YOKOGAWA CL250 User manual

IM CL250
2017.10 11 版 (KYOU)
IM CL250
User's
Manual
保証書付
CL250
Clamp-onTester
クランプテスタ

Contents
■PrecautionsforSafetyUseoftheInstrument………………………………i
1. InstrumentLayout ……………………………………………………………1
2. Measurement ………………………………………………………………… 3
2.1 PreparationforMeasurement ……………………………………… 3
2.2 DCCurrentMeasurement ………………………………………… 3
2.3 ACCurrentMeasurement ………………………………………… 4
2.4 DCVoltageMeasurement ………………………………………… 5
2.5 ACVoltageMeasurement ………………………………………… 6
2.6 ResistanceMeasurement …………………………………………… 7
2.7 ContinuityCheck(400Ωrangefixed) …………………………… 7
2.8 MAXMeasurement ………………………………………………… 8
3. OtherFunctions …………………………………………………………… 9
3.1 SleepFunction ……………………………………………………… 9
3.2 DataHoldFunction ………………………………………………… 9
3.3 OUTPUTTerminal(Forcurrentrangesonly) ……………………10
3.4 OptionalAccessories ……………………………………………… 11
4. BatteryReplacement ………………………………………………………12
5. Specifications ……………………………………………………………… 13
6. CalibrationandAfter-salesService …………………………………… 16

IM CL250 i
■PrecautionsforSafeUseoftheInstrument
When handling the instrument, ALWAYS observe all of the cautionary notes
on safety given below. Yokogawa M&C Corporation is not at all liable for
damageresultingfrommisuseofthisproduct by the user thatiscontraryto
thesecautionarynotes.
Varioussymbolsareusedontheinstrumentandinthismanualtoensurethe
product is used safety and to protect operators and property from possible
hazardsordamage.Thefollowingsafetysymbolsareusedwhereappropriate.
Read the explanations carefully and familiarize yourself with the symbols
beforereadingthetext.
Theinstrumentandthismanualusethefollowingsafetysymbols:
Danger! Handle with Care.
Thissymbolindicatesthattheoperatormustrefertoanexplanationin
theUsersManualinordertoavoidtheriskofpersonalinjuryordeath
and/ordamagetotheinstrument.
DoubleInsulation
Thissymbolindicatesdoubleinsulation.
ACVoltage/Current
ThissymbolindicatesACvoltageorcurrent.
DCVoltage/Current
ThissymbolindicatesDCvoltageorcurrent.
AC/DCVoltage/Current
ThissymbolindicatesAC/DCvoltageorcurrent.
Ground
Thissymbolindicatesground(earth).
Indicatesthatthis instrumentcan clamp onbareconductorswhen
Measuring avoltagecorrespondingtotheapplicableMeasurement
Category,whichismarkednexttothissymbol.
WARNING
Indicatesthatthereisapossibilityofseriouspersonalinjuryorlossoflifeif
theoperatingprocedureisnotfollowedcorrectlyand describes the precau-
tionsforavoidingsuchinjuryorlossoflife.
CAUTION
Indicatesthatthereisapossibilityofseriouspersonalinjuryofdamagetothe
instrumentiftheoperatingprocedureisnotfollowedcorrectlyanddescribes
theprecautionsforavoidingsuchinjuryordamage.

ii IM CL250
NOTE
Draws attention to information essential for understanding the operation and
features.
WARNING
● Nevermakemeasurementonacircuitabove750VACor1000VDC.
● Do not use the instrument in an atmosphere where any flammable or
explosivegasispresent.
● Donotattempttomakemeasurement inthe presenceofflammable
gasses, fumes, vapor or dust. Otherwise, the use of the instrument may
causesparking,whichcanleadtoanexplosion.
● Avoidusingtheinstrumentifithasbeenexposedtorainormoistureorif
yourhandsarewet.
● DonotexceedthemaximumallowabIeinputofanymeasurementrange.
● Neveropenthebatterycompartmentcoverwhenmakingmeasurement.
● Donotusetheinstrumentifthereisanydamagetothecasingorwhenthe
casingisremoved.
● Do notturnthe FunctionSelectorswitch withpluggedintestleadscon-
nectedtothecircuitundertest.
● Donotinstallsubstitutepartsormakeanymodificationtotheinstrument.
ReturntheinstrumenttoYokogawaMeters&Instrumentsoryourdistributor
forrepairorre-calibration.
● Alwaysswitchofftheinstrumentbeforeopeningthebatterycompartment
coverforbatteryreplacement.
●Donotusethetestleadsthathavedeterioratedoraredetective.
●Checkthetestleadscontinuity

IM CL250 iii
WARNING
Toavoiddamagetotheinstrumentorelectricshock!
Therestrictionsonthe maximum voltagelevelforwhichthe CL250 testers
canbeused,dependontheMeasurementcategoriesspecifiedbythesafety
standards.Thesecategoryspecificationsareformulatedtoprotectoperators
againsttransientimpulsevoltagesinpowerlines.
Function
MaximumAllowableInput
MEASUREMENT
CATEGORYⅢ
MEASUREMENT
CATEGORYⅣ
A, A
AC2000Arms
Measuringcircuitvoltage:
AC750Vrms
DC1000V
AC2000Arms
Measuringcircuitvoltage:
AC600Vrms
DC600V
V, V AC750Vrms/DC1000V
AC600Vrms/DC600V
Input terminal-to-
groundvoltage AC750Vrms/DC1000V
O(None,Other)
OthercircuitsthatarenotdirectlyconnectedtoMEAINS.
MeasurementcategoryII(CAT.II)
Local level, appliance, portable equipment etc., with smaller transient
measurementthanCAT.III.
MeasurementcategoryIII(CAT.III):
Distribution level, fixed installation, with smaller transient measurement
thanCAT.IV.
MeasurementcategoryⅣ(CAT. Ⅳ ):
Primarysupplylevel,overheadlines,cablesystems,andon.
CAUTION
● Alwaysmakesuretoinserteachplugofthetestleadsfullyintotheappro-
priateterminalontheinstrument.
● Make sure to remove the test leads from the instrument before making
currentmeasurement.
● Be sure to set the Function Selector switch to the "OFF" position after
use.Whentheinstrumentwillnotbeinuseforalongperiodoftime,place
itinstorageafterremovingthebattery.
● Use a dampclothanddetergentfor cleaning theinstrument.Donotuse
abrasivesorsolvents..
NOTE
●Radiation immunity affects the accuracy of CL250 testers under the
conditionsspecifiedinEN61000-4-.
●If equipment generating strong electromagnetic interference is located
nearly,thetestersmaymalfunction.

IM CL250 1
1.InstrumentLayout
(1)TransformerJaws:Pickupcurrentflowingthroughtheconductor.
(2)Open/CloseLever:Usedtoopenandclosethetransformerjaws.
(3)Function Selector Switch : Selects function to use. Also switches off the
instrumentwhensettothe"OFF"position.
(4)Data Hold Button :Freezes the display reading with " " symbol shown
onthedisplaywhenpushedin.
Note:Whentheplugisinsertedintotheoutputterminal,DataHoldSwitch
operatesasrangeselectionswitch.(Seesection3.3OUTPUTTerminal)
(5)  Button : Used to switch the instrument between the AC and DC
modes.TheinstrumentissettotheACmodewhenitispoweredon.Press
thisbuttontoselecttheDCmode.
(6) Button:Apressofthisbuttononacurrentorvoltagerangeturnsthe
instrument to the MAX measurement mode with " " shown on the
display.PressthebuttonagaintoexittheMAXmode.
A press of the button on the resistance range turns the instrument to the
continuitycheckmodewith" "symbolshownonthedisplay.Inthismode,

2 IM CL250
thebuzzerbeepswhenthereadingisabout50Ωorless.Pressthebutton
againtoexitthecontinuitycheckmode.
(7) Button:Usedforzeroadjustmenton400ADCrangeorforreset-
tingthereadingintheMAXmode." "symbolisshownonthedisplay
whenzeroadjustment isenabledon400ADCrange.(Zero adjustmentis
availableonly400ADCrange.)
(8)LCD Display : Field effect type of liquid crystal display with maximum
countsof3999andmicroprocessor-controlledannunciatorsandthedeci-
malpoint.
(9)TerminalCover:Usedtoenclosetheinput terminals(LoandHi)whenthe
OUTPUTterminalisinuse, thus avoidingaccidentalapplicationofvoltage
totheinstrument.
(10)OUTPUTterminal(forcurrentmeasurementonly):ProvidesDCvoltagein
proportion to the reading on an AC or DC current range. The voltage is
used for such purposes as long term monitoring with a recorder or other
recording devices. This terminal cannot be accessed on a voltage or
resistancerange.
(11)LoTerminal:Acceptstheblacktestleadforvoltageorresistancemeas-
urement.
(12)Hi Terminal : Accepts the red test lead for voltage or resistance meas-
urement.
(13)Safety Hand Strap : Prevents the instrument from slipping off the hand
duringuse.
(14)TestLeads(Model98072):ConnecttoLoandHiterminalsforvoltageor
resistancemeasurement.
(15)OutputPlug(Model98012):InsertthisplugintotheOUTPUTterminalto
obtain DC output voltage. Connect suitable connection cord to the plug
whenitisused.(Seesection3.3OUTPUTTerminal)
(16)Barrier: It is a part providing protection against electrical shock and
ensuringtheminimumrequiredairandcreepagedistances.

IM CL250 3
2.Measurement
2.1PreparationforMeasurement

CAUTION
●Thejawsectionisadelicate,precisionsensor.Donotsubjectthejawto
unreasonablystrongshock,vibration,orforcewhenusingit.
●Ifdustgetsintothetopsofthejaws,removeitimmediately.Donotclose
thejawswhendustistrappedinitsjointsasthesensormaybreak.
●Please check that the range and mode are set to the desired position
beforemeasurement.
2.2DCCurrentMeasurement
WARNING
●Donotmakemeasurementonacircuitabove1000VDC.Thismaycause
shockhazard.
●Do not make current measurement with the test leads connected to the
instrument.
●Keepyourfingersandhandsbehindthebarrierduringmeasurement.

(1)SettheFunctionSelectorswitchtothe" 400A"positionandpressthe
buttontoselecttheDC mode."DC"shouldbeshownon the upper
leftcornerofthedisplay.
(2)With the transformer jaws closed without clamping them onto the con-
ductor, press the button for about one second to zero adjust the
display.( buttonisenabledonlyon400ADCrange.)" "should
beshownonthedisplay.
(3)SettheFunctionSelectorswitchtothepositionappropriatefortheorderof
thecurrentundertest.

4 IM CL250
(4)Press the open/closelevertoopenthetransformerjaws and clamp them
onto the conductor under test and take the reading on the display. The
most accurate reading will be obtained by keeping the conductor at the
centerofthetransformerjaws.
NOTE
●During current measurement, keep the transformer jaws fully closed.
Otherwise, accurate measurement cannot be made. The maximum
measurableconductorsizeisapprox.55mmindiameter.
●Whenthecurrentflowsfromtheupside(thedisplayside)totheunderside
oftheinstrument,thepolarityofthereadingispositiveandviceversa.
●TheoutputvoltagefromtheOUTPUTterminalmaynotreducetonilevenif
thedisplayiszeroadjustedwiththe button.Inthiscase,makezero
adjustment on the recorder or other device that the output voltage is
connectedto.
●Turing theFunctionSelectorswitch toapositionother thanDCAcancels
thezeroadjustment.
2.3ACCurrentMeasurement

WARNING
●Donotmakemeasurementonacircuitabove750V AC.Thismaycause
shockhazard.
●DonotmakecurrentmeasurementwiththetestleadsconnectedtotheHi
andLoterminals.
●Keepyourfingersandhandsbehindthebarrierduringmeasurement.
(1)Set the Function Selector switch tothe" 400A"or" 2000A"position
and select the AC mode. If the instrument is in the DC mode, press the
buttononcetoselecttheACmode.(TheinstrumentissettotheAC
mode when it is powered on.) "AC" should be shown on the upper left
cornerofthedisplay.

IM CL250 5
(2)Press the open/closelevertoopenthetransformerjawsandclamp them
onto the conductor under test and take the reading on the display. The
most accurate reading will be obtained by keeping the conductor at the
centerofthetransformerjaws.
NOTE
●During current measurement, keep the transformer jaws fully closed.
Otherwise, accurate measurement cannot be made. The Maximum
measurableconductorsizeis55mmindiameter.
●UnlikeinDCcurrentmeasurement,zeroadjustmentisnotnecessaryinAC
currentmeasurement.Thereisnopolarityinthereadingeither.
●TheoutputvoltagefromtheOUTPUTterminalmaynotreducetonilevenif
thedisplayiszeroadjustedwiththe button.Inthiscase,makezero
adjustment on the recorder or other device that the output voltage is
connectedto.
2.4DCVoltageMeasurement

WARNING
Do not make measurement on a circuit above 1000VDC. This may cause
electricshockhazard.
(1)Set the Function Selector switch to the "  400V" or "  1000V"
position.IftheinstrumentisintheACmode,pressthe buttononceto
select the DC mode. (The instrument is set to the AC mode when it is
poweredon.)"DC"shouldbeshownontheupperleftcornerofthedisplay.
(2)Slide the terminal cover to the left. Plug the red test lead into the Hi
terminalandtheblacktestleadintotheLoterminal.

6 IM CL250
(3)Connecttheotherendofthetipoftheredtestleadthepositivesideofthe
circuit under test and the tip of the black test lead to the negative side.
Takethereadingonthedisplay.Ifthetestleadconnectionisreversed,the
"-"signisshownonthedisplay.
2.5ACVoltageMeasurements
WARNING
Do not make measurement on a circuit above 750V AC. This may cause
electricshockhazard.
(1)SettheFunctionSelectorswitchtothe" 400V"or" 750V"position.If
theinstrumentisintheDCmode,pressthe button once to select
ACmode.(TheinstrumentissettotheACmodewhenitispoweredon.)
The"AC"shouldbeshownontheupperleftcornerofthedisplay.
(2)Slide the terminal cover to the left. Plug the red test lead into the Hi
terminalandblacktestleadintotheLoterminal.
(3)Connectthetipofthetestleadstothecircuitundertest.Takethereading
onthedisplay.

IM CL250 7
2.6ResistanceMeasurement
WARNING
Nevertrytomakemeasurementonacircuitthatisnotde-energized.
(1)Set the FunctionSelectorswitchtothe" " position. The "Ω"should
beshownontheupperrightcornerofthedisplay.
(2)Slide the terminal cover to the left. Plug the red test lead into the Hi
terminalandtheblacktestleadintotheLoterminal.
(3)Check that the display reads "OL". Then, short the tip of the test leads
togetherandcheckthatthedisplayreads"0".
(4)Connect the tip of the test leads to the circuit under test and take the
readingonthedisplay.
NOTE
●When thetipofthetest leadsisshortedtogether,the displaymayreada
verysmallresistanceinsteadof"0".Thisistheresistanceofthetestleads,
notfault.
●Ifoneofthetestleadshasabreak,thedisplayreads"OL".
2.7ContinuityCheck(400Ωrangefixed)
WARNING
Nevertrytomakemeasurementonacircuitthatisnotde-energized.
(1)SettheFunctionSelectorswitchtothe" "position.
(2)Slide the terminal cover to the left. Plug the red test lead into the Hi
terminalandtheblacktestleadintotheLoterminal.
(3)Press the  button to select the continuity check mode. The " "
symbolshouldbeshownonthedisplay.
(4)Check thatthedisplayreads "OL".Thenshorttogether thetipofthe test
leadsandmakesurethatthedisplayreads"0"andthebuzzerbeeps.

8 IM CL250
(5)Connectthetipofthetestleadstothecircuitundertest.Thebuzzerbeeps
whentheresistanceisabout50Ωorless.
NOTE
●When thetipofthe testleadsisshortedtogether, thedisplaymayread a
verysmallresistanceinsteadof"0".Thisistheresistanceofthetestleads,
notafault.
●Ifoneofthetestleadshasabreak,thedisplayreads"OL".
2.8MAXMeasurement(Responsetime:400ms)
The MAX measurement mode is used to display a maximum reading over a
certainperiodoftime.This function is available on all ranges other than Ω
ranges.
WARNING
●Donotmakemeasurementonacircuitabove750VACor1000VDC.This
maycauseelectricshockhazard.
●Do not make measurement with the test leads connected to the instru-
ment.
(1)SettheFunctionSelectorswitchtothedesiredposition.
(2)Press the  button to select the MAX measurement mode. " "
shouldbeshownonthedisplay.
(3)In order to take a correct reading, press the  button once after
clamping the jaws onto the conductor or connecting the test leads to the
circuitundertest.
(4)Thedisplayshowsthemaximumreadingduringmeasurement.
(5)Press the  button once again to return to the normal measurement
mode.
NOTE
●DataHoldfunctionisdisabledinMAXmeasurementmode.
●For measurement over a period more than 10 minutes, disable the Sleep
function according to the Users Manual in section 3.1 Sleep Function.
Otherwise,theinstrumentautomaticallyturnsitselfoffinabout10minutes.

IM CL250 9
3.OtherFunctions
3.1SleepFunction
This is a function to prevent the instrument from being left powered on in
ordertoconservebatterylife.Thisfunctioncausestheinstrumenttoswitchto
the Sleep (powered-down) mode about 10 minutes after the last switch or
buttonoperation.
ToexittheSleepmode,pressanybuttonorturntheFunctionSelectorswitch
backto"OFF",thentoanyotherposition.
<HowtodisabletheSleepfunction>
Powering the instrument on with the Data Hold button pressed disables the
Sleep function. "P.OFF" is shown on the display for about 3 seconds to
indicatethis.
To enable the Sleep function, turn the Function Selector switch back to
"OFF",thentoanyotherposition.
NOTE
The Sleep function is disabled while the output plug is inserted into the
OUTPUT terminal. When the output plug is disconnected from the terminal,
theSleepfunctionisenabledinabout10minutes.
3.2DataHoldFunction
Thisisafunctionusedtofreezethemeasuredvalueonthedisplay.Pressthe
DataHoldbuttontofreezethereading.Thereadingwillbeheldregardlessof
subsequent variation of current, voltage or resistance under test. " " is
shownontheupperrightcornerofthedisplay.
ToexittheDataHoldmode,presstheDataHoldbuttonagain.
NOTE
●TheDataHoldmodeisdisabledwhentheinstrumentswitchestotheSleep
mode.
●TheDataHoldfunctionisdisabledintheMAXmeasurementmode.

10 IM CL250
3.3OUTPUTTerminal(Forcurrentmeasurementonly)

WARNING
●Donotmakemeasurementonacircuitabove750VACor1000VDC.This
maycauseelectricshockhazard.
●NeverapplyvoltagetotheOUTPUTterminal.
(1)To obtain output voltage from the OUTPUT terminal, connect a suitable
cordtothesuppliedoutputplug.
(2)Slide the terminal cover to the right to enclose the Lo and Hi terminals.
Insert the output plug into the OUTPUT terminal for connection with a
recorderorotherrecordingdevice.
(3)SettheFunctionSelectorswitchtothe" 400A"or" 2000A"posi-
tion. (The output is available only in the two ranges.) Proceed to meas-
urementintheDCorACmode.
NOTE
●In the DC mode, the output voltage from the OUTPUT terminal may not
reducetonilevenifthedisplayiszeroadjustedwiththe button.In
this case, make zero adjustment on the recorder or other device that the
outputvoltageisconnectedto.
●The Sleep function is disabled while the output plug is inserted into the
OUTPUTterminal.Whentheoutputplugisdisconnectedfromtheterminal,
theSleepfunctionisenabledinabout10minutes.
●Set the appropriate sensitivity on the recorder or other recording device.
(Seechapter5.Specifications.)

IM CL250 11
3.4OptionalAccessories
MODEL:99025(ForACcurrentmeasurementonly)
ClampAdapterModel99025isdesignedtoincreasethemeasuringcapability
ofaclampmeter.WiththeuseoftheClampAdapter,youcannotonlyextend
currentrangeover3000A,butalsoclamponalargebus-barorconductor.
(1)SettheFunctionSelectorswitchtothe" 400A"position.
(2)SelecttheACmodewiththe button.
(3)Asshowninthefigurebelow,clampMODELCL250ontothepickupcoilof
MODEL99025.
(4)ClampMODEL99025ontothebus-barorconductorundertest.
(5)TakethereadingonMODELCL250andmultiplyitby10.
NOTE
Forthedetailedspecification,refertotheClampAdapterUsersManual.

12 IM CL250
4.BatteryReplacement

WARNING
To avoid electric shock hazard, make sure to set the Function Selector
switchto"OFF"andremovethetestleadsfromtheinstrumentbeforetrying
toreplacebatteries.

CAUTION
●Donotmixnewandoldbatteries.
●Make sure to install batteries in correct polarity as indicated in battery
compartment.
Iftheinstrumentispoweredon,butthedisplayblanksor" "isshownon
thelowerleftcornerofthedisplay,replacethebatteries.
Note that when the battery is completely exhausted, the display blanks
without" "shown.
(1)SettheFunctionSelectorswitchtothe"OFF"position.
(2)Unscrew andremovethe batterycompartmentcoveronthebottomofthe
instrument.
(3)Replacethebatteriesobservingcorrectpolarity.Makesuretousetwonew
R6Pbatteries.
(4)Replaceandscrewthebatterycompartmentcover.

IM CL250 13
5.Specifications
■InstrumentSpecifications
●MeasuringRangesandAccuracy(at23±5℃,45to85%relativehumidity)
DCCurrent A
Range MeasuringRanges Accuracy
400A 0to± 399.9A ± 1.5%rdg± 2dgt
2000A 0to± 1999A
ACCurrent A
Range MeasuringRanges Accuracy
400A 0to399.9A ± 1.5%rdg± 2dgt(50/60Hz)
± 3.0%rdg± 4dgt(40to500Hz)
± 5.0%rdg± 4dgt(500to1kHz)
2000A 0to1000A
1001to1999A ± 3.0%rdg± 2dgt(50/60Hz)
DCVoltage V(Inputimpedance:2MΩ)
Range MeasuringRanges Accuracy
400A 0to± 399.9A ± 1.0%rdg± 2dgt
1000A 0to± 999A
ACVoltage V(Inputimpedance:2MΩ)
Range MeasuringRanges Accuracy
400A 0to399.9A ± 1.5%rdg± 2dgt(50/60Hz)
± 1.5%rdg± 4dgt(40to1kHz)
750A 0to749A
ResistanceΩ(Auto-ranging)
Range MeasuringRanges Accuracy
400Ω 0to3999Ω ± 1.5%rdg± 2dgt
4000Ω
Resistance,Continuitycheck (RangeFixed)
レンジ 測定範囲 確度（周波数範囲）
400Ω 0to399.9Ω ±1.5%rdg±2dgt
(Buzzerbeepsat50± 35Ωorless)

14 IM CL250
OUTPUT(Outputimpedance:about10kΩ)
MeasuringRange Inputvoltage Accuracy
DC 400A 0to400.0mV 0to400A ±1.5%rdg±3mV
2000A 0to200.0mV 0to2000A
AC 400A 0to400.0mV 0to400A 1.5%rdg± 3mV
(50/60Hz)
± 3.0%rdg± 3mV
(40to500Hz)
± 5.0%rdg± 3mV
(500to1kHz)
2000A
0to100.0mV 0to1000A
100.1 〜 200.0mV 1001to2000A ± 3.0%rdg± 3mV
(50/60Hz)
*Electromagneticcompatibility(IEC61000-4-3)
:RFfieldstrength=<1V/m,totalaccuracy=specifiedaccuracy
:RFfieldstrength=3V/m,totalaccuracy=specifiedaccuracy+2%ofrange

◆GeneralSpecifications
●OperatingSystem:Dualintegration
●MeasurementFunction:DCCurrent,ACCurrent,DCVoltage,ACVoltage,
Resistance,ContinuityCheck
●Display:Liquidcrystaldisplaywithmaximumcountsof3999
●OverrangeIndication:"OL"isdisplayedoneachrange.
●ResponseTime:Approx.2seconds.
●SampleRate:Approx.2.5timespersecond.
●Temperature and HumidityforGuaranteedAccuracy:23℃ ±5℃, relative
humidityupto85%withoutcondensation
●Operating Temperature and Humidity : 0 to 40℃, relative humidity up to
85%withoutcondensation
●Storage Temperature and Humidity : -20 to 60℃, relative humidity up to
85%withoutcondensation
●Effectofconductorposition:Within±1.5%rdg±3dgtofindicatedvalueat
thecentertoa10mm-diaconductorcarrying100A,ateverypartinsidethe
jaws
●Effectofexternalmagneticfield:4AorlessinACorDCmagneticfieldof
400A/m
●PowerSource:TwoR6P(DC1.5V)batteriesorequivalent
●BatteryLife:Approx.100hours(continuity)
●CurrentConsumption:About9mAmax.

IM CL250 15
●Sleep Function : Automatically switchestotheSleepmodeinApprox.10
minutesafterthelastswitchorbuttonoperation(currentconsumptioninthe
Sleepmode:Approx.20μA)
●WithstandingVoltage:8200VACfor5sec.(betweenelectricalcircuitand
housingcasesormetalpartsofjaws)
●Insulation Resistance : 10MΩ or greater at 1000V (between electrical
circuitandhousingcases,ormetalpartsofthejaws
●ConductorSize:Approx.55mmdiametermax.
●Dimensions:Approx.105(W)x250(H)x49(D)mm
●Weight:Approx.530g(withbatteries)
●SafetyStandard:EN61010-1,EN61010-2-033
EN61010-031,EN61010-2-032
AC/DC600VCATⅣ,AC/DC1000VCATⅢ,
Pollutiondegree2,indoorusealtitude2000morless
●EMCStandard:EN61326-1,EN61326-2-1,EN55011
●Radiationimmunity:EN61000-4-3
●Environmentalstandard:EN50581
●Accessories:TestleadsModel98072 …………1set
R6P(SUM3)batteries ……………2
CarryingcaseModel93034 ……1
OutputPlugModel98012 ………1
UsersManuall ………………………1
●OptionalAccessories:ClampadapterModel99025
OutputcableforterminalscrewModel98077
