Yeti SB130 User manual
4. 5.
BRAND OVERVIEW 06
FRAME FEATURES 08
GEOMETRY 10
MAINTENANCE SCHEDULE 12
SETUP
OVERVIEW 12
TECHNICAL
ASSEMBLY OVERVIEW 14
EXPLODED VIEWS
REBUILD KITS 6
LEGAL
WARRANTY 30
CONTACT INFORMATION 31
6. 7.6. 7.
We are condent your new bicycle will exceed
your expectations for value, performance, and
ride quality. Each frameset and component
has been custom specied and designed to
enhance your riding experience. Whether you
are a beginner cyclist, or a seasoned pro,
your Yeti bicycle will provide endless hours of
two-wheeled fun.
This model specic manual is designed to
be used in conjunction with the general Yeti
Owner’s Manual and the manuals supplied by
the suspension manufactures. If you did not
receive the Yeti owner’s manual or the manual
provided by the suspension manufacturer
download the materials off the Internet, or
contact your local dealer.
Bicycling can be a hazardous activity
even under the best of circumstances.
Proper maintenance of your bicycle is your
responsibility and when done properly helps
reduce the risk of injury and damage to your
bicycle.
This manual outlines basic setup and
maintenance recommendations of your new
Yeti. Because it is impossible to anticipate
every situation or condition that may occur
during the assembly, setup, and maintenance
of your bicycle, Yeti recommends that all
service and repairs be performed by your
local authorized Yeti Dealer.
This manual contains many “Warnings” and
“Cautions” concerning the consequences
of failure to maintain or inspect your bicycle.
The word “Warning” indicates a potentially
hazardous situation in which , if not avoided,
could result in serious injury or death. The
word “Caution” indicates a potentially
hazardous situation in which, if not avoided
may result in minor injuries or damage to
your bicycle or a component of your bicycle.
Be sure to read and understand all of the
Warnings and Cautions listed in the manual.
Warning: Make sure you review and understand the warnings, instructions, and content of this manual and accompanying
manuals for your bicycle.
Warning: Technological advances have made bicycles and bicycle components more complex and the pace of innovation is
increasing. It is impossible for this manual or the accompanying manuals to provide all the information required to properly
repair and/or maintain your bicycle. In order to help minimize the chances of an injury, it is critical for you to have work
performed by an authorized Yeti retailer.
8. 9.
1 The SB130 delivers 130 of travel with our patented Switch Infinity
Technology. Efficient pedaling performance while still smooth and
continuous when the going gets rough.
High modulus carbon provides a stiff, strong and light weight chassis.
3 Colleted pivot axles help create a stiff interface between the
front and rear triangles of the frame. Custom Enduro Max sealed
bearings keep things moving freely at the pivots.
4 The SB130 does away with the front derailleur mount, making it a 1x
drive specific frame. This increases stiffness in the frame, making the
SB130 one of the stiffest bikes in our lineup.
5 ISCG 05 chain guide mounts are included on the SB130 if case you
want to go for some extra drivetrain security in the rowdy sections.
6 Using our head tube on the SB130 allows for a larger head
tube with more area, increased stiffness, and lower overall ride height
without compromising any performance.
T SB130 10 55 DP shock, by Fox Racing
Shox.
8 Custom guards on the seat stay, chain stay and down tube keep
things quiet while riding and protect the frame.
9 The SB130 features internal routing for all cables, making the bike
quiet and clean looking as well as reducing cable rub on the paint.
10 Dedicated 12 x 148 Boost dropouts and integrated hanger with axle
threads for strength, stiffness, ease of hanger and wheel installation.
1. SWITCH INFINITY TECHNOLOGY PATENTED SUSPENSION SYSTEM
2. HIGH MODULUS CARBON FIBER MAIN FRAME AND SWING ARM
3. COLLET AXLE SYSTEM ON PIVOTS REDUCES BEARING WEAR
4. OPTIMIZED FOR 1X DRIVETRAINS ONLY
5. ISCG 05 CHAINGUIDE MOUNTS
6. INTERTED ED TBE 41/5
7. SUSPENSION BY FOX
8. CUSTOM DEBRIS AND CHAIN SLAP GUARDS
9. INTERNAL CABLE ROUTING
10. INTEGRATED AXLE AND DERAILLEUR HANGER SYSTEM
10. 11.
MEDIUM 5'7" (170 CM) - 5'11" (180 CM)
LARGE 5'11" (180 CM) - 6'3" (191 CM)
X-LARGE 6'1" (185 CM) - 6'6" (198 CM)
MD LG XL
A WHEEL 29” 29” 29”
B REACH 460 480 505
C EFF. TOP TUBE 6019 65 6534
D STACK 6148 648 6348
E HEAD TUBE LENGTH 99 110 11
F SEAT TUBE LENGTH 410 450 495
G EFF. SEAT TUBE ANGLE 0 69 69
H HEAD TUBE ANGLE 655 655 655
IEST. BB HEIGHT 33 33 33
JCHAINSTAY LENGTH 433 433 433
KFRONT-CENTER 6 9 86
LWHEELBASE 1056 130 159
MSTANDOVER 59 8 306
NALXE TO CROWN 551 551 551
OFORK OFFSET 44 44 44
*All measurements are in millimeters
S
29”
430
50
6110
95
380
1
655
336
433
409
1139
35
551
44
SMALL 5'3" (160 CM) - 5'" (10 CM)
12. 13.
Following these guidelines will help maintain the performance of your bicycle and
prevent more serious problems from arising. It is important to remember that
service intervals can vary depending on climate, trail conditions and riding
frequency. If you are unsure about working on your own bicycle, contact your
authorized Yeti Dealer for more information on general bicycle maintenance.
Yeti strongly recommends using a torque wrench when assembling your frame. Torque
specifications for individual parts on the SB130 are listed below, as well as in the step by
step assembly instructions later in the manual. For general bicycle maintenance please
consult the torque specifications of the component you are adjusting.
PART NUMBER DESCRIPTION TORQUE (NM)
300040485 IN PIOT LE 35
00003 SS PIOT BOLT ELE 15
30003096 COLLET LE 305105 1010 1
300040486 COLLET WEDE BOLT LRE 14
30003093 LIN PIOT RDWRE LE 15 8
30006003 1148 DERILLER NER 9
WEEKLY
MONTHLY
3 MONTHS
ANNUALLY
CLEAN AND LUBE CHAIN
CHECK TIRE PRESSURE
CLEAN BIKE OF MUD AND DEBRIS
CHECK BRAKE FUNCTION
CHECK SHOCK PRESSURE, IF APPLICABLE
CHECK FOR LOOSE BOLTS AND TIGHTEN, IF NECESSARY
CHECK HEADSET AND TIGHTEN / LOOSEN, IF NECESSARY
THOROUGHLY CLEAN PIVOT POINTS WITH A RAG (DO NOT LUBRICATE)
LUBE INFINITY LINK EVERY 40 HRS. (YETI HEAVY MOLYBDENUM GREASE)
CHECK / REPLACE BRAKE PADS, IF NECESSARY
CHECK TIRES FOR WEAR
CHECK SPOKE TENSION AND RETENTION, IF NECESSARY
CHECK CHAIN FOR WEAR AND REPLACE IF NECESSARY
COMPLETE TUNE-UP PERFORMED BY AN AUTHORIZED YETI DEALER
30003005 SCS 610 0L SWITC LIN ONT 1
300040486 COLLET WEDE BOLT SLL 8
300030151 BOLT TI LE 6 10
01.
With a 3mm allen key, remove the lower
cable port access cover near the bottom
bracket.
02.
Install your seatpost housing into the
head tube port, pushing until it exits near
the lower cable port access hole.
04.
While pushing the housing into the head
tube port, continue pushing the cable
up the seat tube through the access
port until the housing exits the seat
tube.
01.
Remove the lower cable port access
cover with a 3mm allen key.
02.
Drop a Park Tool Router tool down
the seat tube until it exits the access
port.
03.
Push your seatpost housing into the frame
from the headtube port until it exits near the
access port.
05.
Pull router tool back through the frame
until your housing exits the seat tube.
04.
Outside of the access port, connect
the Park router tool to the housing.
03.
At the same time, pull the shifter housing
out of the head tube port while pushing the
seatpost housing into the seat tube until
the double barb exits the head tube.
Push the shifter housing into the lower
head tube port on the non-drive side.
Feed the housing back to the ports on
the rear triangle and eventually out near
the drive-side dropout.
01.
Route a section of shifter housing
through the frame using the steps
described in Standard Setups
02.
Connect the double-barb to the shifter
housing and the seatpost housing at
the seat tube.
Push the brake line into the frame starting at the
rear triangle, feeding it forward to the ports into
the front triangle and out the head tube.
03.
Use your finger to help push the
housing around the bend in the frame
up into the seat tube.
01.
With a 5mm allen wrench, remove the main
pivot Collet Wedge Bolt
02.
With a 10mm allen wrench, remove the Main
Pivot Collet Axle. The Collet Nut on the drive
side can remain in the frame.
03.
Rotate your swingarm upwards to access
both grease zerks and expose the whole
Switch Infinity link. With a clean rag and
mild detergent, clean any mud, dust, or
debris off the Switch Infinity Link.
04.
Using a needle-type grease gun, push new
grease into the two Switch Infinity grease
ports until you see grease extruding from
the shaft seals.
05.
Wipe off any excess grease that was
pushed out of the seals.
06.
Lower the swingarm and re-install your Main
Pivot Collet Bolt
Torque 3.5 Nm
07.
Install the Main Pivot Collet Wedge and
torque to 14 Nm.
.
.
Make sure your tools are in good condition.
A worn allen key can round the hex on a bolt
not allowing for proper torque.
Torque settings are listed throughout the
instructions. It is important to prep all bolt
threads. The instructions denote whether to
use a Loctite compound or grease.
Warning: Service on Yeti bicycles requires special knowledge
and tools. Yeti Cycles recommends that all service and
repairs be performed by an authorized Yeti Dealer
• 3mm allen key
• 4mm allen keys
• 5mm allen keys
•6
• 10mm allen key
• Guide pin tool (Or two)
•C
• Torque wrench
• Grease
• Blue (242) Loctite
0.
All the parts you’ll need to get your SB130
frame assembled. Please refer to the exploded
view later in this manual for more information.
0.
P S E S
0.
R T S S P I
B L (200020311)
*Torque to 3Nm.
0.
S 4 W 30003014 4 6 C
S (3000300) B L 4
I 4 C S
I L
O
S
I L
..
0.
P L E O
L 000031 S P
0.
E B R
300040505 P
L S E 00003
000033
0.
I S I L
S W T
T 4
Nm
0.
L P B 000038 L P B
30003093 P L T L P
B I L P B Torque to 8Nm.
0.
S 41 T W 300030069 L/E
S T B 300030151 W 30003006 B
L
Torque to Nm.
..
.
R S
L S E
I B 00003
B
D B
L
.
T S P B 5 Nm
R
0.
R T P
P C 300040485 S R T S I L
P C 300040485 I C N 30003085
*Torque to rou 3. Nm
.
L C
W B 300040454 I
P Torque to Nm
.
S P B
000036 B L 4
B 000036
I S P B
000036 R T
.
O L S E
S
E S
P
.
C
30003096 I L E
S
E
*Torque to Nm
..
.
I 45 T B
3000309 W 300030069
.
B L 4
T B 300030151 S
T B
W 30003006
Torque to Nm
.
I W 300030148 0 B
300030010 I
rou
Nm.
.
C
W B 300040486
C
Torque to 8 Nm.
.
B L 4
B 30003099 I
L C P C 300040504
B
*Torque to Nm
0.
D
30006003 I R T
C 30006005
ASSA
*Torque to Nm
https://www.yeticycles.com/bikes/sb130/?
guide:support-shock-setup
.
2.1
2.3
2.2
4.30.2
4.30.1
4.12
4.10
4.11
4.8
4.9
4.7
4.25
4.24
4.27
4.28
1.3
1.1
4.15
4.17
1.2
4.194.18
3
4.14
4.13
4.22
4.21.2
4.20.1
4.3
4.16
4.17
4.23.1
4.6
4.19
4.18
4.1.2
4.5
4.1.1
4.2
4.4
4.26
4.29
2.4
PREP KEY
LOCTITE
GREASE
4.20.2
.
ITEM# PART # DESCRIPTION QTY
1 N/A SB30 FRONT TRIANGLE ASSEMBLY
1.1 N/A SB130 FRONT TRIANGLE 1
1.2 300070006 ICE AXE HEAD BADGE 1
1.3 400100186 DT PROTECTOR 1
1
1
1
1
2 N/A SB30 SWING ARM ASSEMBLY
2.1 N/A SB130 SWING ARM
1
2.2 40010018 SB130 PROTECTOR CS/SS
1
41 SB130 LIN SBSSEBL 1
411 300040500 SB130 LIN 1
41 3000005 BERIN 690RS ETENDED 15 8 /10
4 000036 BOLT SS PIOT ELE
43 00003 LIN PIOT RDWRE EED LON
44 0000311 LOCRIN 690RS
4.000001 SWITC ININIT 1 ECNIS 1
4.830003005 BOLT 6 10 0L 4
4.930003014 WSER 63101 4
411 300040454 COLLET WEDE SBSSEBL 15 1
4.111 30003068 COLLET BOLT 8 15 1
411 3000306 COLLET WEDE 15 1
4113 300040450 SPIRL RETININ RIN 03 0349 INCES 1
ITEM# PART # DESCRIPTION QTY
41 30003085 COLLET NT 15 15 1
413 30003096 COLLET LE 305 105 10 10 1
414300040486 COLLET WEDE SBSSEBL 10 1
4141 30003084 COLLET BOLT 5 8 1
414 30003083 COLLET WEDE 10 1
4143 30004048 SPIRL RETININ RIN 05 0 INCES 1
415 3000309 BOLT STER TI ELE 8 450 1
416 30003098 BOLT STER TI ELE 8 410 1
41 300030069 WSER 85 15 05
418 300030151 BOLT TI LE 6 10
419 30003006 WSER 65 15 05
40 00003 SSEBL SOC ETENDER TOP 60 1
401 30004050 SOC ETENDER TOP 60 1
40 3000003 BERIN 398 DBL 81910/11 1
41 000033 SSEBL SOC ETENDER BOTTO 60 1
411 300040503 SOC ETENDER BOTTO 60 1
41 3000003 BERIN 398 DBL 81910/11 1
4 300040505 SOC ETENDER BERIN ETENSION
43 30006008 SSEBL ETI SET CLP BOLT ON 316 1
431 N/ COLLR BOLT ON ETI SET CLP 316 1
43 N/ BRREL NT ETI SET CLP BOLT ON 1
433 300030010 BOLT 5 08 16L 1
44 300040504 CBLE PORT COER 1
45 30003099
46 3000005 BERIN 690RS ETENDED 15 8 /10
4 300030010 BOLT 5 08 16L
2.3400100188 SB130 PROTECTOR CS LOWER
2.4400100193 SB130 CS PROTECTOR INNER
3N/A 30 OC E
1
N/A 30 PRT E
000030
45 30003093 LIN PIOT RDWRE LE 15 1
46 000038 STD LIN BERIN ELE 15 1
4.10 300040485 COLLET LE 15
48 300030148 WSER 51 89 10
49
430
431
300030300
30006004
30006005
SOC EELET SPCER
DER NER 3 STNDRD
DER NER CP 3
1
1
1
BOLT LT ED 5 08 16
..
PART # QTY
200020333
DESCRIPTION
30 TER RE T
0000311 LOCRIN SS PIOT
00003 SOC ETENDER 60 TOP W/BERIN 1
000033 SOC ETENDER 60 BOTTO W/BERIN 1
000036 BOLT SS PIOT ELE
00003 LIN PIOT RDWRE EED LON 2
000038 STD LIN BERIN ELE 15 485L 1
30000045 BERIN 690 RS 815 OT 2
3000005 4
30003005
BERIN 690 LL E
BOLT CP 610 4
30003006 WSER SS 65 ID 15
300030069 WSER SS 85 ID 15
300030151 BOLTTILE 61
30003014 WSER 10 6 1 4
30003085 COLLET LE NT 15151 1
30003093 1
30003096
LE LE 15 16 1010
COLLET LE 305105 1010 1
3000309 BOLT STER TI ELE 8 450 1
30003098 BOLT STER TI ELE 8 410 1
30003099 BOLT LT ED 5 08 16
300030300 SOC EELET SPCER 1
300040454 COLLETWEDE SSEBL EN 1
300040485 LE COLLET 1555S13T 1
300040486 COLLETWEDE SSEBL 10 1
20002033 30 ER RE T
3000003 BERIN 398 RS DBL ROW
30000045 BERIN 690 RS 815 OT
3000005 BERIN 690 LL E 4
300040504 CBLE PORT COER 1
300040505 SOC ETENDER BERIN ETENSION
PART # QTY
20002033
DESCRIPTION
30 RRE T
0000311 LOCRIN SS PIOT
00003 SOC ETENDER 60 TOP W/BERIN 1
000033 SOC ETENDER 60 BOTTO W/BERIN 1
000036 BOLT SS PIOT ELE
00003 LIN PIOT RDWRE EED LON 2
000038 STD LIN BERIN ELE 15 485L 1
30003005 BOLT CP 610 4
30003006 WSER SS 65 ID 15
300030069 WSER SS 85 ID 15
300030151 BOLTTILE 61
30003014 WSER 10 6 1 4
30003085 COLLET LE NT 15151 1
30003093 1
30003096
LE LE 15 16 1010
COLLET LE 305105 1010 1
3000309 BOLT STER TI ELE 8 450 1
30003098 BOLT STER TI ELE 8 410 1
30003099 BOLT LT ED 5 08 16
300030300 SOC EELET SPCER 1
300040454 COLLETWEDE SSEBL EN 1
300040485 LE COLLET 1555S13T 1
300040486 COLLETWEDE SSEBL 10 1
300040504 CBLE PORT COER 1
300040505 SOC ETENDER BERIN ETENSION
400100186 SB130 DT PROTECTOR 1
40010018 SB130 CS/SS PROTECTOR 1
400100188 SB130 CS LOWER PROTECTOR 1
300040493 SB130 CS INNER PROTECTOR 1
200020039
30003099 BOLT LT ED 5 08 16
300040504 CBLE PORT COER 1
PART # QTY
DESCRIPTION
30 PORT COVER T
30 E PROTECTOR T
00009
.
DISCLAIMER
YETI Cycles is not responsible for any damages to you or others arising from riding,
transporting or other use of your bicycle. In the event that your frame breaks or malfunctions,
YETI Cycles shall have no liability or obligation beyond the repair or replacement of your frame
pursuant to the terms outlined in the warranty.
*If you have a warranty concern, please contact your authorized Yeti dealer.
YETI CYCLES
621 Corporate Circle, Unit B
Golden, CO 80401
(p) 303-278-6909
(f) 303-278-6906
www.yeticycles.com
BUSINESS HOURS
Monday-Friday
8AM-11:30AM, 1:00PM-5:30PM
(Mountain Time)
HERE’S EVERYTHING YOU NEED TO KNOW ABOUT OUR LIFETIME WARRANTY:
All 2019 (or newer) frames, including the Switch Infinity, are covered for life against damage due
to manufacturing defects for the original purchaser. Paint and finish are covered for 1-year. We
will repair or replace, at our discretion, any frame we deem defective. There are a few
conditions: you must register it online at YetiCycles.com and you must take it to an authorized
Yeti Cycles dealer for processing. Warranty does not cover damage due to ordinary wear and
tear, neglect or intentional destruction. From a slingshot or your truck.
If you happen to have a crash or non-warranty situation, we’ll get you back on the trail with a
reasonable replacement price. Same conditions as above.
Lifetime Warranty applies to all 2019 and newer frames (including the SB100). Model year 2018
and older frames will be covered under our previous warranty (5-year or 2-year based on time
of purchase).
Simple as that. No fine print.
This manual suits for next models
1
Table of contents
Other Yeti Bicycle manuals
