Translation
MOSFETs
External pullups
connect here Internal pullups
connect here
IIC_SDA
NC
HDR 1 X 32
J3
X979_13_01
2

ML403 Board Information
XAPP979 (v1.0) February 26, 2007 www.xilinx.com 12
R
Figure 14 shows the FPGA pins driving the IIC Bus.
TotalPhase Aardvark Adapter
In the reference design, the OPB IIC in the XC4VFX12 on the ML403 board interfaces to the IIC
in the Aardvark Adapter. The Aardvark IIC/SPI Embedded Systems interface is a multi-
functional host adapter. The Aardvark Control Center software interacts with the Aardvark
Adapter. The Control Center controls the functionality of the Aardvark Adapter. It uses the
Aardvark IIC/SPI Software API. the Aardvark Adapter has six functional modes. The IIC-related
modes are the IIC + SPI and IIC Bus Monitoring modes.
The Aardvark must be configured for use before the Aardvark Control Center software can be
used to send and receive messages. Configuring the Aardvark Adapter binds the instance of
the application with the available unit until the adapter is disconnected or the application is
terminated.
The Configure Aardvark Adapter window is organized into two major sections: list of available
adapters connected to the computer and list of the six operational modes. The main application
window is divided into two sections. The top section contains the modules used with the
Aardvark Adapter. The bottom section contains the transaction log which tracks all transactions
that the Aardvark sends or receives. The transaction log contains the time, read or write
transaction, master or slave, bit rate, address, number of bytes, and data.
Figure 14: FPGA IIC Pins
SMA_DIFF_CLK_IN_N
SMA_DIFF_CLK_IN_P
IIC_SCL
IIC_SDA
DDR_CLK1_N
DDR_CLK1_P
DDR_A13
DDR_BA1
DDR_BA0
DDR_CLK_P
MOUSE_DATA
PHY_TXCLK
C12
C13
A17
B17
B10
A10
A15
A16
B12
B13
C14
C15 GPIO_LED_2
GPIO_LED_3
MOUSE_CLK
PHY_RXC_RXCLK
A11
A12
B14
B15
IO_L8N_GC_LC_3_C12
IO_L8P_GC_LC_3_C13
IO_L7N_GC_LC_3_A17
IO_L6N_GC_LC_3_B10
IO_L7P_GC_LC_3_B17
IO_L6P_GC_LC_3_A10
IO_L5N_GC_LC_3_A15
IO_L5P_GC_LC_3_A16
IO_L4N_GC_VREF_LC_3_B12
IO_L4P_GC_LC_3_B13
IO_L3N_GC_LC_3_C14
IO_L3P_GC_LC_3_C15
IO_L2N_GC_VRP_LC_3_A11
IO_L2P_GC_VRN_LC_3_A12
IO_L1P_GC_CC_LC_3_B14
IO_L1P_GC_CC_LC_3_B15
FPGA_BANK3
2.5 VCC0 X979_14_012907

ML403 Board Information
XAPP979 (v1.0) February 26, 2007 www.xilinx.com 13
R
Figure 15 shows the Aardvark Control Center GUI.
Interfacing to the OPB IIC on the ML403 Board to the Aardvark
Adapter
Figure 16 shows the principle interface blocks when transferring data between the OPB IIC in
the XC4VFX12 on the ML403 board and the IIC in the Aardvark Adapter.
Executing the Reference System using the Pre-Built Bitstream and the
Compiled Software Applications
To execute the system using files inside the ml403_ppc_opb_IIC/ready_for_download
directory, follow these steps:
1. Change to the ml403_ppc_opb_IIC/ready_for_download directory.
2. Use iMPACT to download the bitstream by using the following:
impact -batch xapp.cmd
Figure 15: Aardvark Control Center
Figure 16: Interfacing ML403 Board OPB IIC with the Aardvark Adapter
X979_15_012907
DDR
PPC
USB
OPB IIC
BRAM
ML403- XCVFX12
X979_16_012907
Aardvark
Adaptor
PC

ML403 Board Information
XAPP979 (v1.0) February 26, 2007 www.xilinx.com 14
R
3. Invoke XMD and connect to the MicroBlaze processor by the following command:
xmd -opt xapp.opt
4. Download the executable by the following command
dow <path>/executable.elf
Executing the Reference System from EDK
To execute the system using EDK, follow these steps:
1. Open system.xmp inside EDK.
2. Use Hardware →Generate Bitstream to generate a bitstream
3. Download the bitstream to the board using Device Configuration →Download
Bitstream.
4. Invoke XMD with Debug Launch XMD.
5. Download the executable by the following command.
dow <path>/executable.elf
Verifying the Reference Design with Xilinx Microprocessor Debugger
After downloading the bitstream file, issue the following XMD commands to verify that the
ML403 reference design is set up correctly.
mrd 0x42600100 8
The expected value of the control register after a reset, located at 0x42600100 is 0x00000000.
The expected value of the status register, located at 0x42600104, is 0x000000C0. The reset
values of the Transmit and Receive FIFO registers are indeterminate. The reset values of the
Transmit and Receive FIFO Occupancy and the Address registers is 0.
Except for the Status, , Receive FIFO, and Transmit and Receive Occupancy registers, all
registers are writeable.
mwr 0x42600100 0xFFFFFFFF
mrd 0x42600100 1
Using XMD commands, verify that the OPB IIC registers can be written and read as defined in
Tables 2-5.
Software Projects
The reference system contains the following software projects. In each software project
directory, there is a src sub-directory for the source code. The connections in Figure 9 are
used for the eeprom, low_level_eeprom, dynamic_eeprom, and low_level_dynamic_eeprom
projects. These projects interface to the 24LC04. The connections in Figure 3 are used for the
mult_master and repeated_start project. These projects interface to the IIC Bus via the
Aardvark Adapter.
Projects interfacing to Microchip 24LC04
eeprom: This project transmits and receives data using the high level (L1) software driver. The
OPB IIC is the master and the 24LC04 is configured as the slave. The OPB IIC master writes
data into the 24LC04 and reads it back.
low_level_eeprom: This project transmits and receives data using the low level (L0) software
driver. The OPB IIC is the master and the 24LC04 is configured as the slave. The OPB IIC
master writes data into the 24LC04 and reads it back. This is a polled mode example.
dynamic_eeprom: This project transmits and receives data using the high level (L1) software
driver. The OPB IIC is the master and the 24LC04 is configured as the slave. The OPB IIC
master writes data into the 24LC04 and reads it back.

ML403 Board Information
XAPP979 (v1.0) February 26, 2007 www.xilinx.com 15
R
low_level_dynamic_eeprom: This project transmits and receives data using the low level (L0)
software driver. The OPB IIC is the master and the 24LC04 is configured as the slave. The OPB
IIC master writes data into the 24LC04 and reads it back. This is a polled mode example.c
Projects interfacing to Aardvark Adapter
multi_master: This project transmits and receives data using the high level (L1) software
driver. The OPB IIC is an IIC master and the IIC in the Aardvark is a master. The Microchip
24LC04B is configured as a IIC slave. The WP pin of the 24LCO4 is hardwired to ground on the
ML403. The interrupt mode is used. The IIC master in the Aardvark Adapter writes the data to
the MicroChip 24LC04B with the No Stop option enabled. Any attempts to write data from the
OPB IIC master results in a Bus Busy status. The Aardvark Adapter releases the bus by
executing the FREE BUS command. When the bus is free, the OPB IIC master initiates a bus
transaction.
repeated_start: This project transmits and receives the data using the high level (L1) driver.
The IIC devices on the ML300/ML310/ML410 boards do not support the repeated start option.
The ML403 OPB IIC is configured as a master and the Aardvark Adapter IIC is configured as a
IIC slave. The OPB IIC writes the data to the Aardvark IIC in multiple transactions with the
repeated start option enabled. The external IIC device slave address is a 7 bit address defined
by SLAVE_ADDRESS. The number of bytes sent and received is defined by SEND_COUNT
and RECEIVE_COUNT.
Figure 17 shows the repeated start example.
Specify 0x70 as the Address. The SPI Control is not used. The transaction log shows 16 write
and 16 read transactions at address 70.
slave: This project transmits and receives the data using the high level (L1) driver. The ML403
OPB IIC is configured as a slave and the Aardvark Adapter IIC is configured as a IIC master.
The Aardvark Adapter IIC writes the data in test_data to the OPB IIC and reads it back.
Figure 17: Repeated Start Example
X979_17_012907

Running the Applications
XAPP979 (v1.0) February 26, 2007 www.xilinx.com 16
R
Figure 18 shows the slave example. The message is in transmit.txt, and is the sentence "Lester
was here.". The transaction log matches the message. The address is 0x70. Click Master
Write to generate the transaction.
Running the
Applications In XPS, select the Applications tab under the Project Information Area to view the Software
Project.
Figure 19 shows the structure of the dynamic_eeprom project. Make the dynamic_eeprom
project active and the remaining software projects inactive.
Figure 18: Slave Example X979 18012907
Figure 19: Selecting the eeprom Software Project X979_19_012907

Running the Applications
XAPP979 (v1.0) February 26, 2007 www.xilinx.com 17
R
Select dynamic_eeprom and right click to build the project. If more than one software project
is used, make the unused software projects inactive.
Connect a serial cable to the RS232C port on the ML403 board. Start up a HyperTerminal. Set
Bits per second to 9600, Data bits to 8, Parity to None, and Flow Control to None, as shown in
Figure 20.
From XPS, start XMD and enter rst. Invoke GDB and select Run to start the application as
shownin Figure 21.The eeprom.c code writtenfortheML403shown inthe figure runswithout
any modifications on this reference system.
Figure 20: HyperTerminal Parameters
Figure 21: Running dynamic_eeprom in GDB
X979_20_012907
X979_21_012907

Using ChipScope with OPB IIC
XAPP979 (v1.0) February 26, 2007 www.xilinx.com 18
R
Using
ChipScope with
OPB IIC
To facilitate the use of ChipScope to analyze OPB IIC hardware, the iic.cdc file is included in
the ml403_ppc_opb_iic/chipscope directory. The iic.cdc is used to insert a
ChipScope ILA core into the opb_iic core. The following steps are used to insert a core and
analyze OPB IIC problems with ChipScope.
1. Invoke XPS. Run Hardware →Generate Netlist.
2. In the iic.cdc file, change the path <design_directory> name to the directory in which
the design files are installed. Three paths need to be changed.
3. Run Start →Programs →ChipScope Pro →ChipScope Inserter
4. From ChipScope Inserter, run File →Open Project ii.cdc.Figure 22 shows the ChipScope
Inserter setup GUI.
Figure 22: ChipScope Inserter Setup X979_22_012907

Using ChipScope with OPB IIC
XAPP979 (v1.0) February 26, 2007 www.xilinx.com 19
R
5. Figure 23 shows the GUI for making net connections. Click Next to move to the Modify
Connections window. If there are any red data or trigger signals, correct them. The Filter
Pattern can be used to find net(s). As an example of using the Filter Pattern, enter intr in the
dialog box to locate interrupt signals. In the Net Selections area, select either Clock,Trigger,
or Data Signals. Select the net and click Make Connections.
7. Click Insert Core to insert the core into iic_eeprom_wrapper.ngo. In the
ml403_ppc_opb_IIC/implementation directory, copy iic_eeprom_wrapper.ngo to
iic_eeprom_wrapper.ngc.
8. In XPS, run Hardware →Generate Bitstream and Device Configuration →Download
Bitstream. Do not rerun Hardware →Generate Netlist, as this overwrites the
implementation/iic_eeprom_wrapper.ngc produced by the step above. Verify that the
file size of the opb_iic_wrapper.ngc with the inserted core is significantly larger than the
original version.
9. Invoke ChipScope Pro Core Analyzer by selecting
Start →Programs →ChipScope Pro →ChipScope Pro Analyzer
Click on the JTAG chain icon located at the top left of Analyzer GUI. Verify that the message in
the transcript window indicates that an ChipScope ICON is found.
10. The ChipScope Analyzer waveform viewer displays signals named DATA*. To replace the
DATA* signal names with the signal names specified in ChipScope Inserter, select File →
Import and enter iic.cdc in the dialog box.
Figure 23: Making Net Connections in ChipScope Inserter
X979_23_012907

Using ChipScope with OPB IIC
XAPP979 (v1.0) February 26, 2007 www.xilinx.com 20
R
The waveform viewer is more readable when buses rather than discrete signals are displayed.
The Reverse Bus Order operation below Add to Bus in the figure can be useful in analyzing
ChipScope results.
11. Set the trigger in the Trigger Setup window. The trigger used depends on the problem being
debugged.Change theWindows to N samples to a settingof 100. Armthe triggerbyselecting
Trigger Setup →Arm, or clicking on the Arm icon.
As shown in Figure 24, the trigger setup is to trigger when gen_start is High.
12. Run XMD and/or GDB to activate the trigger patterns which cause ChipScope to display
meaningful output.
Figure 24: Setting Up the Chipscope Trigger
X979_24_022307
