XTAG-2 Hardware Manual
Version 1.0
Publication Date: 2009/09/23
Copyright © 2009 XMOS Ltd. All Rights Reserved.

XTAG-2 Hardware Manual (1.0) 2/8
1 Introduction
The XTAG-2 debug adapter converts between an XMOS XSYS connector and USB 2.0,
providing pins for JTAG control, system reset, processor debug, one duplex UART
link and one duplex serial XMOS Link. The XTAG-2 debug adapter can be used to
connect XMOS development kits to most PCs, and provide a 5V power supply.
The diagram below shows the layout of the components on the card.
XS1-L1
LQ64
20-way
IDC XSYS
Connector
Standard-A type
USB Connector
USB Transceiver
To debug a board with the XTAG-2 you must use the XMOS Design Tools version 9.9
or later, available from the XMOS web site.
2 XS1-L1 Device
The XTAG-2 is based on a single XS1-L1 device in a 64LQFP package. The XS1-L1
consists of a single XCore, which comprises an event-driven multi-threaded processor
with tightly integrated general purpose I/O pins and 64 KBytes of on-chip RAM. The
pins are brought out of the package and connected to the card’s components as
follows:
•USB Connector
•XSYS 20-way IDC header (female)
The processor has ports that are directly connected to the I/O pins.
www.xmos.com

XTAG-2 Hardware Manual (1.0) 3/8
3 USB Connector
The XTAG-2 uses a Standard-A type USB connector to link to a PC.
Standard-A type
USB Connector
USB Transceiver (USB3318)
The USB connector is connected to an SMSC USB3318 high-speed transceiver using
a ULPI interface. The I/O pins for the USB transceiver are mapped to ports on the
processor as described in the tables below.
Pin Port Processor
4bit 8bit
XD12 P1E0 ULPI_STP
XD13 P1F0 ULPI_NXT
XD14 P4C0 P8B0
ULPI_DATA[0:7]
XD15 P4C1 P8B1
XD16 P4d0 P8B2
XD17 P4D1 P8B3
XD18 P4D2 P8B4
XD19 P4D3 P8B5
XD20 P4C2 P8B6
XD21 P4C3 P8B7
XD22 P1G0 ULPI_DIR
XD23 P1H0 ULPI_CLK
Each pin can be configured either as a 4-bit port or an 8-bit port. The configuration
is determined by the set of port initialisers used in the software.
The reset pin on the USB transceiver is mapped to a 1-bit port on the processor as
described below:
Pin Port Processor
XD24 P1I0 PHY_RST_N
www.xmos.com

XTAG-2 Hardware Manual (1.0) 4/8
4 XSYS Connector
The XTAG-2 includes an XSYS 20-way IDC header, which can be used to connect it to
an XMOS development board for debugging programs on the hardware.
The XSYS connector provides pins for JTAG control, system reset, processor debug, a
duplex UART link and a 2-bit serial XMOS Link.
Pin Signal Direction Description
1 5V Target to Host Power
2 NC N/A No connection
3 TRST_N Host to Target JTAG Test Reset - Active Low
4 GND N/A Ground
5 TDSRC Host to Target JTAG Test Data
6 XL1_UP1 Target to Host XMOS Link
7 TMS Host to Target JTAG Test Mode Select
8 GND N/A Ground
9 TCK Host to Target JTAG Test Clock
10 XL1_UP0 Target to Host XMOS Link
11 DEBUG Bidirectional Debug
12 GND N/A Ground
13 TDSNK Target to Host JTAG Test Data
14 XL1_DN0 Host to Target XMOS Link
15 RST_N Host to Target System Reset - Active Low.
16 GND N/A Ground
17 UART_RX Host to Target Serial Port
18 XL1_DN1 Host to Target XMOS Link
19 UART_TX Target to Host Serial Port
20 GND N/A Ground
The routing of these I/O pins along with the power pins is shown on the following
page.
www.xmos.com

XTAG-2 Hardware Manual (1.0) 5/8
5V
TRST_N
TDSRC
TMS
TCK
DEBUG
TDSNK
RST_N
UART_RX
UART_TX
1 2
19 20
NC
GND
XL1_UP1
GND
XL1_UP0
GND
XL1_DN0
GND
XL1_DN1
GND
4.1 UART configuration
No UART hardware is provided. Instead, the UART is implemented in software by
mapping the two UART pins to ports on the XS1-L device. The XTAG-2 performs a
UART-to-USB conversion on these pins.
UART_RX
UART_TX
The table below shows the pin-to-port mapping.
Pin Port Processor
1bit 4bit
XD25 P1J0 UART_RX
XD26 P4E0 UART_TX
www.xmos.com

XTAG-2 Hardware Manual (1.0) 6/8
4.2 XMOS Link Configuration
Some of the I/O pins on the processor are configured as a duplex 2-bit serial XMOS
Link. The mapping of XMOS Link to the pins is shown in the table below:
Pin XMOS Link
XD4 XL1_UP1
XD5 XL1_UP0
XD6 XL1_DN0
XD7 XL1_DN1
4.3 JTAG Configuration
Some of the I/O pins on the processor are driven by the JTAG signals. The mapping
of the signals to the pins is shown in the table below:
Pin Port Processor
XD0 P1A0 TDSRC
XD1 P1B0 TDSNK
XD10 P1C0 TMS
XD11 P1D0 TCK
XD35 P1L0 TRST_N
4.4 System Reset
The system reset signal is mapped to a 1-bit port on the processor as described
below. It is used as an output to reset the target processor from the debugger
Pin Port Processor
XD36 P1IM RST_N
5 13MHz Crystal Oscillator
The XS1-L1 is clocked at 13MHz by a crystal oscillator on the card. The processor is
clocked at 400MHz and the I/O ports at 100MHz, by an on-chip phaselocked loop
(PLL).
www.xmos.com

XTAG-2 Hardware Manual (1.0) 7/8
6 I/O Port-to-Pin Mapping
The table below provides a full description of the port-to-pin mappings described
throughout this document.
Pin Port Processor
1b 4b 8b
X0D0 P1A0 TDSRC
X0D1 P1B0 TDSNK
X0D2 P4A0 P8A0
X0D3 P4A1 P8A1
X0D4 P4B0 P8A2 XL1_UP1
X0D5 P4B1 P8A3 XL1_UP0
X0D6 P4B2 P8A4 XL1_DN0
X0D7 P4B3 P8A5 XL1_DN1
X0D8 P4A2 P8A6
X0D9 P4A3 P8A7
X0D10 P1C0 TMS
X0D11 P1D0 TCK
X0D12 P1E0 ULPI_STP
X0D13 P1F0 ULPI_NXT
X0D14 P4C0 P8B0
ULPI_DATA[0:7]
X0D15 P4C1 P8B1
X0D16 P4D0 P8B2
X0D17 P4D1 P8B3
X0D18 P4D2 P8B4
X0D19 P4D3 P8B5
X0D20 P4C2 P8B6
X0D21 P4C3 P8B7
X0D22 P1G0 ULPI_DIR
X0D23 P1H0 ULPI_CLK
X0D24 P1I0 PHY_RST_N
X0D25 P1J0 UART_RX
X0D26 P4E0 UART_TX
X0D27 P4E1
X0D32 P4E2
X0D33 P4E3
X0D34 P1K0 DEBUG
X0D35 P1L0 TRST_N
X0D36 P1M0 RST_N
X0D37 P1N0
X0D38 P1O0
X0D39 P1P0
www.xmos.com

XTAG-2 Hardware Manual (1.0) 8/8
