YOKOGAWA CA310 User manual

User’s
Manual
IM CA310-02EN
3rd Edition
CA310 Volt mA Calibrator
CA320 TC Calibrator
CA330 RTD Calibrator
Getting Started Guide

IM CA310-02EN 1
3rd Edition: October 2017 (YMI)
All Rights Reserved, Copyright © 2015, Yokogawa Test & Measurement Corporation
Printed in Japan
Thank you for purchasing the CA310 Volt mA Calibrator, CA320 TC Calibrator, or CA330 RTD Calibrator. This operation guide focuses
on the handling precautions, basic operations, and specifications of the CA310/CA320/CA330.
To ensure correct use, please read this manual thoroughly before beginning operation. Keep this manual in a safe place for quick
reference in the event that a question arises.
List of Manuals
The following five manuals, including this one, are provided as manuals for the CA310/CA320/CA330.
Please read all manuals.
Manual Title Manual No. Description
CA310 Volt mA Calibrator
CA320 TC Calibrator
CA330 RTD Calibrator
Getting Started Guide
IM CA310-02EN This guide. The guide explains the handling precautions and basic
operations of the CA310/CA320/CA330 and provides a list of
specifications.
CA310 Volt mA Calibrator
User’s Manual
IM 310-01Z2 This manual explains how to use CA310.
CA320 TC Calibrator
User’s Manual
IM 320-01Z2 This manual explains how to use CA320.
CA330 RTD Calibrator
User’s Manual
IM 330-01Z2 This manual explains how to use CA330.
CA310/CA320/CA330 User’s Manual IM CA310-92Z1 For China
Contact information of Yokogawa offices worldwide is provided on the following sheet.
Manual No. Description
PIM113-01Z2 List of worldwide contacts

2IM CA310-02EN
Notes
• The contents of this manual are subject to change without prior notice as a result of continuing improvements to the instrument’s
performance and functionality. The figures given in this manual may differ from those that actually appear on your screen.
• Every effort has been made in the preparation of this manual to ensure the accuracy of its contents. However, should you have any
questions or find any errors, please contact your nearest YOKOGAWA dealer.
• Copying or reproducing all or any part of the contents of this manual without the permission of YOKOGAWA is strictly prohibited.
Trademarks
• Adobe, Acrobat, and PostScript are either registered trademarks or trademarks of Adobe Systems Incorporated.
• In this manual, the ® and TM symbols do not accompany their respective registered trademark or trademark names.
• Other company and product names are trademarks or registered trademarks of their respective companies.
Revisions
November 2015 1st Edition
October 2016 2nd Edition
October 2017 3rd Edition

IM CA310-02EN 3
Product Registration
Thank you for purchasing YOKOGAWA products.
YOKOGAWA provides registered users with a variety of information and services.
Please allow us to serve you best by completing the product registration form accessible from our
homepage.
http://tmi.yokogawa.com/

4IM CA310-02EN
Checking the Contents of the Package
Unpack the box and check the contents before operating the instrument. If the wrong items have been delivered, if items are missing, or
if there is a problem with the appearance of the items, contact your nearest YOKOGAWA dealer.
CA310/CA320/CA330
Check that the product that you received is what you ordered by referring to the model name on the name plate on the rear panel of the
main unit. For reference, the model name and specifications of the products are listed below.
Model Suffix Code Specifications
CA310 Volt mA Calibrator
CA320 TC Calibrator
CA330 RTD Calibrator
For products whose suffix code contains “Z,” an exclusive manual may be included. Please read it along with the standard manual.

IM CA310-02EN 5
Standard Accessories
The following accessories are included. Make sure that all accessories are present and undamaged.
Item Model or
Component Number
Quantity Notes
CA310 CA320 CA330
Lead cable 98064 1 — — For the CA310 1 red, 1 black
Lead cable 98040 — 1 — For the CA320 1 red, 1 black
Lead cable 98035 — — 1 For the CA330 3 red, 1 black
Binding post (red-black pair) 99045 — 1 1 One short plate included
Binding post (red-red pair) 99046 — — 1 One short plate included
Batteries — 4 4 4 AA alkaline batteries (LR6)
Portable case B9108NK 1 1 1
Antiskid rubber — 1 1 1 Antiskid rubber for the bottom panel
Manuals IM CA310-02EN 1 1 1 Getting Started Guide
For CA310, CA320, and CA330
IM CA310-02JA 1 1 1 Japanese manual
For CA310, CA320, and CA330
IM CA310-02Z2 1 — — User’s manual for the CA310
IM CA320-02Z2 — 1 — User’s manual for the CA320
IM CA330-02Z2 — — 1 User’s manual for the CA330
IM CA310-92Z1 1 1 1 Document for China
PIM 113-01Z2 1 1 1 List of contacts
* Standard accessories are not covered by warranty of this instrument.

6IM CA310-02EN
Optional Accessories (Sold separately)
The following optional accessories are available for purchase separately. For information about ordering accessories, contact your
nearest YOKOGAWA dealer.
Item Model or
Component Number
Applicable To Notes
CA310 CA320 CA330
Rubber boots193060 PPPFor protecting the main unit
AC adapter 94012 PPPInput:100 VAC
Operating temperature range: -10°C to 40°C
94013 PPPInput:120 VAC
Operating temperature range: -10°C to 40°C
94016 PPPInput: 220 VAC
Operating temperature range: -10°C to 40°C
RJ sensor 90080 — P— PT100 JIS AA class or equivalent
Thermometer operating temperature range:
-10°C to 55°C
8-polar miniDin connector
Shielded cable 1.5 m
Y terminal (compatible with M3 terminal blocks)
TC mini plug set 90040 — P— 10 types
K/T/J/E/R(S)/G/C/D/N/B(U)
90045 — P— 4 types
K/T/J/E
Grabber clip 98025 P P2P2Red-black pair, separate type (2 m)
Strap 97040 PPPFor rubber boots
Accessory case B9108XA PPP
* Optional accesories(sold separately) are not covered by warranty of this instrument.
1 When rubber boots are attached, the CA310/CA320/CA330 cannot be stored in the portable case.
2 Cannot be used simultaneously with the included binding post (99045/99046).

IM CA310-02EN 7
Safety Precautions
This product is designed to be used by a person with specialized knowledge.
The general safety precautions described herein must be observed during all phases of operation. If the product is used in a manner
not specified in this guide, the protection provided by the product may be impaired. YOKOGAWA assumes no liability for the customer’s
failure to comply with these requirements.
This manual is part of the product and contains important information. Store this manual in a safe place close to the instrument so that
you can refer to it immediately. Keep this manual until you dispose of the instrument.
Failure to comply with the precautions below could lead to injury or death or damage to the instrument.
WARNING
Use the Instrument Only for Its Intended Purpose
This instrument is a calibrator for the voltage/current measuring instrument (CA310), thermocouple/measuring
instrument (CA320), and RTD/measuring instrument (CA330). Use this instrument only as a calibrator.
Check the Physical Appearance
Do not use the instrument if there is a problem with its physical appearance.
The following symbols are used on this instrument.
Warning: handle with care. Refer to the user’s manual or service manual.
This symbol appears on dangerous locations on the meter which require
special instructions for proper handling or use. The same symbol appears in
the corresponding place in the manual to identify those instructions.
Direct current
Functional ground
French
Avertissement : À manipuler délicatement. Toujours se reporter aux manuels
d’utilisation et d’entretien. Ce symbole a été apposé aux endroits dangereux
de l’instrument pour lesquels des consignes spéciales d’utilisation ou
de manipulation ont été émises. Le même symbole apparaît à l’endroit
correspondant du manuel pour identifier les consignes qui s’y rapportent.
Courant direct
Borne de terre fonctionnelle

8IM CA310-02EN
AC adapter
Only use the dedicated AC adapter for the instrument.
Batteries
• Do not mix new and old batteries or mix different brands or types of batteries. The batteries may leak, heat up, or
burst due to their characteristic differences.
• Never replace the batteries while measurement is in progress.
Do Not Operate in an Explosive Atmosphere
Do not use this instrument in the presence of flammable gases or vapors. Doing so is extremely dangerous.
Do Not Remove Covers or Disassemble or Alter the Instrument
Only qualified YOKOGAWA personnel may remove the covers and disassemble or alter the instrument.
Measurement Category
The measurement category of this instrument’s signal input terminals is Other (O). Do not use it to measure the main
power supply or for Measurement Categories II, III, and IV.
Install or Use the Instrument in Appropriate Locations
• Do not install the instrument outdoors or in locations subject to rain or water. Or, use the instrument in such locations.
• Install the instrument so that you can immediately turn off the power if an abnormal or dangerous condition occurs.
Wiring
• Be sure to use the included lead cables.
• The maximum voltage application between all I/O terminals and earth is 50 VDC (measurement terminal of CA310)
or 42 VDC (other than the measurement terminal of CA310). Do not apply voltages that exceed 50 VDC or 42 VDC .
Doing so may cause electric shock or burns or may damage the instrument.
• Always turn off the power of the device under measurement before connecting it. Connecting or disconnecting lead
cables without turning off the device under measurement is extremely dangerous.
• Do not connect current circuits to the CA310 voltage input terminal. Likewise, do not connect voltage circuits to the
current input terminal. Improper connection may cause electric shock or burns or may damage the device under
measurement or the instrument.
• Do not apply currents that exceed the maximum allowable input current to the CA310 current input terminal.

IM CA310-02EN 9
CAUTION
Operating Environment Limitations
This product is a Class A (for industrial environment) product. Operation of this product in a residential area may cause
radio interference in which case the user will be required to correct the interference.
French
AVERTISSEMENT
Ne faites de cet équipement que l’utilisation pour laquelle il a été conçu
Cet équipement est un calibreur pour l’équipement de mesure de tension/courant (CA310), pour l’équipement de
termocouple/mesure (CA320) et pour l’équipement de RTD/mesure (CA330). Utilisez cet équipement à des fins de
calibrage uniquement.
Inspecter l’apparence physique
Ne pas utiliser l’instrument si son intégrité physique semble être compromise.
Adaptateur c.a.
Utiliser exclusivement l’adaptateur c.a. dédié pour l’instrument.
Batteries
• Ne pas mélanger des batteries neuves et des batteries usagées, ni des batteries de marques ou de types différents.
Les batteries risquent de fuir, de chauffer ou d’éclater en raison de leurs différentes caractéristiques.
• Ne jamais remplacer les batteries lorsque la mesure est en cours.
Ne pas utiliser dans un environnement explosif
Ne pas utiliser l’instrument en présence de gaz ou de vapeurs inflammables. Cela pourrait être extrêmement
dangereux.
Ne pas retirer le capot, ni démonter ou modifier l’instrument
Seul le personnel YOKOGAWA qualifié est habilité à retirer le capot et à démonter ou modifier l’instrument.

10 IM CA310-02EN
Catégorie de mesure
La catégorie de mesure des terminaux d’entrée de signal du CA310, CA320, CA330 est Autre(O). Ne pas l’utiliser pour
mesurer l’alimentation électrique, ni pour les catégories de mesureII, III et IV.
Installer et utiliser l’instrument aux emplacements appropriés
• Ne pas installer, ni utiliser l’instrument à l’extérieur ou dans des lieux exposés à la pluie ou à l’eau.
• Installer l’instrument de manière à pourvoir immédiatement le débrancher du secteur en cas de fonctionnement
anormal ou dangereux.
Câblage
• Veillez à utiliser tous les câbles fournis.
• La tension maximum autorisée entre toutes les bornes I/O et la terre est de 50 V c.c. (borne mesure du CA310) ou
de 42 V c.c. (autre que la borne de mesure du CA310). N’appliquez pas de tension supérieure à 50 V c.c (CA310) ou
à 42 V c.c (CA320/CA330). Le cas échéant vous vous exposeriez à des risques de choc électrique ou de brûlure ou
vous risqueriez d’endommager l’équipement.
• Mettez toujours le dispositif à mesurer hors tension avant de le connecter à l’équipement. Il est extrêmement
dangereux de brancher ou débrancher des câbles sans avoir préalablement mis le dispositif à mesurer hors tension.
• Ne branchez pas de circuits de courant sur la borne d’entrée de tension du CA310. Ne branchez pas non plus de
circuits sous tension sur la borne d’entrée de courant. Un branchement incorrect vous exposerait à des risques de
choc électrique ou de brûlure, ou risquerait d’endommager l’appareil à mesurer ou l’équipement.
• N’appliquez pas de courant supérieur au courant d’entrée maximum admissible à la borne d’entrée de courant du
CA310.
ATTENTION
Limitations relatives à l’environnement opérationnel
Ce produit est un produit de classe A (pour environnements industriels). L’utilisation de ce produit dans un zone
résidentielle peut entraîner une interférence radio que l’utilisateur sera tenu de rectifier.

IM CA310-02EN 11
Conventions Used in This Guide
Notes
The notes and cautions in this guide are categorized using the following symbols.
Improper handling or use can lead to injury to the user or damage to the instrument. This symbol appears
on the instrument to indicate that the user must refer to the manual for special instructions. The same
symbol appears in the corresponding place in the manual to identify those instructions. In the manual, the
symbol is used in conjunction with the word “WARNING” or “CAUTION.”
WARNING
Calls attention to actions or conditions that could cause serious or fatal injury to the user, and precautions
that can be taken to prevent such occurrences.
French
AVERTISSEMENT Attire l’attention sur des gestes ou des conditions susceptibles de provoquer des blessures graves (voire
mortelles), et sur les précautions de sécurité pouvant prévenir de tels accidents.
CAUTION
Calls attention to actions or conditions that could cause light injury to the user or damage to the instrument
or user’s data, and precautions that can be taken to prevent such occurrences.
French
ATTENTION Attire l’attention sur des gestes ou des conditions susceptibles de provoquer des blessures légères ou
d’endommager l’instrument ou les données de l’utilisateur, et sur les précautions de sécurité susceptibles
de prévenir de tels accidents.
Note
Calls attention to information that is important for the proper operation of the instrument.

12 IM CA310-02EN
Waste Electrical and Electronic Equipment (WEEE), Directive
(This directive is valid only in the EU.)
This product complies with the WEEE directive marking requirement. This marking indicates that you must not discard this
electrical/electronic product in domestic household waste.
Product Category
With reference to the equipment types in the WEEE directive, this product is classified as a “Monitoring and control instruments”
product. When disposing products in the EU, contact your local Yokogawa Europe B.V. office. Do not dispose in domestic
household waste.
EU Battery Directive
(This directive is valid only in the EU.)
Batteries are included in this product. This marking indicates they shall be sorted out and collected as ordained in the EU battery
directive.
Battery type:
Alkaline
When disposing of alkaline batteries, follow the domestic law concerning disposal. Take the proper action to dispose
batteries in accordance with the established collection system in the European Economic Area. For the battery removal
procedure, see page 26.
Authorized Representative in the EEA
Yokogawa Europe B.V. is the authorized representative of Yokogawa Test & Measurement Corporation for this product in the EEA. To
contact Yokogawa Europe B.V., see the separate list of worldwide contacts, PIM 113-01Z2.

IM CA310-02EN 13
Product Registration................................................................3
Checking the Contents of the Package...................................4
Safety Precautions..................................................................7
Conventions Used in This Guide...........................................11
Waste Electrical and Electronic Equipment (WEEE),
Directive ................................................................................12
EU Battery Directive..............................................................12
Authorized Representative in the EEA..................................12
Names and Functions of Parts ...........................14
Front Panel, Side Panel, and Rear Panel .............................14
Keys ......................................................................................15
Display ..................................................................................17
Making Preparations for Measurements............18
Handling Precautions............................................................18
Installing the Instrument........................................................20
Connecting Cables................................................................23
Using Thermocouple Mini Plugs (CA320 only) .....................25
Installing and Removing Batteries.........................................26
Connecting the AC Adapter...................................................27
Turning the Power On and Off ..............................................28
Common Operations ...........................................29
Troubleshooting, Maintenance, and
Inspection .............................................................32
Troubleshooting ....................................................................32
Recommended Replacement Parts, Consumable Parts, and
Calibration.............................................................................33
Disposing of the Instrument ..................................................33
Specifications.......................................................34
CA310 ...................................................................................34
CA320 ...................................................................................36
CA330 ...................................................................................46
Common Specifications ........................................................49
External Dimensions .............................................................51
Contents

14 IM CA310-02EN
Names and Functions of Parts
Front Panel, Side Panel, and Rear Panel
Display
Keys
I/O terminals
Rotary switch
Selects the range and
sensor type. You can
also select the setup
mode (SETTING).
Measurement/
source switch
POWER key
Turns the power on
and off.
AC adapter jack
Connect the AC
adapter, an
accessory sold
separately.
RJ sensor
connector
(CA320 only)
Connect an RJ
sensor.
Battery cover
CA310 example
CA320
TYPE1 TYPE2

IM CA310-02EN 15
Keys
Source
▲
▲
▲
▲
▲
▲
▲
▲
POWER
OUTPUT
ON/OFF
TYPE
▲
▲
▲
▲
▲
▲
▲
▲
POWER
CA310
OUTPUT ON/OFF key
Turns the output on and off Starts or
stops sweeping in sweep mode. TYPE key
Select the sensor.
Stops or resumes sweeping in sweep mode.
key
Increases the number
key
Decreases the number
Press simultaneously during normal
output to set the display span to 0 %.
Press simultaneously during
normal output to set the display
span to 100%.
Press simultaneously to switch between
normal output, span check, step sweep, and
linear sweep.
CA320/
CA330
key
Increases the number
key
Decreases the number
Press simultaneously to switch the sub display item
(voltage corresponding to temperature (CA320) or
resistance (CA330), span % display, RJ sensor
temperature (CA320)).
Pauses or resumes sweeping in sweep mode.
Set the output to 0% in span check.
Press simultaneously during normal
output to set the display span to 100 %.
Press simultaneously during
normal output to set the display
span to 0%.
Press simultaneously to switch between
normal output, span check, step sweep, and
linear sweep.
Set the output to 100% in span check.
Set to 0% when sweeping is stopped or paused.
Set the output to 100% in span check.
Set to 0% when sweeping is stopped or paused.
Set the output to 0% in span check.
Decreases the output span by 25% in span check.
Increases the output span by 25% in span
check.
Decreases the output span by 25% in span check.
Increases the output span by 25% in span
check.
Names and Functions of Parts

16 IM CA310-02EN
Measurement
▲
▲
▲
▲
▲
▲
▲
▲
POWER
OUTPUT
ON/OFF
TYPE
▲
▲
▲
▲
▲
▲
▲
▲
POWER
CA310
OUTPUT ON/OFF key
Turns LOOP POWER on and off if
LOOP POWER is in use.
TYPE key
Select the sensor.
CA320/CA330
Press simultaneously to switch the sub display item
(voltage corresponding to temperature, span %
display, RJ sensor temperature (CA320)).
On the CA330, select the wiring system from 2W
(two-wire), 3W (three-sire), and 4W (four-wire).
Names and Functions of Parts

IM CA310-02EN 17
Display
1
2
3 4 5 67
89
10
11
12
13 14
CA310
CA320
CA330
15
16
17
No. Description
1 Appears in measurement mode
2 Appears in source mode
3 Battery level
4Appears during sourcing (blinks when sweeping is paused)
5 Appears when the HART/BRAIN communication resistor is
enabled*
6 Sub display. Displays options in setup mode.
7 Sub display unit
8 Output method
Normal output (outputs the specified value): not
displayed
Span check (manual step): SPAN
Step sweep:
Linear sweep:
9 Main display unit
10 Calibration mode (not displayed normally)
11 Appears when auto power off is enabled
12 Main display
13 Selection status of the TC connection terminal
When the thermocouple mini plug terminal is in use: A
When the banana terminal is in use: B
14 RJ sensor setup mode
RJ sensor off: not displayed
When internal RJ sensor is set: RJ
When external RJ sensor is set: EXT RJ
15 Appears when the temperature standard is set to IPTS-68
16 Sensor selection status based on the TYPE key
17
Wiring system. Two-wire: 2W, three-wire: 3W, four-wire: 4W
* Appears only for LOOP POWER even when it is set to ON.
Names and Functions of Parts

18 IM CA310-02EN
Making Preparations for Measurements
Handling Precautions
Safety Precautions
If you are using this instrument for the first time, make sure to thoroughly read “Safety Precautions,” on pages 7 to 10.
Unplug If Abnormal Behavior Occurs
If you notice smoke or unusual odors coming from the instrument, immediately turn off the power, remove the batteries if possible, and
contact your nearest YOKOGAWA dealer.
General Handling Precautions
Do Not Place Objects on Top of the Instrument
Never place objects such as other instruments or objects that contain water on top of the instrument. Doing so may damage the
instrument.
Do Not Subject the Inputs and Outputs to Mechanical Shock
If the I/O connectors or adapters are subjected to mechanical shock, they may be damaged. The instrument may not perform
measurements correctly due to damage or deformation that is not visible to the naked eye.
Do Not Scratch the LCD
Because the LCD can be easily scratched, do not allow any sharp objects near it. Also, do not apply vibration or shock to it. Furthermore,
do not apply strong shock to the LCD or place objects on top of it.
Remove the Batteries during Extended Non-Use
Remove the batteries from the main unit. Remove the AC adapter power cord from the outlet.
When Carrying the Instrument
Remove the power cord and connecting cables.
When Cleaning the Instrument
When cleaning the case or the operation panel, gently wipe the outer surface using a damp, well-wrung, soft, clean cloth. The instrument
can malfunction if water enters inside the instrument.
Do not use chemicals such as benzene or thinner. Doing so may cause discoloring and deformation.

IM CA310-02EN 19
Other Precautions
• Keep electrically charged objects away from the input terminals. They may damage the internal circuitry.
• Do not cover the case or operation panel with a volatile material or leave rubber or vinyl products in contact with the case or operation
panel for a long time.
Storage Precautions
Avoid the following kinds of places for storing the instrument:
• Where the temperature falls outside the storage temperature and humidity ranges
• In direct sunlight or near heat sources
• In an environment with excessive amounts of soot, steam, dust, or corrosive gas
• In an environment subject to large levels of mechanical vibration
• On an unstable surface
• Where an excessive amount of soot, dust, salt, or iron is present
Making Preparations for Measurements
