Yale 7130F Series User manual

7130(F) Series Mortise Exit Devices
Installation Instructions
All dimensions are in inches (mm) unless otherwise noted.
(2) 1/4-20 x 1" PPHMS
(3) 8-32 x 5/16" PUFHMS
End Clamp
End Cap
Attention Installer
Any retrofit or other field modification to a fire rated
opening can potentially impact the fire rating of the
opening, and Yale Locks & Hardware makes no
representations or warranties concerning what such
impact may be in any specific situation. When
retrofitting any portion of an existing fire rated
opening, or specifying and installing a new fire-rated
opening, please consult with a code specialist or
local code official (Authority Having Jurisdiction) to
ensure compliance with all applicable codes and
ratings.
Cover
Outside Trim
Device is packed ready for any
Yale 650F or 660F Series Trim.
Mortise Lock Chart
Function Lock Number
Panic Label Fire Label
Exit Only
F02
F03 (Knob)
F03 (Lever)
F05
F06 (Knob)
F08 (Lever)
35K
35L
38T
38K
38L
35KF
35LF
38TF
38KF
38LF
Mortise Lock
(See Mortise Lock Chart)
798 Universal Strike
(2) 12-12-24 FHPWMS
Armor Front Screw
Armor Front
Device Assembly
(2) 1/4-20 x 3/4" PRHMS
(Special Head)
(2) 8-32 x 5/16" PUFHMS
Dogging Key
Hole Plug
(Fire Devices)
PPHMS
PRHMS
FHPWMS
PUFHMS
PHILLIPS PAN HEAD MACHINE SCREW
FLAT HEAD PHILLIPS WOOD/MACHINE SCREW
PHILLIPS UNDER CUT FLAT HEAD MACHINE SCREW
PHILLIPS ROUND HEAD MACHINE SCREW
FASTENER DESCRIPTION
ABBREVIATION
(2) 12-12-24 FHPWMS
An ASSA ABLOY Group brand
80-9470-0030-000 (11-18)
WARNING
This product can expose
you to lead which is
known to the state of
California to cause cancer
and birth defects or other
reproductive harm. For
more information go to
www.P65warnings.ca.gov.
08/2018

2
To Change Hand
Check Before Starting
Unreinforced Doors or Frames
Doors and Frames with walls having a structural
thickness (metal skin plus reinforcement or solid
hardwood) to engage less than (3) full screw threads
are considered unreinforced.
Unreinforced Doors: Use SNB (sex nuts and bolts).
Unreinforced Frames: Use Blind Rivet Nuts.
Recommended fasteners for unreinforced openings
are not necessarily supplied by Yale Security, Inc. Reinforcement
Door Skin Blind Rivet Nut
Door Must Swing Freely
Min. Door Stile
4-1/2" (114mm)
Maintenance
1. Periodically remove covers and coat mechanisms with a silicone
base lubricant. This is particularly required in corrosive
environments for proper product function.
2. Check mounting fasteners periodically. Retighten if found loose.
Apply screw locking compound (available at automotive part
stores) or change part fasteners if screws continue to back up.
Door and frame must
meet structural and
dimensional specifications
on exit device template(s)
for door and frame
preparation.
LHR DoorRHR Door
Shim Kit Option
Kit consists of Latch Head Shim
(Device Cover seats on shim) and
End Clamp Shim (End Cap seats
on shim).
Each shim is 1/8 (3.2) thick.
More than two Shim Kits require
longer device mounting screws
(not included).
List Number: 723W Black Finish
For Metal, Composite and Wood Doors
Handed Mortise Lock
(See "To Change Mortise Lock Hand", below)
Device is non handed
To Change Mortise Lock Hand
Typical Lock Body with Cover
removed and showing only
components relevant to lock
handing. Other components vary
according to function.
Push In
Note position
of Guard Lever
Latchbolt
Guard Lever
To change lock hand remove,
flip latchbolt and guardbolt
and reinstall.
Guardbolt
Guardbolt Plate Assembly
(Hold in place while
removing guardbolt)
Spring
(Note position before
removing guardbolt)
Remove latchbolt
assembly in this direction.
Nylon Washer (must be between
spring and bracket in case)
An ASSA ABLOY Group brand
80-9470-0030-000 (11-18)

An ASSA ABLOY Group brand
80-9470-0030-000 (11-18)
3
2. Prepare Door & Frame
Spot and Prepare Mounting Holes As Follows:
A. Locate and tape Trim Template to door.
(See instructions packed with Trim.)
B. Locate “Device Template” aligning VERTICAL REFERENCE
and HORIZONTAL REFERENCE lines on door and template.
Tape template to door face.
(1) slot 1/2" (12.7) Dia. x 1" (25.4) on centers thru inside door face and
(2) Device holes for 1/4-20 Machine Screws*, or for 3/8" (9.5) Dia. Sex
nuts and Bolts.
(*) Metal reinforced doors only.
C. Insert lock into mortise, adjust front for door edge (beveled or flat)*.
(2) Lock holes for 12-24 Machine Screws or for #12 Wood Screws.
(*) NOTE: Lock base front has to be field tightened in place, (two screws,
each on lock case top and bottom).
D. Seat strike in frame cutout.
(2) Strike holes for 12-24 Machine Screws, or for #12 Wood Screws.
Factory prepared cutouts with field drilled mounting holes are
recommended. If door (lock) and frame (strike) have to be mortised in
the field, do it before continuing (follow instructions on Installation
Template).
Device Template
1. Mark Door
Finished Floor
Locate and Mark Horizontal and Vertical Reference
Centerlines as shown.
LHR door shown
preparation is typical
for both door hands.
Note: Centerline of Lock (cutout)
must match Horizontal Reference
centerline.
DOOR, LOCK AND STRIKE
(ANSI A115.1 BACKSET)

Device must seat flush on door surface, or
on shims that keep it parallel to door face.
4
4. Clear Raised Door Molding
One Shim Kit #723W required for each 1/8" (3mm) of device lift needed.
Two Shim Kits Maximum for standard device in 1-3/4" (44) door.
For thicker doors, consult the factory.
One Shim Kit #723W
per 1/8" (3mm) of raised
molding.
3. Size Device
An ASSA ABLOY Group brand
80-9470-0030-000 (11-18)

A. Install Lock
Lock in hand, depress guardbolt. Check that
latchbolt is deadlocked.
Check that latchbolt lever (and cylinder lever,
hubs, and thumbpiece lever, if relevant) operate
the lock freely.
Insert Lock Body into door cavity. Fasten to door
edge (2 FHPWMS) Note: Make sure that door
reinforcing clips or doorwalls support lock
immovable (restricting rocking motion).
B. Install Armor Front
Fit over bolts and fasten to lock base front (2
PUFHMS). Check that bolts retract and extend
freely.
C. Install Strike
Seat in place (lip bend away from opening).
Fasten to frame (2 FHPWMS).
D. Install Trim
Follow instructions packed with trim.
E. Install Device
Seat Bar in place (Device finger must engage
latchbolt lever, thru slot in lock case/cover, as
shown in Detail 1). Fasten Device Head (2
PRHMS or SNB).
Set Bar level. Locate End Clamp holes.
Prepare end Clamp mounting holes. Fasten End
Clamp in place. (2 #1/4-20 PRHMS or 3/8" (9.5)
dia SNB)
5. Install Components
5
F. Check Operation
1. Depress touchbar (bolt must retract). Release
touchbar (bolt must extend).
2. Actuate trim (bolt must retract). Release trim
actuator (bolt must extend).
3. (NOT FOR FIRE DEVICES). Depress touchbar,
turn dogging key clockwise (bar must remain
depressed, bolt must remain retracted). Turn
dogging key counterclockwise (bar and bolt
must return to extended position).
4. Close door. Latchbolt should fully engage into
strike cavity, guardbolt should retract over strike
ramp. Door should not rattle.
NOTE: When resulting operation if faulty, check first
for visible binding or interference. If there is no
apparent reason for the fault, remove item from
the door and recheck its operation before
assuming that it is defective.
G. Tighten all mounting screws.
DETAIL 1
An ASSA ABLOY Group brand
80-9470-0030-000 (11-18)

An ASSA ABLOY Group brand
80-9470-0030-000 (11-18)
6. Install Head Cover and End Cap
6
Product Support Tel [phone] • www.yalelocks.com
Yale® is a registered trademark of Yale Security Inc., an ASSA ABLOY Group company. Other products' brand names may be trademarks or registered trademarks of their respective owners and
are mentioned for reference purposes only. These materials are protected under U.S. copyright laws. All contents current at time of publication. Yale Security Inc. reserves the right to change
availability of any item in this catalog, its design, construction, and/or its materials. Copyright © 1996, 2013, Yale Security Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction
in whole or in part without the express written permission of Yale Security Inc., an ASSA ABLOY Group company is prohibited.
Yale Locks & Hardware is a division of Yale Security Inc., an ASSA ABLOY Group company.
Use (3) 8-32 PUFHMS for End Cap
Use (2) 8-32 PUFHMS for Head Cover
