ZKTeco DM10 User manual

1
1
6
2
7
3
8
4
9
5
10
Appearance & Installation
1. Appearance
Status of indicator
Normal communication: the indicator
flash every two secondses .
Abnormal communication: the indicator
will be constant on.
The indicator flashes rapidly within 30s
after the device is connected to the power
supply.
address switch setting address switch setting
Indicator LED
1234
1234
1234
1234
1234
1234
1234
1234
1234
1234
DIP switch Power
EXT RS485
Auxiliary input
Wiegand reader
Lock
Auxiliary
output 12V output
D 10 Quick Start GuideM
Version:1.0 Date:2018.11
Wiegand reader

2
2 Installation.
1 2 Install the device))Fix the guide rail on the wall
The DM10 has to be connected to F18(master device) in order to use the
software.
A access controller can connect eight DM10 at most.
Each device requires a separate power supply.
GND
485+
485-
EXT
1
DC12V
-
+
-
+
DC12V
Router
Wiring to Master Device
28
GND
485A
485B
-
+
DC12V

3
Open ZKAccess3.5 software, click Device > New , input the name and IP[][]
address of F18 , and then click OK .[]
Step 1
After wiring correctly, please follow the below settings.
1. Set RS485 address of D 10 as 2-9.M
2. et F18 serial port as ”host” ( COMM ).S [ .]> [ ]serial port
Quick Start
Click More > Add IO Expansion Board , check RS485 address of DM10,[ ...] [ ]
and then click OK .[]
Step 2

4
After successful configuration, the flashes every two 2Indicator LED
seconds, indicating communicate normally. After adding successfully, the
parameters of the access control could be set, please refer to ZKAccess 3.5
user manual.
