yeedi mop station pro
INSTRUCTION MANUAL
MANUEL D’INSTRUCTIONS
MANUAL DE INSTRUCCIONES

Instruction Manual�������������������������������������������������������������������������������������������������������������� 3
EN
Bedienungsanleitung������������������������������������������������������������������������������������������������������� 31
FR-CA
Manual de instrucciones������������������������������������������������������������������������������������������������� 60
ES-MX

3EN
1. Package Contents....................................................................................................................................................8
2. Operating and Programming.................................................................................................................................13
3. Maintenance ..........................................................................................................................................................20
4. Troubleshooting.....................................................................................................................................................27
5. Product Specications ...........................................................................................................................................30
Contents

4
EN
1� Do not allow to be used as a toy� Close attention
is necessary when used by or near children�
2� Clear the area to be cleaned� Remove
power cords and small objects from the
oor that could entangle the Appliance.
Tuck rug fringe under the rug base, and lift
items such as curtains and tablecloths off
the oor.
3� If there is a drop off in the cleaning area due
to a step or stairs, you should operate the
Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE
USING THIS APPLIANCE.
SAVE THESE INSTRUCTIONS
For Household use only
When using an electrical appliance, basic precautions
should always be followed, including the following:
WARNING: Read all safety warnings and
instructions� Failure to follow the warnings and
instructions may result in electric shock, re or
serious injury�
Appliance to ensure that it can detect the step
without falling over the edge� It may become
necessary to place a physical barrier at the
edge to keep the unit from falling� Make sure
the physical barrier is not a trip hazard�
4� Only use as described in this manual� Only
use attachments recommended or sold by
the manufacturer�
5� Please make sure your power supply voltage
matches the power voltage marked on the
Self-empty Station�
6� Do not handle plug or appliance with wet
hands�
7� Non-rechargeable batteries are prohibited�
8� Do not use without dust bin and/or lters in
place�
9� Do not operate the vacuum in an area where
there are lit candles or fragile objects on the
oor to be cleaned.
10� Do not use and store in extremely hot or
cold environments (below -5˚C /23˚F or
above 40˚C/104˚F). Please charge the robot
in temperature above 0°C/32°F and below
40°C/104°F�

5EN
11� Keep hair, loose clothing, ngers, and all
parts of body away from any openings and
moving parts�
12� Do not operate the Appliance in a room
where an infant or child is sleeping�
13� For INDOOR use ONLY� Do not use the
Appliance in outdoor, commercial or industrial
environments. Do not use Appliance on wet
surfaces or surfaces with standing water�
14� Do not allow the Appliance to pick up large
objects like stones, large pieces of paper or
any item that may clog the Appliance.
15� Do not use Appliance to pick up ammable
or combustible materials such as gasoline,
printer or copier toner, or use in areas where
they may be present�
16� Do not use Appliance to pick up anything
that is burning or smoking, such as cigarettes,
matches, hot ashes, or anything that could
cause a re.
17� Do not put any object into openings� Do not use
with any opening blocked; keep free of dust,
lint, hair, and anything that may reduce air ow.
18� Take care not to damage the power cord�
Do not pull on or carry the Appliance or Self-
empty Station by the power cord, use the
power cord as a handle, close a door on the
power cord, or pull power cord around sharp
edges or corners. Do not run Appliance over
the power cord� Keep power cord away from
hot surfaces� Do not unplug by pulling on cord�
To unplug, grasp the plug, not the cord�
19� If the power cord is damaged, it must be
replaced by the manufacturer or its service
agent in order to avoid a hazard�
20� Do not use the Self-empty Station if it is damaged�
21� Do not use with a damaged power cord
or plug. Do not use the Appliance or Self-
empty Station if it is not working properly,
has been dropped, damaged, left outdoors,
or come in contact with water� It must be
repaired by the manufacturer or its service
agent in order to avoid a hazard�
22� Turn OFF the power switch before cleaning
or maintaining the Appliance. Turn off all
controls before unplugging. Always turn
off this appliance before connecting or
disconnecting motorized nozzle�

6
EN
23� The plug must be removed from the
receptacle before cleaning or maintaining
the Self-empty Station�
24� Remove the Appliance from the Self-empty
Station, and turn OFF the power switch to
the Appliance before removing the battery
for disposal of the Appliance.
25� The battery must be removed and discarded
according to local laws and regulations
before disposal of the Appliance.
26� Please dispose of used batteries according
to local laws and regulations�
27� Do not incinerate the Appliance even if
it is severely damaged� The batteries can
explode in a re.
28� When not using the Self-empty Station for a
long period of time, please unplug it�
29� The Appliance must be used in accordance with
the directions in this Instruction Manual� yeedi
cannot be held liable or responsible for any
damages or injuries caused by improper use�
30� Prevent unintentional starting� Ensure
the switch is in the off position before
connecting to battery pack, picking up
or carrying the appliance� Carrying the
appliance with your nger on the switch or
energizing appliance that have the switch on
invites accidents�
31� When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from
one terminal to another� Shorting the battery
terminals together may cause burns or a re.
32� Under abusive conditions, liquid may be
ejected from the battery; avoid contact�
If contact accidentally occurs, ush with
water� If liquid contacts eyes, additionally
seek medical help� Liquid ejected from the
battery may cause irritation or burns�
33� Do not use a battery pack or appliance
that is damaged or modied. Damaged or
modied batteries may exhibit unpredictable
behavior resulting in re, explosion or risk of
injury�
34� Do not expose a battery pack or appliance
to re or excessive temperature. Exposure to
re or temperature above 130°C may cause

7EN
explosion� The temperature of 130°C can be
replaced by the temperature of 265°F�
35� Follow all charging instructions and do
not charge the battery pack or appliance
outside of the temperature range specied
in the instructions� Charging improperly or at
temperatures outside of the specied range may
damage the battery and increase the risk of re.
36� Have servicing performed by a qualied
repair person using only identical
replacement parts� This will ensure that the
safety of the product is maintained�
37� Do not modify or attempt to repair the
appliance or the battery pack (as applicable)
except as indicated in the instructions for
use and care�
38� Place the cords from other appliances out of
the area to be cleaned�
39� Do not operate the vacuum in a room that
has lit candles on furniture that the vacuum
may accidentally hit or bump into�
40� Do not allow children to sit on the vacuum�
41� Use only as described in this manual� Use only
manufacturer’s recommended attachments�
42� Recharge only with the charger specied by
the manufacturer. A charger that is suitable
for one type of battery pack may create a risk
of re when used with another battery pack.
43� Use appliances only with specically designated
battery packs� Use of any other battery packs
may create a risk of injury and re.
44� The robot contains batteries that are only
replaceable by skilled persons� To replace the
robot’s battery, please contact Customer Service�
45� If the robot will not be used for a long time,
fully charge the robot and power OFF for
storage and unplug the Self-empty Station�
46� To Reduce The Risk Of Electric Shock – Do
not use on wet surfaces� Do not expose to
rain� Store indoors�
47� To Reduce The Risk Of Injury From Moving
Parts – Unplug Before Servicing�
48� Risk Of Injury� Brush May Start Unexpectedly�
Unplug Before Cleaning or Servicing�
49� To reduce the risk of injury, user must read
instruction manual�
50� To Reduce The Risk Of Electric Shock – Do
not use outdoors or on wet surfaces�

8
EN
Direct current
Alternating current
Federal Communications Commission (FCC) Interference
Statement
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules�
These limits are designed to provide reasonable protection
against harmful interference in a residential installation� This
equipment generate, uses and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications�
However, there is no guarantee that interference will not
occur in a particular installation� If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one
of the following measures:
Reorient or relocate the receiving antenna�
Increase the separation between the equipment and receiver�
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected�
Consult the dealer or an experienced radio/TV technician for
help�
This device complies with Part 15 of the FCC Rules�
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation�
FCC Caution: Any changes or modications not expressly
approved by the party responsible for compliance could void
the user’s authority to operate this equipment�
RF exposure warning
This equipment complies with FCC radiation exposure limits
set forth for an uncontrolled environment�
This equipment must be installed and operated in accordance
with provided instructions and the antenna(s) used for this
transmitter must be installed to provide a separation distance
of at least 20 cm from all persons and must not be collocated
or operating in conjunction with any other antenna or
transmitter�
To disable Wi-Fi module on the robot, power the robot ON�
Place the robot on the Self-empty Station making sure the
Charging Contacts on the robot and the Self-empty Station
Pins make a connection�
Press and hold the AUTO Mode Button on the robot for 20
seconds until the robot emits 3 beeps�
To enable Wi-Fi module on the robot, power the robot OFF
and then power ON� The Wi- Fi module is turned on when
the robot is restarted�

9EN
1. Package Contents/1.1 Package Contents
Robot
Mopping components
Sweeping components
(Pre-installed)
Mopping Pad Plates
(Pre-installed) Washable Mopping Pads
Instruction Manual Edge Brush Main Brush
(Pre-installed)
Self-cleaning Station Power Cord Cleaning Tool
Note: Figures and illustrations are for reference only and may differ from actual product appearance�
Product design and specications are subject to changes without notice.
Instruction Manual
Clean Water Bucket Filter
(Pre-installed)

10
EN
Mapping Sensor Anti-drop Sensors
Universal Wheel
Floor Tracking
Sensor
Main Brush
Edge Brush
Driving Wheels
Anti-drop Sensors
Carpet Detection Sensor
Main Brush
Release Button
Shaft Sleeve
Wi-Fi Indicator
Power Switch
AUTO Mode Button
RESET Button
Anti-collision
Bumper
1. Package Contents/1.2 Product Diagram
Robot Bottom View
Charging Contacts

11 EN
Dust Box ①
Dust Box ①
Washable Mopping Pads
Mopping Pad Plates
Multi-function Cleaning Tool
Handle
Release Button
Release Button
Filter Net
Sponge Filter
High-Efciency Filter
Mopping components Sweeping components
Sponge Filter
High Efficiency Filter
Filter Cover Release Button
Dust Box Release Button
Filter Net

12
EN
Top Cover
Wastewater Bucket
Self-cleaning Button
Start/Pause Button
Recall/Exit Button
Clean Water Bucket
Control Panel
Water Level Sensor
Self-cleaning Station
Water Inlet
Control Panel
Self-cleaning Station Pins

13 EN
2. Operating and Programming/2.1 Notes Before Cleaning
Tidy up the area to be cleaned by putting
furniture, such as chairs, in their proper place�
Make sure areas to be cleaned are well
illuminated so Mapping Sensor works
properly�
During the rst use, make sure each room door
is open to help Robot fully explore your house�
It may be necessary to place a physical
barrier at the edge of a drop to stop
the unit from falling over the edge�
Put away objects including wires,
cloths and slippers, etc� on the
oor to improve the cleaning
efciency.
Before using the product on a rug
with tasseled edges, please fold
the rug edges under�
Please do not stand in narrow
spaces, such as hallways, and
make sure not to block the
Detection Sensor�

14
EN
Assemble Self-cleaning Station
Self-cleaning Station Placement
Install Edge Brush
2
3
1
Before using Robot, please remove all protective films or protective strips on Robot and Self-cleaning Station.
2. Operating and Programming/2.2 Quick Start
Add Water to Clean Water Bucket
4
Click
Keep the area around the Station clear of objects and reective object surfaces.

15 EN
6.5h
Power ON
Note: I = ON, O = OFF.
Robot cannot be charged when being powered OFF�
5
Charge Robot
6
2. Operating and Programming
/2.3 yeedi App
To enjoy all available features, it is recommended to control your
Robot via the yeedi App.
Before you start, make sure that:
• Your mobile phone is connected to a Wi-Fi network�
• The 2�4GHz band wireless signal is enabled on your router�
• The Wi-Fi indicator light on Robot is slowly ashing.
yeedi
Wi-Fi Indicator Light
Tips:
If you have any problems during the Wi-Fi setup process, refer to the
Troubleshooting > Wi-Fi Connection section in this manual�
Slowly ashing Disconnected to Wi-Fi or
waiting for Wi-Fi connection
Rapidly ashing Connecting to Wi-Fi
Solid Connected to Wi-Fi

16
EN
Please start mapping in Vacuum Mode to ensure efciency. Take off
the Mopping Pad Plates to switch to Vacuum Mode; Do not remove
the Reservoir�
2. Operating and Programming/2.4 Operating Robot
OR
Start
1Pause
Wake Up
2
3
Note: The robot’s Control Panel stops glowing after the robot is
paused for a few minutes. Press the AUTO Mode Button on Robot to
wake it up�

17 EN
2. Operating and Programming/
2.5 Mopping components
Power OFF
4
Note: When Robot is not working, it is recommended to keep it
switched ON and charging�
Handle
2
Install Mopping components
1

18
EN
2. Operating and Programming/
2.6 Sweeping components
Click
Click
Install Sweeping components
3
2
1
5
4
3

19 EN
3s
2. Operating and Programming/2.7 Self-cleaning Station
1Start/Pause Robot
2Recall Robot/ Direct Robot to Exit Self-cleaning Station
End Cleaning Task, Direct Robot Back to Self-cleaning Station &
Start Cleaning Mopping Pads
3
