Yale D112 User manual

Outside Cylinder
Housing Assembly
Outside
Of Door
Inside
of Door
Deadbolt needs to be extended at all times during installation.
COLLAR ORIENTATION
FOR 1-1/2" HOLE
For 1-1/2" Hole Only
Mounting Plate
Align Tab with keyway slot.
Turning key will expose screw holes.
COLLAR ORIENTATION
FOR 2-1/8" HOLE
D100 Series Grade 1
Cylindrical Deadbolt
Installation Instructions
Attention Installer
Cylindrical deadbolts must be through-bolted in all door applications. Improper product
installation may result in damage to the lock assembly and may void the factory warranty.
IMPORTANT: Accurate door preparation is critical to the proper function of this cylindrical deadbolt. Any misalignment will
cause premature component wear, reducing deadbolt life and lessening security.
Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Yale Locks & Hardware makes no representations or warranties
concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening,
please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
DO NOT USE
FOR 1-1/2" HOLE
An ASSA ABLOY Group brand
80-YMD1-0120-999 (09-12)

Using enclosed template, mark door as
illustrated at desired lock height and
correct backset.
Mark Center
for 2-1/8" Hole
High Side of
Door Bevel
Mark Center
for 1" Hole
Drill 2-1/8" hole through both sides of
the door as shown and 1" dia. hole
into front face of the door. Be certain
holes are perpendicular.
Bore 1" dia.
Hole Second
Bore 2-1/8"
Hole First
Deadbolt needs to be
kept extended at all times
during installation.
Insert deadbolt in hole, keeping it
parallel to face of the door and
scribe line around face plate.
Remove deadbolt and chisel out
scribed area to depth of 5/32" or
until face is flush with door edge.
Insert deadbolt and fasten with two
deadbolt screws (#8-32 x 3/4").
With deadbolt extended, install cylinder
housing without a key in the cylinder and
with the tailpiece in line with the tailpiece
slot in the deadbolt.
TAILPIECE
1-3/8" Thick Door
1. Measure door thickness.
2. If the tailpiece needs to be
shortened; grip the
tailpiece with pliers on both
sides of the score mark
and twist to break off. METAL JAMB
404
Strike
Strike Box
Fasten strike with
3/4" long screws.
WOOD JAMB
Long screws next
to door stop
7/32"
7/32"
Mark jamb exactly opposite centerline of latch hole. Bore two 1" dia.
Holes 7/32" above and below height line to a depth of 1-1/8". Mortise
for strike and box strike. Install and fasten four screws as illustrated.
NOTE: Drill 1/8" dia. pilot holes for 3/4" long screws, and 5/32" dia. for
3" long screws.
All locks are preset for 1-3/4" door thickness. For 1-3/8"
doors, substitute with shorter tailpieces provided in poly bag.
Spring Pin
Tailpiece
Cylinder Cap
HOW TO CHANGE TAILPIECE
Depress spring pin and unscrew
cylinder cap. Remove and replace
tailpiece. Screw cylinder cap onto plug
while holding spring pin depressed until
the cap is tight, then back off one or two
notches as required. Check cylinder for
proper clearance. If cap is too loose, the
key cannot be withdrawn and if too tight
cylinder will bind. Make sure that spring
pin is engaged with cylinder cap.
Tailpiece
Double Cylinder
Tailpiece Configuration
2
