YOKOGAWA CA700 User manual

User’s
Manual
IM CA700-02EN
6th Edition
CA700
Pressure Calibrator
Getting Started Guide
nbn Austria GmbH
nbn Austria GmbH

Product Registration
Thank you for purchasing YOKOGAWA products.
YOKOGAWA provides registered users with a variety of information and services.
Please allow us to serve you best by completing the product registration form
accessible from our website.
http://tmi.yokogawa.com/
PIM 103-04E

i
IM CA700-02EN
Thank you for purchasing the CA700 pressure calibrator. This getting started guide primarily explains
the handling precautions and basic operations of the CA700. To ensure correct use, please read this
manual thoroughly before beginning operation.
After reading this manual, keep it in a safe place. The following manuals, including this one, are
provided as manuals for the CA700. Please read all manuals.
Manual Title Manual No. Description
CA700
Pressure Calibrator
User’s Manual
IM CA700-01EN The manual explains all the CA700 features.
It is included in the accompanying CD.
CA700
Pressure Calibrator
Getting Started Guide
IM CA700-02EN This guide. Provided as a printed manual. This guide
explains the handling precautions, basic operations, and
specifications of the CA700.
CA700
Pressure Calibrator
IM CA700-92Z1 Document for China
The “-EN” in the manual number is the language code.
Contact information of Yokogawa offices worldwide is provided on the following sheet.
Document Description Description
PIM 113-01Z2 List of worldwide contacts
Notes
• The contents of this manual are subject to change without prior notice as a result of continuing
improvements to the instrument’s performance and functionality. The figures given in this manual
may differ from those that actually appear on your screen.
• Every effort has been made in the preparation of this manual to ensure the accuracy of its
contents. However, should you have any questions or find any errors, please contact your nearest
YOKOGAWA dealer.
• Copying or reproducing all or any part of the contents of this manual without the permission of
YOKOGAWA is strictly prohibited.
Trademarks
• Microsoft, Internet Explorer, Windows, Windows 7, Windows 8, and Windows 10 are either
registered trademarks or trademarks of Microsoft Corporation in the United States and/or other
countries.
• Adobe, Acrobat, and PostScript are either registered trademarks or trademarks of Adobe Systems
Incorporated.
• HART is a registered trademark of FieldComm Group.
• In this manual, the TM and ® symbols do not accompany their respective®registered trademark or
trademark names.
• Other company and product names are registered trademarks or trademarks of their respective
holders.
6th Edition: October 2018 (YMI)
All Rights Reserved, Copyright © 2013 Yokogawa Test & Measurement Corporation

ii
Revisions
• 1st Edition: August 2013
• 2nd Edition: September 2015
• 3rd Edition: June 2017
• 4th Edition: October 2017
• 5th Edition: June 2018
• 6th Edition: October 2018

iii
IM CA700-02EN
Checking the Contents of the Package
Unpack the box and check the contents before operating the instrument. If the wrong items have been
delivered, if items are missing, or if there is a problem with the appearance of the items, contact your
nearest YOKOGAWA dealer.
CA700
Check that the product that you received is what you ordered by referring to the model name and suffix
code given on the name plate on the rear panel.
MODEL Suffix Code Specifications
CA700 Pressure calibrator
-E For all countries except Japan
Gauge pressure -01
-02
-03
200 kPa guage model
1000 kPa guage model
3500 kPa guage model
Pressure unit -U1
-U2
SI units
SI units and non-SI units
Input connection -P1
-P2
Rc1/4 female threads
1/4NPT female threads
No. (Instrument number)
When contacting the dealer from which you purchased the instrument, please give them the instrument
number.
Standard Accessories
The instrument is shipped with the following accessories. Make sure that all accessories are present
and undamaged.
Item Model/Part No. Quantity Specifications and Notes
Signal cable 98064 1 Red/Black pair
Shoulder strap B8070CY 1 —
Connector 91080 1 For -P1(Rc1/4)
91081 1 For -P1(Rc1/4)
91082 1 For -P2(1/4NPT female threads)
Dry cells A1070EB 6 Alkaline “AA” (LR6) 1.5 V
Accessory case B9108XA 1 —
Ferrite core A1193MN 2
Cap L4060CL 1 For the pressure input port (comes attached to the
CA700)
CD-ROM (User’s Manuals) L3060TD 1 Contains PDFs of the user’s manuals and USB
driver
User’s manual IM CA700-02EN 1 This guide.
IM CA700-92Z1 1 Document for China
PIM 113-01Z2 1 List of worldwide contacts
Standard accessories are not covered by warranty of this instrument.

iv
CD-ROM (User’s Manuals)
The CD-ROM contains PDF files of the following manuals. To view these user’s manuals, you need
Adobe Reader 5.0 or later.
Japanese
• Model CA700 Pressure Calibrator User’s Manual
IM CA700-01JA
English
• Model CA700 Pressure Calibrator User’s Manual
IM CA700-01EN
WARNING
Never play this CD-ROM, which contains the user’s manuals, in an audio CD player. Doing so
may cause loss of hearing or speaker damage due to the large sounds that may be produced.
French
AVERTISSEMENT
Ce CD contient les manuels d'utilisation. Ne jamais insérer ce CD dans un lecteur de CD
audio. Cela pourrait entraîner une perte d'audition ou l'endommagement des enceintes en
raison du volume potentiellement élevé des sons produits.
Checking the Contents of the Package

v
IM CA700-02EN
Optional Accessories (Sold separately)
The following optional accessories are available for purchase separately. For information about
ordering accessories, contact your nearest YOKOGAWA dealer.
Item Model/
Part No.
Min. Q’ty Specifications Manual No.
Carrying case 93050 1 CA700, accessory case -
Grabber clip 98025 1 Red/Black pair, separate type (2.0 m) -
Grabber clip 98026 1 Red/Black pair, separate type (2.0 m) -
Cleaning unit 91040 1 Pressure input port Rc1/8 female thread,
2 locations (for -P1 and -P2)
-
Cleaning unit 91041 1 Pressure input port 1/8NPT female
thread, 2 locations (for -P1 and -P2)
-
Connector 91080 1 R1/4 male to NPT 1/8 female -
Connector 91081 1 R1/4 male to NPT 1/4 female -
Connector 91082 1 NPT 1/4 male to NPT 1/8 female -
Low pressure pump kit 91050 1 A set containing 91051, case (93052),
and connector set (91052)
-
Low pressure pump 91051 1 -83 Pa to 700 kPa -
Connector set (low pressure
pump)
91052 1 Connector set for 91051 -
Pneumatic pressure pump kit 91055 1 A set containing 91056, case (93053),
and connector set (91057)
-
Pneumatic pressure pump 91056 1 -83 Pa to 4000 kPa -
Connector set (pneumatic
pressure pump)
91057 1 Connector set for 91056 -
Hydraulic pressure pump kit 91060 1 A set containing 91061, case (93053),
and connector set (91062)
-
Hydraulic pressure pump 91061 1 -0 Pa to 70 MPa -
Connector set (hydraulic
pressure pump)
91062 1 Connector set for 91061 -
Case (for 91051) 93052 1 For storing 91051 and 91052 -
Case (for 91056 and 91061) 93053 1 For storing 91056 and 91057, or 91061
and 91062
-
External pressure sensor1PM100 1 -05: 16 MPa range shield gauge model
-06: 70 MPa range shield gauge model
PM100-01EN
Optional accessories(sold separately) are not covered by warranty of this instrument.
1: PM100-*-05: available in 1.10 or later firmware versions of the CA700.
PM100-*-06: available in 1.20 or later firmware versions of the CA700.
You can download the latest firmware version from our website.
Checking the Contents of the Package

vi
Conventions Used in This Manual
Unit
k: Denotes 1000. Example: 100 kS/s (sample rate)
K: Denotes 1024. Example: 720 KB (file size)
Displayed Characters
Bold characters in procedural explanations are used to indicate panel keys and soft keys that are used
in the procedure and menu items that appear on the screen.
Notes
The notes and cautions in this manual are categorized using the following symbols.
mproper handling or use can lead to injury to the user or damage to
the instrument. This symbol appears on the instrument to indicate
that the user must refer to the user’s manual for special instructions.
The same symbol appears in the corresponding place in the user’s
manual to identify those instructions. In the user’s manual, the symbol
is used in conjunction with the word “WARNING” or “CAUTION.”
WARNING
Calls attention to actions or conditions that could cause serious or
fatal injury to the user, and precautions that can be taken to prevent
such occurrences.
CAUTION
Calls attention to actions or conditions that could cause light injury
to the user or cause damage to the instrument or user’s data, and
precautions that can be taken to prevent such occurrences.
Note
Calls attention to information that is important for the proper operation
of the instrument.
French
Une manipulation ou une utilisation incorrectes risquent de
blesser l’utilisateur ou d’endommager l’instrument. Ce symbole
apparaît sur l’instrument pour indiquer à l’utilisateur qu’il doit se
reporter au manuel de l’utilisateur afin d’y lire les instructions
spécifiques correspondantes. Ce même symbole apparaît à la
section correspondante du manuel de l’utilisateur pour signaler
lesdites instructions. Dans le manuel de l’utilisateur, ce symbole est
accompagné des termes AVERTISSEMENT et ATTENTION.
AVERTISSEMENT Attire l’attention sur des gestes ou des conditions susceptibles
de provoquer des blessures graves (voire mortelles), et sur les
précautions de sécurité pouvant prévenir de tels accidents.
ATTENTION
Attire l’attention sur des gestes ou des conditions susceptibles de
provoquer des blessures légères ou d’endommager l’instrument
ou les données de l’utilisateur, et sur les précautions de sécurité
susceptibles de prévenir de tels accidents.

vii
IM CA700-02EN
Safety Precautions
This product is designed to be used by a person with specialized knowledge.
The general safety precautions described herein must be observed during all phases of operation.
If the instrument is used in a manner not specified in this manual, the protection provided by the
instrument may be impaired. YOKOGAWA assumes no liability for the customer’s failure to comply
with these requirements.
This manual is an essential part of the product; keep it in a safe place for future reference. Yokogawa
Electric Corporation assumes no liability for the customer’s failure to comply with these requirements.
The following symbols are used on this instrument.
Handle with care. Refer to the user’s manual or service manual. This symbol appears on
dangerous locations on the instrument which require special instructions for proper handling
or use. The same symbol appears in the corresponding place in the manual to identify those
instructions.
Ground (earth) or functional ground terminal (do not use this terminal as a protective ground
terminal)
Alternating current
Direct current
Power switch
French
À manipuler délicatement. Toujours se reporter aux manuels d’utilisation et d’entretien. Ce
symbole a été apposé aux endroits dangereux de l’instrument pour lesquels des consignes
spéciales d’utilisation ou de manipulation ont été émises. Le même symbole apparaît à l’endroit
correspondant du manuel pour identifier les consignes qui s’y rapportent.
Borne de terre ou borne de terre fonctionnelle (ne pas utiliser cette borne comme prise de
terre.)
Courant alternatif
Courant direct
l’interrupteur d’alimentation

viii
Failure to comply with the precautions below could lead to injury
or death or damage to the instrument.
WARNING
Use the Instrument Only for Its Intended Purpose
This instrument is equipped with DC current and DC voltage measurement and generation
features as well as a pressure measurement feature. It is a calibrator for pressure devices.
Use the instrument only for measuring and generating DC current and DC voltage, measuring
pressure, and calibrating pressure devices.
Check the Physical Appearance
Do not use the instrument if there is a problem with its physical appearance.
Do Not Operate in an Explosive Atmosphere
This instrument is not explosion-proof.
Do not operate the instrument in the presence of flammable gases or vapors. Doing so is
extremely dangerous.
Do Not Remove Covers or Disassemble or Alter the Instrument
Removing covers and disassembling or altering the instrument are strictly prohibited.
Some sections inside the instrument have high voltages that are extremely dangerous. For
internal inspection and adjustment, contact your nearest YOKOGAWA dealer.
Measuring High Pressure Fluid
• Use piping and pressure connectors that can withstand the pressure to be measured.
• Make sure that there are no leaks from the piping, connectors, and joints and that the joints
are not loose. If the fluid under measurement leaks or if a joint comes loose, the pressure
can endanger the user or the surrounding instruments. Note that higher the pressure,
greater the danger.
• Depending on the amount or type of gas, if you are handling gas that is 1 MPa or higher,
safety laws related to high pressure gas may require supervision.
• Do not measure flammable, explosive, poisonous, or corrosive liquids.
Such an act can endanger the user.
Observer the Pressure Limit
Do not apply pressure exceeding the allowable input range. Doing so may cause damage to
the instrument.
Measurement Category
The measurement category of this instrument is Other (O). Do not use it to measure the main
power supply or locations that fall under Measurement Categories II, III, and IV.
Install or Use the Instrument in Appropriate Locations
• The instrument complies with protection level IP54. Do not install the instrument in
locations whose level exceeds this protection level.
• Install the instrument so that you can immediately remove the batteries if an abnormal or
dangerous condition occurs.
CAUTION
• Do not use the instrument to measure gas or liquids that can corrode the piping material,
high temperature liquids (50°C or higher) or gas-liquid mixtures.
If you are measuring gas, make sure the gas is dry and clean. Do not measure air with high
moisture or high oil content.
Safety Precautions
